ADAPTIVE PROSTHETICS Deficits and devices of upper & lower limb - PowerPoint PPT Presentation

ADAPTIVE PROSTHETICS Deficits and devices of upper & lower limb amputees Lorin Merkley, CP Nextremity Prosthetic Design NEXTREMITY PROSTHETIC DESIGN TOPICS COVERED Major amputation levels and prosthetic overview Adaptive


  1. ADAPTIVE PROSTHETICS Deficits and devices of upper & lower limb amputees Lorin Merkley, CP Nextremity Prosthetic Design NEXTREMITY PROSTHETIC DESIGN

  2. TOPICS COVERED ■ Major amputation levels and prosthetic overview ■ Adaptive Prosthetics – definitions and history ■ Lower Limb overview ■ Upper Limb - – Amputation deficits – Upper Limb prosthetic overview – Activity specific/adaptive prosthetics – Indications/Contraindications – The therapist-prosthetist team

  3. MY BACKGROUND home. ■ AZ Native ■ Studied Biomedical Engineering at ASU ■ Practiced in Phoenix for 8 years ■ Faculty at Baylor College of Baylor Medicine College of ■ Returned to AZ to make a Medicine· difference

  4. MAJOR AMPUTATION LEVELS – Lower Limb ■ Lower Limb Amputations – Partial foot · l'- - f:""1.1 --\'!l'--- V. ry ovek s – Ankle disarticulation t- +-:t-- ~ --- M – Transtibial kn – Knee disarticulation – Transfemoral S rt below knee – Hip disarticulation $ nd r, b .tow n Chop rt - Ind oot, ,uch 89 Bo yd Toe ,serti onore~tion

  5. MAJOR AMPUTATION LEVELS – Upper Limb Fore quarter amputation (Implies removal of part of scapula, clavicle and all of upper limb) Shoulder disarticulation (Amputation through glenohumeral joint) ■ Upper Limb Amputations – Digital amputation – Partial Hand Above elbow (AE) – Wrist disarticulation – Transradial Elbow disarticulation a) Short BE – Elbow Disarticulation b) Medium BE Below elbow – Transhumeral (BE) – Shoulder Disarticulation c) Long BE – Inter-scapulothoracic Wrist disarticulation Metacarpophalangeal disarticulation lnterphalangeal Phalangeal disarticulation amputation

  6. PROSTHETIC OVERVIEW ■ Terminology: – Prosthesis (noun) – Any device that replaces a missing part of the body. – Prosthetic (adjective) – Describing anything that deals with a prosthesis. – Socket - The part of the device that encapsulates and interacts with the residual limb. – Foot – It ’s a foot… – Terminal Device – The part of an upper limb prosthesis that interacts with the environment (hook, hand, etc…). – Suspension – The method of holding the prosthesis on to the body.

  7. ADAPTIVE PROSTHETICS ■ Adaptive Prostheses – “Any component or group of components that enable the amputee to engage in (adapt to) a specific Physical activity” 1 ■ A lot of overlap [1] Caroll, Kevin. Adaptive prosthetics for the lower extremity. Foot and Ankle Clinics , Volume 6 , Issue 2 , 371 - 386

  8. HISTORY ADAPTIVE PROSTHETICS ■ Adaptive prostheses were among the first type of prostheses ■ 201 BC - Marcus Sergius was a Greek general who had an iron hand made to support his shield.

  9. HISTORY ADAPTIVE PROSTHETICS - 2 ■ 1509 AD - A hand made representing armor for Goetz von Berlichingen. The fingers could be locked shut to hold a weapon coilhouse.net

  10. HISTORY ADAPTIVE PROSTHETICS - 3 Late 19 th Century - The civil war left many amputees to fend for themselves and ■ create novel "home brew" devices. The prosthesis shown here was made out of a gun stock. Invention.smithsonian.org

  11. HISTORY ADAPTIVE PROSTHETICS - 4 ■ Post WWII - Much was done to get veteran amputees back to their specialized work

  12. LOWER LIMB PROSTHETICS Ottobock.com

  13. LOWER LIMB ADAPTIVE PROSTHETICS - OVERVIEW ■ Socket ■ Suspension ■ Knee ■ Alignable components ■ Ankle ■ Foot Ottobock.com

  14. LOWER LIMB ADAPTIVE PROSTHETICS – GOALS & BENEFITS ■ Activity specific ■ Mostly recreational ■ The major goal is increase in performance Ottobock.com

  15. LOWER LIMB ADAPTIVE PROSTHETICS - EXAMPLES ■ Knees – Focus on shock absorption, rather than stance and swing phases of gait 360oandp.com ■ Feet – Running – Swimming – Skiing – Etc… Ossur.com Hedef prosthetics Freedom Innovations

  16. UPPER LIMB PROSTHETICS Alternative Limb Project

  17. UPPER LIMB ADAPTIVE PROSTHETICS – Amputation Statistics by site ■ Difference in Goals, in numbers, and in cause of amputation 86% Lower Limb 14 0 Upper Limb 0% 20% 40% 60% 80% 100% Kathryn Ziegler- Graham, PhD, et al. “Estimating the Prevalence of Limb Loss in the United States - 2005 to 2050,” Archives of Physical Medicine and Rehabilitation 89 (2008):422 -429.2

  18. UPPER LIMB ADAPTIVE PROSTHETICS – Amputation Statistics by cause 100 % 90 % 80 % 70 % 60 % • Upper Limb 50 % • Lower Limb 40 % 30 % 20 % 10 % Dysvacular Trauma Cancer Congenital Kathryn Ziegler- Graham, PhD, et al. “Estimating the Prevalence of Limb Loss in the United States - 2005 to 2050,” Archives of Physical Medicine and Rehabilitation 89 (2008):422 -429.2

  19. UPPER LIMB ADAPTIVE PROSTHETICS – AMPUTATION DEFICITS – Partial Hand functional Deficiencies • Precision finger manipulation • padded distal end Remaining functions • Fine palmer positioning (Wrist movement, pronation/supination) • Elbow and shoulder movement • Possible fine digital opposition remaining • Suspension in cubital fold • Bilateral Oppositional force • Sensation Percent impaired • thumb: 38%UE, 23%WP • full partial hand: 90%UE, 54%WP

  20. UPPER LIMB ADAPTIVE PROSTHETICS – AMPUTATION DEFICITS - Transradial Deficiencies • Large surface area for load bearing • Pronation/supination? • Fine palmer positioning • Precision finger manipulation • Padded distal end Remaining functions • Elbow and shoulder movement • Suspension in cubital fold • Bilateral oppositional force • Sensation Percent impaired • TR deficiency: 95%UE, 57%WP

  21. UPPER LIMB ADAPTIVE PROSTHETICS – AMPUTATION DEFICITS - Transhumeral Deficiencies • Bilateral opposition • Humeral Rotation • Elbow flexion • Large surface area for load bearing • Pronation/supination? • Fine palmer positioning • Precision finger manipulation • padded distal end • Usable sensation Remaining functions • Shoulder movement • Axilla Oppositional force Percent impaired I • Elbow deficiency: 95%UE, 57%WP

  22. UPPER LIMB ADAPTIVE PROSTHETICS – PROSTHETIC OVERVIEW - BASICS ■ Socket ■ Suspension ■ Elbow ■ Wrist – Pronation, Supination, Flexion, quick change ■ TD – Hook – Hand – Activity Specific Ottobock.com

  23. UPPER LIMB ADAPTIVE PROSTHETICS – PROSTHETIC OVERVIEW - BASICS ■ Main types of Prostheses – Passive – Active – Activity Specific

  24. UPPER LIMB ADAPTIVE PROSTHETICS – PROSTHETIC OVERVIEW - Passive ■ Psychosocial function ■ Basic Opposition ■ Protection ■ Very Costly

  25. UPPER LIMB ADAPTIVE PROSTHETICS – PROSTHETIC OVERVIEW - ACTIVE ■ Controlled articulations at the elbow – Flexion & Extension – Passive humeral rotation ■ Controlled articulations at the wrist – Supination & Pronation ■ Control of the Terminal Device – Open and Close Mobius Bionics

  26. UPPER LIMB ADAPTIVE PROSTHETICS – PROSTHETIC OVERVIEW – BODY POWERED ■ Controlled by shoulder and arm movements – Glenohumeral flexion – Scapular abduction ■ Feedback available ■ Greater precision and speed ■ Less adaptable O&P Library

  27. UPPER LIMB ADAPTIVE PROSTHETICS – PROSTHETIC OVERVIEW – EXTERNAL POWERED ■ Controlled by: – Myoelectric signals (EMG) – Force pads – Potentiometers ■ Less compensatory movements ■ No harnessing ■ Less effort ■ More adaptive

  28. UPPER LIMB ADAPTIVE PROSTHETICS – Overall Goals ■ Improve function/Ease of use ■ Reduce onset of overuse symptoms

  29. UPPER LIMB ADAPTIVE PROSTHETICS – Ease of Use ■ Many tasks require complex manipulation or movement, but not a variety of manipulations. ■ Specialization

  30. UPPER LIMB ADAPTIVE PROSTHETICS – Overuse symptoms ■ Overuse in Contralateral Side – Approximately 50% of patients with a unilateral amputation will experience overuse syndrome 2 ■ Overuse in residual limb [2] Jones LE, Davidson JH: Save that arm: A study of problems in the remaining arm of unilateral upper limb amputees. Prosthet Orthot Int 1999;23:55-58

  31. UPPER LIMB ADAPTIVE PROSTHETICS – Examples - Employment

  32. UPPER LIMB ADAPTIVE PROSTHETICS – How to implement Custom Socket Cuff Wrist Orthosis

  33. UPPER LIMB ADAPTIVE PROSTHETICS – So many options

  34. UPPER LIMB ADAPTIVE PROSTHETICS – Examples – House ADL’s (Kitchen) ■ Eating ■ Food Preparation

  35. UPPER LIMB ADAPTIVE PROSTHETICS – Examples – House ADL’s (Outdoors) H GC02-0N2 H and Hoe Hand Cultivator GS0 1• 0N2 Hand Spade

  36. UPPER LIMB ADAPTIVE PROSTHETICS – Examples – House ADL’s (Out and About)

  37. UPPER LIMB ADAPTIVE PROSTHETICS – Examples - Recreations

  38. UPPER LIMB ADAPTIVE PROSTHETICS – Changing devices ■ Can be difficult for Hands·F ree Tool Changing Station bilateral patients ■ Quick change stands are available

  39. UPPER LIMB ADAPTIVE PROSTHETICS – Other considerations ■ More than just the terminal device you use. ■ Socket alignment, materials, and flexibility are also critical. / 1970 2009

  40. UPPER LIMB ADAPTIVE PROSTHETICS – Limitations ■ Task specific ■ No sensation ■ Learning curve

  41. UPPER LIMB ADAPTIVE PROSTHETICS – Indications/Contraindications ■ “The most expensive prosthesis is the one in the closet.” ■ Aspects to look at – Gaps in function – Overuse possibilities – Motivation www.motherearthnews.com
