An Assertion Language for Debugging SDN Applications Ryan Beckett with X. Kelvin Zou, Shuyuan Zhang, Sharad Malik, Jennifer Rexford, David Walker Princeton University 1 Data Plane Verification Controller Find

slide-1
SLIDE 1

An Assertion Language for Debugging SDN Applications

Ryan Beckett

with

Princeton University

  • X. Kelvin Zou, Shuyuan Zhang,

Sharad Malik, Jennifer Rexford, David Walker

1

slide-2
SLIDE 2

Data Plane Verification

  • Find common misconfigurations
  • Operate in real time
  • Check fixed network properties
  • Can report false positives during

transitions

Controller Data Plane Verifier

2

slide-3
SLIDE 3

Stateful Firewall

client client server server

State Table

s1 A c1 c2 B

3

slide-4
SLIDE 4

Stateful Firewall

client client server server

State Table

s1 A c1 c2 B

3

“A server can only reach a client if the client has communicated with the server” Firewall Property: Firewall Property:

slide-5
SLIDE 5

Stateful Firewall

client client server server

State Table

s1 A c1 c2 B

X

3

“A server can only reach a client if the client has communicated with the server” Firewall Property: Firewall Property:

slide-6
SLIDE 6

Stateful Firewall

client client server server

State Table

s1 A c1 c2 B

3

“A server can only reach a client if the client has communicated with the server” Firewall Property: Firewall Property:

slide-7
SLIDE 7

Stateful Firewall

reachable(s1, c1) client client server server c1 s1

State Table

s1 A c1 c2

Firewall Property: Firewall Property:

B

3

slide-8
SLIDE 8

Stateful Firewall

reachable(s1, c1) ∧ client client server server c1 s1 c2 s1

State Table

s1 A c1 c2

Firewall Property: Firewall Property:

B

reachable(s1, c2)

3

slide-9
SLIDE 9

Stateful Firewall

∀(c,s)∈table, reachable(s, c) client client server server c1 s1 c2 s1

State Table

s1 A c1 c2

Firewall Property: Firewall Property:

B

3

slide-10
SLIDE 10

Stateful Firewall

client client server server c1 s1 c2 s1

State Table

s1 A c1 c2

Firewall Property: Firewall Property:

B

∀c∈clients,∀s∈servers, reachable(s, c) ↔ (c,s)∈table

3

slide-11
SLIDE 11

Stateful Firewall

client client server server c1 s1 c2 s1

State Table

s1 A c1 c2

Controller Code: Controller Code:

B

3

assert_continuously assert_continuously(f)

  • def packet_in(event):

pkt = event.parsed if pkt.typ != eth.IP_TYP: return …

slide-12
SLIDE 12

Stateful Firewall

client client server server

State Table

s1 A c1 c2 B

3

Controller Code: Controller Code:

assert_continuously(f)

slide-13
SLIDE 13

Stateful Firewall

client client server server c1 s1

State Table

s1 A c1 c2 B

r1 r2

3

Controller Code: Controller Code:

assert_continuously(f)

slide-14
SLIDE 14

Stateful Firewall

client client server server c1 s1

State Table

s1 A c1 c2 B

r1 r2

3

Controller Code: Controller Code:

stop(f) assert_continuously(f) assert_continuously(f)

install(r1) install(r2)

slide-15
SLIDE 15

Design Overview

4

Controller Data Plane Verifier

specification

slide-16
SLIDE 16

Design Overview

4

Controller Data Plane Verifier

specification

Controller

Assertion Library

specification

Property Generator Data Plane Verifier

verification conditions

slide-17
SLIDE 17

Design Overview

Controller

Assertion Library

Data Plane Verifier Property Generator

5

slide-18
SLIDE 18

Design Overview

Controller

Assertion Library

Data Plane Verifier Property Generator

5

event

slide-19
SLIDE 19

Design Overview

Controller

Assertion Library

Data Plane Verifier Property Generator

5

event rule

slide-20
SLIDE 20

Design Overview

Controller

Assertion Library

Data Plane Verifier Property Generator

5

event verification conditions assertion state update

slide-21
SLIDE 21

Design Overview

Controller

Assertion Library

Data Plane Verifier Property Generator

5

event exception verification results

slide-22
SLIDE 22

Incremental Verification

6

  • Change in data plane (existing tools handle this)
  • Change in assertion property
slide-23
SLIDE 23

Incremental Verification

6

  • Change in data plane (existing tools handle this)
  • Change in assertion property
  • Incrementally generate new verification conditions
slide-24
SLIDE 24

Incremental Verification

6

reachable(s1, c1)

s1 A c1 c2 B

Firewall Property: Firewall Property:

  • Change in data plane (existing tools handle this)
  • Change in assertion property
  • Incrementally generate new verification conditions
slide-25
SLIDE 25

Incremental Verification

6

reachable(s1, c2) reachable(s1, c1) ∧

Firewall Property: Firewall Property:

  • Change in data plane (existing tools handle this)
  • Change in assertion property
  • Incrementally generate new verification conditions

s1 A c1 c2 B

slide-26
SLIDE 26

Incremental Verification

6

reachable(s1, c1)

Firewall Property: Firewall Property:

  • Change in data plane (existing tools handle this)
  • Change in assertion property
  • Incrementally generate new verification conditions
  • Precompute and cache intermediate results

s1 A c1 c2 B

slide-27
SLIDE 27

Incremental Verification

  • Change in data plane (existing tools handle this)
  • Change in assertion property
  • Incrementally generate new verification conditions
  • Precompute and cache intermediate results

6

reachable(s1, c2) reachable(s1, c1) ∧

Firewall Property: Firewall Property:

s1 A c1 c2 B

slide-28
SLIDE 28

Incremental Data Structure

c=c1 c=c2 s=s1 s=s1

∀c∈clients,∀s∈servers, reachable(s,c) ↔ (c,s)∈table

Firewall Property: Firewall Property:

True False reachable(s1, c1) ↔ (c1,s1)∈table ∀c ∀s ∀s

7

slide-29
SLIDE 29

Incremental Data Structure

s=s2 s=s2

Firewall Property: Firewall Property:

True False

∀c∈clients,∀s∈servers, reachable(s,c) ↔ (c,s)∈table

c=c1 c=c2 s=s1 s=s1

∀c ∀s ∀s

7

slide-30
SLIDE 30

Incremental Data Structure

Firewall Property: Firewall Property:

True False

∀c∈clients,∀s∈servers, reachable(s,c) ↔ (c,s)∈table

c=c1 c=c2 s=s1 s=s1 s=s2 s=s2 c=c3 s=s1 s=s2

∀c ∀s ∀s ∀s

7

slide-31
SLIDE 31

Incremental Data Structure

Firewall Property: Firewall Property:

True False

Query data-plane verifier

∀c∈clients,∀s∈servers, reachable(s,c) ↔ (c,s)∈table

c=c1 c=c2 s=s1 s=s1 s=s2 s=s2

∀c ∀s ∀s

7

c=c3 s=s1 s=s2

∀s

slide-32
SLIDE 32

Incremental Data Structure

Firewall Property: Firewall Property:

True False

∀c∈clients,∀s∈servers, reachable(s,c) ↔ (c,s)∈table

c=c1 c=c2 s=s1 s=s1 s=s2 s=s2

∀c ∀s ∀s

7

c=c3 s=s1 s=s2

∀s

slide-33
SLIDE 33

Incremental Data Structure

Firewall Property: Firewall Property:

True False

∀c∈clients,∀s∈servers, reachable(s,c) ↔ (c,s)∈table

c=c1 c=c2 s=s1 s=s1 s=s2 s=s2

∀c ∀s ∀s

7

c=c3 s=s1 s=s2

∀s

slide-34
SLIDE 34

Incremental Data Structure

Firewall Property: Firewall Property:

True False

∀c∈clients,∀s∈servers, reachable(s,c) ↔ (c,s)∈table

c=c1 c=c2 s=s1 s=s1 s=s2 s=s2

∀c ∀s ∀s

7

c=c3 s=s1 s=s2

∀s

slide-35
SLIDE 35

Prototype Implementation

  • Python assertion debugging library
  • Support for Pyretic, Pox, Ryu
  • Uses the VeriFlow verification tool
  • Initial performance is promising

8

25 50 75 100 10 20 30 40 50 VC % Reduction active hosts (clients)

Stateful Firewall (incremental vs naive)

slide-36
SLIDE 36

Conclusion

  • Assertions to verify dynamic properties
  • Programmatic control over verification timing
  • Incremental algorithm to verify dynamic assertion properties
  • Prototype with reasonable performance

9
