LIFE CYCLE COST ANALYSIS (LCCA)

“A State Perspective”

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

Kevin W. McMullen, P.E. President Wisconsin Concrete Pavement Association

slide-3
SLIDE 3

Introduction

  • PCA Paving Committee Meeting of August

26-27, 2013

  • Meeting focus on LCCA
  • There is a lot of hope that the use of LCCA

will open pavement markets

  • Consensus that project decisions should

not be made on first costs only

  • I continually hear a common statement

made about LCCA

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-4
SLIDE 4

Introduction

  • Everybody knows that someone that is

good at life cycle cost analysis can adjust the inputs to justify an outcome

  • I agree.
  • I was a master of this in my former career

at the Wisconsin Department of Transportation

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-5
SLIDE 5

Did your father ever say to you?

  • Be careful what you ask for……,

you just might get it !!!

  • We don’t want to be in this position after

we have pushed hard for state agencies to use LCCA in the pavement type selection process

  • Coming back and saying we don’t like the

way you are doing it will be very unpopular

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-6
SLIDE 6

This workshop is about…..

  • Why should we do LCCA?
  • The major guiding principles
  • This presentation is about how do we do it

in Wisconsin

  • First a little history.

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-7
SLIDE 7

WisDOT 1993

  • WisDOT had been using some form of

LCCA since 1984 when federal regulations started requiring it.

  • Each project engineer did their design and

LCCA and chose pavement type with minimal review.

  • No real guidance was supplied on how to

do it.

  • Designers were supplied a spreadsheet

that did the thickness design and LCCA

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-8
SLIDE 8

WisDOT 1993

  • Results varied
  • Pavement selections were unpredictable
  • Paving industries were consistently

bringing debates to upper management on project selections

  • WisDOT managers were finding it difficult

to keep pavement quantities balanced in their “two healthy pavement industry concept policy”

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-9
SLIDE 9

WisDOT PAVEMENT QUANTITIES COMPARISON

500 1000 1500 2000 2500 3000 3500 4000 4500 5000 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014

1000s of SY of Concrete and Tons

  • f Asphalt

Fiscal Year

S.Y. Tons

(projected)

slide-10
SLIDE 10

WisDOT 1993

  • Maintaining competition within an industry

and between the industries was a core concept of then Secretary Ron Fiedler.

  • The order was given, “I want a pavement

selection process that is rational, predictable and defendable”.

  • “If both industries are happy you will have

done a great job, if both are unhappy you will have done a good job, if only one of them is happy, I will be unhappy”

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-11
SLIDE 11

WisDOT 1995

  • I completed the work in 1995 and

implemented the new policies

  • Still in force today
  • Basis of PCA Paving: New Realities report

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-12
SLIDE 12

So, what were our goals?

  • Rational – Good Engineering and Pavement

Management Principles

  • Predictable and Defendable – Good Policies in Place
  • This is not about individual projects
  • Rather this is about building pavement programs that are

sustainable year after year.

  • Our goal should be to have the project engineer

equipped with tools and policies such that he/she can do the pavement design, LCCA and selection, develop a concrete alternative for every project and select it when appropriate without ramifications or questions.

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-13
SLIDE 13

Critical Steps in the LCCA Process

  • 1. Develop structurally equivalent alternatives
  • 2. Develop pavement service life models for new

and rehabilitated pavements

  • 3. Select an analysis period
  • 4. Select a discount rate
  • 5. Estimate initial agency costs
  • 6. Estimate future agency costs and timing
  • 7. Estimate residual value
  • 8. Compare alternatives
  • 9. Determine best value alternative

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-14
SLIDE 14

Structurally Equivalent Alternatives

  • WisDOT long policy of AASHTO ‘72
  • WisDOT implementing MEPDG in 2014
  • Cities and counties –StreetPave
  • Non-equivalent designs can be too hard to
  • ver come in the LCCA due to the initial

cost only

  • Getting a concrete alternative and an

asphalt alternative is the key

  • The example of Fond du Lac, WI

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-15
SLIDE 15

Structurally Equivalent Alternatives

  • Known traffic, soils and materials
  • Good construction specifications and standards must be

part of this. – Base – Concrete mix – Joint spacing – Etc.

  • Design life and specifications must compliment each
  • ther
  • If they don’t, it is our responsibility to help them bring this

together.

  • WCPA Municipal Concrete Pavement Specification

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-16
SLIDE 16

Life-Cycle Cost Analysis

What are comparable sections?

  • Traffic
  • Reliability
  • Subgrade
  • Terminal

Condition

  • Traffic
  • Reliability
  • Subgrade
  • Terminal

Condition

=

  • Provide reasonably similar level of service
  • Same structural capacity
  • Similar traffic-carrying capacity over the analysis period

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-17
SLIDE 17

Pavement Service Life Models

  • Are they managing their pavements?
  • Do they really know how long they last?
  • Does their maintenance and rehabilitation

procedures really extend the life as expected?

  • Quality of the model – all asphalt pavement

average being used interstate projects?

  • Pavement design life versus actual life
  • MEPDG is so critical in this effort.
  • The last time I built concrete…….

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-18
SLIDE 18

Equal Levels of Service ? And Equal Service Lives

Minimum Acceptable Condition

Time Pavement Quality

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-19
SLIDE 19

What is the service life?

Minimum Acceptable Condition

Time Pavement Quality

Service life when rehab should be done Service life when rehab actually done ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-20
SLIDE 20

WisDOT Initial Construction Service Lives

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-21
SLIDE 21

WisDOT Rehab Expectations

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-22
SLIDE 22

Analysis Period

  • Timeframe over which the alternative

strategies/treatments are compared.

  • Long enough to reflect significant

differences in performance

  • Must encompass the initial performance

period and at least one major rehabilitation

  • FHWA Policy Statement requires this
  • WisDOT policy requires a 50 year analysis

period

  • The same for all alternatives

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-23
SLIDE 23

Discount Rate

  • Hour long discussion on this topic alone
  • What is being used?
  • Federal OMB Circular A-94?

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-24
SLIDE 24

Discount Rate

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-25
SLIDE 25

Discount Rate

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-26
SLIDE 26

Discount Rate

Common quote from Dr. Mark Wolfgram, former Administrator, Division of Investment Management, Wisconsin DOT

“Discount rates become a controversial issue in the life cycle cost analysis procedure when the policies surrounding the rest of the inputs into the analysis are weak”

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-27
SLIDE 27

Initial Agency Costs

  • The current world of information allows us to

capture the bid tabs

  • We know what they are paying for asphalt and

concrete pavements

  • We have the ability to debate use of inflated

prices or low ball prices in an LCCA

  • States, cities and counties are posting bid tabs
  • n their websites
  • Open records law

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-28
SLIDE 28

Initial Agency Costs

  • Costs should be based on history
  • Agencies spend significant resources on

developing engineering estimates and training staff how to do them

  • There is no one project so special that it

justifies departure from historic costs

  • WisDOT approach: county, surrounding

counties, region, statewide

  • Statewide average unit bid prices are not

allowed

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-29
SLIDE 29

Initial Agency Costs

  • Where there is no market:

– We use their asphalt cost data – This can work to our advantage initially – Several example cities in Wisconsin – We get them concrete data

  • Bid tabs from other agencies
  • WCPA policy on providing concrete paving cost

estimates

  • If we screw up and low ball the number, we

instantly lose the opportunity to do concrete again.

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-30
SLIDE 30

Future Agency Costs and Timing

  • This is a fundamental question
  • How does an agency maintain and

rehabilitate a pavement throughout the analysis period?

  • Agencies need to commit
  • Maintenance Departments need to track

costs by year and by roadway.

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-31
SLIDE 31

Future Agency Costs and Timing

  • State highway agencies typically have

these schedules and service lives in their planning and maintenance sections

  • Cities – sit them down and get them to

document and establish policy.

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-32
SLIDE 32

Future Agency Costs and Timing

  • Focus on historical and current costs of

asphalt or concrete

  • State agencies don’t have a crystal ball
  • Discount rate and present worth analysis

adjusts cost for the future

  • Agencies will debate cost adjustments due

to external forces (oil embargo)

  • Never appropriate to approach a single

project with a non traditional cost impact

  • Dowel bar example

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-33
SLIDE 33

WisDOT HMA Options

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-34
SLIDE 34

WisDOT JPCP Options

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-35
SLIDE 35

WisDOT Initial Construction Service Lives

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-36
SLIDE 36

WisDOT Rehab Expectations

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-37
SLIDE 37

WisDOT Maintenance Options

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-38
SLIDE 38

So what is really going on in real life?

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-39
SLIDE 39

Estimating Residual Value

  • Three ways to do this:

– Net value of the recycled materials (salvage value) – Remaining service life – Residual value as a support layer

  • Policy is required here, remaining service

life is the easiest and most widely used.

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-40
SLIDE 40

Example Expenditure Stream

Agency Costs User Costs Initial Construction First Rehab Second Rehab Periodic Maintenance Periodic Maintenance End of Analysis

T0 T1 T2 T3 T4 T5 T6 T7 TRSL Time

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-41
SLIDE 41

Example Expenditure Stream

Agency Costs User Costs Initial Construction First Rehab Second Rehab Periodic Maintenance Periodic Maintenance End of Analysis

T0 T1 T2 T3 T4 T5 T6 T7 TRSL Time

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-42
SLIDE 42

Comparing Alternatives

  • Best asphalt design
  • Best concrete design
  • No need to do multiple alternatives of a

particular pavement type

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-43
SLIDE 43

CITY OF MILWAUKEE EXAMPLE

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-44
SLIDE 44

Initial Costs – Milw aukee Area Costs

  • Concrete pavement bid prices from City of

Milwaukee projects in the WisDOT letting.

  • HMA bid prices from recent City of

Milwaukee projects

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-45
SLIDE 45

Initial Costs – Milw aukee Area Costs

Type of Work Description of Work Service Life Quantity Unit Price Total Cost PCC Reconstruct 7-Inch Concrete Pavement 60 7111 SY $17.98/SY $127,856

TOTAL $127,856

PCC Reconstruct 3-Inch Roadway Excavation 60 760 CY $15.00/CY $11,400.00 3-Inch CABC 1640 Ton $10.00/Ton $16,400.00 7-Inch Concrete Pavement 7111 SY $17.98/SY $127,856

TOTAL $155,656

HMA 4.5” HMA over 6” Base 3.5-Inch Roadway Excavation 20 886 CY $15.00/CY $13,290 Reconstruct Phase 1 6-Inch CABC 3280 Ton $10.00/Ton $32,800 3-Inch HMA Binder 1230 Ton $48.00/Ton $59,040 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 Reconstruct Phase 2 1.5-Inch HMA Surface 610 Ton $58.00/Ton $35,380 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225

TOTAL $139,923

HMA 5.5” HMA over 8” Base 6.5-Inch Roadway Excavation 20 1645 CY $15.00/CY $24,675 Reconstruct Phase 1 8-Inch CABC 4375 Ton $10.00/Ton $43,750 4-Inch HMA Binder 1640 Ton $48.00/Ton $78,720 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 Reconstruct Phase 2 1.5-Inch HMA Surface 610 Ton $58.00/Ton $35,380 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225

TOTAL $181,938 ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-46
SLIDE 46

Initial Costs – Milw aukee Area Costs

Type of Work Total Cost

PCC Reconstruct $127,856 100% PCC Reconstruct with base $155,656 122% HMA 4.5” HMA over 6” Base $139,923 109% HMA 5.5” HMA over 8” Base $181, 938 142%

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-47
SLIDE 47

Life Cycle Costs

  • Commonly accepted tool for pavement
  • selection. FHWA and WisDOT regulations

and policies require it.

  • Professor William Holahan, Department of

Economics, University of Wisconsin- Milwaukee Paper

– Life cycle cost should be used by government – Net present worth analysis recommended – Assures the lowest possible property taxes

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-48
SLIDE 48

Life Cycle Cost Analysis (LCCA)

  • The decisions you make today effect the

City’s budget and resources of the future.

  • The decision you make today commits the

City for the life cycle.

  • Net present worth attempts to bring all

events into today’s dollars

  • Lowest life cycle cost assures low property

taxes

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-49
SLIDE 49

LCCA Results for Milwaukee

PCC #1 Pavement Design Maintenance and Rehabilitation worksheet.

Expenditures Year Type of Work Description of Work Service Life Quantity Unit Price Total Cost Present Worth Cost Based on 3% Inflation PCC Reconstruct 7-Inch Concrete Pavement 60 7111 SY $17.98/SY $127,856 $127,856 $127,856 15 Maintenance Joint Sealing (15%) 940 LF $0.50/LF $470 $302 $732 30 Maintenance Joint Sealing (30%) 1880 LF $0.50/LF $940 $387 $2,282 Rehabilitation Full Depth Repair 12 CY $170/CY $2,040 $840 $4,952 2% Panels (6-foot repair) Rehabilitation Partial Depth Repair 190 LF $15.00/LF $2,850 $1,174 $6,918 3% Joints Repaired 45 Maintenance Joint Sealing (30%) 1880 LF $0.50/LF $940 $249 $3,555 59 Remaining Service Life $0 $0 $0 Totals $135,096 $130,808 $146,294 ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-50
SLIDE 50

LCCA Results for Milwaukee

PCC #2 Pavement Design Maintenance and Rehabilitation worksheet.

Expenditures Year Type of Work Description of Work Service Life Quantity Unit Price Total Cost Present Worth Cost Based on 3% Inflation PCC Reconstruct 3-Inch Roadway Excavation 60 760 CY $15.00/CY $11,400.00 $11,400.00 $11,400.00 3-Inch CABC 1640 Ton $10.00/Ton $16,400.00 $16,400.00 $16,400.00 7-Inch Concrete Pavement 7111 SY $17.98/SY $127,856 $127,856 $127,856 15 Maintenance Joint Sealing (15%) 940 LF $0.50/LF $470 $302 $732 30 Maintenance Joint Sealing (30%) 1880 LF $0.50/LF $940 $387 $2,282 Rehabilitation Full Depth Repair 12 CY $170/CY $2,040 $840 $4,952 2% Panels (6-foot repair) Rehabilitation Partial Depth Repair 190 LF $15.00/LF $2,850 $1,174 $6,918 3% Joints Repaired 45 Maintenance Joint Sealing (30%) 1880 LF $0.50/LF $940 $249 $3,555 59 Remaining Service Life $0 $0 $0 Totals $162,896 $158,608 $174,094

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-51
SLIDE 51

LCCA Results for Milwaukee

HMA #1 Pavement Design Maintenance and Rehabilitation worksheet.

Expenditures Year Type of Work Description of Work Service Life Quantity Unit Price Total Cost Present Worth Cost Based on 3% Inflation HMA 3.5-Inch Roadway Excavation 20 886 CY $15.00/CY $13,290 $13,290 $13,290 Reconstruct Phase 1 6-Inch CABC 3280 Ton $10.00/Ton $32,800 $32,800 $32,800 3-Inch HMA Binder 1230 Ton $48.00/Ton $59,040 $59,040 $59,040 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 $225 $225 1 Reconstruct Phase 2 1.5-Inch HMA Surface 610 Ton $58.00/Ton $35,380 $34,350 $36,441 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 $218 $232 10 Maintenance Crack Sealing 2000 LF $0.50/LF $1,000 $744 $1,344 15 Maintenance Crack Sealing 2500 LF $0.50/LF $1,250 $802 $1,947 20 Rehabilitation Mill and Remove 3-Inch Depth 20 7111 SY $2.00/SY $14,222 $7,874 $25,687 3-Inch HMA Surface 1230 Ton $58.00/Ton $71,340 $39,499 $128,848 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 $125 $406 25 Maintenance Crack Sealing 2000 LF $0.50/LF $1,000 $478 $2,094 30 Maintenance Crack Sealing 2500 LF $0.50/LF $1,250 $515 $3,034 35 Maintenance Crack Sealing 3000 LF $0.50/LF $1,500 $533 $4,221 40 Rehabilitation Pavement Resurface 20 1 LS $85,787/LS $85,787 $26,299 $279,840 45 Maintenance Crack Sealing 2,000 LF $0.50/LF $1,000 $264 $3,782 50 Maintenance Crack Sealing 2,500 LF $0.50/LF $1,250 $285 $5,480 55 Maintenance Crack Sealing 3,000 LF $0.50/LF $1,500 $295 $7,623 59 Remaining Service Life $0 $0 $0 Totals $322,284 $217,637 $606,334

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-52
SLIDE 52

LCCA Results for Milwaukee

HMA #2 Pavement Design Maintenance and Rehabilitation worksheet.

Expenditures Year Type of Work Description of Work Service Life Quantity Unit Price Total Cost Present Worth Cost Based on 3% Inflation 0 HMA 6.5-Inch Roadway Excavation 20 1645 CY $15.00/CY $24,675 $24,675 $24,675 Reconstruct Phase 1 8-Inch CABC 4375 Ton $10.00/Ton $43,750 $43,750 $43,750 4-Inch HMA Binder 1640 Ton $48.00/Ton $78,720 $78,720 $78,720 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 $225 $225 1 Reconstruct Phase 2 1.5-Inch HMA Surface 610 Ton $58.00/Ton $35,380 $34,350 $36,441 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 $218 $232 10 Maintenance Crack Sealing 2000 LF $0.50/LF $1,000 $744 $1,344 15 Maintenance Crack Sealing 2500 LF $0.50/LF $1,250 $802 $1,947 20 Rehabilitation Mill and Remove 3-Inch Depth 20 7111 SY $2.00/SY $14,222 $7,874 $25,687 3-Inch HMA Surface 1230 Ton $58.00/Ton $71,340 $39,499 $128,848 Tack (.025 Gal/SY) 180 Gal $1.25/Gal $225 $125 $406 25 Maintenance Crack Sealing 2000 LF $0.50/LF $1,000 $478 $2,094 30 Maintenance Crack Sealing 2500 LF $0.50/LF $1,250 $515 $3,034 35 Maintenance Crack Sealing 3000 LF $0.50/LF $1,500 $533 $4,221 40 Rehabilitation Pavement Resurface 20 1 LS $85,787/LS $85,787 $26,299 $279,840 45 Maintenance Crack Sealing 2,000 LF $0.50/LF $1,000 $264 $3,782 50 Maintenance Crack Sealing 2,500 LF $0.50/LF $1,250 $285 $5,480 55 Maintenance Crack Sealing 3,000 LF $0.50/LF $1,500 $295 $7,623 59 Remaining Service Life $0 $0 $0 Totals $364,299 $259,652 $648,349

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-53
SLIDE 53

LCCA Results for Milwaukee

Life Cycle Cost Analysis Present Worth Worksheet

Project: City of Milwaukee - Reconstruct Analysis Period: 60 Years Discount Rate: 3% Roadway Scenario: Length = 2000 LF Pavement Width = 32 LF Roadway SY = 7111 SY Excavation Width = 41 LF 4.5-Inch HMA = 1840 Ton Concrete Alternative #1: PCC Pavement Design 7-Inch Concrete over Existing Concrete Alternative #2: PCC Pavement Design 7-Inch Concrete over 3-Inch CABC HMA Alternative #1: Asphalt Pavement Design 4.5-Inch HMA over 6-Inch CABC HMA Alternative #2: Asphalt Pavement Design 5.5-Inch HMA over 8-Inch CABC Present Worth Costs: Concrete Alternative #1 Concrete Alternative #2 HMA Alternative #1 HMA Alternative #2 7-Inch Concrete over Existing 7-Inch Concrete over 3-Inch CABC 4.5-Inch HMA over 6-Inch CABC 5.5-Inch HMA over 8-Inch CABC Initial Pavement Costs $127,856 $155,656 $139,923 $181,938 Maintenance Costs $938 $938 $3,917 $3,917 Rehabilitation Costs $2,015 $2,015 $73,797 $73,797 Reconstruction Costs $0 $0 $0 $0 Operation Costs *** *** *** *** User Costs *** *** *** *** Agency Costs *** *** *** *** Remaining Service Life $0 $0 $0 $0 Total Facility Present Worth Cost $130,808 $158,608 $217,637 $259,652 Present Worth LF Roadway Cost $65 $79 $109 $130 100% 121% 166% 198%

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-54
SLIDE 54

Life Cycle Costs could be lowered 45 -98 percent utilizing concrete pavements!!!!

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

City of Milwaukee conclusion:

Ghassan Khorban, Commissioner of Public Works

slide-55
SLIDE 55

Where are we going in Wisconsin?

  • Assuring WisDOT policies hold firm (or at

least move in the right direction)

  • Taking what we learned with City of

Milwaukee and spreading the word.

  • Focus is on the LCCA, the requirement for

it and the policies required to use it effectively

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014

slide-56
SLIDE 56

Questions?

ACPA - Applying Life-Cycle Cost Analysis (LCCA) in Pavement Selection - June 24, 2014
