Age At Home

Deep Learning & IoT in Elder Care http://age-at-home.mybluemix.net/ http://ageathome.slack.com/ David C Martin (dcmartin@us.ibm.com) Dima Rekesh (dima.rekesh@optum.com)

Internet-of-Things growing fast

Estimated 30 billion to 200+ billion connected devices by 2020

2016: 10B+ 2020: 100B+ 10M+ +100M

Unspoken challenge

1: 1,000 1: 10,000 10M+

Additional staffing required at current ratio

1. Autonomous transacting agents 2. Decentralized, governed economy 3. Distributed, untrusted environment

Criteria for success

… autonomous software agents outside of human control will participate in 5% of all economic transactions. The result of the prevalence of metacoin platforms will be the emergence of a fully programmable economy operating beyond the control of any single centralized institution or government. It is the metacoin platform that enables automatic enforcement of conditions in a fully distributed and untrusted environment. – Gartner

BlueHorizon

Private, secure, opt-in, auditable value-exchange

1. Tax-free economy 2. Open, standards-based community 3. Technology independence 4. Supply-chain transparency

http://bluehorizon.network

Market opportunity

• Aging population (65+)
• 44MM US
• 65MM India
• 119MM China
• Need for assistance
• 70+ > 10%
• 75+ > 20%
• 80+ > 30%
• IBM addressable market
• $10BB by 2025
• http://www-03.ibm.com/able/

Japan Italy Germany Ireland China Brazil US India Egypt World Percentage of Population 65 years and older 2015

https://www.census.gov/population/socdemo/statbriefs/agebrief.html http://www-03.ibm.com/able/news/bolzano_video.html

Minimum viable product (MVP)

Utilize image analysis to recognize entities (e.g. person) and scenes (e.g. Kitchen) to trigger action (e.g. Gma and Gpa didn’t get up).

Analyze Scene Determine normal vs abnormal Trigger Action (e.g. no person in kitchen by 10 AM)

Components

• Jetson TX2 (1)
• Raspberry Pi3 (3)
• Playstation3 Eye Camera
• 75° or 56° FOV
• Multi-array microphone
• Speaker
• WiFi
• LINUX, Docker, motion package
• DIGITS v5, Caffe v1, JetPack v3

AND IBM WATSON CLOUD

System Overview

PlayStation 3 USB Camera RaspberryPi 3 Bluemix

Watson VR Cloudant DIGITS Motion DIGITS

Jetson TX2

Watson Analytics

K80 (2)

System Details

• Raspberry Pi3 & Playstation3 Eye
• LINUX, Docker, motion package
• Image resolution: 640x480 (8 bit color)
• Field-of-view: 75° (interior) or 56° (exterior)
• IBM Watson Cognitive services
• Alchemy image recognition (deprecated)
• VisualInsights (retired)
• Watson Visual Recognition (current)
• Device installations
• Locations: kitchen, bathroom, road
• DB: rough-fog, damp-cloud, quiet-water
• Event identifier (YYMMDDHHMMSS-##-##)
• Date & time components (Y,M,D,H,M,S)
• ALCHEMY: top result {entity,model,score}
• VISUAL: image ID and results array [{entity,model,score},…]

Process overview

Governed by Smart Contracts Recorded on distributed, shared ledger Governor Escrow

Peer 1 Peer 2 Peer 3

Block- chain

Transacting Peers (full & lite)

Process details

1. Developer create app:

I. Client (RPi) container II. Cloud (X86) container III. BlueMix Container service IV. BlueMix CF app (e.g. Node.js) V. Register in AppStore

1

BlueHorizon

3 4

Developer Owner

C

BUILD

2 B

5

A

• A. DEV offer Cloud run-time
• B. OWN accept (v$ /hr)
• C. DEV deploy container

CLIENT / CLOUD IOTF / MQTT

• 3. OWN offer Client run-time
• 4. DEV accept (v$ /hr)
• 5. OWN deploy container

Public

2. Public become Owner

I. Visit public application II. Acquire Raspberry Pi (DIY) III. Select “app” from Store

Jupyter Notebook Exploration

By Peter Parente (pparent@us.ibm.com) https://gist.github.com/parente/7db992fae487d6e665e7b7dca841ffa2

Watson Analytics Exploration

• 1. Replication from

Cloudant into dashDB

• 2. SQL select,

project, join in dashDB

• 3. Import into

Watson Analytics

• 4. Refine & visualize

BUILD

Signal Quality

• Images classified generically
• Rooms, colors, ..
• Many false-negatives (no

entity detected)

• Uncontrolled vocabulary and

taxnonomy

• Need training exemplars
• Collect in-situ images
• Build taxonomy, ontology
• Train recognition algorithm
• Attenuate iteratively
• Curate training data
• Improve signal:noise
• Increase TOP1 accuracy

All vendors fail out-of-the-box

Microsoft Google Amazon

The default (OOTB) model is always insufficient

• Too noisy and sparse for traditional data cleansing
• Prior examples not specific to application context
• Information content critically dependent on signal

quality Avoid a priori limitations or filters on sensor input

• Empirical data must be collected, curated and learned
• Define positive and negative conditions or outcomes
• Manual “human-in-the-loop” curation into positive and negative
• Training, testing, and refinement of learnings (e.g. classifier)
• Deployment and QA/QC metric monitoring

Lesson 1: you must learn

Generic learning cycle

Ingestion and preparation

• Asynchronous ingestion
• Periodic “changes” from Cloudant
• Collect (FTP) from local RPi devices
• Collate into hierarchy
• Store inventory (Cloudant)
• Dynamic presentation
• Display images from inventory
• Time limit (YYYYMMDDHHMMSS)
• Count (1-20)
• Class (e.g. all, person)
• Classification actions
• Negative class in red (e.g. kitchen)
• Positive class in green (e.g. person)
• Created class in blue (e.g. dog, cat)
• SKIP – more than one class
• Update inventory & repeat
• Remove bad examples
• Squash vs. Crop

Curate – Model – Analyze : Repeat

Curate Model Analyze

Review and label samples to train Watson, e.g. dog, cat, household members

Summary Activity Analysis

Building DL models with DIGITS

General built in cloud (2xK80)

• GoogLeNet
• ImageNet
• 1MM images
• 1000 classes
• 224x224 images
• 44 hours (4 GPU)
• 73% Top1; 91% Top5

Specific built on-premise (TX2)

• Base model from cloud
• End-user selected images
• 1033 images (776/ 257)
• 11 classes
• 224x224 samples
• 18 minutes, 4 s (1 GPU)
• 90.1% Top1; 99.6% Top5

Challenges - Jetsons

• Versioning hell (what version of OpenCV? What version of Caffe?)
• Performance. Full HD and 4K frame processing, anyone?
• Decoding of incoming streams. Can’t on the CPU
• Latency of video streams
• Generation of training sets / effort required from human trainers

Dockerizing Jetson TX1 / TX2

• Docker is the way applications get distributed today
• Developer productivity increase is immense
• Nvidia-docker is not yet supported on the Jetson, so we had to

do a little bit of reverse engineering…

• Install docker
• Get the cuda / cudnn/ drivers right
• A USB3 HD or direct attached SSD is a must to do dev

Focus on moving objects

• Usually, moving objects are the most interesting
• When you camera is stationary, you can use traditional CV to

compute changed pixels with ease

• Must consider both long term and short term motion (front of cat vs

behind cat)

• Now you can draw bounding boxes around these moving objects

and send them to a classic image classification network

• Total number of pixels processed is greatly reduced
• Image is downscaled for motion detection
• Image Classification networks are fast, lean, very accurate and

support thousands of classes

Benefits of working with moving objects

• You get the bounding boxes – and the pixels free
• Now you can train a variety of networks: yolo, detectnet.. FCNs
• The network will guess the label, human can correct only if

needed

• Once the network becomes good at recognizing objects, you

don’t need to ask the human to classify them anymore, just focus

• n more granular classes
• The trained networks can now be placed on moving cameras and

learn to recognize immobile objects in frames

Future work

• LSTMs for more accurate motion detection
• FCNs for more accurate labeling
• Multi-labeled , crowdsourcing tags
• Integration with time series data
• Performance optimizations…

DIGITS Caffe training

GENERAL 73% Top1; 91% Top5 SPECIFIC 90.1% Top1; 99.6% Top5

Scenarios

David, did you take your medications? Take your low- dose aspirin; small, round and yellow in the yellow and green Bayer bottle. David, did you just wake-up? You should eat now that you’ve taken your medications! Breakfast! How about a yogurt? Time to check your blood sugar!

• Curation effects outcome
• Variability in human detection, e.g. missed “cat”
• Defined, discovered and previously unknown

(e.g.“dog” or David)

• Optimize objective functions “top-down”
• Focus curation on utility and expectation (e.g.

notification satisfaction)

• Cascade positives and negatives to subordinate

domain (e.g. image capture interval )

• Enable dynamic subsystem controls (e.g. sensor trigger)
• Any definition should be fact, not opinion, estimate,
• r historical statistic
• Consider all non-defined parameters as learning

inputs or outputs

Lesson 2: context defines success

Many layers of learning

horse car

• dog

ü car ü horse

• bike
• cat
• bottle

ü person

detect locate identify describe understand And more …

Cognitive IoT Cycle

Sense Try Catch Teach Model Analyze Simulate Deploy

• Sense data in-situ
• Try conditional inference
• Catch success & failure
• Teach and share examples
• Model ground truth
• Analyze accuracy & precision
• Simulate future from past
• Deploy improved learnings

A hybrid approach

Inferencing is cheap

• RaspberryPi3 (1 frame/ 6 seconds; US$50)
• nVidia Jetson TX1 (30 frame/ second; US$500)

Latency kills

• Real-time (e.g. driving)
• Constrained (e.g. conversation)
• Opportunistic (e.g. presence)

Predict in private

• Apply to proprietary or sensitive data
• Review successes & failures

Learn quickly

• Collect/share/groom test sets
• Train and test; repeat

Qualify model

• Assess signal (accuracy, recall, TOP1, …)
• Validate with known facts, dimensions, measures
• n-premise

In-cloud

Select Train Test Sense Respond Teach

Community

Truth Model End-users (EU) teach in situ examples

• scenes (kitchen), person (david), ..

Conditional sharing by EU

• “I see a dog”

Community develops (curates) Truth

• dog: detect, locate, identify, …

Specialists build models of Truth

• select, train, test and share

Community evaluates Model

• test against public, private sets

Sell (µ¢) Buy (µ¢) Buy (µ¢) Sell (µ¢) Curate (µ¢)

A shared economy

Hybrid Cognitive

teach

Community curated examples Prioritized lessons

End-user “app” query

Base models Refine base models Deployed, refined, models Curated examples

Thank You

http://age-at-home.mybluemix.net http://ageathome.slack.com/ David C Martin dcmartin@us.ibm.com | @dcmartin | www.dcmartin.com http://bluehorizon.network/
