3-Dimensional Shop Floor Measurements To Improve Yield Dr. r. E Eri rik N Novak Good Metrology Saves Significant Money According to Quality Digest, poor quality control costs an average of $2M/year over the 100 companies they surveyed.

slide-1
SLIDE 1

3-Dimensional Shop Floor Measurements To Improve Yield

Dr.

  • r. E

Eri rik N Novak

slide-2
SLIDE 2

Good Metrology Saves Significant Money

  • According to Quality Digest,

poor quality control costs an average of $2M/year over the 100 companies they surveyed.

  • NIST performed 16 economic

studies since 2000, showing average benefit of metrology investment is 47:1

10/2/2018 2

slide-3
SLIDE 3

Consequences of Poor Quality Control Are Severe

Internal Failure Costs

– Waste – Scrap – Rework – Additional failure analysis – Reinspection – Downgrading – Shortages

External Failure Costs

– Repair and service – Warranty claims – Complaints – Returns – Travel and Return time – Throughput – Downtime – Post-warranty costs – Dissatisfaction – Customer perception

10/2/2018 3

slide-4
SLIDE 4

The Modern Take on ‘An Ounce of Prevention…’

10/2/2018 4

slide-5
SLIDE 5

Effects on Measurement Capability Are Interrelated

10/2/2018 5

Operator

slide-6
SLIDE 6

Micro-Scale Defects Are Critical To Understand

  • Performance

– Pitting/porosity, scratches, affect efficiency – Nicks and dents can cause leaks – Burrs can cause damage to other parts

  • Longevity

– Defects can lead to excessive wear – Imperfections can initiate corrosion – Structural integrity is compromised by voids

  • Perception

– The human eye is excellent at seeing small flaws – The human eye is terrible at estimating their size – Customers will reject parts they suspect

10/2/2018 6

slide-7
SLIDE 7

Metrology Tradeoffs Must Be Balanced

10/2/2018 7

Lateral Resolution Field of View Vertical Resolution Depth Range Standoff Distance

  • Max. Feature Height

Ease

  • f Use

Flexible Software

  • Major Goals:
  • Quantify anything an operator can readily see
  • Quantify anything a scribe gauge or ‘calibrated fingernail’ can feel
  • Meet current and next-gen part spec drawings
  • Instant results
  • Future Proof – Automation Capability, Customizable, Cloud-enabled…
slide-8
SLIDE 8

Traditional Shop-Floor Inspection Methods Are Insufficient

Visual / Finger Test

  • Operator dependent
  • Non-gage capable

10/2/2018 8

Comparison Test Plate

Replication combined with surface profiler

  • High material costs
  • 30+ mins/measurement
  • Operator and material dependent

***When in doubt – reject or rework… Expensive!!!

slide-9
SLIDE 9

Test: Which Pit Is Deepest?

10/2/2018 9

1 2 3 4 5 6

slide-10
SLIDE 10

Test: Which Pit Is Deepest?

10/2/2018 10

25 um .001” 80 um .0032” 20 um .0008” 150 um .006” 150 um .006” 20 um .0008” < 5 um <.0002”

slide-11
SLIDE 11

Most Portable Tools Are 2D and Lack Resolution

Laser Scanners and Stereoscopes

  • Limited lateral resolution >2mil (50um)
  • Non-gage capable for micro-defects <10mils
  • Single line doesn’t capture full defect (i.e. deepest point)
  • Sensitive to material finish, reflectivity and slope

10/2/2018 11

2D Stylus Profilers

  • Limited vertical range
  • Give PV value only
  • Can’t measure edges, corners across steps

***Portable and convenient but not capable of measuring micro-defects

slide-12
SLIDE 12

10/2/2018 12

Pit Measurement Using 2D Trace Varies

.0030” (76 um)

slide-13
SLIDE 13

10/2/2018 13

Pit Measurement Using 2D Trace Varies

.0025” (63 um)

slide-14
SLIDE 14

10/2/2018 14

Pit Measurement Using 2D Trace Varies

.0022” (56 um)

slide-15
SLIDE 15

Automated 3D Results Eliminate Uncertainty

10/2/2018 15

.0028” (71 um)

slide-16
SLIDE 16

Large Defects Are Even Harder To Assess

10/2/2018 16

.0023” (58 um)

slide-17
SLIDE 17

Large Defects Are Even Harder To Assess

10/2/2018 17

.0009” (23 um)

slide-18
SLIDE 18

Large Defects Are Even Harder To Assess

10/2/2018 18

.0017” (43 um)

slide-19
SLIDE 19

Large Defects Are Even Harder To Assess

10/2/2018 19

.0013” (33 um)

slide-20
SLIDE 20

Analysis of Entire Defect Eliminates Uncertainty

10/2/2018 20

.0029” (74 um)

slide-21
SLIDE 21

3D Lab-Based Metrology Is Impractical

3D Optical Profilers

  • $75-200K
  • Limited to small parts
  • Requires dedicated, trained operator
  • Slow feedback due to measurement turnaround time

10/2/2018 21

3D Stylus Profilers

  • $25-150K
  • Limited to small parts
  • Limited to single trace – can’t measure full feature
  • Measurements take several minutes
  • Slow feedback due to measurement turnaround time

***Lab-based metrology provides adequate resolution but is not practical for shop-floor inspection

slide-22
SLIDE 22

What Are Critical Criteria For Success?

  • Easy To Use
  • Non-Destructive
  • Sufficient Resolution
  • Sufficient Range
  • Field of View
  • Correlation

– Between Units – With other techniques

  • Robustness
  • Extensible

10/2/2018 22

slide-23
SLIDE 23

3D Shop Floor Measurements Provide Instant Feature Analysis

10/2/2018 23

slide-24
SLIDE 24

Interferometry/Structured Light/Fringe Projection: Scalable Surface Metrology

24

Laser Interferometry: Optic Shape White Light Interferometry: Micro-Roughness Fringe Projection: Large Irregular Shape Optical Coherence Tomography: Retina Phase Contrast Microscopy (DIC): Spyrogira Cell

24

4D Technology Corporation

10/2/2018

Resolution depends primarily on the wavelength of fringes

10/2/2018 24

slide-25
SLIDE 25

Polarization Combined With Structured Light Allows Fast 3D Measurements

Array of micro-polarizers matched to detector

US Patent 7,230,719

α=45, φ=90 α=0, φ=0 α=135, φ=270 α=90, φ=180

Unit Cel

  • Uses 4 pixels to reconstruct phase
  • 3D image in one frame
  • Slight loss in lateral resolution

25 25

4D Technology Corporation

10/2/2018

Array of color filters matched to detector

  • Uses 4 pixels to reconstruct color
  • Color image in one frame
  • Slight loss in lateral resolution

10/2/2018

slide-26
SLIDE 26

Polarized Structured Light (PSL) Enables Precision Hand-Held Metrology

  • Structured light uses the

bending of projected lines to compute 3D shape

  • Generally requires multiple

patterns, colors, or angles so is not vibration-immune

  • High-resolution difficult to

achieve, especially on metal surfaces

  • Polarization enables both

single-frame and high- resolution measurements

10/2/2018 26

slide-27
SLIDE 27

4D InSpec Designed Specifically for Shop Floor Metrology

10/2/2018 27

Specification 4D InSpec 4D InSpec XL

Vertical Resolution 2.5 um (0.0001”) 2.5 um (0.0001”) Depth Range 2.5mm (0.1000”) 9mm (0.35”) Standoff distance 35mm (1.3”) 60mm (2.3”) Field of View 8 x 8mm (0.3”x0.3”) 15x15mm (0.6”x0.6”) Lateral Sampling 3.5 um (0.00015”) 7.0 um (0.0003”) Meas+Analysis time <1sec <1sec

slide-28
SLIDE 28

PSL Measures Many Materials and Finishes

  • Carbon Fiber
  • Composites
  • Glass
  • Plastics
  • Cast Iron
  • Metals
  • Silicon
  • Rubber
  • Paper
  • Textiles
  • Semi-transparent/cloudy Surfaces
  • Ultra-finish
  • Matte
  • Rough
  • Flat
  • Curved
  • Corners

10/2/2018 28

Paint Layer Thickness Ultra-finished Blades Spline Gear

slide-29
SLIDE 29

PSL Provides High Repeatability

  • Measured 0.00075” (19um) defect 30 times
  • Results Shown Below
  • Standard deviation = .00002” (0.5um)

10/2/2018 29

0.0001 0.0002 0.0003 0.0004 0.0005 0.0006 0.0007 0.0008 0.0009 5 10 15 20 25 30 35 Pit Depth (inches) Measurement #

slide-30
SLIDE 30

Cross Platform Correlation Is Important

  • Range of pit depths observed on field hardware (25-75 um, 0.001 to 0.003”)
  • Results are within ±2.5um (0.0001”) on average
  • FRT white light profilometer and 4D InSpec are statistically indistinguishable

10/2/2018 30

slide-31
SLIDE 31

3 System Correlation Data Shows Excellent Agreement

  • Feature range from .0008

to .014” (20 um to 355 um)

  • Offset <.00009” (2 um)
  • Slope <1.2% different
  • R^2 >.996

10/2/2018 31

y = 1.0125x + 9E-05 R² = 0.9961

  • 0.016
  • 0.014
  • 0.012
  • 0.01
  • 0.008
  • 0.006
  • 0.004
  • 0.002
  • 0.01600 -0.01400 -0.01200 -0.01000 -0.00800 -0.00600 -0.00400 -0.00200 0.00000

IS171104 vs. IS161201

y = 0.9986x - 6E-05 R² = 0.9975

  • 0.01600
  • 0.01400
  • 0.01200
  • 0.01000
  • 0.00800
  • 0.00600
  • 0.00400
  • 0.00200

0.00000

  • 0.016
  • 0.014
  • 0.012
  • 0.01
  • 0.008
  • 0.006
  • 0.004
  • 0.002

IS171104 vs. Demo

y = 0.9989x - 6E-05 R² = 0.9973

  • 0.01600
  • 0.01400
  • 0.01200
  • 0.01000
  • 0.00800
  • 0.00600
  • 0.00400
  • 0.00200

0.00000

  • 0.016
  • 0.014
  • 0.012
  • 0.01
  • 0.008
  • 0.006
  • 0.004
  • 0.002

IS161201 vs. Demo

slide-32
SLIDE 32

InSpec Vs. 3D Microscope Shows Excellent Correlation on Shot Peened Roughness

10/2/2018

4D Technology Corporation Confidential Info

32

y = 1.0048x + 0.5809 R² = 0.9978 5 10 15 20 25 5 10 15 20 25

Ra (micrometer)

slide-33
SLIDE 33

Reliability Can Matter as Much as Capability

10/2/2018 33

slide-34
SLIDE 34

34

Optics Allow Fold Mirror To Access Tight Spaces

10/2/2018

slide-35
SLIDE 35

Custom Fixturing Makes Specific Part Measurements Simple

10/2/2018 35

45º Blade Edge Corner Flat

slide-36
SLIDE 36

Key Shop Floor Measurement Applications

  • Part Types

– Turbine blades – Pipes – Shafts – Gears and transmissions – Solder joints and connectors – Rivets and fasteners – Solar panels – 3D printed metals and plastics

  • Types of Measurements:

– Porosity – Corrosion depth, volume, areal coverage – Rivet depth and planarity – Radius of curvature – Pit and scratch depth, area, aspect ratios, volume – Die peen, laser mark depth, uniformity, and planarity – Cooling hole geometry

10/2/2018 36

slide-37
SLIDE 37

Intuitive, Touchscreen Interface Provides Instant Results

10/2/2018 37

Live Video Results History Analyses

slide-38
SLIDE 38

Rapid Return on Investment Possible With Appropriate Metrology

  • Reduced rework rate by 30% on a critical engine

component with ability to measure corrosion and wear

  • Reduced measurement time of pitting on a large

aerospace component from 3 days to 2 hours

  • Increased yield by 20% at a new-make machine

shop after quantifying visually ID’d defects as merely cosmetic

  • Reduced labor by 1 week in service through

elimination of disassembly/assembly prior to inspection of a critical component

10/2/2018 38

slide-39
SLIDE 39

Good Metrology Enables Integration and Customization

  • Remote Interface option allows control of

InSpec from 3rd party applications for easy of use with robotics and automated staging

  • Full surface can be exported into XYZ point

cloud for outside analysis, storage, or CAD integration

  • Defect results stored in simple CSV format for

interface with factory QC systems

  • IronPython Scripting allows user-customized

analyses

10/2/2018 39

slide-40
SLIDE 40

Applications: 3D Sintered Printing

10/2/2018 40

slide-41
SLIDE 41

Applications: 3D Polymer Printing: Layer Height, Periodic Errors

10/2/2018 41

slide-42
SLIDE 42

Applications: 3D Polymer Printing – Process Variations

10/2/2018 42

slide-43
SLIDE 43

Rivet Depth And Planarity

  • Large depth of focus and

field of view allows snapshot measurement of fasteners

  • Quantify

– Recession – Tilt – Uniformity

10/2/2018 43

slide-44
SLIDE 44

Applications: Cooling Hole Geometries benefit of large depth of focus

  • Angle of hole is about 20

degrees with respect to surface

  • Depth of hole is about 20

mils

  • Geometry can be checked

without bright-field uncertainties

10/2/2018 44

slide-45
SLIDE 45

Dot Peen, Laser Marking Depths Are Easily Quantified

  • Structures too deep can

lead to corrosion

  • Markings too shallow can

wear prematurely and cause loss of serialization

  • InSpec quantifies each

individual feature automatically

10/2/2018 45

slide-46
SLIDE 46

Applications: Defects on Radiused Surfaces

  • User defined size thresholds

for identifying features of interest

  • Finds all defects that meet

criteria

  • Reports depth, volume, area,

slope, location and more

10/2/2018

4D Technology Corporation Confidential Info

46

*** Auto Feature Analysis removes all uncertainty

slide-47
SLIDE 47

Applications: Scratch Severity

  • No need to guess at

maximum depth

  • InSpec calculates 2 point

maximum depth and weighted depth (average

  • f user set % of deepest

points)

10/2/2018

4D Technology Corporation Confidential Info

47

slide-48
SLIDE 48

Applications: Corrosion Tracking

10/2/2018 48

slide-49
SLIDE 49

Applications: Robotic Inspection

  • Vibration immunity allows

measurement without isolation

  • Defects automatically

reported as they are found

  • 100% Inspection possible

10/2/2018

4D Technology Corporation Confidential Info

49

slide-50
SLIDE 50

Shop Floor 3D Measurements Saves Money

  • Measure components prior to

disassembly

  • Avoid delays from using metrology lab
  • Halt reliance on human’s ‘calibrated

fingernail’ or ‘calibrated eye’

  • Eliminate errors from replicast/cross

sectioning

  • Measure at any angle
  • Measure without line of sight
  • Accurate, repeatable results
  • Improve Yields Dramatically!

10/2/2018 50

slide-51
SLIDE 51

NSF Acknowledgement

  • This material is based upon work supported by the

National Science Foundation under Grant No.

  • 455066. Any opinions, findings, and conclusions or

recommendations expressed in this material are those of the authors and do not necessarily reflect the views of the National Science Foundation.

10/2/2018 51

slide-52
SLIDE 52

Questions? For more info please: Visit IMTS booth 122027 visit www.4dInSpec.com email us at info@4dtechnology.com call at (520) 294-5600

10/2/2018 52
