Automated Case Identification and Coding of Cancer Pathology Reports

Jon Patrick PhD, DipLSurv, MSc, BSc(Psych), Grad Dip Psych, FACHI, FACS,MAMIA CEO

Awarded 7th June 2018

The Many Faces of NLP?

• Text Mining - rules, regular expressions, bag of words

– deterministic – cannot find anything that hasn’t been defined in the rules – Strong on Positives but typically over-generalises. No ability to find unseens.

• Real NLP – the field of computing the structure of

language - nka Computational Linguistics

• Statistical NLP – NLP plus Machine Learning from

examples and then can generalize – non-deterministic – finds what it hasn’t seen

• Language Engineering – Building production grade

SNLP solutions

California Cancer Registry Problem

• 500,000 documents per annum

– potentially 1 million in the coming years

• 50% unwanted and need to be filtered out
• Separation of non-reportable and reportable

cancers

• Coding the reportables

California CR Project Objectives - Analysis of Histopathology Reports

• Develop an automated service to:
• Determine Reportability
• Codify 5 attributes of

– Site – Histology – Grade – Behaviour – Laterality

The Language Engineering Issues

• How well can we do it - efficiency
• With what volume of training materials - 5000
• In what amount of time – 15 months
• To what accuracy - 90%
• For what cost – not enough
• The SNLP is our infrastructure – it is the

Language Modeling using machine learning, and coding to the client deliverables that have to be engineered.

Language Engineering Overview

• f Tasks
• Pathology Reports Classifier

– In scope – histopathology – Out-of-scope - Immunohistochemistry & Genetics

• Case Identification – Reportability Classifier
• Clinical Concept Recognizer
• Coding Inference Engine

Two Training Corpora needed to create a Gold Standard for learning

• 5000 Reportables in 10 Batches
• 5000 Non-Reportbales
• From 50+ laboratories
• Covering

– 133 Histology codes – 140 Site codes

• Subsequently - 212 Reportables in Non-

Reportables corpus transferred to Batch 11

Pathology Report Type Classifier

Classes

TP FP FN P R F- Score

Histopathology

4373 57 29 98.71 99.34 99.03

Other

653 29 57 95.75 91.97 93.82

OVERALL

5026 86 86 98.32 98.32 98.32

Reportability Results for Reportability Corpus

TP FP FN TN P R F 3510 27 111 1160 99.24 96.93 98.10 Interpreted as 0.76% FP and 3.07% FN (loss of Cancer reports to the Non-cancer class). Acceptable but pride would want us to do better.

Finding Clinical Concepts: Annotating and Tagging

• Design a schema of semantic tags
• Manually annotate the training corpus with

the tags

• Build a machine learning Language Model

with the training corpus to recognise the tags

• Check the consistency of the annotations

with the model

• Iteratively correct the annotations and the

structure of the model to improve it

Language Model Accuracy – RUN 29B & Run 41 - Sample of 34/32 Tags

TP FP FN P R F N F N

Site

18072 50 59 99.72 99.67 99.70 18131 99.87 21943

Histology

11172 7 87 99.94 99.23 99.58 11259 99.78 13784

Behaviour

8247 5 27 99.94 99.67 99.81 8274 99.91 9603

Grade

897 1 19 99.89 97.93 98.90 916 98.79 1335

Laterality

6351 10 20 99.84 99.69 99.76 6371 99.89 8000

Total (34 tags)

115550 226 921 99.80 99.21 99.51 116471 99.71 141412

>99%

29 16 21 27

>99.5%

29 10 14 22

TOTAL

34 34 34 32

2017 2018

Coding Reports to ICD O3 – Problem Definition

• Separate out each specimen.
• Clinical Concept Recognition: Apply the Language

Model to tag the correct concepts needed for coding.

• CODIFY: Map the tags to the appropriate elements in

the ICD O3 definitions for each coded attribute including applying:

– SEER multiple primaries rules and – any other local rules.

• Evaluate each specimen for its cancer reportability
• The Summary - Select the specimens that are required

to produce the correct case codes.

Coding Results Overview – All Reportables 2017.v1

Extractable # of records # of correct coded Accuracy Site (4 digits) 3165 3014 95.23% hist_type (4 digits) 3165 3050 96.37% hist_grade 3165 3126 98.77% hist_behavior 3165 3150 99.53% laterality 3165 3096 97.82% TOTAL 15825 15436 487.72% Average 97.54%

FINAL Estimated Efficiency Gains

• 100% automated Case finding - Reportability
• 72% automated coding at 94% overall accuracy =>

28% manual coding.

• Up to 90% automatic coding is possible.
• Histology codes coverage: 93.9% of supplied examples
• Site codes coverage: 94.2% of supplied examples
• Automated Coding of code set coverage 97.5% of

reports.

• Reduce manual errors by 40-80%.
• More improvements are being made.

Epilogue – 2018 Revisions

• 187 Site codes – 35% increase
• 237 Histology codes – 85% increase
• 15% increase in reports

– Drawn from audits, new samplings

• 2018.v1 is being tested by CCR
• 2017.v2 is released

The Foreseeable Future

• Increase accuracy for more difficult complexity classes ->

reduces manual processing

• Further investigate tumour stream classifications for

improving accuracy

• Analyse Immunohistochemistry and Genetics reports
• Add more extraction and coding functions – e.g.

Biomarkers, recurrence, tumour size, margins, …

• Add more document types – Radiology, Nuclear Medicine,
• For the CDPH – Other Health topics – First Fractures of
• steoarthritis, Adherence to National guidelines for

diagnostics

• Provide a Subscription Reportability Service for third

parties.

• END
