ANYSPACE Joy Park, Justin Pedley, Alana Peters, Laura Stadley, Meiji Yue What is AnySpace? Mechanism-Animation Risks Pinch points Locking mechanism to hold the seat at a desired length Load capacity must be enough to prevent seat from

SLIDE 1

ANYSPACE

Joy Park, Justin Pedley, Alana Peters, Laura Stadley, Meiji Yue

SLIDE 2

What is AnySpace?

SLIDE 3

Mechanism-Animation

SLIDE 4

Risks

Pinch points Locking mechanism to hold the seat at a desired length Load capacity must be enough to prevent seat from caving in Binding

SLIDE 5

Preliminary Contract

Customer Need Product Attributes Engineering specification (s) As comfortable as a typical bench Padding Pressure distribution

n body does not

exceed [psi value of typical chair] Easily expandable Weight/Force needed to move <200N force needed to expand Anyspace Can hold up to 3 people Maximum Load Can hold at least 800lbs on any part of the seat without breaking/collapsing Affordable Cost [Approximately the cost of one average

couch. ]

SLIDE 6

Future Work

Developing a locking mechanism Minimizing pinch points/access to pinch points Quantifying the maximum load Increasing comfort
