A SHORT INTRODUCTION TO TWO-PHASE FLOWS Condensation and boiling - - PowerPoint PPT Presentation

A SHORT INTRODUCTION TO TWO-PHASE FLOWS Condensation and boiling heat transfer Herv e Lemonnier DM2S/STMF/LIEFT, CEA/Grenoble, 38054 Grenoble Cedex 9 Ph. +33(0)4 38 78 45 40, herve.lemonnier@cea.fr herve.lemonnier.sci.free.fr/TPF/TPF.htm


slide-1
SLIDE 1

A SHORT INTRODUCTION TO TWO-PHASE FLOWS Condensation and boiling heat transfer

Herv´ e Lemonnier DM2S/STMF/LIEFT, CEA/Grenoble, 38054 Grenoble Cedex 9

  • Ph. +33(0)4 38 78 45 40, herve.lemonnier@cea.fr

herve.lemonnier.sci.free.fr/TPF/TPF.htm ECP, 2011-2012

slide-2
SLIDE 2

HEAT TRANSFER MECHANISMS

  • Condensation heat transfer:

– drop condensation – film condensation

  • Boiling heat transfer:

– Pool boiling, natural convection, ´ ebullition en vase – Convective boiling, forced convection,

  • Only for pure fluids. For mixtures see specific studies. Usually in a

mixture, h xihi and possibly ≪ hi.

  • Many definitions of heat transfer coefficient,

h[W/m2/K] = q ∆T , Nu = hL k , k(T?)

Condensation and boiling heat transfer 1/42

slide-3
SLIDE 3

CONDENSATION OF PURE VAPOR

  • Flow patterns

– Liquid film flowing. – Drops, static, hydrophobic wall (θ ≈ π). Clean wall, better htc.

  • Fluid mixture non-condensible

gases: – Incondensible accumulation at cold places. – Diffusion resistance. – Heat transfer deteriorates. – Traces may alter significantly h

Condensation and boiling heat transfer 2/42

slide-4
SLIDE 4

FILM CONDENSATION

  • Thermodynamic equilibrium at the interface,

Ti = Tsat(p∞)

  • Local heat transfer coefficient,

h(z) q Ti − Tp = q Tsat − Tp

  • Averaged heat transfer coefficient,

h(L) 1 L L h(z)dz

  • NB: Binary mixtures Ti(xα, p) and pα(xα, p). Approximate equilibrium condi-

tions, – For non condensible gases in vapor, pV = xPsat(Ti), Raoult relation – For dissolved gases in water, pG = HxG, Henry’s relation

Condensation and boiling heat transfer 3/42

slide-5
SLIDE 5

CONTROLLING MECHANISMS

  • Slow film, little convective effect, conduction

through the film (main thermal resistance)

  • Heat transfer controlled by film characteristics,

thickness, waves, turbulence.

  • Heat transfer regimes,

Γ ML P , ReF 4Γ µL – Smooth, laminar, ReF < 30, – Wavy laminar, 30 < ReF < 1600 – Wavy turbulent, ReF > 1600

Condensation and boiling heat transfer 4/42

slide-6
SLIDE 6

CONDENSATION OF SATURATED STEAM

  • Simplest situation, only a single heat source: interface, stagnant vapor,
  • Laminar film (Nusselt, 1916, Rohsenow, 1956), correction 10 to 15%,

h(z) = k3

LρLg(ρL − ρV )(hLV +0, 68CP L[Tsat − TP ])

4µL(Tsat − TP )z 1

4

  • Averaged heat transfer coefficient (TW = cst) : h(z) ∝ z− 1

4 , h(L) = 4

3h(L)

  • Condensate film flow rate, energy balance at the interface,

Γ(L) = h(L)(Tsat − TP )L hLV

  • Heat transfer coefficient-flow rate relation,

¯ h(L) kL

  • µ2

L

ρL(ρL − ρV ) 1

3

= 1, 47 Re

− 1

3

F

  • hLV and ρV at saturation. kL, ρL at the film temperature TF 1

2(TW +Ti),

  • µ = 1

4(3µL(TP ) + µL(Ti)), exact when 1/µL linear with T.

Condensation and boiling heat transfer 5/42

slide-7
SLIDE 7

SUPERHEATED VAPOR

  • Two heat sources: vapor (TV > Ti) and interface.
  • Increase of heat transfer wrt to saturated conditions, empirical correction,

¯ hS(L) = ¯ h(L) 1 + CP V (TV − Tsat) hLV 1

4

  • Energy balance at the interface, film flow rate,

Γ(L) = ¯ hS(L)(TW − Tsat)L hLV + CP V (TV − Tsat)

Condensation and boiling heat transfer 6/42

slide-8
SLIDE 8

FILM FLOW RATE-HEAT TRANSFER COEFFICIENT

  • Laminar,

¯ h(L) kL

  • µ2

L

ρL(ρL − ρV ) 1

3

= 1, 47 Re

− 1

3

F

  • Wavy laminar and previous regime (Kutateladze, 1963), h(z) ∝ Re−0,22

F

), ¯ h(L) kL

  • µ2

L

ρL(ρL − ρV ) 1

3

= ReF 1, 08Re1,22

F

− 5, 2

  • Turbulent and previous regimes (Labuntsov, 1975), h(z) ∝ Re0,25

F

, ¯ h(L) kL

  • µ2

L

ρL(ρL − ρV ) 1

3

= ReF 8750 + 58Pr−0,5

F

(Re0,75

F

− 253)

  • NB: Implicit relation, ReF depends on h(L) through Γ.

Condensation and boiling heat transfer 7/42

slide-9
SLIDE 9

OTHER MISCELLANEOUS EFFECTS

  • Steam velocity, vV , when dominant effect,
  • Vv descending flow, vapor shear added to gravity,
  • Decreases fil thickness,
  • Delays transition to turbulence turbulence,

h ∝ τ

1 2

i

  • See for example Delhaye (2008, Ch. 9, p. 370)
  • When 2 effects are comparable, h1 stagnant, h2 with dominant shear ,

h = (h2

1 + h2 2)

1 2

Condensation and boiling heat transfer 8/42

slide-10
SLIDE 10

CONDENSATION ON HORIZONTAL TUBES

  • Heat transfer coefficient definition,

¯ h = 1 π π h(u)du

  • Stagnant vapor conditions, laminar film,

Nusselt (1916) ¯ h = 0.728 (0.70) k3

LρL(ρL − ρV )ghLV

µL(Tsat − Tp)D 1

4

  • 0.728, imposed temperature, 0.70, im-

posed heat flux.

  • Γ, film flow rate per unit length of tube.

Condensation and boiling heat transfer 9/42

slide-11
SLIDE 11
  • Film flow rate- heat transfer coefficient, energy balance,

¯ h kL

  • µ2

L

ρL(ρL − ρV ) 1

3

= 1.51 (1.47) Re

− 1

3

F

  • Vapor superheat and transport proprieties, same as vertical wall
  • Effect of steam velocity (Fujii),

¯ h h0 = 1.4 u2

V (Tsat − TP )kL

gDhLV µL 0.05 1 < ¯ h h0 < 1.7,

  • Tube number effect in bundles, (Kern, 1958),

h(1, N) h1 = N −1/6

Condensation and boiling heat transfer 10/42

slide-12
SLIDE 12

DROP CONDENSATION

  • Mechanisms,

– Nucleation at the wall, – Drop growth, – Coalescence, – Dripping down (non wetting wall)

  • Technological perspective,

– Wall doping or coating – Clean walls required, fragile – Surface energy gradient walls. Self- draining

Condensation and boiling heat transfer 11/42

slide-13
SLIDE 13
  • heat transfer coefficient,

1 h = 1 hG + 1 hd + 1 hi + 1 hco

  • G : non-condensible gas, d : drop, i : phase change, co coating thickness.
  • Non-condensible gases effect, ωi ≈ 0, 02 ⇒ h → h/5
  • Example, steam on copper, Tsat > 22oC, h in W/cm2/oC,

hd = min(0, 5 + 0, 2Tsat, 25)

Condensation and boiling heat transfer 12/42

slide-14
SLIDE 14

POOL BOILING

  • Nukiyama (1934)
  • Only one heat sink, stagnant saturated

water,

  • Wire NiCr and Pt,

– Diameter: ≈ 50µm, – Length: l – Imposed power heating: P

Condensation and boiling heat transfer 13/42

slide-15
SLIDE 15

BOILING CURVE

  • Imposed heat flux,

P = qπDl = UI

  • Wall and wire temperature are equal,

D → 0 R(T) = U I , < | T> | 3 ≈ TW

  • Wall super-heat: ∆T = TW − Tsat
  • Heat transfer coefficient,

h q TW − Tsat

Condensation and boiling heat transfer 14/42

slide-16
SLIDE 16

BOILING CURVE

  • http://www-heat.uta.edu, Next

Condensation and boiling heat transfer 15/42

slide-17
SLIDE 17

HEAT TRANSFER REGIMES

  • OA: Natural convection
  • AD: Nucleate boiling
  • DH: Transition boiling
  • HG: Film boiling

Condensation and boiling heat transfer 16/42

slide-18
SLIDE 18

TRANSITION BOILING STABILITY

  • Wire energy balance,

MCv dT dt = P − qS

  • Linearize at ∆T0, q0, T = T0 + T1,

MCv dT1 dt = P − q0S

  • =0

−S ∂q ∂∆T T1

  • Solution, linear ODE,

T1 = T10 exp(−αt), α = S MCv ∂q ∂∆T

  • T0
  • 2 stable solutions, one unstable (DH),

∂q ∂∆T < 0

  • Transition boiling, imposed temperature experiments (Drew et M¨

uller, 1937).

Condensation and boiling heat transfer 17/42

slide-19
SLIDE 19

NATURAL CONVECTION

  • Wire diameter D, natural convection

q = h(TF − Tsat), Nu = hD k Pr = νL αL , Ra = gβ(TF − Tsat)D3 νLαL

  • Nusselt number is the non-dimensional heat transfer coefficient (h).
  • kL, αL, νL at the film temperature 1

2(TF + Tsat), β `

a Tsat.

  • Churchill & Chu (1975), 10−5 < Ra < 1012,

Nu =   0, 60 + 0, 387 Ra1/6

  • 1 +

0,559

Pr

9/168/27   

2

Condensation and boiling heat transfer 18/42

slide-20
SLIDE 20

NATURAL CONVECTION ON A FLAT PLATE

  • Scales A, P, plate area and perimeter. Length scale, L = A

P .

Nu = hL k = qL kL(TP − T∞), Ra = gβ(TP − T∞)L3 νLαL

  • Two regimes,

Nu =          0, 560 Ra1/4

  • 1 + (0, 492Pr)9/164/9

1 < Ra < 107 0, 14 Ra1/3 1 + 0, 0107Pr 1 + 0, 01Pr

  • 0, 024 Pr 2000,

Ra < 2 1011

  • Thermodynamic and transport properties Raithby & Hollands (1998). For

liquids: all at TF = 1

2(TP + T∞)

Condensation and boiling heat transfer 19/42

slide-21
SLIDE 21

ONSET OF NUCLEATE BOILING

  • Control parameters: pL et TW = TL∞
  • Super-heated wall: TL∞ = Tsat(pL) + ∆T
  • Site distribution: r, R = R(r, θ)
  • Mechanical balance: pV = pL + 2σ

R

  • Thermodynamic equilibrium:

pV = psat(TLi) ⇒ TLi = Tsat(pV ) TLi = Tsat(pL+2σ R ) ≈ (TL∞−∆T)+2σ R dT dp sat

  • Heat flux to interface: q > 0, ˙

R > 0 q = h(TL∞ − TLi) = h

  • ∆T − 2σ

R dT dp sat

  • ∆T > ∆Teq = 2σ

R dT dp sat,

R > Req =

2σ ∆T dT dp sat

1 bar, ∆T = 3oC, Req = 5, 2 µm, 155 bar, ∆T = 3oC, Req = 0, 08 µm

Condensation and boiling heat transfer 20/42

slide-22
SLIDE 22

NUCLEATE BOILING MECHANISMS

  • Super-heated liquid transport, Yagumata et al.

(1955) q ∝ (TP − Tsat)1.2n0.33

  • n: active sites number density,

n ∝ ∆T 5÷6

sat

⇒ q ∝ ∆T 3

sat

  • Very hight heat transfer, precision unneces-

sary.

  • Rohsenow (1952), analogy with convective h. t.: Nu = CReaPrb,
  • Scales : Re = ρLV L

µL , – Length: detachment diameter, capillary length: L ≈

  • σ

g(ρL−ρV )

– Liquid velocity: energy balance, q = ˙ mhLV , V ≈

q ρLhLV

Ja CpL(TP − Tsat) hLV = CsfRe0.33Prs

L

  • Csf ≈ 0.013, s = 1 water, s = 1.7 other fluids.

Condensation and boiling heat transfer 21/42

slide-23
SLIDE 23

BOILING CRISIS, CRITICAL HEAT FLUX

  • Flow pattern close to CHF: critical heat flux), Rayleigh-Taylor instability,
  • Stability of the vapor column: Kelvin-Helmholtz,
  • Energy balance over A,

λT = 2π √ 3

  • σ

g(ρL − ρV ), 1 2ρV U 2

V < π σ

λH , qA = ρV UV AJhLV

Condensation and boiling heat transfer 22/42

slide-24
SLIDE 24
  • Zuber (1958), jet radius RJ = 1

4λT , λH = 2πRJ, marginal stability,

qCHF = 0.12ρ1/2

V hLV

4

  • σg(ρV − ρL)
  • Lienhard & Dhir (1973), jet radius RJ = 1

4λT , λH = λT ,

qCHF = 0.15ρ1/2

V hLV

4

  • σg(ρV − ρL)
  • Kutateladze (1948), dimensional analysis and experiments,

qCHF = 0.13ρ1/2

V hLV

4

  • σg(ρV − ρL)

Condensation and boiling heat transfer 23/42

slide-25
SLIDE 25

FILM BOILING

  • Analogy with condensation (Nusselt, Rohsenow), Bromley (1950), V ⇆ L

NuL = 0.62 ρV g(ρL − ρV )h′

LV D3

µV kV (TW − Tsat) 1

4

, h′

LV = hLV

  • 1 + 0.34CP V (TW − Tsat)

hLV

  • Transport and thermodynamical properties:

– Liquid at saturation Tsat, – Vapor at the film temperature, TF = 1

2(Tsat + TW ).

  • Radiation correction: TW > 300oC, ǫ : emissivity, σ = 5, 67 10−8 W/m2/K4

h = h(T < 300oC) + ǫσ(T 4

W − T 4 sat)

TW − Tsat

Condensation and boiling heat transfer 24/42

slide-26
SLIDE 26

TRANSITION BOILING

  • Minimum flux,

qmin = ChLV

4

  • σg(ρL − ρV )

(ρL + ρV )2 – Zuber (1959), C = 0.13, stability of film boiling, – Berenson (1960), C = 0, 09, rewetting, Liendenfrost temperature.

  • Scarce data in transition boiling,
  • Quick fix, ∆Tmin and ∆Tmax, from each neighboring regime (NB and FB),
  • Linear evolution in between (log-log plot!).

Condensation and boiling heat transfer 25/42

slide-27
SLIDE 27

SUB-COOLING EFFECT

  • Liquid sub-cooling, TL < Tsat, ∆Tsub Tsat − TL
  • Ivey & Morris (1961)

qC,sub = qC,sat

  • 1 + 0, 1

ρL ρV 3/4 CP L∆Tsub hLV

  • Condensation and boiling heat transfer

26/42

slide-28
SLIDE 28

CONVECTIVE BOILING REGIMES

→ Increasing heat flux, constant flow rate →

  • 1. Onset of nucleate boiling
  • 3. Liquid film dry-out
  • 2. Nucleate boiling suppression
  • 4. Super-heated vapor

Condensation and boiling heat transfer 27/42

slide-29
SLIDE 29

BACK TO THE EQUILIBRIUM (STEAM) QUALITY

  • Regime boundaries depend very much on z. Change of variable, xeq
  • Equilibrium quality, non dimensional mixture enthalpy,

xeq h − hLsat hLV

  • Energy balance, low velocity, stationary flows,

M dh dz = MhLV dxeq dz = qP

  • Uniform heat flux, xeq linear in z. Close to equilibrium, xeq ≈ x
  • According to the assumptions of the HEM,

0 > xeq single-phase liquid (sub-cooled) 0 < xeq < 1 two-phase, saturated 1 < xeq single-phase vapor (super-heated)

Condensation and boiling heat transfer 28/42

slide-30
SLIDE 30

CONVECTIVE HEAT TRANSFER IN VERTICAL FLOWS

Boiling flow description

  • Constant heat flux heating,
  • Fluid temperature evolution, (Tsat),
  • Wall temperature measurement,
  • Flow regime,
  • Heat transfer controlling mechanism.

Condensation and boiling heat transfer 29/42

slide-31
SLIDE 31

From the inlet, flow and heat transfer regimes,

  • Single-phase convection
  • Onset of nucleate boiling, ONB
  • Onset of signifiant void, OSV
  • Important points for pressure drop calculations, flow oscillations.

Condensation and boiling heat transfer 30/42

slide-32
SLIDE 32
  • Nucleate boiling suppression,
  • Liquid film dry-out, boiling crisis (I),
  • Single-phase vapor convection.

Condensation and boiling heat transfer 31/42

slide-33
SLIDE 33

HEAT TRANSFER COEFFICIENT

DO: dry-out, DNB: departure from nucleate boiling (saturated, sub-cooled), PDO: post dry-out, sat FB: saturated film boiling, Sc Film B: sub-cooled film boiling

Condensation and boiling heat transfer 32/42

slide-34
SLIDE 34

BOILING SURFACE

Condensation and boiling heat transfer 33/42

slide-35
SLIDE 35

S-Phase conv: single-phase convection, PB: partial boiling, NB: nucleate boiling (S, saturated, Sc, subcooled), FB: film boiling, PDO: post dry-out, DO: dry-out, DNB: departure from nucleate boiling.

Condensation and boiling heat transfer 34/42

slide-36
SLIDE 36

SINGLE-PHASE FORCED CONVECTION

  • Forced convection (Dittus & Boelter, Colburn), Re > 104,

Nu hD kL = 0, 023Re0,8Pr0,4, Re = GD µL , PrL = µLCP L kL

  • Fluid temperature, TF , mixing cup temperature, that corresponding to the

area-averaged mean enthalpy.

  • Transport properties at Tav

– Local heat transfer coefficient, q h(TW − TF ), Tav = 1 2(TW + TF ) – Averaged heat transfer coefficient (length L), ¯ q ¯ h( ¯ TW − ¯ TF ), ¯ TF = 1 2(TF in + TF out), Tav = 1 2( ¯ TW + ¯ TF )

  • Always check the original papers...

Condensation and boiling heat transfer 35/42

slide-37
SLIDE 37

NUCLEATE BOILING & SIGNIFICANT VOID

  • Onset and suppression of nucleate boiling, ONB, (Frost & Dzakowic, 1967),

TP − Tsat = 8σqTsat kLρV hLV 0,5 PrL

  • Onset of signifiant void, OSV, (Saha & Zuber, 1974)

Nu = qD kL(Tsat − TL) = 455, P´ e < 7 104, thermal regime St = q GCP L(Tsat − TL) = 0, 0065, P´ e > 7 104, hydrodynamic regime

Condensation and boiling heat transfer 36/42

slide-38
SLIDE 38

DEVELOPPED BOILING AND CONVECTION

  • Weighting of two mechanisms, xeq > 0 (Chen, 1966)

– Nucleate boiling(Forster & Zuber, 1955), S, suppression factor,same model for pool boiling, – Forced convection, Dittus Boelter, F, amplification factor, h = hFZS + hDBA 1 S = 1 + 2.53 10−6(ReF 1.25)1.17, F =    1 1/X 0.1 2.35(1/X + 0.213)0.736 1/X > 0.1

Condensation and boiling heat transfer 37/42

slide-39
SLIDE 39

CHEN CORRELATION (CT’D)

  • Nucleate boiling,

hF Z = 0.00122 k0.79

L

C0.45

pL ρ0.49 L

σµ0.29

L

h0.24

LV ρ0.24 V

(TW − Tsat)0.24∆p0.75

sat

  • Forced convection

hDB = 0.023 kL D Re0.8Pr0.4

L

  • From Clapeyron relation, slope of saturation line,

∆psat = hLV (TW − Tsat) Tsat(vV − vL)

  • Non dimensional numbers definitions,

Re = GD(1 − xeq) µL , X = 1 − xeq xeq 0.9 ρV ρL 0.5 µL µV 0.1 , PrL = µLCpL kL

  • NB: implicit in (TW − Tsat).

Condensation and boiling heat transfer 38/42

slide-40
SLIDE 40

CRITICAL HEAT FLUX

  • No general model.

– Dry-out, multi-field modeling – DNB, correlations or experiment in real bundles

  • Very sensitive to geometry, mixing grids,
  • Recourse to experiment is compulsory,
  • In general, qCHF(p, G, L, ∆Hi, ...), artificial reduction of dispersion.
  • For tubes and uniform heating, no length effect, qCHF(p, G, xeq)

– Tables by Groenveld, – Bowring (1972) correlation, best for water in tubes – Correlation by Katto & Ohno (1984), non dimensional, many fluids, regime identification.

Condensation and boiling heat transfer 39/42

slide-41
SLIDE 41

MAIN PARAMETERS EFFECT ON CHF

After Groeneveld & Snoek (1986), tube diameter, D = 8 mm.

1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 −20 20 40 60 80 100 CHF[kW/m2] exit quality [%] G=1000 kg/s/m2 P= 10 bar P= 30 bar P= 45 bar P= 70 bar P= 100 bar P= 150 bar P= 200 bar 1000 2000 3000 4000 5000 6000 −20 20 40 60 80 100 CHF[kW/m2] exit quality [%] p=150 bar G= 0 kg/s/m2 G=1000 kg/s/m2 G=5000 kg/s/m2 G=7500 kg/s/m2

  • Generally decreases with the increase of the exit quality. qCHF → 0, xeq → 1.
  • Generally increases with the increase of the mass flux,
  • CHF is non monotonic with pressure.

Condensation and boiling heat transfer 40/42

slide-42
SLIDE 42

MORE ON HEAT TRANSFER

  • Boiling and condensation,

– Delhaye (1990) – Delhaye (2008) – Roshenow et al. (1998) – Collier & Thome (1994) – Groeneveld & Snoek (1986)

  • Single-phase,

– Bird et al. (2007) – Bejan (1993)

Condensation and boiling heat transfer 41/42

slide-43
SLIDE 43

REFERENCES

Bejan, A. (ed). 1993. Heat transfer. John Wiley & Sons. Bird, R. B., Stewart, W. E., & Lightfoot, E. N. 2007. Transport phenomena. Revised second edn. John Wiley & Sons. Collier, J. G., & Thome, J. R. 1994. Convective boiling and condensation. third edn. Oxford: Clarendon Press. Delhaye, J. M. 1990. Transferts de chaleur : ebullition ou condensation des corps purs. Techniques de l’ing´ enieur. Delhaye, J.-M. 2008. Thermohydraulique des r´ eacteurs nucl´

  • eaires. Collection g´

enie atom-

  • ique. EDP Sciences.

Groeneveld, D. C., & Snoek, C. V. 1986. Multiphase Science and Technology. Vol. 2.

  • Hemisphere. G. F. Hewitt, J.-M. Delhaye, N. Zuber, Eds. Chap. 3: a comprehensive

examination of heat transfer correlations suitable for reactor safety analysis, pages 181–274. Raithby, G. D., & Hollands, K. G. 1998. Handbook of heat transfer. 3rd edn. McGraw-

  • Hill. W. M. Roshenow, J. P. Hartnett and Y. I Cho, Eds. Chap. 4-Natural convection,

pages 4.1–4.99. Roshenow, W. M., Hartnett, J. P., & Cho, Y. I. 1998. Handbook of heat transfer. 3rd

  • edn. McGraw-Hill.

Condensation and boiling heat transfer 42/42
