Vulcano 2010 Inhomogeneity in the SN Remnant Distribution as the Origin of the PAMELA Anomaly, and the B/C ratio (i.e., a mundane solution to PAMELA, while abiding to stringent CR constraints) Nir J. Shaviv (Hebrew U.) with Tsvi Piran (Hebrew

slide-1
SLIDE 1

Vulcano 2010 Inhomogeneity in the SN Remnant Distribution as the Origin of the PAMELA Anomaly, and the B/C ratio (i.e., a mundane solution to PAMELA, while abiding to stringent CR constraints)

Nir J. Shaviv (Hebrew U.) with Tsvi Piran (Hebrew U.), Ehud Nakar (TAU) & David Binyamin (Hebrew U.)

... and a few words about Cosmic Rays and Climate

slide-2
SLIDE 2
  • CRs and Climate
  • Solar activity and Climate
slide-3
SLIDE 3

Forbush decreases

  • Carefully select Forbush decreases which large

atmospheric ionization effect

AERONET

  • 15 -10 -5

5 10 15 20 days 1.10 1.15 1.20 1.25 1.30 1.35 Aangstroem 340-440nm

SSM/I

  • 15 -10 -5

5 10 15 20 days 0.084 0.086 0.088 0.090 0.092 CWC (kg/m2)

MODIS

  • 15 -10 -5

5 10 15 20 days 0.340 0.345 0.350 0.355 0.360 0.365 Liquid Water CF

ISCCP

  • 15 -10 -5

5 10 15 20 days 0.310 0.315 0.320 0.325 0.330 0.335 Low IR CF

  • 15
  • 10
  • 5

5 CLIMAX (%)

Svensmark et al. GRL 2009 5 strongest forbush decreases (1987-2007)

slide-4
SLIDE 4

Experimental Results

slide-5
SLIDE 5

Cloud Experiment @ CERN

  • Positive Results soon to come!
  • Fig. 6: The CLOUD experiment, showing the 0.5m cloud
condensation particle counters (CPC) differential mobility particle sizers (DMPS) mass spectrometers ion mobility spectrometers piston actuator external analysers piston control system trace gas analysers vacuum system CCD cameras Mie scattering detector liquid FC cooling inspection video camera gas & aerosol systems cooling /temperature control synthetic air/ argon water vapour aerosols trace gases ice particle detector cryogenics expansion system retractable probe refractive index gas thermometer lasers beam telescope scintillation counter roof (GCR monitor) aerosol /trace gas analysers in situ analysers temperature & pressure mixing chamber field cage voltage UV illumination

Kirkby et al.

slide-6
SLIDE 6

Sea Level change rate Solar Flux

Sea Level Variations

Shaviv, JGR 2008

slide-7
SLIDE 7

Synopsis

❖ The Standard Picture of

CR Acceleration & Diffusion

❖ The PAMELA anomaly ❖ New Type of sources?? ❖ A SN Remnant Solution: ✴ Distribution of SNe ✴ Implications (e.g., B/C)

slide-8
SLIDE 8

Standard View

  • Electrons and Protons

are mostly accelerated by supernova/ interstellar medium (ISM) shocks.

  • Pairs are produced by

the protons interacting with the ISM

  • Positron / Electron ratio

should decrease with energy! C, p, e- spectrum at source C, p, e- spectrum in galaxy

faster diffusion EVEN faster diffusion

B, e+ e- spectrum in galaxy

slide-9
SLIDE 9

These models fit the data well

Typical parameter values

D(E>E0) = D0 (E/E0)!

"

D0 = 3-5 ! 1028 cm2/s E0 ~ 3 GeV ! = 0.3-0.6 lH =2-4 kpc

slide-10
SLIDE 10

PAMELA results:

slide-11
SLIDE 11

1st Type of Solutions: Astrophysical Sources of Pairs: Pulsars

slide-12
SLIDE 12

2nd Type of Solutions: Decay of exotic particles (WIMPs)

slide-13
SLIDE 13

Source distribution: Most SNe

  • ccur in the spiral arms
  • In the Milky Way: Almost all

SNe are non-Type Ia, and

  • ccur where almost all star

formation takes place: In the Spiral Arms

  • Meteorites: Show that

density changes by a factor

  • f > 2.5
  • Deconvolved Synchrotron:

Shows arm to inter-arm ratio of ~ 3

slide-14
SLIDE 14

DECLINATION (B1950) RIGHT ASCENSION (B1950) 20 34 15 00 33 45 30 60 03 02 01 00 59 59 58 57 56 55 54 0.5 1.0 1.5 2.0

3rd Type of Solution: Source Distribution

NGC6946

Lacey & Duric 2003

slide-15
SLIDE 15

Meteoritic and Terrestrial Evidence

Shaviv & Veizer 2003

slide-16
SLIDE 16

So?

  • If CRs primarily come from the

spiral arms, it takes them time!

  • Along the way, electrons cool

though Synchrotron & Compton (on CMB, IR background and starlight).

  • Above some energy, they don’t

have enough time to reach us.

slide-17
SLIDE 17

So?

slide-18
SLIDE 18

This means that...

  • Above Eb ~ 20 GeV, the electrons

will start cooling.

  • Positrons however, form along the

way from proton-ISM interactions, therefore the positron/electron ratio will increase

slide-19
SLIDE 19
  • Primary electrons cool and

disappear before reaching earth

  • Secondary electrons/positrons

form nearer and can reach earth before cooling

slide-20
SLIDE 20
  • Electrons from Sprial

arms above ~ 20 GeV cool (synchrotron and inverse-Compton) before reaching the solar system!

  • Protons do not cool, so

positron production near us does not care (too much) about cooling.

What does it mean?

p, e- spectrum at source p spectrum in galaxy faster diffusion

  • ut of the galaxy!

e+ e- spectrum in galaxy e

  • s

p e c t r u m i n g a l a x y

slide-21
SLIDE 21
  • Electrons from Sprial

arms above ~ 20 GeV cool (synchrotron and inverse-Compton) before reaching the solar system!

  • Protons do not cool, so

positron production near us does not care (too much) about cooling. p, e- spectrum at source p spectrum in galaxy faster diffusion

  • ut of the galaxy!

e+ e- spectrum in galaxy e- s p e c t r u m i n g a l a x y

What does it mean?

slide-22
SLIDE 22

Monte Carlo Model

slide-23
SLIDE 23

Results

slide-24
SLIDE 24

e+/(e++e-) ratio and e- spectrum

slide-25
SLIDE 25

e+/(e++e-) ratio and e- spectrum

Contribution from nearby KNOWN young SNRs: Geminga, Monogem, Vela LoopI and Cygnus Loop

A comaprison with Pamela/Fermi/ HESS data

?

slide-26
SLIDE 26

e+/(e++e-) ratio and e- spectrum

Contribution from nearby KNOWN young SNRs: Geminga, Monogem, Vela LoopI and Cygnus Loop Exact CR diffusivity effects high E behavior (effect of singular SNRs)

slide-27
SLIDE 27

e+/(e++e-) ratio and e- spectrum

Preliminary results (Bruno, here) are consistent with a spectral break at ~50 GeV This is naturally interpreted as the contribution from disk +local SNR Break

slide-28
SLIDE 28

Does this disturbe the protons?

  • Arm + non-truncated

disk - dotted line

  • Arm + truncated disk
  • dashed line
  • Arm + truncated disk

+ nearby sources - full line

  • Nearby sources -

dot-dashed line

Break due to the solar wind

slide-29
SLIDE 29

More detailed modeling

  • All the galaxy.
  • Allowing arm dynamics (important for B/C):

★ CR age at high energy: Diffusion time

(smaller for larger E)

★ CR age at low energies: Time from last

arm passage (tp ~ few 10^7 yr)

slide-30
SLIDE 30

More detailed modeling

  • All the galaxy.
  • Allowing arm dynamics (important for B/C):

★ CR age at high energy: Diffusion time

(smaller for larger E)

★ CR age at low energies: Time from last

arm passage (tp ~ few 10^7 yr) second./prim. ~ d2/κ c ~ E-1/3 d

slide-31
SLIDE 31

More detailed modeling

  • All the galaxy.
  • Allowing arm dynamics (important for B/C):

★ CR age at high energy: Diffusion time

(smaller for larger E)

★ CR age at low energies: Time from last

arm passage (tp ~ few 10^7 yr) second./prim. ~ tp v ~ E+1/2 tp

slide-32
SLIDE 32

Results for B/C

slide-33
SLIDE 33

Conclusions

➡

Taking the real distribution of SNRs gives the correct positron/electron energy behavior.

➡

NO Free parameters give the correct break energy (constrained by cosmic ray age).

➡

Nearby young known SNRs dominate around 800

  • GeV. e+/e- @ high E depends on exact κ.

➡

Predictions:

❖

e+/etot ratio should saturate < 50%

❖

At higher energies the ratio should decrease! (due to fresh electrons)

➡

B/C ratio naturally explained once including the arm dynamics. No need for ad hoc assumptions (break in diffusivity, wind, reacceleration)

slide-34
SLIDE 34

That’s it!
