WDSN 2008 – Anchorage, AK 1

Blocking and Non-blocking Checkpointing and Rollback Recovery for Networks-on-Chip

Claudia Rusu1, Cristian Grecu2, Lorena Anghel1

1 TIMA Laboratory, CNRS-UJF-INP, Grenoble, France

2 SoC Laboratory, University of British Columbia, Vancouver, Canada

WDSN 2008 – Anchorage, AK 2

OUTLINE

• Introduction

– – Networks-on-Chip Networks-on-Chip

– Checkpoint and rollback recovery

• Coordinated checkpointing
• Blocking and non-blocking coordinated

checkpointing

• Case study
• Conclusions and future work

WDSN 2008 – Anchorage, AK 3

Network-on-Chip based Systems

• NoC advantages

– Efficient sharing

• f wires

– Shorter design time, lower effort – Scalability

P2P Bus NoC

• NoC vs. traditional connection systems

Router

PE Link

WDSN 2008 – Anchorage, AK 4

NoC QoS vs. Faults

• Quality of service (QoS)

– reliability, throughput, latency, bandwidth

• Unreliable signal transmission medium

– timing and data errors – process variation, crosstalk, electromagnetic interference, radiations

=> Increased vulnerability to faults

• Technology down

scaling

• Increased system

complexity

WDSN 2008 – Anchorage, AK 5

Fault Tolerance in Networks-on-Chip

Physical Data link Network Transport Application

• Faults and Fault Tolerance

– At different NoC components

• Links
• Routers

– switching blocks – memories

– At different levels of the communication protocol stack

• Fault tolerant solutions

– adaptive routing – stochastic communication – EDC, ECC, NMR

Router

PE Link Fault

WDSN 2008 – Anchorage, AK 6

OUTLINE

• Introduction

– Networks-on-Chip

– – Checkpoint and rollback recovery Checkpoint and rollback recovery

• Coordinated checkpointing
• Blocking and non-blocking coordinated

checkpointing

• Case study
• Conclusions and future work

WDSN 2008 – Anchorage, AK 7

Checkpoint and Rollback Recovery.

Principle

• No failure tolerance

– Failure => Restart

• Checkpoint and rollback

recovery

– Failure => Resume from a more recent state

t

failure restart consistent state

t

failure rollback

rollback recovery

start start

– Principle

• Failure-free

– periodically store states on stable storage

• Failure

– rollback to the last consistent stored state

WDSN 2008 – Anchorage, AK 8

Checkpoint and Rollback Recovery.

Consistent State

• Message types vs. recovery line

SA TA TB SB

late message early/orphan message past message future message t t

• Consistent state with late messages
• early messages are avoided
• late messages are to be replayed after rollback

SA TA TB SB

late message future message past message future message t t

WDSN 2008 – Anchorage, AK 9

Checkpoint and Rollback Recovery.

Classification

message logging causal

• ptimistic

pessimistic

• Checkpointing
• Message logging

checkpointing uncoordinated coordinated blocking non-blocking communication-induced

WDSN 2008 – Anchorage, AK 10

OUTLINE

• Introduction

– Networks-on-Chip – Checkpoint and rollback recovery

• Coordinated

Coordinated checkpointing checkpointing

• Blocking and non-blocking coordinated

checkpointing

• Case study
• Conclusions and future work

WDSN 2008 – Anchorage, AK 11

Coordinated Checkpointing

• Principle

TA TB TC

global synchronizations consistent states

epoch rollback

• Failure-free

– synchronization –> consistent state

• Failure

– rollback to the last consistent state

TD

• Task checkpoint

– task state – list of late messages

• Late messages log

– optimistic approach

• > small latency on failure-free

– logged at receiver

• > small recovery overhead
• Unique coordinator

– reduced overhead

• Unique blocking and non-blocking

protocol

– allows for the same checkpoint the blocking of a task set and the non-blocking of another

WDSN 2008 – Anchorage, AK 12

• Synchronization. Markers
• Markers

– are used to

• avoid early messages
• identify late messages and to

end the log of late messages

– dedicated messages (avoid long checkpointing durations when communication among certain tasks is scarce)

• A task has taken the

checkpoint only after state and late messages form

• ther tasks are on stable

storage

message 2

( l a t e)

TA

message 1

(early)

TB TC

message 2

( f

• r

r e p l a y )

message 1

marker 1 m a r k e r 2

TA TB TC

Inconsistent state

Consistent state using markers

WDSN 2008 – Anchorage, AK 13

OUTLINE

• Introduction

– Networks-on-Chip – Checkpoint and rollback recovery

• Coordinated checkpointing
• Blocking and non-blocking coordinated

Blocking and non-blocking coordinated checkpointing checkpointing

• Case study
• Conclusions and future work

WDSN 2008 – Anchorage, AK 14

Blocking and Non-blocking Coordinated Checkpointing Protocol

• Checkpointing protocol

I TA TB TD TC

• Synchronization

messages

Initiator

• broadcast

CK_REQ

• when CK_TAKEN

received from all tasks

• validate

global checkpoint Non-initiator (blocking or not)

• on CK_REQ receipt
• broadcast

CK_START

• when CK_START

received from all tasks

• take local

checkpoint

• send to

initiator CK_TAKEN

WDSN 2008 – Anchorage, AK 15

Blocking and Non-blocking Overhead

– n nodes

• CK_REQ n
• CK_START n*(n-1) O(n2)
• CK_TAKEN n

I

TA TB TD TC

Blocking

– synchronization messages

• Synchronization messages

Non-blocking

– synchronization messages – application messages

• Messages in NoC during checkpointing

WDSN 2008 – Anchorage, AK 16

Checkpointing Duration

• Long checkpointing durations

–> reduced number of checkpoints

• When failure rate is comparable with

checkpointing duration

• > rollbacks to the same old checkpoint

TA TB TC rollback TD TA TB TC rollback TD

• High overhead during checkpointing

–> checkpointing phase reduced

WDSN 2008 – Anchorage, AK 17

OUTLINE

• Introduction

– Networks-on-Chip – Checkpoint and rollback recovery

• Coordinated checkpointing
• Blocking and non-blocking coordinated

checkpointing

• Case study

Case study

• Conclusions and future work

WDSN 2008 – Anchorage, AK 18

Case Study

• 4x4 mesh direct NoC

– XY routing – Wormhole switching

• Consider

– Different traffic loads

• uniform traffic loads
• constant message length

– Different failure rates

• Analyze

– Checkpointing duration and overhead – Application latency

Router

PE Link

WDSN 2008 – Anchorage, AK 19

Checkpointing Duration and Overhead

• Memory Overhead
• Checkpointing Duration

WDSN 2008 – Anchorage, AK 20

Application Latency

WDSN 2008 – Anchorage, AK 21

OUTLINE

• Introduction

– Networks-on-Chip – Checkpoint and rollback recovery

• Coordinated checkpointing
• Blocking and non-blocking coordinated

checkpointing

• Case study
• Conclusions and future work

Conclusions and future work

WDSN 2008 – Anchorage, AK 22

Conclusions and Future Work

• Blocking and Non-blocking coordinated checkpointing

– unique protocol

• Analyze and compare overhead and latency

– Checkpointing duration increases with the traffic load

• Non-blocking: significantly
• Blocking: lesser

– Application latency increases with the traffic load and the failure rate

• Non-blocking: significantly
• Blocking: lesser

–> For higher traffic loads and higher failure rates, the blocking approach becomes mandatory

• Future work

– Evaluate the proposed protocol

• n other traffic patterns
• n application with high traffic loads and critical tasks

–> subsets of blocking and non-blocking tasks

WDSN 2008 – Anchorage, AK 23

Thank you!
