UNCLASSIFIED Approved for public release Aerospace Division Overview Dr Richard Chester Acting Chief Aerospace Division DSTO Partnerships week 1 UNCLASSIFIED Approved for public release DSTO Roles in the Aerospace Domain Defence

slide-1
SLIDE 1

1

Aerospace Division

Overview

Dr Richard Chester

Acting Chief Aerospace Division DSTO Partnerships week

UNCLASSIFIED – Approved for public release

slide-2
SLIDE 2

2

Defence Operations Acquisition Projects Sustainment Strategic Research

DSTO Roles in the Aerospace Domain

UNCLASSIFIED – Approved for public release

slide-3
SLIDE 3

3

Changing Australian Air Domain platforms

KC30B Multi-Role Tanker Transport F/A-18G Growler C-17 Globemaster Joint Strike Fighter F-35 Lightning II Wedgetail AEW&C MRH-90 ARH Tiger C-27J P- 8

UNCLASSIFIED – Approved for public release

slide-4
SLIDE 4

4

DSTO Aerospace Division

Purpose:

To provide advice on the exploitation of aerospace science and technology in support

  • f Australian Defence Force (ADF), operations,

the acquisition of ADF aircraft, the cost- effective sustainment of ADF aircraft and to conduct strategic research in selected areas.

6 Branches:

  • Aircraft Structures
  • Airframe Technologies & Safety
  • Applied Hypersonics
  • Aerospace Systems Effectiveness
  • Aircraft Performance & Survivability
  • Aircraft Health & Sustainment
  • 300 staff and contractors

UNCLASSIFIED – Approved for public release

slide-5
SLIDE 5

5

Aerospace Division Major Recent Projects

  • HIFiRE Hypersonics program 2006->, wins ICAS Von Karman award 2012
  • Helicopter gearbox fault diagnosis by application of time frequency analysis
  • Live Virtual Constructive Simulation Exercises, - Black Skies, Coalition Virtual Flag
  • Development of Joint Air Warfare Battle Lab, JAWBL at RAAF Williamtown
  • C-130 J - Full Scale Fatigue test, Main wing
  • JDAM-ER gliding weapon, extended range
  • F/A-18 - Centre Barrel fatigue life extension
  • Hawk Mk127 - Full Scale Fatigue Test

HIFiRE

UNCLASSIFIED – Approved for public release

slide-6
SLIDE 6

6

Aerospace Domain

Aerospace Systems Effectiveness Aircraft Performance & Survivability Aircraft Health & Sustainment Airframe Technology & Safety Aircraft Structures Applied Hypersonics

Aircraft Structural Sciences Aircraft Performance and Health Aerospace Systems and Mission Effectiveness Strategic Research Program

= Strong synergies

Aerospace Capability Analysis

Aerospace Operations

JOAD Joint & Operations Analysis Division AD Aerospace Division UNCLASSIFIED – Approved for public release

MD Maritime Division LD Land Division WCSD Weapons & Combat Systems Division CEWD Cyber & Electronic Warfare Division NSID National Security & Intelligence, Surveillance & Reconnaissance Division

slide-7
SLIDE 7

7

  • Synthetic Collective Training
  • Live Virtual Constructive Simulation
  • Team training in realistic multi-aircraft

& multi-national mission scenarios

Interaction of humans & systems for optimal performance

  • Helicopter Systems Effectiveness
  • Flight models, ship wakes, slung loads,

degraded visual environment

  • Human Factors, Vision, Perception,

Autonomy, Training, Cognitive Modelling

Aerospace Systems Effectiveness

UNCLASSIFIED – Approved for public release

slide-8
SLIDE 8

8

  • Aircraft IR Signature Modelling ,

Measurement and Control

  • Aero-Thermodynamic Test Facilities,

Combustion Test Facility

  • Trusted Autonomy
  • Novel UAV Technologies: Alternative

Navigation, Power & Energy

Aerodynamics, Aerothermodynamics, Aeroelasticity, Aerial Autonomy

  • Aerodynamic Test Facilities,

Transonic and Low Speed (Subsonic) Wind Tunnels

  • Advanced Computational Fluid

Dynamics, including Fluid-Structure Interaction

Aircraft Performance & Survivability

UNCLASSIFIED – Approved for public release

slide-9
SLIDE 9

9

  • Vibration based condition monitoring
  • Acoustic signature measurement & modelling
  • Wear debris analysis and HUMS
  • Systems acquisition and sustainment analysis

Asset management strategies & health management technologies

  • Fuel technology
  • Advanced Experimental Stress Techniques (TSA)
  • Diagnostic Systems for Airframe Structural Management
  • Aero-engine life prediction, risk and durability analyses

Aircraft Health & Sustainment

UNCLASSIFIED – Approved for public release

slide-10
SLIDE 10

10

  • Aircraft Forensic Engineering & Accident

Investigation

  • Additive metallic repair and

manufacturing technologies

Structural & Damage Mechanics, Composites, Metallics , Forensics

  • Crack growth modelling
  • Structural mechanics
  • Advanced composite systems
  • Composite sustainment support
  • Corrosion structural life modelling

Airframe Technology and Safety

UNCLASSIFIED – Approved for public release

slide-11
SLIDE 11

11

  • Fatigue Crack Analysis
  • Advanced Investigative Techniques

Aircraft Structural Integrity

  • Full Scale Fatigue Test Capability
  • Structural Life prediction capability
  • Airframe Life extension expertise

Aircraft Structures

UNCLASSIFIED – Approved for public release

slide-12
SLIDE 12

12

  • Research, Design, Build, Fly, Analyse
  • An aero-thermodynamic problem

Hypersonic Flight Research & Flight Test Trials

  • Hypersonic air-breathing combustion

for sustained controlled flight

  • Integration of complex systems
  • perating in extreme environments

Applied Hypersonics

UNCLASSIFIED – Approved for public release

slide-13
SLIDE 13

13

13

  • An Opportunity to Revolutionise Airframe Testing

Dr Albert Wong

  • DSTO Rework Shape Optimisation Technology

Dr Stephen Galea

  • Trusted Autonomous Systems

Dr Michael Skinner

  • Ultra High Temperature Materials

Dr Ross Antoniou UNCLASSIFIED – Approved for public release

Presentations to follow

slide-14
SLIDE 14

14

An Opportunity to Revolutionise Airframe Testing

Dr Albert K. Wong

Research Leader – Aircraft Structures

UNCLASSIFIED – Approved for public release

slide-15
SLIDE 15

15

Full Scale Fatigue Tests (FSFTs)

form the cornerstone of the certification process for any new aircraft type

Comet FSFT, Farnborough UK, 1954 Airbus A380 FSFT, Dresden, 2005-2009 F-35 FSFT, Ft Worth & Brough, 2010 - …

…at tremendous costs! Some major F-35 STOVL FSFT failures: 2010: bulkhead cracking @ ~1500 hrs (cf 16,000 hrs scheduled testing) 2011: wing root cracking @ ~2100 hrs 2013: bulkhead cracking @ ~9100 hrs UNCLASSIFIED – Approved for public release

slide-16
SLIDE 16

16

A Unique DSTO Technology…

that can change how FSFTs are conducted in the future viz., Thermoelastic Stress Analysis (TSA) using microbolometers

FLIR Lepton Size: 9mm x9mm x 6mm FPA: 80x60

Free trial microbolometer TSA (MiTE) software: http://www.dsto.defence.gov.au/mite/ Reference: http://onlinelibrary.wiley.com/doi/10.1111/str.12116/epdf POC: nik.rajic@dsto.defence.gov.au

UNCLASSIFIED – Approved for public release

slide-17
SLIDE 17

17

William Thomson Lord Kelvin (1824-1907)

s K T T    

  • 40
  • 30
  • 20
  • 10

10 20 30 40 1 2 3 4 5 time (sec) Stress (MPa)

  • 0.24
  • 0.18
  • 0.12
  • 0.06

0.06 0.12 0.18 0.24

Temp (C)

  • 40
  • 30
  • 20
  • 10

10 20 30 40 1 2 3 4 5 time (sec) Stress (MPa)

  • 0.24
  • 0.18
  • 0.12
  • 0.06

0.06 0.12 0.18 0.24

Temp (C)

The Thermoelastic Effect

UNCLASSIFIED – Approved for public release

slide-18
SLIDE 18

18

The Thermoelastic Effect

UNCLASSIFIED – Approved for public release

slide-19
SLIDE 19

19

The Thermoelastic Effect

UNCLASSIFIED – Approved for public release

slide-20
SLIDE 20

20

TSA used to validate stressing model

F/A-18 CB fatigue test region of interest computed stresses TSA scan close-up TSA scan

Applications to F/A-18 Centre Barrel Fatigue Test

UNCLASSIFIED – Approved for public release

slide-21
SLIDE 21

21

TSA Robot (TSAR) Demonstrator

Hardware:

  • 6DOF Robotic Arm
  • A35 IR microbolometer
  • digital camera for 3-D

reconstruction TSAR Mk I

  • Perform pervasive & persistent

surveillance of a large section of F/A-18 bulkhead FSFT UNCLASSIFIED – Approved for public release

slide-22
SLIDE 22

22

TSAR Preliminary Results

UNCLASSIFIED – Approved for public release

slide-23
SLIDE 23

23 FSFT Analyst inspects test via virtual environment TSARs provide pervasive & persistent surveillance of FSFT Virtual wireframe in Cloud rendered with TSA data

TSARs to Rule over Future FSFTs

UNCLASSIFIED – Approved for public release

slide-24
SLIDE 24

24

PARTNERS IN CRIME TO: 1. CO-DEVELOP Tsar Marcus 1st 2. Co-develop tsarS of the future

Reward

To effect transformational impact on future airframe certification tests

UNCLASSIFIED – Approved for public release

slide-25
SLIDE 25

25

UNCLASSIFIED – Approved for public release

Dr Stephen Galea

Acting Research Leader Airframe Technology and Safety Branch

Contact POC Manfred Heller, manfred.heller@dsto.defence.gov.au

Rework Shape Optimisation for Structural Life Extension

slide-26
SLIDE 26

26

Structural optimisation background

  • A design process to best distribute material

in a loaded structure

  • DSTO focus is on repair & life extension of

fatigue critical airframe components by stress minimisation

  • Aim is to improve aircraft availability and

reduce sustainment costs

  • Small shape changes can lead to significant

improvements in fatigue life

Critical regions High initial stresses

UNCLASSIFIED – Approved for public release

slide-27
SLIDE 27

27

Concept of optimised shape reworking

Improved rework shapes remove the damaged material and minimise stresses

Initial shape Traditional rework DSTO Improved rework

(limited benefit) (lower stress) (lowest stress)

Crack

UNCLASSIFIED – Approved for public release

slide-28
SLIDE 28

28

Features of the DSTO approach

Modelling

  • Aim is constant local stress via material

removal

  • In house software & commercial Finite

Element Analysis codes

  • Iterative method based on biological

growth

  • Can handle manufacturing constraints and

load orientation variability Manufacturing

  • Accurate in-situ methods developed – 2.5D

UNCLASSIFIED – Approved for public release

slide-29
SLIDE 29

29

Optimised holes

  • Aim was to achieve Planned

Withdrawal Date & extend inspection intervals

  • 25 - 50% stress reduction
  • Implemented on 6 aircraft
  • 16 locations per aircraft

Example: F-111 wing pivot fitting application

Optimised stiffener run-out

UNCLASSIFIED – Approved for public release

Stiffener run-outs and fuel flow vent holes

slide-30
SLIDE 30

30

Example: F/A-18 A/B

  • Cracking at housing guide rails
  • 33 % stress reduction
  • Portable rework jig developed
  • Successful flight trials completed
  • Fleet wide implementation pending

Fwd Outboard

Forward hanger

ASRAAM Cracking

Guide rail

FWD hanger

LAU-7

Nominal Reworked

UNCLASSIFIED – Approved for public release

LAU-7 missile launcher optimal rework

slide-31
SLIDE 31

31

Example: F/A-18 A/B

  • Cracking at grounding holes
  • Family of enlarged rework shapes
  • 18% stress reduction
  • Portable rework jig developed
  • Fleet wide implementation expected

After reworking Before rework

UNCLASSIFIED – Approved for public release

Front spar grounding hole rework optimisation

slide-32
SLIDE 32

32

  • Potential to transition technology more

widely

– Airframes – Other vehicles

  • Potential collaboration to further develop the

current capabilities to full 3D

– Modelling – Machining via compact robotics

Partnering opportunities

UNCLASSIFIED – Approved for public release

slide-33
SLIDE 33

33

Trusted Autonomous Systems

Dr Michael Skinner

Autonomy Team Leader Aerospace Systems Effectiveness Human Machine Teaming

UNCLASSIFIED – Approved for public release

slide-34
SLIDE 34

34

  • Automation versus Autonomy
  • What will Trusted Autonomous Systems Deliver?

Intelligent machines seamlessly integrated with humans – Maximising mission performance in complex and contested environments (AFRL Autonomy S&T Strategy)

What are Trusted Autonomous Systems?

Human Machine Teaming

UNCLASSIFIED – Approved for public release

slide-35
SLIDE 35

35

Philosophical and mathematical basis; Significantly reduce exposure to harmful consequences; Guaranteed to not exceed boundary conditions; new means to certify for ADF use. Exploit existing and develop new: sensors, platforms, materials & propulsion; Sound validation and test with increasing accuracy of uncertainty (simulation to field); Innovations with high technical risk, but low strategic program risk. Fast reactive and simultaneous slow logical “thinking”; Machine high-level fusion, planning and intent subject to uncertainty; Large scale control of machines; Machine-machine interaction and tasking.

Foundations of Autonomy

Interacting hybrid teams more effective than human-only teams; Understand organisation changes required to acquire and operate; Trust of machines; Mission Command of machines.

Platforms, Sensors & Effectors Trustworthy Partners Cognitive Machines

TAS Strategic Research Initiative: Research Themes

UNCLASSIFIED – Approved for public release

slide-36
SLIDE 36

36

Alternative Navigation for UAS

Uninhabited Aerial Systems

Bio-inspired micro-UAS Hybrid Propulsion and Power Management Autonomous UAS Platform Management

Key enabling challenges for trusted autonomy in aerial systems

UNCLASSIFIED – Approved for public release

slide-37
SLIDE 37

37

Tactical Urban Operations for Micro-UAS

  • Challenges of the urban environment
  • Current system limitations

Uninhabited Aerial Systems

http://www.darpa.mil/uploadedImages/Content/NewsEvents/Releases/2014/FLAMissionGraphicMedium.jpg http://en.wikipedia.org/wiki/List_of_slums#mediaviewer/File:Petare_Slums_in_Caracas.jpg

UNCLASSIFIED – Approved for public release

slide-38
SLIDE 38

38

  • Research themes

– Integration of Human and autonomous systems – Advanced interfaces for Adaptive Supervisory Control – Artificial Intelligence approaches to optimised human-machine teaming

Human Machine Teaming

UNCLASSIFIED – Approved for public release

slide-39
SLIDE 39

39

Partnering Opportunities

  • Uninhabited Aerial Systems
  • Human Machine Teaming
  • Trusted Autonomous Systems

Strategic Research Initiative

UNCLASSIFIED – Approved for public release

slide-40
SLIDE 40

40

POC Chris A. Wood

Ultra-High Temperature Ceramic (UHTC) Materials Development Program for Hypersonic Applications

Dr Ross A. Antoniou

Acting Research Leader-Aircraft Health and Sustainment UNCLASSIFIED – Approved for public release

slide-41
SLIDE 41

41

Motivation

  • The next step beyond ‘heat-sink’ experimental vehicles
  • Develop materials suitable for leading edges of experimental hypersonic air vehicles
  • Geometric stability essential over flight duration
  • Explore use of these materials in other applications

Sustained Hypersonic Flight

Velocities >Mach 6+ Heat flux at leading edges >4 MW/m2 Thermal equilibrium! UNCLASSIFIED – Approved for public release

slide-42
SLIDE 42

42

The Development Program (1)

  • Research candidate materials;

– Refractory metals, carbon composites, UHTCs considered – UHTCs identified as the most viable way ahead

– High temperature properties – Ability to fabricate – Cost

  • Develop UHTC compositions and fabricate test specimens

– Focus on carbide and boride-based compositions – HfB2, ZrB2, HfC, etc. – Hot-pressing and spark plasma sintering (SPS) processing routes UNCLASSIFIED – Approved for public release

slide-43
SLIDE 43

43

The Development Program (2)

  • Microstructural characterisation of densified UHTC specimens

– Assessment of microstructure, phases, porosity

  • Thermal testing of UHTC specimens

– High-temperature exposure of leading edge geometries

  • Microstructural characterisation of heat-exposed UHTC test

specimens

– Material changes – Oxide layers – Oxide adherence UNCLASSIFIED – Approved for public release

slide-44
SLIDE 44

44

Development of UHTCs

60.0 70.0 80.0 90.0 100.0 110.0 Density (%)

Densification of test specimens

  • Hot pressing
  • 1900oC, 25 MPa

UNCLASSIFIED – Approved for public release

slide-45
SLIDE 45

45

Development of UHTCs

Microstructures

  • Single and multi-phase microstructures
  • Carbides, Diborides, Oxides, Nitrides, Silicides
  • 1900oC, 25 MPa

50 mm 10 mm 100 mm 10 mm

HfC-based material HfB2-based material

UNCLASSIFIED – Approved for public release

slide-46
SLIDE 46

46

Introducing HoMER - High-temperature Materials Evaluation Rig

  • Oxygen-acetylene flame; Flame temp >3300oC; Heat flux >8 MWm-2
  • Programmable X-Y stage; H.T. pyrometer; video acquisition

Test specimen

Thermal test specimen geometry – 20 degree wedge

UNCLASSIFIED – Approved for public release

slide-47
SLIDE 47

47

Post-Test Results (1)

  • Good performance, above.

Sharp leading edge geometry maintained after 3 minutes.

  • Poor performance, right.

Low melting point phase causes rapid LE recession.

UNCLASSIFIED – Approved for public release

slide-48
SLIDE 48

48

Post-Test Results (2)

Cross-sections show leading edge geometry, oxidation products and material changes after high-temperature exposure.

Specimen 4 Specimen 30

Oxide Heat-Affected Material Original Material Original Material Oxide Heat-Affected Material Heat-Affected Material Original Material Oxide Heat-Affected Material Original Material Oxide

1 minute 3 minutes

UNCLASSIFIED – Approved for public release

slide-49
SLIDE 49

49

Where to next…

  • Benchmark tests against refractory metals
  • Explore different processing routes

– Pressure vs. Pressureless processing – Contrast dry vs. Colloidal processing

  • Composition refinement of best performing materials
  • Fabrication of full-scale leading edge geometries

– Traditional and EDM Machining (potential for collaboration) – Near Net Shape Formation

  • Thermal Testing of full-scale leading edge geometries

– HoMER – Arc-jet

UNCLASSIFIED – Approved for public release

slide-50
SLIDE 50

50

Aerospace Division

UNCLASSIFIED – Approved for public release
