Airbreathing engines Introduction to Aeronautical Engineering Prof. dr. ir. Jacco Hoekstra R. Macdonald - CC - BY Work by engines . p Area A x p W V The combustion cycle Intake p Net work Compression Combustion Expansion p

slide-1
SLIDE 1
  • Prof. dr. ir. Jacco Hoekstra

Airbreathing engines

Introduction to Aeronautical Engineering

  • R. Macdonald - CC - BY
slide-2
SLIDE 2

W

Work by engines

p

Δx Area A V p

.

slide-3
SLIDE 3

The combustion cycle

p V p Intake Compression Combustion Expansion Exhaust Net work

slide-4
SLIDE 4

Aviation piston engines

  • 1. 2 Stroke engines

Obsolete

  • 2. 4 Stroke engines

Common

  • 3. Wankel engine

‘New’

  • 4. Diesel engine

New

Zerega - CC - BY - NC - ND Zephyris - CC - BY - SA

slide-5
SLIDE 5

Piston engines: In-line engines

slide-6
SLIDE 6

Piston engines: Radial engine

Stoianovici - CC - BY - SA

slide-7
SLIDE 7

Piston engines: Boxer engine

Anynobody - CC - BY - SA

slide-8
SLIDE 8

Piston engines

In-line V-engine Radial Boxer

Wapcaplet - CC - BY - SA Siemens PLM Software - CC - BY - SA Stahlkocher - CC - BY - SA

slide-9
SLIDE 9

Airbreathing engines

  • A. DeSantis - CC - BY
