ACOUSTIC EMISSION FOR IDENTIFICATION OF THE DOMINANT STRESS COMPONENT IN POLYMER COMPOSITES AT EARLY LOADS 1 ST INTERNATIONAL ELECTRONIC CONFERENCE ON APPLIED SCIENCES Kalliopi-Artemi Kalteremidou, Dimitrios G. Aggelis, Danny Van Hemelrijck and

slide-1
SLIDE 1

1ST INTERNATIONAL ELECTRONIC CONFERENCE ON APPLIED SCIENCES

ACOUSTIC EMISSION FOR IDENTIFICATION OF THE DOMINANT STRESS COMPONENT IN POLYMER COMPOSITES AT EARLY LOADS

Kalliopi-Artemi Kalteremidou, Dimitrios G. Aggelis, Danny Van Hemelrijck and Lincy Pyl

slide-2
SLIDE 2

ASEC 2020 11-2020 | 2

PRESENTATION OUTLINE

  • Introduction
  • Theoretical background
  • Aim of the study
  • Material and testing equipment
  • Experimental results: quasi-static tests
  • Experimental results: incremental loading tests
  • Conclusions
slide-3
SLIDE 3

ASEC 2020 11-2020 | 3

INTRODUCTION

  • Reduction of weight → primary target in

many engineering fields

  • Fibre reinforced polymer composite

materials → promising for reducing weight and CO2 emissions

  • Main advantage: lightweight

materials

  • Carbon Fibre Reinforced Polymer

(CFRP): extra advantages like exceptional durability, application flexibility, corrosion resistance

slide-4
SLIDE 4

ASEC 2020 11-2020 | 4

THEORETICAL BACKGROUND

  • Composites: anisotropic materials
  • Multiaxial stresses occur in the composite laminas even under uniaxial loading

due to different fibre orientations (internal multiaxiality)

slide-5
SLIDE 5

ASEC 2020 11-2020 | 5

THEORETICAL BACKGROUND

  • Damage sequence in composites is complicated (interfacial debondings, matrix

cracks, delaminations, fibre breaks)

  • Even more complicated when multiaxial stresses occur → can lead to different

mechanical response, influencing the structural integrity of the laminate

slide-6
SLIDE 6

ASEC 2020 11-2020 | 6

THEORETICAL BACKGROUND

  • Multiaxiality not extensively studied in literature
  • Monitoring of damage with respect to different multiaxial stresses in lab

conditions necessary → predictive tool for real applications

  • Prediction of stress states and identification of dominant stresses essential

even from early loading stages

  • Acoustic Emission (AE) CAN be used to give solutions to these problems!
slide-7
SLIDE 7

ASEC 2020 11-2020 | 7

THEORETICAL BACKGROUND

  • Acoustic Emission: characterisation of

damage of materials by interpreting the generated elastic waves

  • Commonly applied in composite materials for

investigations in the time domain and frequency domain

  • Clustering approaches have been proposed
  • No link to multiaxial stress states
slide-8
SLIDE 8

ASEC 2020 11-2020 | 8

THEORETICAL BACKGROUND

  • Feature analysis: selection of the most

appropriate signal features

  • It has been used so far for damage mode

classification

  • Rise Time (RT) and Average Frequency (AF)

among the most popular

slide-9
SLIDE 9

ASEC 2020 11-2020 | 9

THEORETICAL BACKGROUND

  • Kaiser effect: the absence of detectable AE

until the previously maximum applied stress is exceeded

  • Felicity effect: the presence of detectable AE at

stress levels below those previously applied → described by the Felicity Ratio (FR)

  • 𝐺𝑆=

stress level at which AE resumes during a loading step maximum stress applied at the previous loading step

  • The Calm Ratio (CR) can be another damage

parameter

  • 𝐷𝑆=

AE activity during the unloading part of the cycle AE activity over the total cycle

slide-10
SLIDE 10

ASEC 2020 11-2020 | 10

AIM OF THE STUDY

  • To verify that AE can distinguish the different damage modes under

multiaxial stress states

  • Can AE indicate the dominant stress/strain component within the composite

laminate from early loading stages?

  • Which AE parameters are the most effective for such stress indications?
slide-11
SLIDE 11

ASEC 2020 11-2020 | 11

MATERIAL AND TESTING EQUIPMENT

  • To introduce different multiaxial stress

states → two angle-ply carbon/epoxy laminates were tested

  • Based on the multiaxiality ratio

λ12=σ6/σ2

Loading direction

[0o/30o]2s: λ12=2.02 [0o/60o]2s: λ12=0.64 [0o/30o]2s: dominant shear stresses [0o/60o]2s: dominant transverse stresses

slide-12
SLIDE 12

ASEC 2020 11-2020 | 12

MATERIAL AND TESTING EQUIPMENT

  • Continuous static tests and interrupted tests

displacement controlled at 1 mm/min rate

  • Two Pico sensors for the AE acquisition → 35 dB

threshold

  • Digital Image Correlation (DIC) for strain

measurements

  • Through-the-thickness free-edge damage

monitoring at regular steps with optical microscopy

slide-13
SLIDE 13

ASEC 2020 11-2020 | 13

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

[0o/90o]2s laminates Tensile failure Shear failure

slide-14
SLIDE 14

ASEC 2020 11-2020 | 14

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

[0o/30o]2s laminates [0o/60o]2s laminates

slide-15
SLIDE 15

ASEC 2020 11-2020 | 15

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

AE onset

slide-16
SLIDE 16

ASEC 2020 11-2020 | 16

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

Appearance of delaminations

slide-17
SLIDE 17

ASEC 2020 11-2020 | 17

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

Appearance of matrix cracking Appearance of delaminations

slide-18
SLIDE 18

ASEC 2020 11-2020 | 18

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

Dominant shear stresses Dominant transverse stresses

slide-19
SLIDE 19

ASEC 2020 11-2020 | 19

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

slide-20
SLIDE 20

ASEC 2020 11-2020 | 20

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

slide-21
SLIDE 21

ASEC 2020 11-2020 | 21

EXPERIMENTAL RESULTS: QUASI-STATIC TESTS

slide-22
SLIDE 22

ASEC 2020 11-2020 | 22

EXPERIMENTAL RESULTS: INCREMENTAL LOADING TESTS

slide-23
SLIDE 23

ASEC 2020 11-2020 | 23

EXPERIMENTAL RESULTS: INCREMENTAL LOADING TESTS

slide-24
SLIDE 24

ASEC 2020 11-2020 | 24

EXPERIMENTAL RESULTS: INCREMENTAL LOADING TESTS

slide-25
SLIDE 25

ASEC 2020 11-2020 | 25

EXPERIMENTAL RESULTS: INCREMENTAL LOADING TESTS

Dominant shear stresses Dominant transverse stresses

slide-26
SLIDE 26

ASEC 2020 11-2020 | 26

EXPERIMENTAL RESULTS: INCREMENTAL LOADING TESTS

slide-27
SLIDE 27

ASEC 2020 11-2020 | 27

CONCLUSIONS

  • AE can be effectively used for the identification of damage in polymer composites
  • Significant differences from early loading stages allowing indications of the dominant stress

component

  • RT good indicator for the identification of damage modes and the transition between modes
  • Low RT linked to tensile related phenomena and high RT to shear related phenomena
  • Continuous increase of RT when shear is dominant
  • FR is characterised by reduction when delaminations occur → can be used as damage mode

transition indicator

  • FR appears lower values when shear is dominant → FR is not only material dependent, but also

stress state dependent → can be used as stress state indicator

  • Higher CR values for shear dominated laminates even from early loads → can indicate the

dominant stress component and the consequent deterioration
