Advanced Java Class

Web Applications – Part 1 (Servlets)

Named vs. Anonymous Servlets

• Anonymous Syntax:

http://hostname/MyApp/servlet/myapp.servlets.MyServlet

• Named Syntax: http://hostname/MyApp/Myservlet

in web.xml: <servlet> <servlet-name>MyServlet</servlet-name> <servlet-class>myapp.servlets.MyServlet</servlet-class> </servlet> < servlet-mapping> <servlet-name>MyServlet</servlet-name> <url-pattern>/MyServlet</url-pattern> </servlet-mapping>

• advantages of named: user friendly, more secure

Servlet API

• HttpServlet

– Your Servlets must extend this class

• HttpServletRequest

– Interface type of object sent to Servlet

• HttpSession

– Useful for storing user session data

• HttpServletResponse

– Interface type of object sent to Servlet

HttpServlet

• doGet(HttpServletRequest req,

HttpServletResponse resp)

– [send page to user]

• doPost(HttpServletRequest req,

HttpServletResponse resp)

– [process user input]

HttpServletRequest

• HttpSession getSession()
• String getParameter(String name)
• java.util.Map getParameterMap()
• Object getAttribute(String name)
• void setAttribute(String name)

HttpSession

• Object getAttribute(String name)
• setAttribute(String name, Object value)

Processing HTML Forms

• in HTML page

– < form method=post action="/SkiClub/LoginServlet"> – < input type="text" name="LNAME" value="">

• in Servlet

– doPost method implemented – Call getParameter("LNAME") to find what they want to login as

HTTP Response options

• write HTML as text into the Output

Stream

• forward request to another resource in

web app: HTML, JSP, Servlet, etc.

• Redirect request to any web resource
• Return an error

HttpServletResponse

• ServletOutputStream getOutputStream();
• RequestDispatcher rd =

request.getRequestDispatcher(“[resource we’re forwarding request to]”); rd.forward(request, response);

• void sendRedirect(String location);
• void sendError(int sc, String msg);

Servlet filtering

• Encryption
• to use : implement Filter interface, and

write doFilter method, initialize with FilterConfig

• Can make subclasses of HttpRequest

& HttpResponse for special behavior

Web App Continuity

• Problem:

Http protocol is inherently stateless, but often a web app requires a "conversation", which has state.

• Solutions:

– Storing Data on Server side

• Request
• Session
• Application
• DB

– Storing Data on Client side

• Cookies
• URL Rewriting
• Hidden form fields

Storing Data on Server side; available scopes

• Request scope [HttpRequest]

– good for a forward to a JSP page or another servlet

• Session scope [HttpSession]

– good for session-long variables, like 'username‘

• Application scope - getServletContext()

– global for all servlets & clients

• DB scope

– permanent

Storing Data in HttpSessions

• Attributes may be stored in sessions - so long as they

are serializable.

• There should be one session per client browser

session.

• Sessions reside on the server. They are not passed to

the client.

– Instead, a cookie stored on the client machine tells the server which session belongs to which client browser.

• Knowing when to end a session is tricky, but usually

you want them to time out after a period of inactivity. You want the session to remain active as long as the user is "using" the site.

Storing Data on Client side

• Cookies (permanent, but may be

disabled)

• URL rewriting (use if cookies are

disabled)

• Hidden form fields (temporary)

Cookies

• Name-value string pairs
• Last beyond one session
• Stored on the client side, tagged with IP

address that they came from.

• When client sends request, it includes all the

cookies from the IP that it's contacting.

• HttpServletResponse.addCookie(String name,

String value);

• Cookie[] HttpServletRequest.getCookies();
• No security involved! Be careful.

URL Rewriting

• What if cookies are disabled on the client

machine?

• These methods put the cookie info into the

URL if cookies are disabled.

– String HttpServletResponse.encodeURL(String url) – String HttpServletResponse.encodeRedirectURL(String url)

• Encoded with an easy to decrypt algorithm - still

not secure.

Hidden form fields

• HTML Syntax:

– <input type="hidden" name="formID" value=TA45"/>

• Not user modifiable
• Not secure - visible in view source
• Client side storage area to pass data to

servlet

Digital Flashcards Example Activity

• 1. What is the highest scope at which each

the following values should be stored?

– username of currently logged in user – Quiz word for the next page – list of valid user names and passwords – Number of words correct in current quiz – History of correctness for this word
