1 ALTERNATIVE POWER IN THE GLOBAL SUPPLY CHAIN MILITARY AEROSPACE / / / GLOBAL TRANSPORTATION / / / INDUSTRIAL / / / GRID STORAGE Large Format Lithium Ion Batteries ENERDEL is developing technology to serve global markets with energy storage

slide-1
SLIDE 1

1

ENERDEL is developing technology to serve global markets with energy storage solutions

MILITARY AEROSPACE / / / GLOBAL TRANSPORTATION / / / INDUSTRIAL / / / GRID STORAGE

Large Format Lithium Ion Batteries

ALTERNATIVE POWER IN THE GLOBAL SUPPLY CHAIN

1

slide-2
SLIDE 2

2

WHO WE ARE…

Large-Format, High- energy Lithium-Ion Battery Solutions Alternative Fuel Cell Research & Development High-energy Lithium Ion Battery Production Research & Development Nano- technology and Film Disposition www.ener1.com NASDAQ: HEV Current Estimated Market Cap $600-700M

2

ENERDEL is part of the ENER1 portfolio

slide-3
SLIDE 3

3

GLOBAL SUPPLY STRATEGY

3

slide-4
SLIDE 4

4

US OPERATIONS –

INDIANAPOLIS

4

  • Heritage 19 years :

― Ener1 Lithium Group Established in 1990 ― Delphi Lithium Group 1998 ― EnerDel 2004 ― Personnel

  • ~ 170 Employees
  • Hague Rd. Existing Space

― Total Area: ~ 98,000 ft2 ― Significant Capital Investment Allocated For

Production Readiness.

  • Mixers, Proprietary Coating Line, NMP

Recovery System, Automation, Completely Automated Electrode Stacking

― Main Product

  • Lithium Ion Cell for Automotive

Applications

slide-5
SLIDE 5

5

US OPERATIONS –

NOBLESVILLE

5

  • 38,500 Ft2 of Mfg., Test & Offices
  • Lease signed in September, 2008
  • Reconditioned Building & Site – 3/09
  • Main Product

― Battery pack assembly and testing

  • Sample Build Area – Jan. 2009

― 1st Module & Pack Assembly – Jan 2009 ― 32 Employees – May 2009 ― BMS Engineering & Test – May 2009

slide-6
SLIDE 6

6 Cell

  • Advanced Prismatic Design

Module

  • High Performance Li-Ion Cells
  • Integrated Thermal Management
  • Voltage & Temperature

Monitoring

System

  • Integration of Multiple Subsystems
  • Battery
  • BMS
  • Software
  • Mechanical
  • Thermal

ENERDEL’S

LITHIUM-ION ENERGY STORAGE SYSTEM

6

Robust Sub-System Design & Integration Required For a Successful ESS Solution

slide-7
SLIDE 7

7

GLOBAL LITHIUM BATTERY MARKET

–YR 2020 $66B

7

Source: Deutsche Bank

slide-8
SLIDE 8

8

  • Transportation
  • Energy Storage
  • Government
  • Military
  • Maritime
  • Commercial - Consumer Products
  • Aerospace

MARKET SECTORS – ENERGY SYSTEMS

8

slide-9
SLIDE 9

9

RECENT DEVELOPMENTS

9 September 09: ENER1 teams with Volvo Car Corporation to provide lithium-ion batteries for the Volvo C30 battery electric vehicle prototype November 09: ENERDEL wins U.S. Army contract to develop batteries for new “Hybrid Humvee” August 09: ENER1 takes 31% stake in EV manufacturer, Think Global August 09: ENERDEL selected to receive $118.5 M in federal grant funding under the stimulus package July 09: ENERDEL and the Nissan Motor Co. to research electrical conductive material July 09: ENER1 & Think selected for Japan Postal Service EV Conversion Program July 09: ENERDEL to supply lithium-ion batteries for Volvo’s V70 PHEV demonstration program May 09: AC Transit selects ENERDEL to supply batteries for next-generation fuel cell buses; additional partners UTC and VanHool July 09: ENERDEL awarded $3.3 million for safety research on auto lithium-ion battery December 09: ENERDEL partners with Mazda and Itochu for smart grid integration project November 09: ENERDEL enters utility energy storage market to supply new DOE-backed smart grid program

slide-10
SLIDE 10

10

TH!NK – CITY

VEHICLE INTEGRATION

  • Supply agreement with

development phase

– Production 2010

  • Integrated EnerDel battery

system into vehicle:

– Mechanical – Electrical (Power, Signal, CAN) – Thermal Management

  • Successfully accomplished

– Vehicle traction drive – Regen acceptance – Charging system interface

10

slide-11
SLIDE 11

11

VOLVO – C30 COUPE VEHICLE INTEGRATION

  • The C30 Battery Electric Vehicle (BEV)
  • Part of Volvo Car Corporation’s DRIVe Towards Zero Strategy

– zero emission, city commuter car – 150km (95 mile) range – covers the daily mobility needs of more than 90 percent of European commuters.

  • The EnerDel battery is a 'split battery', with an energy content of over 24 kWh nominal

energy.

  • Follows the recently announced collaboration for the plug-in hybrid V70 demonstration

vehicles being road tested in Europe, which also feature EnerDel lithium-ion batteries.

11

slide-12
SLIDE 12

12

XM1124 – HMMWV VEHICLE INTEGRATION

  • Working with US Army to develop a next-

generation battery system for the Humvee

– EnerDel Will provide:

  • Multiple Chemistries
  • Complete Architecture
  • Thermal Management
  • System Electronics
  • TARDEC will be testing two of

EnerDel’s chemistries

– EnerDel will successfully demonstrate:

  • Two systems that will be exposed

to extreme performance situations

12

slide-13
SLIDE 13

13

AC TRANSIT BUS

FUEL-CELL/ELECTRIC HYBRID

  • Sixteen new, next-generation, hybrid-electric fuel cell buses for Alameda-Contra Costa

Transit District (AC Transit)

  • Demonstrates scalability for use in heavy-duty applications.
  • Hydrogen tanks on the roof of the bus will provide a range of approximately 300 miles.
  • Collaboratively designed by EnerDel, AC Transit, Van Hool (the bus manufacturer and

integrator), and UTC Power, a United Technologies Corp. (the fuel cell system provider).

  • Twelve will be the backbone of AC Transit's fuel cell fleet in the California Air Resources

Board's only Advanced Zero-Emission Bus Demonstration program.

  • Four will be operated by various transit agencies under the Federal Transit Administration's

National Fuel Cell Bus Program.

13

slide-14
SLIDE 14

14

JAPAN’S TSUKUBA PROJECT

14

  • Three Mazda 2 cars will be converted to EVs

– EnerDel will supply the advanced battery systems – Uses proprietary EV drive-train system, developed for the Th!nk City – Slated to begin in March of 2010 – Offered to the public through a car-sharing service, akin to America’s Zipcar

  • Groundbreaking project linking up all of the essential building blocks needed to integrate

the smart grid, electric vehicles and renewable energy technologies.

  • First time that EVs, stationary grid storage, solar power and rapid charging infrastructure

are combined in a real-world operating environment.

  • Located outside Tokyo in Tsukuba City, Japan –

a major center for scientific R&D

  • Involves more than a dozen major partners from around the globe
  • Illustrates the opportunities in the global clean tech marketplace.
slide-15
SLIDE 15

15

TSUKUBA: A GREEN PROTOTYPE COMMUNITY

15 Mazda 2 (EV) ENERDEL Battery Rapid Transit System EV Sharing Station Fast Charge Station EV Service Station EV Sharing Station Fast Charge Station PV Arrays, IES EV Sharing Station Fast Charge Station PV Arrays, IES (ENERDEL) Convenience Store City Hall EV Sharing Station Fast Charge Station PV Arrays, IES Data Center

slide-16
SLIDE 16

16

LIFE CYCLE ANALYSIS

  • VS. COMPARABLE GASOLINE-FUELED VEHICLE

ENERGY ITEMS HYBRID ELECTRIC VEHICLE ELECTRIC VEHICLE ENERGY USE PER UNIT OF PRODUCTION

  • 39%
  • 50%

ENERGY COST PER UNIT OF PRODUCTION

  • 39%
  • 64%

GREENHOUSE GASES

  • 39%
  • 73%

SULFUR DIOXIDE

  • 39%
  • 60%

NITROGEN DIOXIDE

  • 39%
  • 92%

PARTICULATES

  • 39%
  • 83%

16

As compared to lightweight gasoline-fueled car, driven for 100,000 miles (baseline). Includes all aspects from extraction of raw materials through recycling/disposal at end of life. Includes batteries reconditioned and repurposed after 100,000 miles vs. disposal.

slide-17
SLIDE 17

17

ONE STEP FURTHER

Reduce, Recycle, Reuse – Zero Landfill Goal

  • Copper, steel and aluminum recycled (bulk of cell material)
  • Bubble wrap/shrink wrap recycled
  • Wood pallets and boxes that are not reused are recycled for mulch
  • Plastics (#1 & #2), glass, cardboard, recycled
  • Paper shredded for recycle (confidential and non-confidential)
  • All other non-hazardous trash sent to Covanta to be burned for energy for

downtown Indianapolis

  • Hazardous production cleaning solvent wastes recycled for fuel blending
  • Primary coating solvent collected for off-site recycle and reuse

17

slide-18
SLIDE 18

18

SUMMARY

  • Battery-based energy storage systems are versatile

and efficient

– Vehicles large and small – Grid/home/office energy storage – Alternative power storage and “availability shifting” – Utility load shifting – Rapidly deployable emergency power

  • ARRA and other funding will help accelerate the

migration from traditional fuels to alternative energy sources

– Communication technology – “smart grid” – Production capacity – batteries and vehicles – Infrastructure – “filling stations”

18

slide-19
SLIDE 19

19

HISTORICAL SUPPLY CHAIN DYNAMICS

  • 1900

~ 20 million horses ~ 2500-4000 cars

  • Steam (~49%), Electric (34%), Gasoline (17%)
  • 90% of available roads were unpaved
  • Gasoline was waste product of kerosene production

– car owners went to the kerosene plant to get their gasoline – or filled up from a barrel at the local grocery (using a funnel)

  • 1905

First purpose-built gas station

  • pened (St. Louis)
  • 1907

Second gas station opened (Seattle)

19

slide-20
SLIDE 20

20

SUPPLY CHAIN DYNAMICS

  • 1908

The Model T debuted

  • 1909

312,000 cars in the US

  • 1911

Gasoline outsold kerosene

  • 1920

~ 8 million cars in the US ~ 15,000 gas stations

  • 1932

The last steam-powered car was built

  • 1970

> 200,000 gas stations in US

  • 2000

> 133 million cars in the US

  • 2008

~ 107,000 gas stations in the US

20
