AndRadar: Fast Discovery of Android Applications in Alternative - - PowerPoint PPT Presentation

Martina Lindorfer, Stamatis Volanis, Alessandro Sisto Matthias Neugschwandtner, Elias Athanasopoulos, Federico Maggi Christian Platzer, Sotiris Ioannidis, Stefano Zanero

• Vienna University of Technology

Foundation for Research & Technology – Hellas Politecnico di Milano


 AndRadar:


Fast Discovery of Android Applications
 in Alternative Markets


Low infection rates?

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 1

• The Core of the Matter (NDSS13)

0.0009%

• The Company You Keep (WWW14)

0.28%

Google: Android Security From The Ground Up (VirusBulletin 2013)

AV vendors paint a different picture…

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 2

Fortinet 2014 Threat Landscape Report TrendMicro TrendLabs 1Q 2014 Security Roundup McAfee Labs Threats Report June 2014

Motivation

• How are malicious apps distributed?
• Official Google Play Store
• Torrents, One-Click Hosters
• Websites, Blogs, …
• Alternative App Markets
• How wide-spread are malicious apps, how often are

they downloaded?

• Do alternative markets employ security measures?
• Collect metadata for malware analysis
• Andrubis, AndroTotal

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 3

Market Metadata: Google Play

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 4

Market Metadata: Google Play

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 5

Outline

• Market Characterization
• Android Market Radar (AndRadar)
• Evaluation and Case Study
• Future Work and Conclusion

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 6

Market Characterization

• Alternative markets are popular because of …
• Country gaps (e.g. no paid apps in Google Play China)
• Promotion
• Specific needs and specialization
• Preliminary study on 8 alternative marketplaces
• Crawled them entirely between July and Nov 2013
• Downloaded 318,515 apps

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 7

(1) Distribution of Unwanted Apps

Do markets distribute known, unwanted apps?

• Yes, they do!
• 5-8% malicious apps in whole dataset


10+ AV detections, excluding adware

• Some markets specialize in adware/”madware”

• Detection of Intrusions and Malware & Vulnerability Assessment, July 2014

8

2 4 6 8 10 20 30

Number of positive AV detections Percentage of malware on market

• pera

andapponline camangi slideme fdroid blackmart getjar pandapp 20 40 60 10 20 30

Number of positive AV detections Percentage of ad−/malware on market

• pera

andapponline camangi slideme fdroid blackmart getjar pandapp

(2) Publication of malicious apps

Do markets allow the publication of malicious apps?

• Yes, they do!
• Ranking based on number

• f published apps
• Well visible and known to


market operators

• Top authors publish both


benign and malicious apps

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 9

andapponline camangi

• pera

pandaapp slideme 50 100 150 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5

Top 5 authors per market Number of apps published

Malware Goodware

(3) Distinctive metadata

Do malicious apps have distinctive metadata?

• Yes, they do!
• Malicious apps slightly larger than goodware


à Additional malicious code in repackaged apps

• Malicious apps are downloaded more often


à Inflation of ranking with app rank boosting services

• Detection of Intrusions and Malware & Vulnerability Assessment, July 2014

10

How are markets related to each other?

• Markets share up to 47% MD5s, 75% package names

(4) Market Overlap

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 11

• 59%

59% 38% 38% 15% 15% 19% 19% 12% 12% 22% 22% 12% 12% 36% 36% 16% 16% 15% 15% 13% 13% 63% 63% 32% 32% 16% 16% 31% 31% 12% 12% 75% 75% 26% 26% 41% 41% 21% 21% 26% 26% 22% 22%

Intersection by MD5 Intersection by package name

Outline

• Market Characterization
• Android Market Radar (AndRadar)
• Evaluation and Case Study
• Future Work and Conclusion

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 12

AndRadar Design Goals

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 13

• Discover apps in markets in real-time
• Distribution of apps across markets
• Increasing space and time requirements
• Meta information dynamic à regular crawling of apps
• Crawling of complete markets becomes infeasible
• Plethora of alternative markets


~ 196 in October 2011 (Vidas et al. CODASPY13)
 ~ 500 in Juniper Threats Report March 2012/2013
 ~ 89 in our market study in June 2013

AndRadar Architecture

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 14 Metadata Scraper Downloader Search

App Metadata Market Specifications

Tracker

Seed

App Discovery

• Lightweight identifier to select target apps
• Package name uniquely identifies app on device
• Package name identifies app in markets
• Part of an app’s “Branding”

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 15

App Discover: AppChina

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 16

App Discovery: Appszoom

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 17

App Matching

• Match downloaded app to malicious app in seed
• Different levels of confidence based on
• Package name
• MD5 hash
• Fingerprint of developer’s certificate
• Method signatures
• Detection of Intrusions and Malware & Vulnerability Assessment, July 2014

18

MD5 match? fingerprint match? a.b.c MD5 part of seed a.b.c MD5' from market method signature match? perfect match same application weak match

N N Y Y

strong match different application by same author

N Y

strong match repackaged version method signature match? very strong match different version by same author

Y N

Collected Metadata

• Continuous monitoring of discovered apps
• Harvest meta information from market listing
• Upload date
• Description
• Screenshots
• Number of downloads
• User ratings
• Reviews
• Other apps by the same author
• Delete date

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 19

Outline

• Market Characterization
• Android Market Radar (AndRadar)
• Evaluation and Case Study
• Future Work and Conclusion

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 20

Overall performance

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 21

• Track tens of thousands of apps per market/day
• Tracked 20,000 apps/1,500 app deletions

1 10 100 1000 Deleted Non-deleted Match count MD5 Fingerprint+Similarity Similarity Fingerprint Package name

Application Lifecycles

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 22

• Normal Lifecycle:


Market deletes app after it is detected by AVs

• Market Self-Defense:


Market deletes app before it is detected by AVs

• Malware Hopping:


App is republished after detection
 “Failover” strategy

• tav

tpub tdel

market reaction time first crawl date app detected by AVs app published in market app deleted from market community reaction time

Market Reaction Time

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 23

0.5 0.6 0.7 0.8 0.9 1 100 200 300 400 500 600 CDF Days for deletion google-play appchina anzhi

Community Reaction Time

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 24

0.2 0.4 0.6 0.8 1 100 200 300 400 500 600 700 CDF Days for detection google-play appchina anzhi

Outline

• Market Characterization
• Android Market Radar (AndRadar)
• Evaluation and Case Study
• Future Work and Conclusion

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 25

Future Work

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 26

• Automated notification system for markets
• Extend app discovery in markets based on
• Application name
• Image characteristics (icon, screenshots)
• Description of functionality
• Versioning of malicious apps
• Identify fraud in markets (“App rank boosting”)
• Inflated download numbers
• Fake ratings and reviews

Conclusion

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 27

• In-depth measurement on 8 alternative markets
• AndRadar to discover malicious apps in real-time
• Tracking of app distribution across markets
• Collect metadata about apps
• Branding
• Updates
• Download numbers
• Ratings & reviews
• Expose publishing patterns of malware authors
• “Failover” strategies to migrate between markets

28

Questions?

• apking@iseclab.org

mlindorfer@iseclab.org

• http://www.iseclab.org/people/mlindorfer

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014

Malicious App Seed

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 29

• Feed of known malware or unwanted apps
• Continuous stream of apps from …
• Manually vetted malware repository (VirusShare)
• Submission feed from VirusTotal based on # of AV signatures
• Submissions to Andrubis based on dynamic analysis result
• Seed format: APK files

<Package name, Certificate, Method signatures, MD5>

1Mobile

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 30

Anzhi

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 31

Aptoide

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 32

CoolAPK

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 33

F-Droid

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 34

Lenovo

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 35

Moborobo

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 36

Nduoa

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 37

SlideME

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 38

Wandoujia

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 39

Z-Android

Detection of Intrusions and Malware & Vulnerability Assessment, July 2014 40
