ALEXMOLDS SPYROS ALEXOPOULOS MECHANICAL PARTS AND TOOLS DESIGN AND MANUFACTURING MAIN PRODUCTION AREA EQUIPMENT LIST CNC MACHINING CENTER AKIRA SEIKI V2,5 XP X760 Y435 Z520 WITH 5 AXIS ROTARY TABLE AUTOCAM ATS160A CNC MACHINING CENTER

SLIDE 1

ALEXMOLDS

SPYROS ALEXOPOULOS

MECHANICAL PARTS AND TOOLS DESIGN AND MANUFACTURING

SLIDE 2

MAIN PRODUCTION AREA

SLIDE 3

EQUIPMENT LIST

 CNC MACHINING CENTER AKIRA SEIKI V2,5 XP X760 Y435 Z520 WITH 5 AXIS ROTARY TABLE AUTOCAM ATS160A  CNC MACHINING CENTER HAAS VF2 X760 Y410 Z500 with 4 AXIS ROTARY TABLE Φ210mm  CNC MACHINING CENTER AKIRA SEIKI V4,5 XP X1150 Y640 Z660  CNC MACHINING CENTER CH MV1200 X1200 Y600 Z650  CNC LATHE HAAS TL2 Φ400X1200  CNC MILL MACHINE X800 Y400 Z400  CMM MACHINE DEA X700 Y500 Z500  ADDITIVE MANUFACTURING EOS EOSINT M280 (laser sintering system)  PLASTIC LASER SINTERING SYSTEM EOS FORMIGA P110  (Next planned investment OKUMA GENOS L300 EM)

SLIDE 4

MATERIALS

 Stainless steel  Aluminum  High temp alloys (Inconel)  Titanium  Tool steels (+ Hardened)  Plastics  Beryllium copper  Copper  Bronze

SLIDE 5

MANUFACTURING CAPABILITIES

 Metallic - High Precision Complex Parts  Prototyping  Small and medium quantities production  Tools and Jigs  Plastic Injection Tools  Aluminum die casting Tools  Progressive Tools  Composite Tools

SLIDE 6

A few things about us

 Personnel: 8 people (2 engineers, 6 operators)  Annual turnover: 450.000 €  EN9100C Certified (OIN 6142658880)

SLIDE 7

MAIN ADVANTAGES

Leaving aside the quality and on time delivery which in our days is considered a given, our company’s main advantages are:

 30 years of experience  Skilled and trained personnel (all mechanical engineers)  Flexibility in production, on part numbers and batch sizes starting from prototyping and regardless of requested quantity (1, 10, 100, 1000 etc.)  Assembly operations  Wide range of materials  Quality system EN9100C  Prompt response in demands  Low cost due to the current conditions in Greece  Addition of extra shifts in order to cover our customers’ needs  Secondary existing work area ready to be adjusted to our customers’ needs

SLIDE 8

What our company can offer:

 Flexibility in production, from prototypes, small quantities up to medium to large runs, due to extra shift that can be employed and secondary production area ready to be exploited for new projects  Wide variety of materials and at this point initial manufacturing of Titanium parts  Prompt response to demands  Low hourly rate  Loyalty and dedication to our customers. Ask for their opinion and follow their advise in order to improve ourselves and better cover their needs  Continuous improvement. Each year we add new capabilities in order to be able to provide a turnkey solution for our customers. Initially started with EN9100 development and application, moved to 5 axis machining, then to laser sintering / metal 3D printing and finally to Engineering solutions (and continuing…)  Engineering solutions. Design optimization, Plastic Injection Tools design, Composite Tools design, Aluminum Die Casting Tools design  Milling and Turning capabilities

SLIDE 9

What we brag about…

 100% on time delivery  No complaints from our customers  0 issues with suppliers  Continuous improvement  New customers always continue to do business with us with increasing frequency

SLIDE 10

MAIN CUSTOMERS

 Theon Sensors: machined parts for vision systems (AL7075, AL6082, INOX 304)  BIC Violex: machined parts for general industry applications (AL7075, AL5083, INOX 304, Tool steels)  INASCO Hellas integrated aerospace services: Aerospace prototypes, machined parts and composite tools manufacturing (INCONEL, AISI410, INOX 316)  Elfon LTD: Junction boxes for cables and harnesses (AL6061, Sand casting, AISI 304)  Intracom Defense Electronics (IDE), machined parts for defense electronics (AISI 304, AL7075, AL6082)

SLIDE 11

SLIDE 12

SLIDE 13

High Precision complex parts manufactured from blocks for AEROSPACE applications for SAFRAN Materials used: Inconel 718, AISI316L

SLIDE 14

High precision complex parts manufactured from blocks for AEROSPACE applications Material used: AL7075

SLIDE 15

Tools for Aerospace applications for RUAG (flap calibration tools and balance tail installation tools)

SLIDE 16

Small Production 5 Axis Machined Parts

SLIDE 17

Machined Parts from Tool Steels and Aluminum

SLIDE 18

Titanium Parts

SLIDE 19

Stainless Steel Parts

SLIDE 20

Milled and Turned Parts for Vision systems

SLIDE 21

SENSORS MADE FRON STAINLESS STEEL, CERAMICS, INCONEL

SLIDE 22

Aluminum and Bronze Junction Boxes for cables and harnesses for MILITARY and NAVAL applications

SLIDE 23

SLIDE 24

Automotive Aluminum Parts

SLIDE 25

Machined parts from hardened tool steels (56-60 HRc)

SLIDE 26

Plastic Injection Tools Design and Manufacturing

SLIDE 27

Plastic Injection Tools Design and Manufacturing

SLIDE 28

Composite Tools Design and Manufacturing Composite parts Machining
