Adding Monotonic Counters to Automata and Transition Graphs

Wong Karianto

karianto@informatik.rwth-aachen.de

Lehrstuhl f¨ ur Informatik VII

SLIDE 2

Motivations: Parikh Automata (Klaedtke & Rueß, ICALP 2003)

Idea: how to recognize a language with arithmetical properties, such as Labc := {akbkck | k ≥ 1}?

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 2

SLIDE 3

Motivations: Parikh Automata (Klaedtke & Rueß, ICALP 2003)

Idea: how to recognize a language with arithmetical properties, such as Labc := {akbkck | k ≥ 1}? Use a finite automaton recognizing a+b+c+. Assign a vector to each input symbol. Put a Presburger constraint on the summed vector (x, y, z): x = y = z.

(c, (0, 0, 1)) (b, (0, 1, 0)) (a, (1, 0, 0)) (a, (1, 0, 0)) (b, (0, 1, 0)) (c, (0, 0, 1))

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 2

SLIDE 4

Outline

1. Parikh automata

Semi-linear sets and Parikh’s theorem Parikh automata and the Chomsky hierarchy

2. Monotonic-counter extensions of (infinite) graphs

Some classes of infinite graphs Monotonic-counter extensions

3. Reachability problem

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 3

SLIDE 5

Part 1 Parikh Automata

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 4

SLIDE 6

Semi-Linear Sets and Parikh’s Theorem

A ⊆ Nn linear: A = {¯ x0 + k1¯ x1 + . . . + km¯ xm | k1, . . . , km ∈ N} for some ¯ x0, ¯ x1, . . . , ¯ xm ∈ Nn Semi-linear set: finite union of linear sets. Example: B := {(x1, x2, x3) ∈ N3 | x1 < x2 < x3} is linear: {(0, 1, 2) + k1(0, 0, 1) + k2(0, 1, 1) + k3(1, 1, 1) | k1, k2, k3 ∈ N} .

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 5

SLIDE 7

Semi-Linear Sets and Parikh’s Theorem

A ⊆ Nn linear: A = {¯ x0 + k1¯ x1 + . . . + km¯ xm | k1, . . . , km ∈ N} for some ¯ x0, ¯ x1, . . . , ¯ xm ∈ Nn Semi-linear set: finite union of linear sets. Example: B := {(x1, x2, x3) ∈ N3 | x1 < x2 < x3} is linear: {(0, 1, 2) + k1(0, 0, 1) + k2(0, 1, 1) + k3(1, 1, 1) | k1, k2, k3 ∈ N} . Properties of semi-linear sets: effective closure under Boolean operations [Ginsburg & Spanier] equivalence to Presburger-definable sets [Ginsburg & Spanier]

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 5

SLIDE 8

Semi-Linear Sets and Parikh’s Theorem

A ⊆ Nn linear: A = {¯ x0 + k1¯ x1 + . . . + km¯ xm | k1, . . . , km ∈ N} for some ¯ x0, ¯ x1, . . . , ¯ xm ∈ Nn Semi-linear set: finite union of linear sets. Example: B := {(x1, x2, x3) ∈ N3 | x1 < x2 < x3} is linear: {(0, 1, 2) + k1(0, 0, 1) + k2(0, 1, 1) + k3(1, 1, 1) | k1, k2, k3 ∈ N} . Properties of semi-linear sets: effective closure under Boolean operations [Ginsburg & Spanier] equivalence to Presburger-definable sets [Ginsburg & Spanier] Parikh’s theorem: The Parikh image of any context-free language is effectively semi-linear.

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 5

SLIDE 9

Parikh Automata

(c, (0, 0, 1)) (b, (0, 1, 0)) (a, (1, 0, 0)) (a, (1, 0, 0)) (b, (0, 1, 0)) (c, (0, 0, 1))

Parikh finite automaton (Parikh-FA) (A, C) of dimension n ≥ 1 over Σ: finite automaton A over Σ × D (D ⊆ Nn finite, nonempty) semi-linear set C ⊆ Nn

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 6

SLIDE 10

Parikh Automata

(c, (0, 0, 1)) (b, (0, 1, 0)) (a, (1, 0, 0)) (a, (1, 0, 0)) (b, (0, 1, 0)) (c, (0, 0, 1))

Parikh finite automaton (Parikh-FA) (A, C) of dimension n ≥ 1 over Σ: finite automaton A over Σ × D (D ⊆ Nn finite, nonempty) semi-linear set C ⊆ Nn Word u := a1 · · · am is accepted iff v := (a1, ¯ d1) · · · (am, ¯ dm) ∈ L(A) exists, for some ¯ d1, . . . , ¯ dm ∈ D, and Φ(v) := ¯ d1 + · · · + ¯ dm ∈ C.

❆ ❆ ❑

extended Parikh mapping Φ: (Σ × D)∗ → Nn

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 6

SLIDE 11

Emptiness Problem

Lemma (Klaedtke & Rueß): If the Parikh image of L ⊆ (Σ × D)∗ is effectively semi-linear, then also its extended Parikh image Φ(L). Theorem (Klaedtke & Rueß): The emptiness problem for Parikh-FA’s is decidable. Proof idea. L(A, C) = ∅ iff Φ(L(A)) ∩ C = ∅

– Both sets are semi-linear.

– Intersection of semi-linear sets is effectively semi-linear. = ⇒ (Non-)Emptiness is decidable.

RWTH Aachen – Wong Karianto

Adding Monotonic Counters to Automata and Transition Graphs – p. 7

SLIDE 12

Parikh Automata and the Chomsky Hierarchy

Automata of the Chomsky hierarchy as the automaton component A:

finite automata pushdown automata linear-bounded automata Turing machines Parikh-TM

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 8

SLIDE 13

Parikh Automata and the Chomsky Hierarchy

Automata of the Chomsky hierarchy as the automaton component A:

finite automata pushdown automata linear-bounded automata Turing machines Parikh-FA Parikh-PDA Parikh-LBA Parikh-TM

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 8

SLIDE 14

Parikh Automata and the Chomsky Hierarchy

Automata of the Chomsky hierarchy as the automaton component A:

finite automata pushdown automata linear-bounded automata Turing machines Parikh-FA Parikh-PDA Parikh-LBA Parikh-TM (1) (1) (2) (3)

1. {akbkck | k ≥ 1}
2. {wwR | w ∈ {a, b}∗}
3. semi-linearity
f

Parikh-PDA recognizable languages

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 8

SLIDE 15

Part 2 Monotonic-Counter Extensions of (Infinite) Graphs

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 9

SLIDE 16

Monotonic-Counter Graphs

Σ-labeled graph G := (V, (Ea)a∈Σ)

a · · · · · · · · · · · ·

b

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 10

SLIDE 17

Monotonic-Counter Graphs

(Σ × D)-labeled graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

(a, (1, 0)) (b, (0, 1))

a · · · · · · · · · · · ·

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 10

SLIDE 18

Monotonic-Counter Graphs

(Σ × D)-labeled graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

Monotonic-counter extension of G:

Σ-labeled graph G := ( V , ( Ea)a∈Σ) with

V := V × Nn and ((α, ¯

x), (β, ¯ y)) ∈ Ea iff (α, β) ∈ E(a, ¯

d) and

¯ y = ¯ x + ¯ d, for some ¯ d ∈ D.

(a, (1, 0)) (b, (0, 1))

a (0, 0) (1, 0) a a (0, 1) (1, 1) a b b b b (2, 0) a (2, 1) b b a a (0, 2) (1, 2) a b b (2, 2) a b · · · · · · · · · · · · · · · · · ·

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 10

SLIDE 19

Some Classes of Infinite Graphs with Finite Representations

Vertices: regular sets over alphabet Γ Edges: automaton-definable relations over words, e.g.: pushdown graphs [Muller & Schupp]: transitions of ε-free pushdown automata prefix-recognizable graphs [Caucal]: generalized prefix rewriting rules synchronized rational graphs or automatic graphs [Frougny & Sakarovitch, Blumensath & Gr¨ adel]: synchronized rational relations rational graphs [Morvan]: rational relations

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 11

SLIDE 20

Hierarchy of Graph Classes

prefix-recognizable graphs synchronized rational graphs rational graphs finite graphs pushdown graphs

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 12

SLIDE 21

Hierarchy of Graph Classes

prefix-recognizable graphs synchronized rational graphs rational graphs PR-MC R-MC finite graphs pushdown graphs PD-MC F-MC SR-MC

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 12

SLIDE 22

Hierarchy of Graph Classes

prefix-recognizable graphs synchronized rational graphs rational graphs PR-MC R-MC (2) (4) finite graphs pushdown graphs PD-MC F-MC SR-MC (1) (1) (1) (3)

1. infinite two-dimensional grid
2. decidability of the reachability

problem

3. graphs with vertices of

unbounded degree

4. graphs with repetition-free

cycles of unbounded length

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 12

SLIDE 23

Synchronized Rational Graphs

Vertices: regular set V over alphabet Γ Edges: synchronized rational relations, i.e. edge relation Ea is recognized by a finite-state automaton working on pairs (X1 · · · Xm, Y1 · · · Yn) ∈ Γ∗ × Γ∗ with two one-way input tapes and simultaneously moving input heads.

X1 X2 X3 · · · Xm ⋄ · · · ⋄ · · · · · · Y1 Y2 Y3 Ym+1 Ym Yn new symbol finite memory

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 13

SLIDE 24

Synchronized Rational Graphs: Example

ε b X Y a XX b c XY Y Y b Y Y Y XXX b XXY b XY Y b · · · · · · · · · · · · c c a a

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 14

SLIDE 25

Monotonic-Counter Extensions of Synchronized Rational Graphs

(Σ × D)-labeled synchronized rational graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 15

SLIDE 26

Monotonic-Counter Extensions of Synchronized Rational Graphs

(Σ × D)-labeled synchronized rational graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

Σ-labeled SRMC graph
G := (

V , ( Ea)a∈Σ) with V := V × Nn and ((α, ¯ x), (β, ¯ y)) ∈ Ea iff (α, β) ∈ E(a, ¯

d) and

¯ y = ¯ x + ¯ d, for some ¯ d ∈ D.

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 15

SLIDE 27

Monotonic-Counter Extensions of Synchronized Rational Graphs

(Σ × D)-labeled synchronized rational graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

Σ-labeled SRMC graph
G := (

V , ( Ea)a∈Σ) with V := V × Nn and ((α, ¯ x), (β, ¯ y)) ∈ Ea iff (α, β) ∈ E(a, ¯

d) and

¯ y = ¯ x + ¯ d, for some ¯ d ∈ D. Proposition: G is synchronized rational. Proof sketch. Encode vertex (α, (x1, . . . , xn)) of G by means of word #1 · · · #1

· · · #n · · · #n

α Define automaton for Ea working on pairs (#x1

1 · · · #xn n α, #y1 1 · · · #yn n β):

1. Guess a vector ¯

d ∈ D and check whether ¯ x + ¯ d = ¯ y.

2. Simulate the automaton for E(a, ¯

d) on (α, β).

Bounded delay sufficient since D and Γ are finite.

RWTH Aachen – Wong Karianto

Adding Monotonic Counters to Automata and Transition Graphs – p. 15

SLIDE 28

Part 3 Reachability Problem

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 16

SLIDE 29

Logical Decision Problems over Transition Graphs

Reachability: Given a graph G and two vertices α and β in G, is β reachable from α? First-order (FO) theory: Given a graph G and a first-order sentence ϕ, does ϕ hold in G? Monadic second-order (MSO) theory: Given a graph G and a monadic second-order sentence ϕ, does ϕ hold in G?

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 17

SLIDE 30

Logical Decision Problems over Transition Graphs

prefix-recognizable graphs PR-MC finite graphs pushdown graphs PD-MC F-MC synchronized rational graphs rational graphs undecidable decidable FO theory

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 17

SLIDE 31

Logical Decision Problems over Transition Graphs

prefix-recognizable graphs PR-MC finite graphs pushdown graphs PD-MC F-MC synchronized rational graphs rational graphs undecidable decidable MSO theory undecidable decidable FO theory

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 17

SLIDE 32

Logical Decision Problems over Transition Graphs

prefix-recognizable graphs PR-MC finite graphs pushdown graphs PD-MC F-MC synchronized rational graphs rational graphs undecidable decidable MSO theory undecidable decidable FO theory undecidable decidable reachability

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 17

SLIDE 33

Prefix-Recognizable Graphs

Σ := {a, b} Γ := {Z}

✁ ✁ ☛

rule U

a

− → V with U, V ⊆ Γ∗ regular Prefix-rewriting system R := { ε a − → Z , ε b − → Z+ } Prefix-recognizable graph G = (V, Ea, Eb) defined by R: V = Γ∗, Ea = {(Zi, Zi+1) | i ∈ N}, and Eb = {(Zi, Zj) | i, j ∈ N and i < j}.

Z2 a a Z3 a a b b b ε Z b · · · · · · · · ·

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 18

SLIDE 34

Monotonic-Counter Extensions of Prefix-Recognizable Graphs

(Σ × D)-labeled prefix-recognizable graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 19

SLIDE 35

Monotonic-Counter Extensions of Prefix-Recognizable Graphs

(Σ × D)-labeled prefix-recognizable graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

Σ-labeled PRMC graph
G := (

V , ( Ea)a∈Σ) with V := V × Nn and ((α, ¯ x), (β, ¯ y)) ∈ Ea iff (α, β) ∈ E(a, ¯

d) and

¯ y = ¯ x + ¯ d, for some ¯ d ∈ D.

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 19

SLIDE 36

Monotonic-Counter Extensions of Prefix-Recognizable Graphs

(Σ × D)-labeled prefix-recognizable graph G := (V, (E(a, ¯

d))(a, ¯ d)∈Σ×D)

(D ⊆ Nn finite, nonempty)

Σ-labeled PRMC graph
G := (

V , ( Ea)a∈Σ) with V := V × Nn and ((α, ¯ x), (β, ¯ y)) ∈ Ea iff (α, β) ∈ E(a, ¯

d) and

¯ y = ¯ x + ¯ d, for some ¯ d ∈ D. Reachability problem for G: Given: regular sets U, U′ ⊆ V of vertices in G and semi-linear sets C, C′ ⊆ Nn Question: are there vertices (α, ¯ x) ∈ U × C and (β, ¯ y) ∈ U ′ × C′ in G such that (β, ¯ y) is reachable from (α, ¯ x)?

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 19

SLIDE 37

Reachability Problem for PRMC Graphs

Proposition: The reachability problem for the monotonic-counter extension of any prefix-recognizable graph is decidable. Proof sketch. Let L ⊆ (Σ × D)∗ be the traces of G with U and U ′ as the set of initial and final vertices, respectively. Show U′ × C′ is reachable from U × C iff (C + Φ(L)) ∩ C′ = ∅ Right-hand side: – L is context-free and effectively constructible (Caucal 2003). – Φ(L) is effectively semi-linear. – Effective closure of semi-linear sets under + and ∩. = ⇒ (Non-)Emptiness is decidable

RWTH Aachen – Wong Karianto

Adding Monotonic Counters to Automata and Transition Graphs – p. 20

SLIDE 38

Summary

Parikh automata correspond to adding monotonic counters with an additional semi-linearity test. No increase in language recognition power for linear-bounded automata, in contrast to finite and pushdown automata. Application to transition graphs: no increase for synchronized rational graphs, but for pushdown and prefix-recognizable graphs. For prefix-recognizable graphs, reachability remains decidable.

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 21

SLIDE 39

Further Prospects

Using more general frameworks than monotonic counters, e.g. reversal-bounded counters. Allowing intermediate tests during computations. Comparing Parikh automata to reversal-bounded counter automata. Using more general arithmetical conditions than semi-linear sets.

RWTH Aachen – Wong Karianto Adding Monotonic Counters to Automata and Transition Graphs – p. 22
