A WARDS 2 O RIGIN OF I DEA W ATERSHORTAGE 3 O UR G OAL G LOBAL W - PowerPoint PPT Presentation

A WARDS 2

O RIGIN OF I DEA W ATERSHORTAGE 3

O UR G OAL G LOBAL W ATER S AVING 4

M ECCA M ILLIONS O F P RAYER Every Muslim is undergoing the ablution five times a day During each ablution drinking water is used 5

G LOBAL WATER CONSUMPTION I NTERNET R ESOURCE : WIKIPEDIA . ORG 6

W UDU / A BLUTION Mosque Entry ablution area Ablution area / Wudu 7

U SE AS LESS WATER AS POSSIBLE 8

P ROTOTYPING F OR W UDU W ASH D ESIGN C ONCEPTS BY B AGNO S ASSO M OBILI 9

T EST IN L ABORATORY , Z URICH 10

T EST IN M OSQUE , D UBAI Ablution / Wudu first go 11

W ATERCONSUMPTION S TANDARD T AP From the standard draw-off tap 1 liter of water flows within 3 seconds. 1 liter 3 seconds From a self-closing tap 1 liter of water flows in 16 seconds. By longer sessions the valve must always be pressed in again, which can be unpleasant for the user (mosque). 1 liter 16 seconds 12

W ATERCONSUMPTION S WISS E CO T AP 1 LITER 116 SECONDS The Swiss Eco Tap sprays 1 liter of water in 116 seconds. The consumption of the Swiss Eco Tap valve is 3% at an equal time of wash compared to the standard valve. 13

C OMPARISON W ATERCONSUMPTION S WISS E CO T AP S TANDARD C OMPETITOR S WISS E CO T AP 14

The ECO-water jet uses 90% less water than a conventional outlet valve, thus protecting the resources and the environment. Several turbulators in the ECO-tap increase the internal energy of water flow, which is set free by exiting the nozzle. While using a minimum of water a high cleaning effect is achieved. This creates a very pleasant feeling to the skin. 15

F EATURES • 90 % less waterconsumption • 100 % energy saving due to cold water • 0 % energy consumption costs • no costs for warm water preparation • no uncomfortable sence to coldness on skin due to a special spraytechnique • quick cleaning power 16

P ILLAR T AP 17

W HERE TO USE 18

W ORLDWIDE S ALE 19

S ALE D ISPLAY & P ACKAGING selling boxes presentation case versions and surfaces 20

D IMENSIONAL D RAWING 21

S WISS E CO T AP / S WISS E CO F OAM PERFECT COMBINATION • biodegradable soap foam • hardly requires water • 58% cost reduction • 5dl for 1200 washes 22

S OME R EFERENCES 23

A QUATOWER F IRST S KYSCRAPER W ITH L ESS E NERGY www.aquaturm.de 24

EAWAG, D ÜBENDORF S WITZERLAND G OVERNMENT B UILDING , B ELGIUM A IRPORT , T IMISOARA R OMANIA R ESTAURANT R OTHORN , L ENZERHEIDE S WITZERLAND 25

T SCHUGGENHÜTTE , A ROSA S WITZERLAND C ARMENNAHÜTTE , A ROSA S WITZERLAND W EISSHORN , A ROSA S WITZERLAND H ÖRNLIHÜTTE , A ROSA S WITZERLAND 26

S TATEMENTS « In a modern passiv house building heating is negligible. This does not hold true for the hot water consumption. The spray valves in fixures represent a quantum leap in building techniques. The technology saves 90% of water consumption and 100% of hot water energy – just brilliant. » Dietrich Schwarz Prof. Dipl. Arch. ETH / SIA Glas X, Zürich «The combination of ecology, technology and design has been implemented perfectly in the new spray tap. Once again it has been proved how highly innovative Swiss SME’s are - congratulations» Diego Brüesch Eidg. Dipl. Sanitärplaner und Heizungstechniker HF Guyer Wärme und Wasser AG, Zürich 27

«The spray tap is a sign of understanding - the understanding of a task, the understanding of a need. The faucet is a sign far across the object. The fitting leads to a change in thinking not only in terms of water consumption but also in respect of the building, an essential approach to reduce today’s building installations.» Mark Aurel Wyss Dipl. Arch. ETH / SIA / BSA Wyss Architekten, Zollikon «Genial - brilliant idea / genius realization - overall brilliant. We should all be proud that such products have their origin in Switzerland . At a stroke, the water consumption for washing hands is reduced by more than a factor of 10 . Hot water is unnecessary - try this faucet, it will convince you.» Balzer Ingenieure AG Chur / Winterthur 28

Saving water and energy - combined with design! This technology will revolutionize the sanitary world. After having installed the first taps at the facilities of selected customers, the demand for these fittings began to rise continuously. Our technicians and even our customers have always new ideas for different applications. Even the kitchen manufacturer: He wants to use this tap as an additional fitting for pre-cleaning the dishes and to clean fruits and vegetables. Major customers have quickly realized that they cannot only save water and energy with this technology, Axel Burg but they can also minimize maintenance costs. The possibilities Owner and CEO of Burg Sanitär und where to use this tap are really endless ....... Heizungstechnik GmbH / OffenburgGermany, in the 4th generation 29

P RODUCT O F : General Distribution of Canada / USA www.swissecotap.com KEMA Nano Tec Inc. 87 Morland Crescent D ESIGNED B Y : Aurora, ON L4G 7Z1 Canada Phone: 1-647-267-7075 Email: mhilgerink@kema-nanotec.com Website: www.kema-nanotec.com www.bagnosasso.com 30
