AFS Server Performance Comparisons Bo Tretta Kim Kimball Jet Propulsion Laboratory Information Services - FIL Service http://fil.jpl.nasa.gov SLAC AFS Best Practices Workshop March 24, 2004 JPLIS-FIL Server Performance Comparisons 1 n

SLIDE 1

JPLIS-FIL Server Performance Comparisons 1

AFS Server Performance Comparisons

Bo Tretta Kim Kimball Jet Propulsion Laboratory Information Services - FIL Service http://fil.jpl.nasa.gov SLAC AFS Best Practices Workshop March 24, 2004

SLIDE 2

2 JPLIS-FIL Server Performance Comparisons 2

n Performance benchmarks of various hardware configurations n Range of ages for hardware n Different AFS versions n Most hardware is already in operation and limits the testing we can perform n Partitioned network n Testing was performed on both sides of the network firewall. n Operational Implications

SLIDE 3

3 JPLIS-FIL Server Performance Comparisons 3

Can we use less expensive hardware and still meet performance goals?

SLIDE 4

4 JPLIS-FIL Server Performance Comparisons 4

Cell Configuration

n At the Jet Propulsion Laboratory in Pasadena, the AFS cell is configured with a firewall that splits the database servers as well as the fileservers.

SLIDE 5

5 JPLIS-FIL Server Performance Comparisons 5

Internet

File Servers Database Servers Firewall Flight Ops Firewall Clients File Servers Database Servers Clients Clients Database Servers File Servers Test Cell

afs06, afs07, afs20

SLIDE 6

6 JPLIS-FIL Server Performance Comparisons 6

Benchmarking

n First assessment of OpenAFS fileserver hardware using Andrew Benchmark. n Initial goal: Determine if further assessment of inexpensive fileservers is warranted – without wasting time and resources in the initial trials.

SLIDE 7

7 JPLIS-FIL Server Performance Comparisons 7

Methodology

n Compare Andrew Benchmark results from inexpensive Intel-based fileservers with results from existing Sun Solaris fileservers.

SLIDE 8

8 JPLIS-FIL Server Performance Comparisons 8

Host O.S. AFS software Hardware Memory (MB) Proc 1 (MHz) Proc 1 (MHz) Storage Device afs06 Solaris8 3.6 2.45 Ultra - 1 256 167 N/A Sparc Array afs07 Solaris8 3.6 2.45 Ultra - 1 256 167 N/A Sparc Array afs12 Solaris8 3.6 2.45 Ultra - 2 256 N/A 2 * Sparc Array afs15 Solaris8 3.6 2.45 Ultra - 2 256 200 200 A 3500 afs16 Solaris8 3.6 2.45 Ultra -2 256 296 N/A 2 * A5000 afs17 Solaris8 3.6 2.45 Ultra - 60 256 450 450 A3500 afs18 Solaris8 3.6 2.45 Ultra - 60 1536 450 450 A3500 afs19 Solaris8 3.6 2.45 E 420 R 2048 450 450 A3500 afs20 Solaris8 3.6 2.45 280 R 2048 900 900 2 * T3 afslinux01 RH Enterprise 3 1.2.11 Compaq ML330 640 P3 1.4 GHz N/A HP Storageworks Smart Array afslinux02 RH Enterprise 3 1.2.11 Compaq ML330 640 P3 1.4 GHz N/A HP Storageworks Smart Array afslinux03 RH Enterprise 3 1.2.11 Aberdeen 845 PE 512 P4 2.4 GHz N/A ATA 100 Internal afstest03 Solaris8 3.6 2.45 Ultra - 1 256 167 N/A Sparc Array afstest05 Solaris8 3.6 2.51 Ultra - 1 256 167 N/A Sparc Array

SLIDE 9

9 JPLIS-FIL Server Performance Comparisons 9

Performance test from a client outside of the firewall

SLIDE 10

10 JPLIS-FIL Server Performance Comparisons 10

Observations

n afslinux02 was not performing the same as afslinux01 which is identical hardware. n After examining afslinux02, it was found that the L2 cache module was not installed. n The subsequent tests were performed with the L2 cache module installed.

SLIDE 11

11 JPLIS-FIL Server Performance Comparisons 11

Performance test from a client outside of the firewall with L2 cache installed

SLIDE 12

12 JPLIS-FIL Server Performance Comparisons 12

Performance test from a client inside of the firewall. Did not test to the test cell systems because the production servers can not be modified.

SLIDE 13

13 JPLIS-FIL Server Performance Comparisons 13

Conclusions

n Inexpensive hardware for OpenAFS fileservers is not ruled out. n Follow on: Proceed to stress testing to determine feasible transaction rates.

SLIDE 14

14 JPLIS-FIL Server Performance Comparisons 14

Examining a Myth

n Expensive “big iron” is frequently purchased because “we know it will get the job done.” n The result can be a collection of a small number of expensive fileservers.

SLIDE 15

15 JPLIS-FIL Server Performance Comparisons 15

But…

n A larger number of inexpensive fileservers may provide equivalent performance. n It may be that the initial investment in the larger number of less expensive fileservers does not significantly differ from the smaller collection of “big iron” for a given aggregate transaction load.

SLIDE 16

16 JPLIS-FIL Server Performance Comparisons 16

Benefits

n Initial cost aside, the “more and cheaper fileserver” approach offers:

w Inexpensive incremental increase in capacity. w Cost effective redundancy. w Better manageability.

SLIDE 17

17 JPLIS-FIL Server Performance Comparisons 17

Cost effective redundancy

n If a fileserver fails, it can be immediately replaced, with similar (or identical) hardware kept for this purpose.

SLIDE 18

18 JPLIS-FIL Server Performance Comparisons 18

Better manageability

n We theorize that it will be easier to take a machine

ut of service when it houses less RW data.

SLIDE 19

19 JPLIS-FIL Server Performance Comparisons 19

Assumption

n That the time required to move the Read/Write volumes in the OpenAFS namei implementation does not increase to a point that volume moves are truly abysmal.

SLIDE 20

20 JPLIS-FIL Server Performance Comparisons 20

Benefit

n It will be easier to recover from unexpected hardware failure. It’s easier to justify a “spare server” at $10,000 than at $100,000.

SLIDE 21

21 JPLIS-FIL Server Performance Comparisons 21
