slide-1
SLIDE 1

A General Technique for Non-blocking Trees

Trevor Brown, University of Toronto, Canada Faith Ellen, University of Toronto, Canada Eric Ruppert, York University, Canada PPoPP 2014

Trevor Brown A General Technique for Non-blocking Trees

slide-2
SLIDE 2

Problem

Balanced binary search trees (BSTs) are important, but there has been little success implementing them without locks. Coarse-grained transactions. Limited concurrency, high abort rates, code needs fallback paths. Single-word CAS. Extremely complex algorithms and proofs or lack of rigorous proofs. Multi-word compare-and-swap (CAS). Inefficiency.

Trevor Brown A General Technique for Non-blocking Trees

slide-3
SLIDE 3

Previous Frameworks for Tree Updates

Tsay and Li (1994): wait-free trees using LL/SC.

Every update or search must copy an entire path from root to leaf.

Natarajan et al. (2013): extends Tsay and Li’s framework.

Searches no longer copy nodes. Updates can avoid copying some nodes in special cases. Updates must “lock” each node on a root to leaf path with CAS (similar to lock-coupling).

Trevor Brown A General Technique for Non-blocking Trees

slide-4
SLIDE 4

Goals of This Work

Goal 1 A template for efficient non-blocking implementation of down-trees that are: Linearizable Non-blocking Relatively simple to prove correct, and Allow disjoint updates to succeed concurrently. Goal 2 A practical, provably correct, non-blocking balanced BST.

Trevor Brown A General Technique for Non-blocking Trees

slide-5
SLIDE 5

LLX and SCX

The LLX and SCX primitives: can be implemented from CAS, and work on data records, which contain some mutable fields and some immutable fields LLX(r) returns a snapshot of the mutable fields of r SCX(V, R, field, new) by process p writes value new into field, which is a mutable field of a data record in V finalizes all data records in R

  • nly if no record in V has changed since p’s LLX on it

After a data record is finalized, no further changes allowed.

Trevor Brown A General Technique for Non-blocking Trees

slide-6
SLIDE 6

Template

We give a template using LLX/SCX to make local changes to a down-tree.

root

Any data structure based on a down-tree that follows our template for all its updates is automatically linearizable and non-blocking.

Trevor Brown A General Technique for Non-blocking Trees

slide-7
SLIDE 7

Representing a Tree Using Data Records

Represent each node as a data record. Child pointers are mutable fields. Other data stored in a node is immutable. (To change any of this data, a new copy of the node is made.)

Trevor Brown A General Technique for Non-blocking Trees

slide-8
SLIDE 8

Tree Update Template

top root

1

read child pointers, from root to some node top

2

LLX top and a contiguous set of its descendants

3

Select subgraph R to replace and create replacement subgraph N

4

Use SCX to change child pointer of par:

replaces R by N and finalizes R

  • nly if LLXed nodes unchanged

Requirements Children of R = Children of N Must LLX par and all nodes in R

Trevor Brown A General Technique for Non-blocking Trees

slide-9
SLIDE 9

Tree Update Template

top root

1

read child pointers, from root to some node top

2

LLX top and a contiguous set of its descendants

3

Select subgraph R to replace and create replacement subgraph N

4

Use SCX to change child pointer of par:

replaces R by N and finalizes R

  • nly if LLXed nodes unchanged

Requirements Children of R = Children of N Must LLX par and all nodes in R

Trevor Brown A General Technique for Non-blocking Trees

slide-10
SLIDE 10

Tree Update Template

N R top root

1

read child pointers, from root to some node top

2

LLX top and a contiguous set of its descendants

3

Select subgraph R to replace and create replacement subgraph N

4

Use SCX to change child pointer of par:

replaces R by N and finalizes R

  • nly if LLXed nodes unchanged

Requirements Children of R = Children of N Must LLX par and all nodes in R

Trevor Brown A General Technique for Non-blocking Trees

slide-11
SLIDE 11

Tree Update Template

par N R top root

1

read child pointers, from root to some node top

2

LLX top and a contiguous set of its descendants

3

Select subgraph R to replace and create replacement subgraph N

4

Use SCX to change child pointer of par:

replaces R by N and finalizes R

  • nly if LLXed nodes unchanged

Requirements Children of R = Children of N Must LLX par and all nodes in R

Trevor Brown A General Technique for Non-blocking Trees

slide-12
SLIDE 12

Tree Update Template

par N R top root

1

read child pointers, from root to some node top

2

LLX top and a contiguous set of its descendants

3

Select subgraph R to replace and create replacement subgraph N

4

Use SCX to change child pointer of par:

replaces R by N and finalizes R

  • nly if LLXed nodes unchanged

Requirements Children of R = Children of N Must LLX par and all nodes in R

Trevor Brown A General Technique for Non-blocking Trees

slide-13
SLIDE 13

Linearizing the Tree Updates

Linearization point of each update: its successful SCX. Invariant Tree is the same as it would be if tree updates were done in

  • rder by linearization points.

Trevor Brown A General Technique for Non-blocking Trees

slide-14
SLIDE 14

Fast Queries

Some queries can be done quickly by reads only. Example: SEARCH(k) in a BST Just read sequence of pointers from root to leaf. Ignore concurrent updates along the path Leaf reached was on the search path to k at some time during the SEARCH. This is sufficient to linearize the SEARCH

Trevor Brown A General Technique for Non-blocking Trees

slide-15
SLIDE 15

Non-blocking Balanced Trees

Braginsky and Petrank, SPAA 2012: B+tree. Natarajan, Savoie and Mittal, SSS 2013: red-black tree using wait-free tree framework.

Trevor Brown A General Technique for Non-blocking Trees

slide-16
SLIDE 16

Red-Black Trees

Each node is red or black. Root is black. Leaves are black. Red nodes have black parents. Every root to leaf path contains the same number of black nodes. Search, Insert, Delete take O(log n) steps. amortized O(1) rebalancing steps per update

Trevor Brown A General Technique for Non-blocking Trees

slide-17
SLIDE 17

Red-Black Trees

Each node is red or black. Root is black. Leaves are black. Red nodes have black parents. Every root to leaf path contains the same number of black nodes. Search, Insert, Delete take O(log n) steps. amortized O(1) rebalancing steps per update

Trevor Brown A General Technique for Non-blocking Trees

slide-18
SLIDE 18

Red-Black Trees

Each node is red or black. Root is black. Leaves are black. Red nodes have black parents. Every root to leaf path contains the same number of black nodes. Search, Insert, Delete take O(log n) steps. amortized O(1) rebalancing steps per update

Trevor Brown A General Technique for Non-blocking Trees

slide-19
SLIDE 19

Concurrent Red-Black Trees

Each update and its necessary rebalancing steps must be performed atomically. Limits concurrency. Solution: decouple reblancing from updating, so they can be interleaved.

Trevor Brown A General Technique for Non-blocking Trees

slide-20
SLIDE 20

Concurrent Red-Black Trees

Each update and its necessary rebalancing steps must be performed atomically. Limits concurrency. Solution: decouple reblancing from updating, so they can be interleaved.

Trevor Brown A General Technique for Non-blocking Trees

slide-21
SLIDE 21

Chromatic Tree

Relaxed version of red-black tree designed for use with locks. allow red node to have a red parent (red-red violation). allow a black node to count more than others (overweight violation). a chromatic tree with no violations is a red-black tree. rebalancing steps can be deferred and interleaved with inserts and deletes. amortized O(1) rebalancing steps per insert or delete. 22 different rebalancing steps.

Trevor Brown A General Technique for Non-blocking Trees

slide-22
SLIDE 22

Chromatic Tree

Relaxed version of red-black tree designed for use with locks. allow red node to have a red parent (red-red violation). allow a black node to count more than others (overweight violation). a chromatic tree with no violations is a red-black tree. rebalancing steps can be deferred and interleaved with inserts and deletes. amortized O(1) rebalancing steps per insert or delete. 22 different rebalancing steps.

Trevor Brown A General Technique for Non-blocking Trees

slide-23
SLIDE 23

Chromatic Tree

Relaxed version of red-black tree designed for use with locks. allow red node to have a red parent (red-red violation). allow a black node to count more than others (overweight violation). a chromatic tree with no violations is a red-black tree. rebalancing steps can be deferred and interleaved with inserts and deletes. amortized O(1) rebalancing steps per insert or delete. 22 different rebalancing steps.

Trevor Brown A General Technique for Non-blocking Trees

slide-24
SLIDE 24

Chromatic Tree

Relaxed version of red-black tree designed for use with locks. allow red node to have a red parent (red-red violation). allow a black node to count more than others (overweight violation). a chromatic tree with no violations is a red-black tree. rebalancing steps can be deferred and interleaved with inserts and deletes. amortized O(1) rebalancing steps per insert or delete. 22 different rebalancing steps.

Trevor Brown A General Technique for Non-blocking Trees

slide-25
SLIDE 25

Representing a Chromatic Tree

Leaf oriented: every value is stored in a leaf. Internal nodes store keys that are only used to direct searches towards a leaf. Each node is represented by a data record. immutable fields: key, weight, value mutable fields: left, right

key weight left right key weight value Internal node Leaf

Trevor Brown A General Technique for Non-blocking Trees

slide-26
SLIDE 26

Search

Same as in a sequential binary search tree Can completely ignore concurrent updates

Trevor Brown A General Technique for Non-blocking Trees

slide-27
SLIDE 27

Insert(k,v)

repeat Search for leaf ux where k should be inserted If ux.key = k then return try to apply INSERT using tree update template if successful then if a violation was created then Cleanup(k) return

+ u u ux ux.w-1 new

+ +1

1 Insert

Trevor Brown A General Technique for Non-blocking Trees

slide-28
SLIDE 28

Delete(k)

repeat Search for leaf n2 where k should be located If n2.key = k then return try to apply DELETE using tree update template if successful then if a violation was created then Cleanup(k) return

+ n0 n0 n1 n1.w+n3.w new f1 f0 f1 f0 n3 Delete n2

Trevor Brown A General Technique for Non-blocking Trees

slide-29
SLIDE 29

Cleanup(k)

repeat Search for leaf with key k until a violation is found If no violation found then return Choose which rebalancing step to apply Try to apply the rebalancing step using tree update template INVARIANT: If a violation is on the search path for k before a rebalancing step, then it is eliminated or it remains on this path. When contention is c, chromatic tree has height O(c + log n).

Trevor Brown A General Technique for Non-blocking Trees

slide-30
SLIDE 30

Applying a Rebalancing Step

n0 n0 n1 >0 >0 n1.w n′

3

n2 n3 RB2 n′

2

n′

1

Trevor Brown A General Technique for Non-blocking Trees

slide-31
SLIDE 31

Applying a Rebalancing Step

>0 >0

A C B D E root

Apply RB2 to fix violation at C:

1

Read path from root to C

2

LLX A, D, B, C

3

Create new nodes B′, C′, D′ to replace R = D, B, C

4

SCX(A, D, B, C, D, B, C, A.right, B′)

changes A.right to B′ and finalizes D, B, C

  • nly if A, D, B, C unchanged

Trevor Brown A General Technique for Non-blocking Trees

slide-32
SLIDE 32

Applying a Rebalancing Step

>0 >0

A B D E root C

Apply RB2 to fix violation at C:

1

Read path from root to C

2

LLX A, D, B, C

3

Create new nodes B′, C′, D′ to replace R = D, B, C

4

SCX(A, D, B, C, D, B, C, A.right, B′)

changes A.right to B′ and finalizes D, B, C

  • nly if A, D, B, C unchanged

Trevor Brown A General Technique for Non-blocking Trees

slide-33
SLIDE 33

Applying a Rebalancing Step

>0 >0

A B D E root C

R

C′ B′ D′

N

D.w

Apply RB2 to fix violation at C:

1

Read path from root to C

2

LLX A, D, B, C

3

Create new nodes B′, C′, D′ to replace R = D, B, C

4

SCX(A, D, B, C, D, B, C, A.right, B′)

changes A.right to B′ and finalizes D, B, C

  • nly if A, D, B, C unchanged

Trevor Brown A General Technique for Non-blocking Trees

slide-34
SLIDE 34

Applying a Rebalancing Step

>0 >0

A B D E root C

R

C′ B′ D′

N

D.w

Apply RB2 to fix violation at C:

1

Read path from root to C

2

LLX A, D, B, C

3

Create new nodes B′, C′, D′ to replace R = D, B, C

4

SCX(A, D, B, C, D, B, C, A.right, B′)

changes A.right to B′ and finalizes D, B, C

  • nly if A, D, B, C unchanged

Trevor Brown A General Technique for Non-blocking Trees

slide-35
SLIDE 35

Using the Tree Update Template

Makes application of rebalancing steps easy: atomically replace the left side with the right side specific details of rebalancing steps are unimportant Makes proofs of correctness and proofs of progress much easier: data structure correctness progress unbalanced binary search tree 19 pages 4 pages B+ Tree 27 pages 6 pages chromatic tree 4 pages 1 page

Trevor Brown A General Technique for Non-blocking Trees

slide-36
SLIDE 36

Improving Practical Performance

Count violations as you search for the leaf to update After updating, invoke Cleanup if at least b violations seen Tree has height O(c + b + log n)

Trevor Brown A General Technique for Non-blocking Trees

slide-37
SLIDE 37

Other Non-blocking Balanced Trees

Relaxed balance data structures: decouple rebalancing from other updates to the data structure allow updates to be interleaved arbitrarily many relaxed balance versions of sequential data structures exist in the literature are well suited for non-blocking implementations using the tree update template Relaxed AVL tree: non-blocking implementation took a first-year undergraduate student one week

Trevor Brown A General Technique for Non-blocking Trees

slide-38
SLIDE 38

Experiments

Measured the throughput (number of operations/second) for Chromatic tree Chromatic tree allowing 5 violations (Chromatic 6) Non-blocking multiway search tree (SkipTree) Non-blocking skip list (SkipList) lock-based AVL tree (AVL-B) lock-based AVL tree with non-blocking search (AVL-D) STM-based skiplist (SkipListSTM) STM-based red-black tree (RBSTM) lock-based red-black tree (RBGlobal)

Trevor Brown A General Technique for Non-blocking Trees

slide-39
SLIDE 39

Experiments

Trevor Brown A General Technique for Non-blocking Trees

slide-40
SLIDE 40

20% Ins, 10% Del, 70% Get, Key Range [0, 104)

1 32 64 96 128 20 40 d d d d d B B B B B

Trevor Brown A General Technique for Non-blocking Trees

slide-41
SLIDE 41

How Performance Changes with Contention

Trevor Brown A General Technique for Non-blocking Trees

slide-42
SLIDE 42

How Performance Changes with Contention

Trevor Brown A General Technique for Non-blocking Trees

slide-43
SLIDE 43

Summary

Template for building non-blocking trees vastly simplifies proof of correctness, proof of progress. Very efficient, provably correct implementation of non-blocking chromatic tree. Searches are invisible, and extremely fast. Cleanup algorithm allows tree invariants to be relaxed for better concurrency without losing the height bound. (Idea can be applied to many relaxed data structures.) Future work: Investigating HTM implementation of LLX/SCX

Trevor Brown A General Technique for Non-blocking Trees
