A Statistical Framework for Designing On-chip Thermal Sensing Infrastructure

Yufu Zhang, Bing Shi, Ankur Srivastava

University of Maryland, College Park

{yufuzh, bingshi, ankurs}@umd.edu

2

Outline

 Motivation/overview  Fusion center design  Sensor design/compression

 Noisy sensor behavior  Exploiting the correlation

 Sensor placement  Overall flow and interplay  Results and conclusion

3

Motivation

 Thermal/power stress

 Heavy task execution  Increasing chip density  Leakage power

 Dynamic thermal management (DTM)

 Essentially sacrificing performance for lower temperature  Need accurate runtime thermal information

4

Motivation

 Need sensors to provide accurate runtime

thermal input

 On-chip thermal sensors

 On-chip sensors can sample the thermal state of the

chip during runtime

Counter Sensor Output Enabled for a fixed period of time tp

EN

A simple ring

• scillator-based

thermal sensor

Motivation

 Several problems for a naïve thermal

sensing scheme.

 Sensors cannot go everywhere  Sensors are subject to noise  Resource is limited

 Our goal --- a complete thermal sensing

infrastructure that includes:

 Sensor design/compression  Sensor placement  Data fusion

5

Overall structure

6

Fusion Center Design

 Central register (finite size M)

 Could be a single or multiple actual registers

 Fusion algorithm

 Model the thermal profile as a random vector T  Predict (T) given the sensor obs vector (TS)  Exploit statistical information (mean, var, correlation etc.)

 Bayesian Estimation Philosophy

7

1

( | ) ( )

S S T S TS SS

E T T T µ µ

−

= + Σ Σ −          

( | ) ( )

TS T S T S S S

E T T T ρ σ µ µ σ = + −

Scalar case: Vector case:

85 90 95 100 105 110 115 500 1000 1500 2000 2500 3000 3500 4000 Temperature (degrees Celsius) Number of samples

Fusion Center Design

 Given sensor input, the variance of T is reduced to:

 Diagonal elements – variance of the thermal estimates.  Reflects the fundamental uncertainty of our estimation.

(how far away our estimates are from the real temperature)

 Used to drive sensor placement.

 A better metric to drive sensor placement?

 Sensors are not like cameras  Generate the probability of capturing all hotspots

8



( )

1

( ( | )) ( ( | ))T

TT s s TT TS SS ST

E T E T T T E T T

−

Σ = − ⋅ − = Σ − Σ Σ Σ

Sensor Design

 Noisy sensor behavior (Monte Carlo Simulation)  Sensor readings are

compressed as well due to center register size constraint

 Hypothesis testing

9

1 1 ( )

PHL PLH

f P N t t = = +

3 4 2 1 ln ( / ) ( ) 2

t DD t PHL n

• x

n DD t DD t DD

V V V C t C W L V V V V V µ     − = +     − −    

0.002( )

t t

V V T T = + −

1.5 /

( / )

n p

T T µ µ

−

=

50 100 150 200 250 300 350 0.5 1 1.5 2 2.5 3 3.5x 10

4

Sensor frequency(MHz) Number of samples

T = 20°C T = 40°C T = 100°C T = 80°C T = 60°C

Counter Sensor Output Enabled for a fixed period of time tp

EN

Sensor Design

 Target: minimize the expected prediction error:

 Optimal decision rule:  Implement as an encoder at the sensor output

10

1

(| | ) | | ( | )

pred real

• bs

n pred i real i

• bs

i

Cost E T T T T H prob T H T

=

= − = − ⋅ =

∑

1

( | ) ( ) ( | ) ( | )

• bs

real i i

• bs
• bs

real i i n

• bs

real j j j

prob T T H P prob T prob T T H P prob T T H P

=

= ⋅ = = ⋅ = = ⋅

∑

1...

( ) arg min (| | )

pred n

pred

• bs

pred real

• bs

T H H

T T E T T T δ

=

= = −

Bayes rule

Sensor and fusion center co-design

 How do we compress sensors so that…

 They fit into the central register  Collectively they provide better accuracy

• --- more compressed sensors vs fewer non-compressed ones

 Bit allocation problem:

 Decide how to allocate a total of M bits to n sensors so that the

• verall expected estimation error is minimum:

(suppose si is the number of bits allocated to sensor i )

Minimize Subject to

11

1 2

( ( , ,..., ))

n

E error s s s

i i i i

s b s M ≤ ≤    =  ∑

Sensor Compression

 Target: to reduce the overall expected error caused by

sensor compression.

 Different compression scheme leads to different overall error.  Can be formulated as a optimization problem (see details in our

paper).

12

( )

1 2 : 1

( , ,..., ) | ( | ) ( | ) | | ( ) |

n c a s s i i grids i c a s s TS SS rows

TotalCost E error s s s E E T T E T T E T T

∀ − ∀

=   = −       = Σ Σ −    

∑ ∑

       

1

( | ) ( )

i

S i S S T TS SS

E T T T µ µ

−

= + Σ Σ −      

Sensor Placement

 Let “S” and “T” represent the set of sensor

locations and all chip locations, respectively.

 Problem formulation:  As mentioned earlier represents the

fundamental uncertainty/variance associated with our thermal estimates

13



| | ( )

TT

choose S T with S n such that trace is minimized ⊂ = Σ

TT

Σ



1 TT TT TS SS ST −

Σ = Σ − Σ Σ Σ

Sensor Placement Algorithm

14

Overall flow and interplay

15

Sensor placement Bit allocation/ sensor compression Evaluate overall E(error) = Fusion center design total size of CR = M Design spec Statistical info Too much error? Yes Increase number of sensors No Done



( )

TT

trace Σ

Experimental Results

16

1200 1300 1400 1500 1600 1700 1800 75 80 85 90 95 100 105 Time (seconds) Temperature (degrees Celsius) Actual temperature Our estimates Range-based estimates

• Fig. 1 Dynamic temperature tracking curves

Experimental Results

17

• Fig. 2 RMS error comparison when increasing

the number of sensors

Conclusion

 We presented a unified statistical framework for

designing a complete thermal sensing infrastructure.

 Significant improvement in thermal sensing accuracy can

be achieved with very small overhead

 Our methodology has the capability of trading off

complexity for accuracy at will. It also takes into account various design considerations such as sensor noise and area constraints.

18

19

Thank you!
