A data model for supplying a Data Center with several energy sources Ins de Courchelle Tom Gurout Yann Labit Thierry Monteil IRIT/LAAS LAAS-CNRS LAAS-CNRS LAAS-CNRS idecourc@irit.fr tguerout@laas.fr ylabit@laas.fr monteil@laas.fr

SLIDE 1

A data model for supplying a Data Center with several energy sources

Inès de Courchelle IRIT/LAAS idecourc@irit.fr

18 juillet 2016

Tom Guérout LAAS-CNRS tguerout@laas.fr Yann Labit LAAS-CNRS ylabit@laas.fr Thierry Monteil LAAS-CNRS monteil@laas.fr

SLIDE 2

2 26

Plan

I. Introduction
II. RenewSim
III. Modeling
IV. Results
V. Conclusion

SLIDE 3

Introduction RenewSim Modeling Results Conclusion Introduction

3 26

CONTEXT

◆ Smart cities ◆ Home automation ◆ Smart building ◆ Smart Grid ◆ ... ◆ Use renewable energy sources ◆ Reducing the CO2 foot print ◆ Smart Building ◆ Supply a Data Center ◆ The running cost is more and more expensive ◆ Actual Data Center capacities ◆ 40 000 servers ◆ 500 000 services (VM) ◆ > 1 million

SLIDE 4

Introduction RenewSim Modeling Results Conclusion Introduction

4 26

Data Center Consumption

2000 70 Twh in the world 2007 330 Twh, 2% World C02 production 2011 France is the 6th electricity consumer in the world 2020 104 billion kW in European area 2008 56 billion kW in European area

How to supply Data Center ? Economically ? Environmentally ?

SLIDE 5

Introduction RenewSim Modeling Results Conclusion Introduction

5 26

Challenge & Problematic

◆ Use several energy sources ◆ Green energy (solar panels, batteries, etc.) ◆ Brown energy (suppliers, etc.)

The problematic is how to characterize the heterogeneous electricity sources to make a decision to reduce electricity bills ?

◆ Control ◆ Energy Sources ◆ Energy Destinations

SLIDE 6

6 26

Introduction RenewSim Modeling Results Conclusion Introduction

Context

Overview

◆ What is it ? ◆ Green IT Simulator ◆ Co-simulation tool ◆ Based on a micro-grid architecture ◆ Why ? ◆ Use several energy sources ◆ Managing the power flow in a clever way ◆ How is it composed ? ◆ Each element is plugged to the bus ◆ Converter module ◆ Control system

SLIDE 7

7 26

Introduction RenewSim Modeling Results Conclusion Introduction

Control module

◆ Find the best trade-off (electricity vs IT) ◆ Manage the power flow into the smart grid ◆ Task allocation characterize by ◆ CPU & Memory capacities ◆ Energy demand and available servers

RenewSim aims at reducing the energy cost by studying the power flow and the Data Center demand in a decision block.

SLIDE 8

Introduction RenewSim Modeling Results Conclusion Introduction

8 26

The Modeling

◆ Manage the different degrees of freedom ◆ Specify the intrinsic behavior of each block

SLIDE 9

Introduction RenewSim Modeling Results Conclusion Introduction

9 26

Context

Freedom degrees 1/2

◆ No degrees ◆ The power asked by the Data Center does not let us a lot freedom degrees ◆ Input of the system asked by the user and application ◆ Solar production does not depend on the system ◆ weather and time of the day ◆ Freedom degrees ◆ The Suppliers ◆ The Batteries

SLIDE 10

Introduction RenewSim Modeling Results Conclusion Introduction

10 26

Freedom degrees 2/2

◆ Batteries ◆ Store energy from solar panels or suppliers ◆ Unload energy from batteries ◆ The suppliers ◆ Price depends of time (night and day) ◆ Store energy into the batteries or sell it

SLIDE 11

Introduction RenewSim Modeling Results Conclusion Introduction

11 26

Element characterization

Source (St) Backup (Bt) Destination (Dt) Overflow (Ot) Gives energy to destinations Receives energy from the sources Stores energy which can not be accepted by the destinations Unloads energy which can be feed the destinations

SLIDE 12

Introduction RenewSim Modeling Results Conclusion Introduction

12 26

Example (1/3)

◆ The modeling is presented as a matrix with 4 columns ◆ Each line is a component of our system

Source Destination Backup Overflow Solar Panels 1 Data Center 1 Battery 1 1 Supplier 2 2

SLIDE 13

Introduction RenewSim Modeling Results Conclusion Introduction

13 26

Example (2/3)

1 5 2 5 5 5 Source Destination Backup 1 Overfull 1 Backup 2 Overfull 2

SLIDE 14

Introduction RenewSim Modeling Results Conclusion Introduction

14 26

Example (3/3)

1 5 2 5 Source Destination Backup 1 Overfull 1 Backup 2 Overfull 2 5

SLIDE 15

Introduction RenewSim Modeling Results Conclusion Introduction

15 26

Algorithms

SLIDE 16

16 26

Introduction RenewSim Modeling Results Conclusion Introduction

Study area (1/2)

◆ Converter ◆ CM1: 15% ◆ CM2: 17% ◆ CM3: 13% ◆ CM4: 14% ◆ ADREAM ◆ Data solar panels: 48h ◆ 1648 measures ◆ Inputs

SLIDE 17

17 26

Introduction RenewSim Modeling Results Conclusion Introduction

Inputs (1/2)

SLIDE 18

18 26

Introduction RenewSim Modeling Results Conclusion Introduction

Inputs (2/2)

SLIDE 19

19 26

Introduction RenewSim Modeling Results Conclusion Introduction

Study area (2/2)

Load unload Capacity 10 000 joules

Battery Supplier

Sale Purchase d

SLIDE 20

20 26

Introduction RenewSim Modeling Results Conclusion Introduction

Experimentation 1

Source Destination Backup Overflow Solar Panels 1 Data Center 1 Battery 1 1 Supplier 2 2

SLIDE 21

21 26

Introduction RenewSim Modeling Results Conclusion Introduction

Battery and supplier

SLIDE 22

22 26

Introduction RenewSim Modeling Results Conclusion Introduction

Experimentation 2

Day Source Destination Backup Overflow Solar Panels 1 Data Center 1 Battery 1 1 1 Supplier 2 2 Night Source Destination Backup Overflow Solar Panels 1 Data Center 1 Battery 1 Supplier 1

SLIDE 23

23 26

Introduction RenewSim Modeling Results Conclusion Introduction

Battery and supplier

SLIDE 24

24 26

Introduction RenewSim Modeling Results Conclusion Introduction

Conclusion

◆ Renewsim allows: ◆ Design a Green modular architecture ◆ Simulate various kind of inputs and storage models ◆ Manage the power redirection through labeled and prioritized energy

sources

◆ Analyze the impact of the IT feed on energy sources

SLIDE 25

25 26

Introduction RenewSim Modeling Results Conclusion Introduction

Perspectives

◆ The expansion prospects consist in: ◆ Heuristics, algorithms of learning machine ◆ Prediction of production & usage ◆ Tasks priority ◆ QoS management ◆ The purpose of RenewSim is to be a co-simulation tool allowing communication

simulators dedicated to each component.

SLIDE 26

Any Questions ?

Inès de Courchelle IRIT/LAAS idecourc@irit.fr Tom Guerout LAAS-CNRS tguerout@laas.fr Yann Labit LAAS-CNRS ylabit@laas.fr Thierry Monteil LAAS-CNRS monteil@laas.fr
