Abilene Observatory Datasets Matt Zekauskas, matt@internet2.edu 03-Jun-2004 Major Datasets, roughly size order Flow data (last 11bits of IP zeroed) Latency (one-way, 2*11^2 paths (v4, v6)) Near future: IGP (IS-IS updates/node)

slide-1
SLIDE 1

03-Jun-2004

Abilene Observatory Datasets

Matt Zekauskas, matt@internet2.edu

slide-2
SLIDE 2

03-Jun-2004 2

Major Datasets, roughly size order

Flow data (last 11bits of IP zeroed) Latency (one-way, 2*11^2 paths (v4, v6)) Near future: IGP (IS-IS updates/node) SYSLOG from router (internal at least, future) Router snapshots 1 and 5 min SNMP usage, errors Throughput (iperf, 1Gb limited, 2*2*11^2 sets (v4, v6, TCP, UDP)) [multicast]

slide-3
SLIDE 3

03-Jun-2004 3

Common Theme

Summaries available via Web

  • Graphs, Tables
  • Time series (of summaries) via “web services”

Raw data in diverse formats, only by special request (often on HPSS / MSS)

  • (Probably) not enough metadata kept
  • Stored by date; some tarballs
  • Recovery is a manual process
  • Except router snapshots. Have all XML files.

Flow data gone after 30 days

slide-4
SLIDE 4

03-Jun-2004 4

Other problems

Stuff is archived in many places (with different administrative hurdles)

  • OSU, Columbus [RAID]
  • IU, Bloomington [HPSS]
  • Internet2 / Ann Arbor [RAID, tape]

Although all “available” off of http://abilene.internet2.edu/observatory it’s a twisty maze of Web links (and no access to archived data) Validation? Know some of flow data bad…

slide-5
SLIDE 5

03-Jun-2004 5

Some future plans

New databases: IGP, BGP Looking to use a DHS grant to help clean up databases & improve access Hope to contribute to this effort

slide-6
SLIDE 6

03-Jun-2004 6

URLs

http://abilene.internet2.edu/observatory

  • Pointers to all measurements/sites/projects
  • Particularly

http://abilene.internet2.edu/observatory/data-views.html

http://www.abilene.iu.edu/

  • NOC home page. Weathermap, Proxy, SNMP measurements

http://netflow.internet2.edu/weekly/

  • Summarized flow data

http://www.itec.oar.net/abilene-netflow/

  • “Raw” – matricies; (Anon) feeds available on request
slide-7
SLIDE 7

03-Jun-2004

Details on select datasets

slide-8
SLIDE 8

03-Jun-2004 8

Flow data

Collected using Mark Fullmer’s flowtools

  • 1/100 sampling ; may be losing some, bet don’t note

Stored (last 11 bits zeroed) on a RAID for 30 days Summaries stored forever

  • http://www.itec.oar.net/abilene-netflow/
  • http://netflow.internet2.edu/weekly/

Raw: access via rsync.

  • One directory per day per router
  • Files with 5 min chunks (so 288/day)
  • Not necessarily available in real time, <=24 hr delay possible
slide-9
SLIDE 9

03-Jun-2004 9

Latency

Our own owamp implementation

  • 1/sec poisson ; full mesh among router nodes

Summaries

  • Stored in mySQL
  • Web displays, including graphical and “worst 10”
  • XML/SOAP access

http://abilene.internet2.edu/ami/webservices.html using GGF Network Measurement WG schema…

Raw

  • Directory per path per day
  • Tar in to one large file per day, then compressed
  • HPSS, no public access
slide-10
SLIDE 10

03-Jun-2004 10

Router Snapshots

1/hr query of routers using XML & Junoscript; config, routing state, interface status… Raw

  • Stored as compressed XML files forever
  • Access via SOAP/XML or fetching files
  • http://loadrunner.uits.iu.edu/~gcbrowni/Abilene/raw-data.html

Web page veneer

  • http://loadrunner.uits.iu.edu/~gcbrowni/Abilene/
  • Current status, and also old available by date
  • Some processed more than others (including some into rrd

files and graphs [rrd files available in addition to graphs])

slide-11
SLIDE 11

03-Jun-2004 11

5 min SNMP

Polled using custom software, stored into RRD files Access depends on link type

  • Backbone from weathermap
  • Access by clicking on map of router nodes
  • Either way, end up with typical MRTG-style

Raw

  • RRD files for current day off MRTG-style page
  • RRD files stored per day (I believe) on HPSS

–No public access, but should be available on request

slide-12
SLIDE 12

03-Jun-2004 12

slide-13
SLIDE 13

03-Jun-2004 13

Questions

Brief description of data sets Tools used (?) Cataloging and Archiving the data Problems with the data Desirable database support Future plans

slide-14
SLIDE 14

03-Jun-2004 14

Observatory

Publishing measurement data

  • Stuff we collect for operations
  • Stuff we collect for research

The ability for research projects to add their equipment, or run software on our platform

  • Peer reviewed
  • Why? Passive, collocation makes analysis easier
  • AMP, PMA, Planetlab
