SLIDE 1
61A Lecture 23
Friday, October 19
Last day
- f Midterm
Trees with Internal Node Values
2
61A Lecture 23 Friday, October 19 Trees with Internal Node Values - - PowerPoint PPT Presentation
61A Lecture 23 Friday, October 19 Trees with Internal Node Values - - PowerPoint PPT Presentation
Last day of Midterm 2 Material 61A Lecture 23 Friday, October 19 Trees with Internal Node Values 2 Trees with Internal Node Values Trees can have values at their roots as well as their leaves. 2 Trees with Internal Node Values Trees can
SLIDE 2
SLIDE 3
Trees with Internal Node Values
Trees can have values at their roots as well as their leaves.
2
SLIDE 4
Trees with Internal Node Values
Trees can have values at their roots as well as their leaves.
2
fib(6) fib(4) fib(2) 1 fib(5) fib(3) fib(1) fib(2) 1 fib(3) fib(1) fib(2) 1 fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1
SLIDE 5
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 6
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 7
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 8
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 9
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 10
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 11
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 12
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 13
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 14
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: return Tree(0) Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 15
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: return Tree(0) if n == 2: Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 16
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: return Tree(0) if n == 2: return Tree(1) Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 17
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: return Tree(0) if n == 2: return Tree(1) left = fib_tree(n-2) Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 18
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: return Tree(0) if n == 2: return Tree(1) left = fib_tree(n-2) right = fib_tree(n-1) Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 19
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: return Tree(0) if n == 2: return Tree(1) left = fib_tree(n-2) right = fib_tree(n-1) return Tree(left.entry + right.entry, left, right) Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 20
Trees with Internal Node Values (Entries)
Trees need not only have values at their leaves.
3
class Tree(object): def __init__(self, entry, left=None, right=None): self.entry = entry self.left = left self.right = right def fib_tree(n): if n == 1: return Tree(0) if n == 2: return Tree(1) left = fib_tree(n-2) right = fib_tree(n-1) return Tree(left.entry + right.entry, left, right) Demo Valid if left and right are each either None or a Tree instance A valid tree cannot be a subtree of itself (no cycles!)
SLIDE 21
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
SLIDE 22
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
def count_factors(n):
SLIDE 23
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
def count_factors(n):
(Demo)
SLIDE 24
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
Time (remainders)
def count_factors(n):
(Demo)
SLIDE 25
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
Time (remainders)
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors
(Demo)
SLIDE 26
n
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
Time (remainders)
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors
(Demo)
SLIDE 27
n
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
Time (remainders)
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors
(Demo)
SLIDE 28
n
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
Time (remainders)
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors sqrt_n = sqrt(n) k, factors = 1, 0 while k < sqrt_n: if n % k == 0: factors += 2 k += 1 if k * k == n: factors += 1 return factors
(Demo)
SLIDE 29
n
bpnc
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time to compute their result.
4
Time (remainders)
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors sqrt_n = sqrt(n) k, factors = 1, 0 while k < sqrt_n: if n % k == 0: factors += 2 k += 1 if k * k == n: factors += 1 return factors
(Demo)
SLIDE 30
The Consumption of Space
5
SLIDE 31
The Consumption of Space
Which environment frames do we need to keep during evaluation?
5
SLIDE 32
The Consumption of Space
Which environment frames do we need to keep during evaluation? Each step of evaluation has a set of active environments.
5
SLIDE 33
The Consumption of Space
Which environment frames do we need to keep during evaluation? Each step of evaluation has a set of active environments. Values and frames in active environments consume memory.
5
SLIDE 34
The Consumption of Space
Which environment frames do we need to keep during evaluation? Each step of evaluation has a set of active environments. Values and frames in active environments consume memory. Memory used for other values and frames can be reclaimed.
5
SLIDE 35
The Consumption of Space
Which environment frames do we need to keep during evaluation? Each step of evaluation has a set of active environments. Values and frames in active environments consume memory. Memory used for other values and frames can be reclaimed.
5
Active environments:
SLIDE 36
The Consumption of Space
Which environment frames do we need to keep during evaluation? Each step of evaluation has a set of active environments. Values and frames in active environments consume memory. Memory used for other values and frames can be reclaimed.
5
Active environments:
- Environments for any statements currently being executed
SLIDE 37
The Consumption of Space
Which environment frames do we need to keep during evaluation? Each step of evaluation has a set of active environments. Values and frames in active environments consume memory. Memory used for other values and frames can be reclaimed.
5
Active environments:
- Environments for any statements currently being executed
- Parent environments of functions named in active environments
SLIDE 38
Fibonacci Memory Consumption
6
fib(6) fib(5) fib(3) fib(2) 1 fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 fib(1) fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1
SLIDE 39
Fibonacci Memory Consumption
6
fib(6) fib(5) fib(3) fib(2) 1 fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 fib(1) fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 Assume we have reached this step
SLIDE 40
Fibonacci Memory Consumption
7
fib(6) fib(5) fib(3) fib(2) 1 fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 fib(1) fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 Assume we have reached this step
SLIDE 41
Fibonacci Memory Consumption
7
fib(6) fib(5) fib(3) fib(2) 1 fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 fib(1) fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 Assume we have reached this step Has an active environment
SLIDE 42
Fibonacci Memory Consumption
7
fib(6) fib(5) fib(3) fib(2) 1 fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 fib(1) fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 Assume we have reached this step Has an active environment Can be reclaimed
SLIDE 43
Fibonacci Memory Consumption
7
fib(6) fib(5) fib(3) fib(2) 1 fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 fib(1) fib(4) fib(2) 1 fib(3) fib(1) fib(2) 1 Assume we have reached this step Has an active environment Can be reclaimed Hasn't yet been created
SLIDE 44
Order of Growth
8
SLIDE 45
Order of Growth
A method for bounding the resources used by a function as the "size" of a problem increases
8
SLIDE 46
Order of Growth
A method for bounding the resources used by a function as the "size" of a problem increases
8
n: size of the problem
SLIDE 47
Order of Growth
A method for bounding the resources used by a function as the "size" of a problem increases
8
n: size of the problem R(n): Measurement of some resource used (time or space)
SLIDE 48
R(n) = Θ(f(n))
Order of Growth
A method for bounding the resources used by a function as the "size" of a problem increases
8
n: size of the problem R(n): Measurement of some resource used (time or space)
SLIDE 49
R(n) = Θ(f(n))
Order of Growth
A method for bounding the resources used by a function as the "size" of a problem increases
8
n: size of the problem R(n): Measurement of some resource used (time or space) means that there are positive constants k1 and k2 such that
SLIDE 50
R(n) = Θ(f(n)) k1 · f(n) ≤ R(n) ≤ k2 · f(n)
Order of Growth
A method for bounding the resources used by a function as the "size" of a problem increases
8
n: size of the problem R(n): Measurement of some resource used (time or space) means that there are positive constants k1 and k2 such that
SLIDE 51
R(n) = Θ(f(n)) k1 · f(n) ≤ R(n) ≤ k2 · f(n)
Order of Growth
A method for bounding the resources used by a function as the "size" of a problem increases
8
n: size of the problem R(n): Measurement of some resource used (time or space) means that there are positive constants k1 and k2 such that for sufficiently large values of n.
SLIDE 52
Iteration vs Memoized Tree Recursion
Iterative and memoized implementations are not the same.
9
def fib_iter(n): prev, curr = 1, 0 for _ in range(n-1): prev, curr = curr, prev + curr return curr @memo def fib(n): if n == 1: return 0 if n == 2: return 1 return fib(n-2) + fib(n-1) Time Space
SLIDE 53
Iteration vs Memoized Tree Recursion
Iterative and memoized implementations are not the same.
9
def fib_iter(n): prev, curr = 1, 0 for _ in range(n-1): prev, curr = curr, prev + curr return curr @memo def fib(n): if n == 1: return 0 if n == 2: return 1 return fib(n-2) + fib(n-1) Time Space
Θ(n)
SLIDE 54
Iteration vs Memoized Tree Recursion
Iterative and memoized implementations are not the same.
9
def fib_iter(n): prev, curr = 1, 0 for _ in range(n-1): prev, curr = curr, prev + curr return curr @memo def fib(n): if n == 1: return 0 if n == 2: return 1 return fib(n-2) + fib(n-1) Time Space
Θ(n) Θ(1)
SLIDE 55
Iteration vs Memoized Tree Recursion
Iterative and memoized implementations are not the same.
9
def fib_iter(n): prev, curr = 1, 0 for _ in range(n-1): prev, curr = curr, prev + curr return curr @memo def fib(n): if n == 1: return 0 if n == 2: return 1 return fib(n-2) + fib(n-1) Time Space
Θ(n) Θ(n) Θ(1)
SLIDE 56
Iteration vs Memoized Tree Recursion
Iterative and memoized implementations are not the same.
9
def fib_iter(n): prev, curr = 1, 0 for _ in range(n-1): prev, curr = curr, prev + curr return curr @memo def fib(n): if n == 1: return 0 if n == 2: return 1 return fib(n-2) + fib(n-1) Time Space
Θ(n) Θ(n) Θ(n) Θ(1)
SLIDE 57
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time.
10
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors sqrt_n = sqrt(n) k, factors = 1, 0 while k < sqrt_n: if n % k == 0: factors += 2 k += 1 if k * k == n: factors += 1 return factors
Time Space
SLIDE 58
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time.
10
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors sqrt_n = sqrt(n) k, factors = 1, 0 while k < sqrt_n: if n % k == 0: factors += 2 k += 1 if k * k == n: factors += 1 return factors
Time Space
Θ(n) Θ(1)
SLIDE 59
The Consumption of Time
Implementations of the same functional abstraction can require different amounts of time.
10
def count_factors(n): factors = 0 for k in range(1, n+1): if n % k == 0: factors += 1 return factors sqrt_n = sqrt(n) k, factors = 1, 0 while k < sqrt_n: if n % k == 0: factors += 2 k += 1 if k * k == n: factors += 1 return factors
Time Space
Θ(n) Θ(1) Θ(√n) Θ(1)
SLIDE 60
Exponentiation
11
SLIDE 61
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
SLIDE 62
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1)
SLIDE 63
bn =
- 1
if n = 0 b · bn−1
- therwise
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1)
SLIDE 64
bn =
- 1
if n = 0 b · bn−1
- therwise
bn = 1 if n = 0 (b
1 2 n)2
if n is even b · bn−1 if n is odd
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1)
SLIDE 65
bn =
- 1
if n = 0 b · bn−1
- therwise
bn = 1 if n = 0 (b
1 2 n)2
if n is even b · bn−1 if n is odd
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x
SLIDE 66
bn =
- 1
if n = 0 b · bn−1
- therwise
bn = 1 if n = 0 (b
1 2 n)2
if n is even b · bn−1 if n is odd
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x def fast_exp(b, n):
SLIDE 67
bn =
- 1
if n = 0 b · bn−1
- therwise
bn = 1 if n = 0 (b
1 2 n)2
if n is even b · bn−1 if n is odd
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x def fast_exp(b, n): if n == 0: return 1
SLIDE 68
bn =
- 1
if n = 0 b · bn−1
- therwise
bn = 1 if n = 0 (b
1 2 n)2
if n is even b · bn−1 if n is odd
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x def fast_exp(b, n): if n == 0: return 1 if n % 2 == 0: return square(fast_exp(b, n//2))
SLIDE 69
bn =
- 1
if n = 0 b · bn−1
- therwise
bn = 1 if n = 0 (b
1 2 n)2
if n is even b · bn−1 if n is odd
Exponentiation
Goal: one more multiplication lets us double the problem size.
11
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x def fast_exp(b, n): if n == 0: return 1 if n % 2 == 0: return square(fast_exp(b, n//2)) else: return b * fast_exp(b, n-1)
SLIDE 70
Exponentiation
Goal: one more multiplication lets us double the problem size.
12
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x def fast_exp(b, n): if n == 0: return 1 if n % 2 == 0: return square(fast_exp(b, n//2)) else: return b * fast_exp(b, n-1) Time Space
SLIDE 71
Exponentiation
Goal: one more multiplication lets us double the problem size.
12
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x def fast_exp(b, n): if n == 0: return 1 if n % 2 == 0: return square(fast_exp(b, n//2)) else: return b * fast_exp(b, n-1) Time Space
Θ(n) Θ(n)
SLIDE 72
Exponentiation
Goal: one more multiplication lets us double the problem size.
12
def exp(b, n): if n == 0: return 1 return b * exp(b, n-1) def square(x): return x*x def fast_exp(b, n): if n == 0: return 1 if n % 2 == 0: return square(fast_exp(b, n//2)) else: return b * fast_exp(b, n-1) Time Space
Θ(n) Θ(n) Θ(log n) Θ(log n)
SLIDE 73
Comparing orders of growth (n is the problem size)
13
SLIDE 74
Θ(bn)
Comparing orders of growth (n is the problem size)
13
SLIDE 75
Θ(bn)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where
SLIDE 76
Θ(bn)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor.
SLIDE 77
Θ(bn) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor.
SLIDE 78
Θ(bn) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Quadratic growth. E.g., operations on all pairs.
SLIDE 79
Θ(bn) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 80
Θ(bn) Θ(n) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 81
Θ(bn) Θ(n) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 82
Θ(bn) Θ(n) Θ(log n) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 83
Θ(bn) Θ(n) Θ(log n) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Logarithmic growth. These processes scale well. Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 84
Θ(bn) Θ(n) Θ(log n) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Logarithmic growth. These processes scale well. Doubling the problem only increments R(n). Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 85
Θ(bn) Θ(n) Θ(log n) Θ(1) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Logarithmic growth. These processes scale well. Doubling the problem only increments R(n). Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 86
Θ(bn) Θ(n) Θ(log n) Θ(1) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Logarithmic growth. These processes scale well. Doubling the problem only increments R(n).
- Constant. The problem size doesn't matter.
Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 87
Θ(bn) Θ(n) Θ(log n) Θ(1) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Logarithmic growth. These processes scale well. Doubling the problem only increments R(n).
- Constant. The problem size doesn't matter.
Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
SLIDE 88
Θ(bn) Θ(n) Θ(log n) Θ(1) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Logarithmic growth. These processes scale well. Doubling the problem only increments R(n).
- Constant. The problem size doesn't matter.
Quadratic growth. E.g., operations on all pairs. Incrementing n increases R(n) by the problem size n.
Θ(n6)
SLIDE 89
Θ(bn) Θ(n) Θ(log n) Θ(1) Θ(n2)
Comparing orders of growth (n is the problem size)
13
Exponential growth! Recursive fib takes
Θ(φn) φ = 1 + √ 5 2 ≈ 1.61828
steps, where Incrementing the problem scales R(n) by a factor. Linear growth. Resources scale with the problem. Logarithmic growth. These processes scale well. Doubling the problem only increments R(n).
- Constant. The problem size doesn't matter.
