spcl.inf.ethz.ch @spcl_eth T OBIAS G YSI , T OBIAS G ROSSER , L AURIN B RANDNER , AND T ORSTEN H OEFLER A Fast Analytical Model of Fully Associative Caches

spcl.inf.ethz.ch @spcl_eth The Cost of Data Movement Depends on Global State and Does Not Compose int N = 1000; for ( int i = 0; i < N; i++) { for ( int j = 0; j < i; j++) { for ( int k = 0; k < j; k++) { percentage of cache misses? A[i][j] -= A[i][k] * A[j][k]; L1 cache 1.6% } L2 cache 1.4% A[i][j] /= A[j][j]; } most expensive memory access? for ( int k = 0; k < i; k++) { A[j][k] A[i][i] -= A[i][k] * A[i][k]; } amount of compulsory and capacity misses? A[i][i] = sqrt(A[i][i]); # compulsory misses 31,752 } # capacity misses 10,630,620 Cholesky kernel from https://sourceforge.net/projects/polybench/ 2

spcl.inf.ethz.ch @spcl_eth HayStack Output for Cholesky Factorization parameters: relative number of cache misses (statement) • cache sizes (32k and 512k) • cacheline size (64B) 5 for (int i = 0; i < N; i++) { 6 for (int j = 0; j < i; j++) { 7 for (int k = 0; k < j; k++) { 8 A[i][j] -= A[i][k] * A[j][k]; ----------------------------------------------------------------------------- ref type comp[%] L1[%] L2[%] tot[%] reuse[ln] A[i][j] rd 0.00459 0.00000 0.00000 24.86910 8,10 A[i][k] rd 0.00000 0.00000 0.00000 24.86910 8,10 A[j][k] rd 0.00000 1.58635 1.38213 24.86910 8,10,13,15 A[i][j] wr 0.00000 0.00000 0.00000 24.86910 8 ----------------------------------------------------------------------------- absolute number of cache misses (program) compulsory: 31'752 capacity (L1): 10'630'620 capacity (L2): 9'258'460 total: 668'166'500 3

spcl.inf.ethz.ch @spcl_eth Comparison to Simulation 1 day 1 hour 1 minute 1 seconds 4

spcl.inf.ethz.ch @spcl_eth Symbolic Counting Avoids the Explicit Enumeration 1d illustration i j Barvinok algorithm enumeration #points = 3 #points = 1 #points = 2 #points = j-i+1 = 3 symbolic i j enumeration #points = 1 #points = 2 #points = 3 #points = 4 #points = 5 #points = 6 #points = 7 #points = 8 #points = 9 symbolic #points = j-i+1 = 9 Alexander I. Barvinok, A Polynomial Time Algorithm for Counting Integral Points in Polyhedra When the Dimension is Fixed . 1994. 5

spcl.inf.ethz.ch @spcl_eth The LRU Stack Distance Allows Us to Model Fully Associative Caches example memory accesses LRU stack int sum = 0; distance 3 distance 4 distance 2 distance 1 i=0 M(0) M(0) M(1) M(0) M(2) M(1) M(3) M(2) for ( int i=0; i<4; ++i) hit i=1 M(1) M(0) M(1) M(2) M(2) M(3) M(1) S0: M[i] = i; for ( int j=0; j<4; ++j) i=2 M(2) M(1) M(0) M(3) M(2) S1: sum += M[3-j]; miss i=3 M(3) M(3) M(0) j=0 M(3) j=1 M(2) deliberately generic model j=2 M(1) j=3 M(0) Richard L Mattson, Jan Gecsei, Donald R Slutz, and Irving L Traiger, Evaluation techniques for storage hierarchies. 1970. 6

spcl.inf.ethz.ch @spcl_eth Compute the LRU Stack Distance example 𝑞 𝑘 = 𝑘 + 1 int sum = 0; 4 for ( int i=0; i<4; ++i) S0: M[i] = i; stack distance 3 for ( int j=0; j<4; ++j) S1: sum += M[3-j]; 2 1 apply symbolic counting once j 0 1 2 3 4 Kristof Beyls and Erik H D’Hollander , Generating cache hints for improved program efficiency . 2005. 7

spcl.inf.ethz.ch @spcl_eth Count the Cache Misses Given the LRU Stack Distance example 𝑞 𝑘 = 𝑘 + 1 int sum = 0; misses 4 for ( int i=0; i<4; ++i) hits S0: M[i] = i; stack distance 3 for ( int j=0; j<4; ++j) S1: sum += M[3-j]; cache size C=2 2 1 apply symbolic counting twice j 0 1 2 3 4 many different pieces and 𝑘 ∶ 𝒒 𝒌 > 𝑫 ∧ 0 ≤ 𝑘 < 4 𝑘 ∶ 𝒒 𝒌 > 𝑫 ∧ 0 ≤ 𝑘 < 4 = 2 sometimes non-affine polynomials 8

spcl.inf.ethz.ch @spcl_eth Some Access Patterns Result in Non-Linearities example original int sum = 0; int sum = 0; for ( int i=0; i<4; ++i) for ( int t=0; t<4; ++t) { S0: M[i] = i; for ( int i=0; i<4; ++i) for ( int j=0; j<4; ++j) S0: M[i] = i; i j S1: sum += M[3-j]; for ( int m=0; m<t; ++m) 𝑞 𝑘 = 𝑘 + 1 for ( int n=0; n<t; ++n) N[m][n] = t; additional time loop for ( int j=0; j<4; ++j) t S1: sum += M[3-j]; } i j 𝑞 𝑘, 𝑢 = 𝒖 𝟑 + 𝑘 + 1 partial enumeration 9

spcl.inf.ethz.ch @spcl_eth Enumerate the Non-Affine Dimensions p 𝐮=𝟏 𝑘 = 𝟏 + 𝑘 + 1 0 1 2 𝑞 𝑘, 𝑢 = 𝒖 𝟑 + 𝑘 + 1 0 ≤ 𝑢 < 3 (0,0) (1,0) (2,0) 0 π t 𝑞 𝐮=𝟐 𝑘 = 𝟐 + 𝑘 + 1 (0,1) (1,1) (2,1) 1 0 1 2 2 (0,2) (1,2) (2,2) 0 ≤ (𝑘, 𝑢) < 3 p 𝐮=𝟑 𝑘 = 𝟓 + 𝑘 + 1 0 1 2 12.4x speedup due to partial enumeration 10

spcl.inf.ethz.ch @spcl_eth Modelling Cache Lines Introduces Floor Terms example original int sum = 0; for ( int i=0; i<4; ++i) S0: M[i] = i; i j for ( int j=0; j<4; ++j) S1: sum += M[3-j]; 𝑞 𝑘 = 𝑘 + 1 modelling cache lines equalization and rasterization i j 𝑞 𝑘 = 𝑘 𝟑 − 𝒌 − 𝟐 𝒌 + 1 2 𝟑 11

spcl.inf.ethz.ch @spcl_eth Split the Domain to Eliminate Floor Terms 𝑞 𝑘 𝒌%𝟑=𝟏 = 𝑘 2 𝟐 + 1 0 2 𝑞 𝑘 = 𝑘 𝟑 − 𝒌 − 𝟐 𝒌 + 1 2 𝟑 3 0 1 2 𝑞 𝑘 𝒌%𝟑>𝟏 = 𝑘 0 ≤ 𝑘 < 4 2 𝟏 + 1 1 3 1.9x speedup due to equalization 12

spcl.inf.ethz.ch @spcl_eth Accuracy of HayStack for the L1 Cache of Our Test System 13

spcl.inf.ethz.ch @spcl_eth Error of HayStack Compared to Simulation (Dinero IV) HayStack (fully associative) Dinero IV (fully associative) Dinero IV (8-way associative) 14

spcl.inf.ethz.ch @spcl_eth Performance of HayStack for the Large Problem Size of PolyBench 15

spcl.inf.ethz.ch @spcl_eth Performance of HayStack Compared to PolyCache and Dinero Dinero IV PolyCache - simulator - analytical cache model - setup to simulate full associativity - models set associativity - problem size dependent performance - one core per cache set 370x speedup 21x speedup Jan Elder and Mark D. Hill, Dinero IV Trace-Driven Wenlei Bao, Sriram Krishnamoorthy, Louis-Noel Pouchet, and P Sadayappan, Uniprocessor Cache Simulator . 2003. Analytical modeling of cache behavior for affine programs. 2017. 16

spcl.inf.ethz.ch @spcl_eth Conclusion generic model of fully associative caches accurate results compared to measurements fast enough to provide interactive feedback excellent performance compared to alternatives 17
