A Principled Intermediate Language for JavaScript Verification

Daiva Naudˇ zi¯ unien˙ e

Imperial College London

Resource Reasoning Meeting

2/40

The Team

Philippa Gardner Gareth Smith Thomas Wood Jos´ e Fragoso Santos Petar Maksimovi´ c

3/40

Running Example: Where is Alice?

var Person = function (x) { this.name = x; } Person.prototype.sayHi = function () { return ”Hi! I am ” + this.name; } var alice = new Person(”Alice”); alice .sayHi();

4/40

Where is Alice?

var Person = function (x) { this.name = x; }

Person.prototype.sayHi = function() { return “Hi! I am ” + this.name; } var alice = new Person(”Alice”); alice.sayHi();

1.Evaluate the function literal and assign to var Person

• 2. Evaluate the function literal,

and assign to “Person.prototype.sayHi”

• 3. Create new object
• 4. Evaluate function body with this being an object created in Step 3
• 5. Assign new object to var alice
• 6. Call alice.sayHi()

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop

xproto

5/40

Where is Alice?

var Person = function (x) { this.name = x; }

Person.prototype.sayHi = function() { return “Hi! I am ” + this.name; }

var alice = new Person(”Alice”); alice.sayHi();

• 1. Evaluate the function literal and assign to var Person

2.Evaluate the function literal, and assign to “Person.prototype.sayHi”

• 3. Create new object
• 4. Evaluate function body with this being an object created in Step 3
• 5. Assign new object to var alice
• 6. Call alice.sayHi()

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop sayHi:

xproto

6/40

Where is Alice?

var Person = function (x) { this.name = x; } Person.prototype.sayHi = function() { return “Hi! I am ” + this.name; } var alice =new Person(”Alice”); alice.sayHi();

• 1. Evaluate the function literal and assign to var Person
• 2. Evaluate the function literal,

and assign to “Person.prototype.sayHi”

3.Create new object

• 4. Evaluate function body with this being an object created in Step 3
• 5. Assign new object to var alice
• 6. Call alice.sayHi()

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop sayHi:

xproto

@proto:

xthis

7/40

Where is Alice?

var Person = function (x) { this.name = x; } Person.prototype.sayHi = function() { return “Hi! I am ” + this.name; } var alice =new Person(”Alice”); alice.sayHi();

• 1. Evaluate the function literal and assign to var Person
• 2. Evaluate the function literal,

and assign to “Person.prototype.sayHi”

• 3. Create new object

4.Evaluate function body with this being an object created in Step 3

• 5. Assign new object to var alice
• 6. Call alice.sayHi()

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop sayHi:

xproto

@proto: name: “Alice”

xthis

8/40

Where is Alice?

var Person = function (x) { this.name = x; } Person.prototype.sayHi = function() { return “Hi! I am ” + this.name; }

var alice = new Person(”Alice”);

alice.sayHi();

• 1. Evaluate the function literal and assign to var Person
• 2. Evaluate the function literal,

and assign to “Person.prototype.sayHi”

• 3. Create new object
• 4. Evaluate function body with this being an object created in Step 3

5.Assign new object to var alice

• 6. Call alice.sayHi()

alice: Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop sayHi:

xproto

@proto: name: “Alice”

xthis

9/40

Where is Alice?

var Person = function (x) { this.name = x; } Person.prototype.sayHi = function() { return “Hi! I am ” + this.name; } var alice = new Person(”Alice”);

alice.sayHi();

• 1. Evaluate the function literal and assign to var Person
• 2. Evaluate the function literal,

and assign to “Person.prototype.sayHi”

• 3. Create new object
• 4. Evaluate function body with this being an object created in Step 3
• 5. Assign new object to var alice

6.Call alice.sayHi()

alice: Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop sayHi:

xproto

@proto: name: “Alice”

xthis

10/40

Running Wrong Example: We Cannot Find Alice

var Person = function (x) { this.name = x; } Person.prototype.sayHi = function () { return ”Hi! I am ” + this.name; } var alice = Person(”Alice”); alice .sayHi();

11/40

We cannot find Alice

var Person = function (x) {

this.name = x;

} Person.prototype.sayHi = function() { return “Hi! I am ” + this.name; } var alice =Person(”Alice”); alice.sayHi();

• 1. Evaluate the function literal and assign to var Person
• 2. Evaluate the function literal,

and assign to “Person.prototype.sayHi”

• 3. Create new object

4.Evaluate function body with this being undefined

• 5. Assign return value to var alice
• 6. Call alice.sayHi()

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop sayHi:

xproto

@proto: name: “Alice”

xthis

12/40

Verifying JavaScript Programs

‘Towards a Program Logic for JavaScript’, POPL’12, Gardner, Maffeis, and Smith.

13/40

Overall Project

JSVerify: A verification tool for JavaScript programs based on an intermediate language JSIL

JS Logic JSIL Logic JSVerify ES5 Strict JSIL

14/40

From ES5 Strict to JSIL - Our choices

We implemented, tested, and proved correct a principled translation from ES5 Strict to JSIL. JSIL was specifically designed as a simple verification language for Javascript:

◮ small language; ◮ simple semantics; ◮ similar memory model to JavaScript’s

memory model.

ES5 Strict JSIL Principled Translation

15/40

JSIL

Simple goto language:

C ∈ Cmd

• x := E

| skip | goto l | goto [E] l1, l2 l denotes a label and E is an expression with no side effects.

16/40

JSIL

Procedure calls:

C ∈ Cmd

• x := E

| skip | goto l | goto [E] l1, l2 | x := p(E, . . . , E) p ∈ {E, eval, built-in-PId}

17/40

JSIL

JavaScript heap commands:

C ∈ Cmd

• x := E

| skip | goto l | goto [E] l1, l2 | x := p(E, . . . , E) | x := new() | x := hasField(E, E) | x := [E, E] | [E, E] := E | x := delete(E, E)

18/40

JSIL

Prototype-based inheritance:

C ∈ Cmd

• x := E

| skip | goto l | goto [E] l1, l2 | x := p(E, . . . , E) | x := new() | x := hasField(E, E) | x := [E, E] | [E, E] := E | x := delete(E, E) | x := protoField(E, E) | x := protoObj(E, E)

19/40

JSIL

C ∈ Cmd

• x := E

| skip | goto l | goto [E] l1, l2 | x := p(E, . . . , E) | x := new() | x := hasField(E, E) | x := [E, E] | [E, E] := E | x := delete(E, E) | x := protoField(E, E) | x := protoObj(E, E) Procedure

• proc PId(x1, . . . , xn){

0: C0 1: C1

. . .

m: Cm

}

20/40

JSIL Logic versus JS Logic

21/40

However...

The complexity of JavaScript does not

• disappear. It has moved to the code

generated by the translation

22/40

Back to Example: Where is Alice?

var Person = function (x) { this.name = x; } var alice = new Person(”Alice”);

23/40

Translating: Where is Alice in JSIL?

◮ The translation generates a top level procedure for each

function literal.

◮ The translation generates a special procedure main for the

global code.

◮ No nesting of procedures. JavaScript Code JSIL Code var Person = function (x) { ... } proc PProc(xsc, xthis, x){...} Whole Program proc main(){...}

24/40

Translating: Where is Alice in JSIL?

JavaScript Code

var Person =function (x) {

this.name = x; }

var alice = new Person(”Alice”);

1.Evaluate the function literal

• 2. Assign function object to var Person
• 3. Create new object
• 4. Evaluate function body with

this being an object created in Step 3

• 5. Assign new object to var alice

JSIL Code

xproto := new() [xproto, @proto] := lop xperson := new() [xperson, @code] := “PProc” [xperson, @scope] := [lg] [xperson, @proto] := lfp [xperson, “prototype”] := xproto

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop

xproto

25/40

Translating: Where is Alice in JSIL?

JavaScript Code

var Person = function (x) { this.name = x; }

var alice = new Person(”Alice”);

• 1. Evaluate the function literal

2.Assign function object to var Person

• 3. Create new object
• 4. Evaluate function body with

this being an object created in Step 3

• 5. Assign new object to var Alice

JSIL Code

[lg, “Person”] := xperson

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop

xproto

26/40

Translating: Where is Alice in JSIL?

JavaScript Code

var Person = function (x) { this.name = x; } var alice =new Person(”Alice”);

• 1. Evaluate the function literal
• 2. Assign function object to var Person

3.Create new object

• 4. Evaluate function body with

this being an object created in Step 3

• 5. Assign new object to var alice

JSIL Code

xthis := new() [xthis, @proto] := xproto

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop

xproto

@proto:

xthis

27/40

Translating: Where is Alice in JSIL?

JavaScript Code

var Person = function (x) { this.name = x; } var alice =new Person(”Alice”);

• 1. Evaluate the function literal
• 2. Assign function object to var Person
• 3. Create new object

4.Evaluate function body with this being an object created in Step 3

• 5. Assign new object to var alice

JSIL Code

xsc := [xperson, @scope] xf := [xperson, @code] xret := xf(xsc, xthis, “Alice”)

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop

xproto

@proto: name: “Alice”

xthis

28/40

Translating: Where is Alice in JSIL?

JavaScript Code

var Person = function (x) { this.name = x; }

var alice = new Person(”Alice”);

• 1. Evaluate the function literal
• 2. Assign function object to var Person
• 3. Create new object
• 4. Evaluate function body with

this being an object created in Step 3

5.Assign new object to var alice

JSIL Code

[lg, “alice”] := xthis

alice: Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop

xproto

@proto: name: “Alice”

xthis

29/40

Back to Wrong Example: We Cannot Find Alice

var Person = function (name) { this.name = name; } var alice = Person(”Alice”); We “forgot” the new.

30/40

Translating: We Cannot Find Alice

JavaScript Code

var Person = function (x) {

this.name = x;

} var alice =Person(”Alice”);

• 1. Evaluate the function literal
• 2. Assign function object to var Person
• 3. Create new object

4.Evaluate function body with this being undefined

• 5. Assign return value to var alice

JSIL Code

xsc := [xperson, @scope] xf := [xperson, @code] xret := xf(xsc, undefined, “Alice”)

Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

sayHi:

xproto

@proto: name: “Alice”

xthis

31/40

Simplifications

Naive translation, but makes soundness proof simple!

ES5 Strict JSIL Translation

32/40

Simplifications

Standard compiler optimizations, e.g. constant propagation, dead code elimination, algebraic simplifications etc.

ES5 Strict JSIL Translation Simplifications

33/40

Simplifications

Further simplifications using symbolic execution.

ES5 Strict JSIL Translation Further Simplifications

34/40

Trusted Translation

ES5 Strict JSIL

• Principled

Translation ◮ Proven correct with respect to an

• perational semantics

◮ Tested using Test262

35/40

Validating the JSIL Compiler

◮ We have used ES6 Test262 ◮ Targeted ES5 Strict Subset

Chapters 8-14 except for:

◮ Getters and Setters ◮ Arguments Object ◮ Property attributes

◮ We pass 100% of our targeted ES5

Strict subset

14998 Tests 11328 Tests 3575 Tests 2365 Tests ES5 Strict Mode Chapters 8-14 Targeted Fragment

36/40

JSVerify

◮ Program logic for JSIL and a symbolic execution tool based

• n Separation Logic

ES5 Strict + JS Logic Specs JSIL + JISL Specs Symbolic Execution Bi-abduction Logic Rules Entailment coreStar JSVerify

37/40

JSVerify - Specifying and Verifying the Example

JavaScript Code

var Person = function (x) { this.name = x } var alice = new Person(”Alice”);

JSIL Code

{(xthis, “name”) → } PProc(xsc, xthis, x){...}

• (xthis, “name”) → x∗

ret . = undefined

38/40

Specifying and Verifying the Example

Correct Example

   (xperson, @scope) → [lg]∗ (xperson, @code) → “PProc”∗ (xthis, “name”) →    xsc := [xperson, @scope] xf := [xperson, @code] xret := xf (xsc, xthis, “Alice”)          (xperson, @scope) → [lg]∗ (xperson, @code) → “PProc”∗ (xthis, “name”) → “Alice”∗ xsc . = [lg] ∗ xf . = “PProc”∗ xret . = undefined         

The spec:

{(xthis, “name”) → } PProc {(xthis, “name”) → x ∗ ret . = undefined} Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

@proto: lop

xproto

@proto: name: “Alice”

xthis

39/40

Specifying and Verifying the Wrong Example

Wrong Example

(xperson, @scope) → [lg]∗ (xperson, @code) → “PProc”

• xsc := [xperson, @scope]

xf := [xperson, @code] xret := xf (xsc, undefined, “Alice”)

ERROR!

The spec:

{(xthis, “name”) → } PProc {(xthis, “name”) → x ∗ ret . = undefined} Person:

lg

@code: “PProc” @scope: [lg] @proto: lfp prototype:

xperson

sayHi:

xproto

@proto: name: “Alice”

xthis

40/40

Connecting JSIL to other tools

ES5 Strict JSIL JSIL Logic INFER Facebook Tool CBMC Oxford/Amazon VIPER ETH JSVerify
