• 5. Advanced Topography

Selecting Premium IOLs and Complex Cases

www.medsalesacademy.co.uk

Today we will learn

๏

Why K readings are important to IOL calculations

๏

How to take accurate measurements

๏

How to compare readings from different devices

๏

How to investigate irregular K readings

๏

Understanding different ways to measure corneal curvature

๏

Understanding Astigmatism front and back

๏

Using reports to screen out unsuitable patients

www.medsalesacademy.co.uk

Topography & IOL

๏

IOL = A constant - 2.5 AL - 0.9K

๏

Axial Length specific location for measure

๏

A constant - Manufacturer or Optimised

๏

K readings ??????

๏

0.1mm in K reading = 0.5D change

๏

Today we will look at K readings and curvature

www.medsalesacademy.co.uk

Curvature

๏

The cornea is not a uniform shape

๏

It varies depending on where we measure the K reading

• Auto Keratometer 3-3.3 mm
• IOL Master 2.4mm
• Pentacam 3mm

www.medsalesacademy.co.uk

Measuring Accurately

๏

Most readings are reflections of the tear film

๏

Make sure tear film is consistent across the surface

๏

Use Artificial Tears

๏

Haigis says don’t use ANY drops on cornea prior to measurement

๏

Use an instrument that measures cornea directly?

www.medsalesacademy.co.uk

Pentacam

๏

Pentacam measures cornea not tear film, so should be unaffected by artificial tears

๏

But … the cornea will change shape as it is lubricated

๏

0.1mm change in curvature equates to 0.5D change in power

www.medsalesacademy.co.uk

Solution

๏

The drier the eye the more it will be affected by artificial tears

๏

Take measurements before and after drops

๏

Discuss with patient. If they are likely to keep with dry eye regime after surgery then use the lubricated reading

๏

If not use the pre drop reading

www.medsalesacademy.co.uk

Comparing K Readings

๏

Check quality

๏

Review Images

๏

Were artificial tears used?

www.medsalesacademy.co.uk

Comparing K Readings

Set Zone to Diameter you wish to compare. Eg 2.4 for IOL master Choose Apex or Pupil. Eg for IOL Master choose pupil Choose Zone or Ring. Eg for IOL Master choose ring

www.medsalesacademy.co.uk

Compare K Readings

๏

Compare eg Pentacam with IOL Master

๏

If the readings are close use the IOL master readings

๏

If the readings are different you may need to investigate further

www.medsalesacademy.co.uk

Investigating K Readings

๏

Using Pentacam because

• Most popular
• Images from and back surfaces of cornea
• I have most experience with it

www.medsalesacademy.co.uk

Check Zone and Ring are Similar

X X XX/2=K2 X X XX/2=K1

www.medsalesacademy.co.uk

If not - BAD

www.medsalesacademy.co.uk

Tips

๏

Asymmetry is suspicious

๏

Check other reports like Belin Ambrosio

๏

Check for Artefacts

๏

Egg Shaped pupil suggests movement

www.medsalesacademy.co.uk

Power Distribution

www.medsalesacademy.co.uk

Corneal Curvature

๏

Sim Ks

• Anterior taken at 3mm (2.4 IOL Master)

๏

True Net Power

• Add Anterior and Posterior power together
• Thin Lens Formula

๏

Total Corneal Refractive Power

• Ray trace through all surfaces
• Thick lens formula

www.medsalesacademy.co.uk

True Net Power

Cornea n=1.376 Aqueous n=1.336 Air n=1 PowerD = n-1 x1000 rmm

+

www.medsalesacademy.co.uk

Total Corneal Refractive Power

www.medsalesacademy.co.uk

Astigmatism

ATR 0-30 ATR 150-180 WTR 60-120 OBL 30-160 O B L 1 2

• 1

5

www.medsalesacademy.co.uk

Astigmatism

Anterior surface-based keratometry compared with Scheimpflug tomography- based total corneal astigmatism.

Tonn B1, Klaproth OK1, Kohnen T1.

https://www.ncbi.nlm.nih.gov/pubmed/25468887

www.medsalesacademy.co.uk

Axis

www.medsalesacademy.co.uk

Cataract Pre-Op

www.medsalesacademy.co.uk

Also

๏

Chord Distance

๏

Difference between Pupil Centre and Apex (where the patient is looking)

๏

Jack Holladay - over 0.5 mm not suitable for MF

๏

For more info www.gatinel.com

www.medsalesacademy.co.uk

Example

๏ Lets review the topography

www.medsalesacademy.co.uk

4 Maps Refractive

www.medsalesacademy.co.uk

Power Distribution

www.medsalesacademy.co.uk

BAD

www.medsalesacademy.co.uk

Holladay Report - Chord

www.medsalesacademy.co.uk

Refractive - Chord

www.medsalesacademy.co.uk

Cataract Report

www.medsalesacademy.co.uk

Today we have learnt

✓

Why K readings are important to IOL calculations

✓

How to take accurate measurements

✓

How to compare readings from different devices

✓

How to investigate irregular K readings

✓

Understanding different ways to measure corneal curvature

✓

Understanding Astigmatism front and back

✓

Using reports to screen out unsuitable patients

www.medsalesacademy.co.uk

Thank you!

๏

We will email you some questions.

๏

Please send your questions and comments to emma@medsalesacademy.com

๏

We look forward to seeing you on the next course - A Constants and Formula
