ANDES WP2: Uncertainties and covariances of nuclear data

Arjan Koning NRG ANDES semester meeting NEA Issy-les-Moulineaux November 19, 2010

2

Contents

• Partner list
• Objectives
• Tasks
• Milestones and deliverables

3

Objectives

Enhance the European capability to produce covariance data for isotopes important for advanced reactors Three aspects of nuclear data evaluation come together:

• Uncertainty/covariance evaluation of experimental data
• Uncertainty/covariance evaluation of data from models
• A proper theoretical treatment and evaluation of nuclear

reactions on actinides (especially fission models) and its relation with 1. and 2. In addition:

• Covariances for radioactive decay and fission yield data
• Use all of the above in processing, reactor and fuel cycle

codes. In ANDES-WP2, all this is organized in 5 tasks

4

Partner list

• NRG (Koning): TALYS nuclear model code, production of nuclear

data libraries + covariances, RRR+URR+fast neutrons, applied (benchmarking) criticality, shielding and reactor calculations

• CEA-DAM (Bauge): experimental uncertainty methods + TALYS

fission model development

• CEA-CAD (de Saint-Jean): CONRAD resonance code
• Univ Bucharest(Sin): Fission modeling
• UNED/UPM (Cabellos): Uncertainty propagation for back-end of

the fuel cycle, apply covariance data in activation code.

• NNL (Mills): Covariances for fission yield and decay data, spent

fuel inventory and decay heat calculations

• TUW (Leeb): uncertainty methods: GENEUS
• CIEMAT (Gonzalez): fuel cycle codes
• JSI (Trkov): processing and application

5

Task 2.1 : Scientific coordination

Task leader: NRG Monitoring of progress by all WP2 partners Collection of information for this meeting. For the rest, nothing specific since the kick-off meeting Several partners: new post-docs or PhD students in 2011

6

Task 2.2:Covariance tool development

TASK leader: TU Wien

• Experimental covariance tool (CEA-DAM)
• Post-doc identified. She will start beginning 2011
• GENEUS evaluation tool (TU Wien):
• Activities started directly at 01-05-2010
• ANDES funds PhD student : Denise Neudecker
• Report of first results at JEFF meeting june 2010
• Uncertainties on OMP and level densities included
• Ongoing: extension of GENEUS (based on TALYS-

1.2) for fission channels

• CONRAD (CEA-DEN) evaluation tool
• Not yet started

7

TU Wien (Leeb, Neudecker)

8

9

10

11

Task 2.3 Covariance data evaluation

TASK leader: NRG NRG: covariance production for actinides:

• Extended nuclear data libraries with uncertainties for number of

fission neutrons (MF31) and fission neutron spectrum (MF35)

• Started new complete evaluation of Pu-239 including full

covariance data. Testing with Total Monte Carlo for WP3. Univ Bucharest: Improve methods for actinide evaluation:

• 2 weeks of EMPIRE development by Capote at JSI( Slovenia).
• Testing new models for direct and pre-equilibrium reactions.
• Uncertainties for n+237Np and n+242Pu assessed based on

different evaluations, experiments and EMPIRE-Kalman: will be used for Monte Carlo covariance evaluations.

12

NRG (Koning, Rochman)

13

TALYS code system

A loop over nuclear physics, data libraries, processing and applications:

• Resonance parameters + uncertainties
• An EXFOR database with more uncertainties than errors
• The TALYS code
• The Reference Input Parameter Library (RIPL)
• Software for remaining reaction types (nubar, fns + unc.)
• For many nuclides: A set of adjusted model parameters +

uncertainties + “non-physical evaluation actions”

• All major world libraries
• The ENDF-6 formatting code TEFAL
• NJOY, MCNP(X) + other codes
• A script that drives everything

The secret: Insist on absolute reproducibility

14

15

Resonance Parameters .

TARES

Experimental data (EXFOR)

• Nucl. model

parameters

TALYS TEFAL

Output Output ENDF

• Gen. purpose

file ENDF/EAF

• Activ. file

NJOY

PROC. CODE

MCNP FIS- PACT Nuclear data scheme + covariances

• K-eff
• Neutron flux
• Etc.
• activation
• transmutation

Determ. code Other (ORIGEN) +Uncertainties +Uncertainties +Covariances +Covariances +Covariances +(Co)variances +Covariances +Covariances

TASMAN

Monte Carlo: 1000 TALYS runs

16

TENDL: Complete ENDF-6 data libraries

MF1: description and average fission quantities MF2: resonance data MF3: cross sections MF4: angular distributions MF5: energy spectra MF6: double-differential spectra, particle yields and residual products MF8-10: isomeric cross sections and ratios MF12-15: gamma yields, spectra and angular distributions MF31: covariances of average fission quantities (TENDL-2010) MF32: covariances of resonance parameters MF33: covariances of cross sections MF34: covariances of angular distributions MF35: covariances of fission neutron spectra (TENDL-2010) and particle spectra (TENDL-2011) MF40: covariances of isomeric data (TENDL-2011)

17

Resonance Parameters .

TARES

Experimental data (EXFOR)

• Nucl. model

parameters

TALYS TEFAL

Output Output ENDF

• Gen. purpose

file ENDF/EAF

• Activ. file

NJOY

PROC. CODE

MCNP FIS- PACT Nuclear data scheme: Total Monte Carlo

• K-eff
• Neutron flux
• Etc.
• activation
• transmutation

Determ. code Other codes +Uncertainties +Uncertainties +Covariances +Covariances

TASMAN

Monte Carlo: 1000 runs of all codes

18

19

Optimization of Pu-239

• Select 120 ICSBEP benchmarks
• Create 630 random Pu-239 libraries, all within, or closely

around, the uncertainty bands

• Do a total of 120 x 630 =75600 MCNP criticality

calculations

• Do another 120 x 4 calculations:

20

Optimization of Pu-239

21

Optimization of Pu-239

• 6% of libraries have lower chi-2 than JEFF-3.1
• Library #307 has the lowest

22

23

• Univ. Bucharest (Sin)

24

UB: Cross sections of neutron induced reactions on 239Pu

• available evaluations: ENDF-VII, JEFF 3.1.1, JENDL 4,

ROSFOND 2010, TENDL 2009, JENDL/Ac, Minsk/Act, etc

• “very” preliminary calculations in the energy range 1 KeV-20 MeV

performed with EMPIRE-3 & RIPL-3

25

Calculations with EMPIRE code

Direct - coupled channels ECIS06 Compound nucleus – Hauser-Feshbach, HRTW Preequilibrium – exciton model - PCROSS

Input parameters – default values from RIPL-3

 regional dispersive OMP for actinides (2408 for n, 5408 for p)  discrete level schemes (the recommended number of discrete levels adjusted)

 gamma strength functions MLO1(normalized to exp. strength function)

 level densities for normal states EGSM  fission barrier parameters (tuned to fit the experimental data)  level densities at saddles EGSM

Models

26

(n,n’) (n,2n)

27

In the next stage, most of the effort will be focused on direct and preequilibrium neutron emission.

28

Task 2.4: Covariances for activation, decay and fission yields

Task leader: UPM NNL: Fission yield and decay data

• ACAB methods for these data investigated
• Method available for including each individual fissioning
• system. Correlations with decay data and time

dependence are being studied UPM: Covariance data for spent fuel inventories and decay heat:

• See presentation of Oscar Cabellos
• ANDES is combined with Spanish research and teaching

fellowship for a new student for ANDES: Carlos Javier Diez de la Obra.

29

UNED (Sanz)

• System of reference: industrial-scale transmutation facility

EFIT

• core cooled by pure lead
• thermal power 400 MW,
• initial total mass of actinides 2.074 tonnes (21.7% MA)
• 150 GWd/tHM discharge burn-up corresponding to an

equilibrium cycle ( 778 irradiation days). 2011: Use Total Monte Carlo with ACAB code to get full uncertainties of inventories, using random ENDF-6 libraries and EAF (European Activation File) libraries.

30

Task 2.5: Application to advanced reactors

Task leader: CIEMAT (Use covariance files in reactor and fuel cycle codes for designs from other EU projects. Determine uncertainty for most important parameters) No technical progress reported.

31

Deliverables and milestones (year 1 only)

D2.1: Activation data libraries for Monte Carlo uncertainty propagation in fuel cycle code ACAB (M12)(NRG, CIEMAT, UPM)

32

Conclusions

• WP2 on uncertainty data well underway
• New Phd and post-doc projects will start in 2011
