Introducing our Blue Line Backlit Panels with Advance CertaDrive X Series LED Drivers! June 25 th , 2020 Zach Eagleton & Oscar Velderrain Signify Classified - Internal Todays Agenda Blue Line LED Backlit Flat Panels Key Benefits

slide-1
SLIDE 1

Introducing our Blue Line Backlit Panels with Advance CertaDrive X Series LED Drivers!

June 25th, 2020

Zach Eagleton & Oscar Velderrain

slide-2
SLIDE 2

Signify Classified - Internal

▪ Blue Line LED Backlit Flat Panels

▪ Key Benefits ▪ Key Features

▪ Advance CertaDrive X Series LED Drivers

▪ Key Applications ▪ Key Benefits

Today’s Agenda

2

slide-3
SLIDE 3

Signify Classified - Internal

Blue Line LED Backlit Flat Panel Key Benefits

3

▪ DLC v 5.0 compliant ▪ Premium: (130 LPW) and Standard (110 LPW) efficiency ▪ >60,000 hours L70 ▪ 3500, 4000 CCT available (3/5K on module only) ▪ CRI80 , 4 SDCM ▪ Uniform illumination from Panel Lens ▪ Signify Qualified LED ▪ DLC multiple Listing available ▪ Advance CertaDrive X Series family of drivers ▪ 50,000 hrs. lifetime ▪ Supports UL Class P, NEMA77 and T24 compliance ▪ 0-10V dimming to 10% ▪ 2x4, 2x2, 1x4 options available ▪ Complete luminaires and separate modules available ▪ Modules compatible with wide range of Advance Linear drivers ▪ Single pack on luminaire level, 4-pack on the panel modules ▪ 5 year Signify limited warranty

slide-4
SLIDE 4

Signify Classified - Internal

  • High efficiency Advance CertaDrive X LED driver: 120-277V, 60/50Hz, (PF > 0.9), THD < 20%, 0-10V

10% dimming

  • Low profile backlit panel design
  • Uniform distribution of light on Lens minimizing glare in from the ceiling plane
  • Designed for use with standard Grid (NEMA “G”) or Narrow Grid (NEMA “NFG”) ceiling T-bars.
  • Extruded aluminum frame post painted with gloss white enamel finish. Corners are precision welded

for seamless aesthetic.

  • Integral T-bar clips for recessed applicated

4

Blue Line LED Backlit Flat Panel Key Features (Slide 1 of 2)

slide-5
SLIDE 5

Signify Classified - Internal

▪ One luminaire per white “pizza-box” for ease of inventory/stocking/shipping ▪ EMI compliant to FCC Title 47 Part 15 Class A ▪

  • Flicker and stroboscopic effect compliant to NEMA 77-2017

▪

  • TM-21 predicted L70 maintenance > 60,000 hours per LM80 reports, 4 SDCM color consistency

▪

  • cULus listed, suitable for dry and damp locations

▪

  • Ambient temperature rated from -10° C to 40° C , IC rated

5

Blue Line LED Backlit Flat Panel Key Features (Slide 2 of 2)

slide-6
SLIDE 6

Signify Classified - Internal

6

Blue Line LED Backlit Flat Panel

Catalog Code Description Type DLC Size Lumens Power LPW CCT/CRI Input Voltage Dimming Boxing Qty per Box Qty per Pallet Qty per Container

929002705013 BLFP2230L835UNVS Full Fixture Standard 2x2 3000 27 111 835 120-277 0-10V 10% Single Pizza Box 1 78 1482 929002705113 BLFP2230L840UNVS Full Fixture Standard 2x2 3000 27 111 840 120-277 0-10V 10% Single Pizza Box 1 78 1482 929002705213 BLFP2240L835UNVS Full Fixture Standard 2x2 4000 36 111 835 120-277 0-10V 10% Single Pizza Box 1 78 1482 929002705313 BLFP2240L840UNVS Full Fixture Standard 2x2 4000 36 111 840 120-277 0-10V 10% Single Pizza Box 1 78 1482 929002705413 BLFP2440L835UNVS Full Fixture Standard 2x4 4000 36 111 835 120-277 0-10V 10% Single Pizza Box 1 42 798 929002705513 BLFP2440L840UNVS Full Fixture Standard 2x4 4000 36 111 840 120-277 0-10V 10% Single Pizza Box 1 42 798 929002705613 BLFP2453L835UNVS Full Fixture Standard 2x4 5300 48 110 835 120-277 0-10V 10% Single Pizza Box 1 42 798 929002705713 BLFP2453L840UNVS Full Fixture Standard 2x4 5300 48 110 840 120-277 0-10V 10% Single Pizza Box 1 42 798 929002705813 BLFPHE1432L835UNVS Full Fixture Premium 1x4 3200 24 133 835 120-277 0-10V 10% Single Pizza Box 1 98 1862 929002705913 BLFPHE1432L840UNVS Full Fixture Premium 1x4 3200 24 133 840 120-277 0-10V 10% Single Pizza Box 1 98 1862 929002706013 BLFPHE2232L835UNVS Full Fixture Premium 2x2 3200 24 133 835 120-277 0-10V 10% Single Pizza Box 1 78 1482 929002706113 BLFPHE2232L840UNVS Full Fixture Premium 2x2 3200 24 133 840 120-277 0-10V 10% Single Pizza Box 1 78 1482 929002706213 BLFPHE2440L835UNVS Full Fixture Premium 2x4 4000 28 143 835 120-277 0-10V 10% Single Pizza Box 1 42 798

slide-7
SLIDE 7

Signify Classified - Internal

7

Fortimo HEBL High Efficiency LED Backlit Panel

929002706413 Fortimo HEBL LED Panel 14 830 G1 Panel

  • nly

1x4 3000 21 142 830 33 4 per box 4 96 1824 929002706513 Fortimo HEBL LED Panel 14 835 G1 Panel

  • nly

1x4 3200 21 152 835 33 4 per box 4 96 1824 929002706613 Fortimo HEBL LED Panel 14 840 G1 Panel

  • nly

1x4 3200 21 152 840 33 4 per box 4 96 1824 929002706713 Fortimo HEBL LED Panel 14 850 G1 Panel

  • nly

1x4 3200 21 152 850 33 4 per box 4 96 1824 929002706813 Fortimo HEBL LED Panel 22 830 G1 Panel

  • nly

2x2 3000 21 142 830 33 4 per box 4 72 1368 929002706913 Fortimo HEBL LED Panel 22 835 G1 Panel

  • nly

2x2 3200 21 152 835 33 4 per box 4 72 1368 929002707013 Fortimo HEBL LED Panel 22 840 G1 Panel

  • nly

2x2 3200 21 152 840 33 4 per box 4 72 1368 929002707113 Fortimo HEBL LED Panel 22 850 G1 Panel

  • nly

2x2 3200 21 152 850 33 4 per box 4 72 1368 929002707213 Fortimo HEBL LED Panel 24 830 G1 Panel

  • nly

2x4 3800 24 156 830 38 4 per box 4 48 912 929002707313 Fortimo HEBL LED Panel 24 835 G1 Panel

  • nly

2x4 4000 24 164 835 38 4 per box 4 48 912 929002707413 Fortimo HEBL LED Panel 24 840 G1 Panel

  • nly

2x4 4000 24 164 840 38 4 per box 4 48 912 929002707513 Fortimo HEBL LED Panel 24 850 G1 Panel

  • nly

2x4 4000 24 164 850 38 4 per box 4 48 912

Catalog Code Description Type DLC Size Lumens Power LPW CCT/CRI Input Voltage Dimming Boxing Qty per Box Qty per Pallet Qty per Container

slide-8
SLIDE 8

Signify Classified - Internal

Fixture Label Module Label

8

slide-9
SLIDE 9

Signify Classified - Internal

9

Fixture Box Dimensions Module Box Dimensions

Length Width Height 1x4 1252mm 330mm 70mm 2x2 642mm 630mm 70mm 2x4 1252mm 630mm 70mm Length Width Height 1x4 1270mm 225mm 360mm 2x2 660mm 225mm 660mm 2x4 1270mm 225mm 660mm

slide-10
SLIDE 10

Simple Solutions for Basic Lighting Advance CertaDrive X Series LED Drivers

Oscar Velderrain

slide-11
SLIDE 11

Signify Classified - Internal

11

Overview Advance CertaDrive X Series LED Drivers

▪ Advance CertaDrive X Series LED drivers cover all lumen package fixture needs for any basic commercial troffer, panel, strip, wrap, etc. with 0-10V dimming down to 10% while providing superior quality and performance associated with the Advance brand. ▪ Ten models, in a T280 housing, are available now, ranging from 14W to 55W. ▪ An 11th 65W model, in a T360 housing, will be available later in Q2 2020.

Part Number Housing Lout (mA) Pout max (W) CI014C030V048CDX1 T280 250/300 14 CI018C038V048CDX1 T280 350/380 18 CI025C051V048CDX1 T280 485/515 25 CI026C055V048CDX1 T280 500/550 26 CI031C064V048CDX1 T280 625/640 31 CI034C070V048CDX1 T280 675/700 34 CI041C085V048CDX1 T280 800/850 41 CI045C093V048CDX1 T280 900/935 45 CI049C102V048CDX1 T280 950/1025 49 CI055C115V048CDX1 T280 1035/1150 55 CI065C135V048CDX1 T360 1225/1350 65

slide-12
SLIDE 12

Signify Classified - Internal

Key Applications

12

▪ Low profile (21 mm) design ideal for backlit panel, LED troffer, strip or wrap around fixtures. ▪ Suitable for basic general and commercial indoor lighting, including, but not limited to: ▪ Indoor linear troffers, pendants ▪ Office spaces/areas ▪ Retail centers/stores ▪ Educational facilities ▪ Healthcare locations

slide-13
SLIDE 13

Signify Classified - Internal

13

Key Benefits

▪ Low Profile Design (21mm) ▪ Availability from 14 – 65W with various output current options ▪ High efficiency meets DLC Standard and Premium ▪ Direct replacement for T280/T360 mm length linear drivers ▪ Excellent thermal performance (Max. temp. case = 80°C) ▪ Made in Mexico ▪ 50,000 hours lifetime @ 65°C ▪ NEMA77 and T24 compliance ▪ Optimized for specific voltage-current combinations ▪ Improved output current ripple ▪ 10% minimum dimming

slide-14
SLIDE 14

Signify Classified - Internal

14

Advance CertaDrive X Series LED Drivers Easy to use

  • Direct replacement for CertaDrive linear

drivers and other T280/T360 linear drivers

  • Class P
  • Selectable output current via dip switch

Reliability Value adding Features

  • T280/T360 low profile formfactor, 21mm
  • 0-10V dimming down to 10%
  • CSA, ETL and UL Class P
  • High power factor and low total harmonic

distortion

  • 50,000-hour lifetime1 at 65°C case

temperature

  • Excellent thermal performance
  • 5-year Signify limited warranty2
  • 1. Advance CertaDrive X Series LED drivers are manufactured to engineering standards correlating to a designed and average life expectancy
  • f 50,000 hours of operation at maximum rated case temperature. Minimum 90% survivals based on MTTF modeling.
  • 2. For up to date warranty information please go to https://www.signify.com/en-us/support/warranties
slide-15
SLIDE 15

Signify Classified - Internal

15

Upgraded Features from CertaDrive

▪ Beginning Q3 2020, the original CertaDrive will begin to phaseout, with the new CertaDrive X being a drop-in replacement. ▪ Key Upgraded Features: ▪ Improved formfactor designed to fit all modern LED panels ▪ Greater ease of installation with pushpin wire holes ▪ Output current selectable via dip switch

slide-16
SLIDE 16

Signify Classified - Internal

Questions?

16

slide-17
SLIDE 17

Signify Classified - Internal

Thank you for your time

17
