Adam McLaughlin, Duane Merrill, Michael Garland, and David A. Bader - - PowerPoint PPT Presentation

Parallel Methods for Verifying the Consistency of Weakly-Ordered Architectures

Adam McLaughlin, Duane Merrill, Michael Garland, and David A. Bader

Challenges of Design Verification

• Contemporary hardware designs require

mi mill llions

• ns of lines of RTL code

– More lines of code written for verification than for the implementation itself

• Tradeoff between performance and design

complexity

– Speculative execution, shared caches, instruction reordering – Performance wins out

GTC 2016, San Jose, CA

2

Performance vs. Design Complexity

• Programmer burden

– Requires correct usage of synchronization

• Time to market

– Earlier remediation of bugs is less costly – Re-spins on tapeout are expensive

• Significant time spent of verification

– Verification techniques are often NP- complete

GTC 2016, San Jose, CA

3

Memory Consistency Models

• Contract between SW and HW regarding the

semantics of memory operations

• Classic example: Sequential Consistency (SC)

– All processors observe the same ordering of

• perations serviced by memory

– Too strict for modern optimizations/architectures

• Nomenclature

– ST[A] → 1 1 “Wrote a value of 1 to location A” – LD[B] ← 2 2 “Read a value of 2 from location B”

GTC 2016, San Jose, CA

4

ARM Idiosyncrasies

• Our focus: ARMv8

Mv8

• Speculative

eculative Ex Execution cution is allowed

• Threads can reo

eorde rder rea eads ds an and wr writes tes

– Assuming no dependency exists

• Writes are not

t guar aranteed anteed to to be be simu multaneo ltaneously usly vi visible ible to other cores

GTC 2016, San Jose, CA

5

Problem Setup

• 1. Construct an initial graph

– Vertices represent load, store, and barrier insts – Edges represent memory

• rdering
• Based on architectural rules

2.

• 2. Iter

erati tive vely ly infer er add ddit itio ional ed edge ges to the e gr graph ph

– Based on existing relationships

• 3. Check for cycles

– If one exists: contradiction!

GTC 2016, San Jose, CA

6

LD[B] ← 92 LD[A] ← 2 ST[B] → 92 LD[B] ← 93 LD[B] ← 92 CPU 0 CPU 1 ST[B] → 90

• Given an inst. trace from a simulator, RTL, or silicon

TSOtool

• Hangal et al., ISCA ’04

– Designed for SPARC, but portable to ARM

• Each store writes a unique value to memory

– Easily map a load to the store that wrote its data

• Tradeoff between accuracy and runtime

– Polynomial time, but false positives are possible – If a cycle is found, a bug indeed exists – If no cycles are found, execution appears ars consistent

GTC 2016, San Jose, CA

7

Need for Scalability

• Must run many tests to maximize coverage

– Stress different portions of the memory subsystem

• Longer tests put supporting logic in more interesting

states

– Many instructions are required to build history in an LRU cache, for instance

• Using a CPU cluster does not suffice

– The results of one set of tests dictate the structure of the ensuing tests – Faster tests help with interactivity!

• Solution: Efficient algorithms and parallelism

GTC 2016, San Jose, CA

8

Inferred Edge Insertions (Rule 6)

• S can reach X
• X does not load data

from S

GTC 2016, San Jose, CA

9

W: ST[A] → 2 X: LD[A] ← 2 S: ST[A] → 1

Inferred Edge Insertions (Rule 6)

• S can reach X
• X does not load data

from S

• S co

comes mes be before

• re th

the node that stored X’s dat ata

GTC 2016, San Jose, CA

10

W: ST[A] → 2 X: LD[A] ← 2 S: ST[A] → 1

Inferred Edge Insertions (Rule 7)

• S can reach X
• Loads read data from S, not X

GTC 2016, San Jose, CA

11

L: LD[A] → 1 X: ST[A] → 2 S: ST[A] → 1 M: LD[A] → 1

Inferred Edge Insertions (Rule 7)

• S can reach X
• Loads read data from S, not X
• Load

ads s ca came me be befor

• re

e X

GTC 2016, San Jose, CA

12

L: LD[A] → 1 X: ST[A] → 2 S: ST[A] → 1 M: LD[A] → 1

Initial Algorithm for Inferring Edges

for_each(store vertex S) { for_each(reachable vertex X from S) //Getting this set is expensive! { if(location[S] == location[X]) { if((type[X] == LD) && (data[S] != data[X])) { //Add Rule 6 edge from S to W, the store that X read from } else if(type[X] == ST) { for_each(load vertex L that reads data from S) { //Add Rule 7 edge from L to X } } //End if instruction type is store } //End if location } //End for each reachable vertex } //End for each store

GTC 2016, San Jose, CA

13

Virtual Processors (vprocs)

• Split instructions from physical to virtual processors
• Each vproc is sequentially consistent

– Program order ↔ Memory order

GTC 2016, San Jose, CA

14

ST[B] → 91 ST[A] → 1 LD[A] ← 2 ST[B] → 92 VPROC 0 ST[A] → 1 LD[A] ← 2 VPROC 1 VPROC 2 ST[B] → 91 ST[B] → 92 CPU 0

Reverse Time Vector Clocks (RTVC)

• Consider the RTVC of

ST[B] = 90

Purple: ST[B] = 92 Blue: NULL Green: LD[B] = 92 Orange: LD[B] = 92

• Track the earliest

successor from each vertex to each vproc

– Captures transitivity

GTC 2016, San Jose, CA

15

LD[B] ← 92 LD[A] ← 2 ST[B] → 92 LD[B] ← 93 LD[B] ← 92 CPU 0 CPU 1 ST[B] → 90

Complexity of inferring edges: 𝑃 𝑜2𝑞2𝑒𝑛𝑏𝑦

Updating RTVCs

• Computing RTVCs once is fast

– Process vertices in the reverse

• rder of a topological sort

– Check neighbors directly, then their RTVCs

• Every time a new edge is

inserted, RTVC values need to change

– # of edge insertions ≈ 𝑛

GTC 2016, San Jose, CA

16

• TSOtool implements both vprocs and RTVCs

Facilitating Parallelism

• Repeatedly updating RTVCs is expensive

– For 𝑙 edge insertions, RTVC updates take 𝑃(𝑙𝑞𝑜) time

• 𝑙 = 𝑃 𝑜2 , but usually is a small multiple of 𝑜
• Idea: Update RTVCs once per iteration rather than

per edge insertion

– For 𝑗 iterations RTVC updates take 𝑃(𝑗𝑞𝑜) time

• 𝑗 ≪ 𝑙 (less than 10 for all test cases)

– Less communication between threads

• Complexity of inferring edges: 𝑃(𝑜2𝑞)

GTC 2016, San Jose, CA

17

Correctness

• Inferred edges found by our approach will not be the

same as the edges found by TSOtool

– Might not infer an edge that TSOtool does

• RTVC for TSOtool can change mid-iteration

– Might infer an edge that TSOtool does not

• Our approach will have “stale” RTVC values
• Both approaches make forward progress

– Number of edges monotonic

• tonically

ally increases eases

• Any edge inserted by our approach could have been

inserted by the naïve approach [Thm 1]

• If TSOtool finds a cycle, we will also find a cycle [Thm 2]

GTC 2016, San Jose, CA

18

Parallel Implementations

• OpenMP

– Each thread keeps its own partition of added edges – After each iteration of inferring edges, reduce

• CUDA

– Assign threads to each store instruction – Threads independently traverse the vprocs of this store – Atomically add edges to a preallocated array in global memory

GTC 2016, San Jose, CA

19

Experimental Setup

• Intel Core i7-2600K CPU

– Quad core, 3.4GHz, 8MB LLC, 16GB DRAM

• NVIDIA GeForce GTX Titan

– 14 SMs, 837 MHz base clock, 6GB DRAM

• ARM system under test

– Cortex-A57, quad core

• Instruction graphs range from 𝑜 = 218 to 𝑜 = 222

vertices, 𝑜 ≈ 𝑛

– Sparse, high-diameter, low-degree – Tests vary by their distribution of LD/ST/DMB instructions, # of vprocs, and inst dependencies

GTC 2016, San Jose, CA

20

Importance of Scaling

GTC 2016, San Jose, CA

21

• 512K instructions

per core

• 2M total

instructions

Speedup over TSOtool (Application)

Graph Size # of tests Lazy RTVC OMP 2 OMP 4 GPU 64K*4 = 256K 27 5.64x 7.62x 9.43x 10.79x 128K*4 = 512K 27 5.31x 7.12x 8.90x 10.76x 256K*4 = 1M 23 6.30x 9.05x 12.13x 15.47x 512K*4 = 2M 10 3.68x 6.41x 10.81x 24.55x 1M*4 = 4M 2 3.05x 5.58x 9.97x 37.64x

GTC 2016, San Jose, CA

22

• GPU is always best; scales much better to larger tests
• Extreme case: 9 hours

rs using TSOtool → unde der 10 min inutes es using our GPU approach

• Avg. Parallel speedups over our improved sequential

approach:

– 1.92x (OMP 2), 3.53x (OMP 4), 5.05x (GPU)

Summary

• Relaxing the updates to RTVCs lead to a better

sequential approach and and facilitated parallel implementations

– Trade off between redundant work and parallelism

• Faster execution leads to interactive bug-finding
• The GPU scales well to larger problem instances

– Helpful for corner case bugs that slip through pre-silicon verification

• For the twelve largest test cases our GPU

implementation achieves a 26.36x average application speedup

GTC 2016, San Jose, CA

23

Acknowledgments

• Shankar Govindaraju, and Tom Hart for their

help on understanding NVIDIA’s implementation of TSOtool for ARM

GTC 2016, San Jose, CA

24

Questions

“To raise new questions, new possibilities, to regard old problems from a new angle, requires creative imagination and marks real advance in science.”– Albert Einstein

25

GTC 2016, San Jose, CA

Backup

26

GTC 2016, San Jose, CA

Sequential Consistency Examples

• Valid
• Invalid

GTC 2016, San Jose, CA

27

P1: ST[x]→1 P2: LD[x]←1 LD[x]←2 P3: LD[x]←1 LD[x]←2 P4: ST[x]→2 t=0 t=1 t=2 P1: ST[x]→1 P2: LD[x]←1 LD[x]←2 P3: LD[x]←2 LD[x]←1 P4: ST[x]→2 t=0 t=1 t=2

• ST[x]→1 handled before

ST[x]→2

• Writes propagate to P2

and P3 in a different

• rder

– Valid for weaker memory models

Weaker Models

• SC is intuitive, but is too strict

– Prevents common compiler/arch. optimizations

• Commercial products use weaker models

– x86: Total Store Order (TSO) – Power/ARM: Relaxed Memory Ordering (RMO)

• Weaker models allow for greater optimization
• pportunities

– Cost: More complicated semantics

GTC 2016, San Jose, CA

28

Initial Algorithm: Weaknesses

• Expensive to compute

– 𝑃(𝑜3), assuming edges can be inserted in 𝑃(1) time – Repeated iteratively until a fixed point is reached

• Requires the transitive closure of the graph

– Expensive to store – Capturing 𝑜2 relationships (does vertex 𝑗 reach vertex 𝑘?)

• Adds lots of redundant edges

– Should leverage transitivity when possible

GTC 2016, San Jose, CA

29

A B C

Reverse Time Vector Clocks (RTVCs)

• vprocs provide implicit orderings

GTC 2016, San Jose, CA

30

ST[B] → 91 ST[B] → 92 ST[A] → 1

Reverse Time Vector Clocks (RTVCs)

• vprocs provide implicit orderings
• Reverse Vector Time Clock

– Track the earliest successor from each vertex to each vproc

• Bounds the number of reachable edges to be

inspected by 𝑞, the number of vprocs

– No need to compute or store the transitive closure!

GTC 2016, San Jose, CA

31

ST[B] → 91 ST[B] → 92 ST[A] → 1

Reverse Time Vector Clocks (RTVCs)

• Track the earliest successor from each vertex to

each vproc

– Captures transitivity

• Traverse vprocs rather than the graph itself

– No need to check every reachable vertex

• Bounds the number of reachable edges to be

inspected by 𝑞, the number of vprocs

– No need to compute or store the transitive closure!

GTC 2016, San Jose, CA

32

Superfluous work?

• Our approach tends

to add more edges than TSOtool, some of which are redundant

– Worst case: 36% additional edges – The redundancy is well worth the performance benefits

GTC 2016, San Jose, CA

33

Test Info

𝒐 = 𝑾 𝒏 = 𝑭 TSOtool Inferred Iterations ST/LD/BAR (%) 2,097,963 3,799,254 4,487,224 5 76/24/0 2,098,219 3,686,624 4,411,887 4 79/21/0 1,977,832 4,453,340 5,179,108 5 46/53/1 2,097,741 3,875,831 4,635,852 7 77/23/0 1,936,321 5,109,990 5,236,671 5 44/54/2 2,098,321 2,491,062 4,257,077 6 80/20/0 2,097,809 4,321,793 4,404,753 7 78/21/1 1,871,831 3,660,617 4,861,044 6 44/54/2 2,097,809 4,434,120 4,418,555 5 80/20/0 4,195,405 6,934,725 9,338,902 7 76/23/1 4,194,961 7,960,567 8,963,281 6 78/22/0

GTC 2016, San Jose, CA

34

Speedup over TSOtool (Inferring edges)

Graph Size # of tests Lazy RTVC OMP 2 OMP 4 GPU 64K*4 = 256K 27 15.09x 29.31x 53.45x 57.90x 128K*4 = 512K 27 16.41x 31.49x 57.34x 76.98x 256K*4 = 1M 23 14.51x 27.98x 51.68x 72.32x 512K*4 = 2M 10 4.01x 7.52x 14.19x 42.90x 1M*4 = 4M 2 3.08x 5.70x 10.39x 45.16x

GTC 2016, San Jose, CA

35

• Number of tests decreases with test size because
• f industrial time constraints

– Motivation for this work

• Avg. Parallel speedups over our improved

sequential approach:

– 1.92x (OMP 2), 3.53x (OMP 4), 5.05x (GPU)

Problem Setup

• 1. Construct an initial graph

– Vertices represent load, store, and barrier insts – Edges represent memory

• rdering
• Based on architectural rules
• 2. Iteratively infer additional

edges to the graph

– Based on existing relationships

• 3. Check for cycles

– If one exists: contradiction!

GTC 2016, San Jose, CA

36

LD[B] ← 92 LD[A] ← 2 ST[B] → 92 LD[B] ← 93 LD[B] ← 92 CPU 0 CPU 1 ST[B] → 90

• Given an inst. trace from a simulator, RTL, or silicon

Importance of Scaling

GTC 2016, San Jose, CA

37

• 128K instructions

per core

• 512K total

instructions

Importance of Scaling

GTC 2016, San Jose, CA

38

• 256K instructions

per core

• 1M total

instructions
