A Testbed For Policy Closed Loop Network Management 1 Outline of the presentation In this presentation we will cover the following points: Paper Contribution System Architecture Network Configuration and Scenario The Policy and


slide-1
SLIDE 1

1

A Testbed For Policy Closed Loop Network Management

slide-2
SLIDE 2

2

Outline of the presentation

In this presentation we will cover the following points:

  • Paper Contribution
  • System Architecture
  • Network Configuration and Scenario
  • The Policy and Decision
  • Future Work
  • Demo and Questions
slide-3
SLIDE 3

3

Contributions of our Work

  • Straightforward method to test management policies
  • Test bed for the deployment of policies
  • onto realistic networks
  • Quick evaluation of policies
  • through real time monitoring
slide-4
SLIDE 4

4

System Architecture

slide-5
SLIDE 5

5

Network Configuration and Scenario

  • Mininet hosts, switches and links are created and

handled by Floodlight controller

  • VLC Player is used to stream video across the network
slide-6
SLIDE 6

6

Network Configuration and Scenario

  • Central link is confgured with a restricted bandwidth
  • While both paths are open the video stream is not

negatvely afected by the restricton

slide-7
SLIDE 7

7

Network Configuration and Scenario

  • During the video stream a central link is brought down
  • Forcing both video streams to travel over the

restricted link

slide-8
SLIDE 8

8

The Policy Component

slide-9
SLIDE 9

9

SLA Decision

  • Analyses customer context information to ensure no

customers have violated Service Level Agreements

  • Identifies the customer furthest from violating their SLA
  • Restriction of identified customer, granting optimal

bandwidth for the other stream

slide-10
SLIDE 10

10

Priority Decision

  • Analyses customer context information to extract customer

priority status

  • Customers who are not prioritised are identified
  • Restriction of customers without priority, leaving the

prioritised customer stream unaffected.

slide-11
SLIDE 11

11

Future Work Where we want to take this

slide-12
SLIDE 12

12

Demo

slide-13
SLIDE 13

13

Thanks for listening
