SLIDE 1
25th Avenue Grade Separation
JPB Board April 4, 2019 – Agenda Item#10
Agenda
I. Project Need, Benefits & Description II. Construction – Construction Status – Construction Challenges III. Contract and Budget
2
25 th Avenue Grade Separation JPB Board April 4, 2019 Agenda - - PowerPoint PPT Presentation
25 th Avenue Grade Separation JPB Board April 4, 2019 Agenda - - PowerPoint PPT Presentation
25 th Avenue Grade Separation JPB Board April 4, 2019 Agenda Item#10 Agenda I. Project Need, Benefits & Description II. Construction Construction Status Construction Challenges III. Contract and Budget 2 Project Need,
SLIDE 2
SLIDE 3
Project Need, Benefits and Description
SLIDE 4
Project Location
4
SLIDE 5
- E. 25th Ave Railroad Crossing
- 92 Caltrain trains each weekday use this
crossing, in addition to freight
- No. 8 on California Public Utilities Commission
(CPUC) priority list for railroad crossing safety.
5
SLIDE 6
Project Benefits
- Enhanced East-West connectivity
- Improved pedestrian and motorist safety
- Improved traffic flow
- Fewer system-wide delays
- Support Caltrain electrification
- Improve Customer experience with new Station
- Enable future California High Speed Rail
(CAHSR)
- Safe rail operations
6
SLIDE 7
Factors Driving Award Date
- Coordination with Peninsula Corridor
Electrification Project (PCEP) required expedited Contract award: – Foundations Constructed as part of 25th Grade Separation (GS). – Poles and wires installed by PCEP
7
SLIDE 8
Risk Factors at Award
- Fiber Optic relocation was pending resolution
- f negotiations with Union Pacific Railroad
(UPRR)
- Funding from CAHSR was pending
8
SLIDE 9
Contract Award
- Contract Awarded to Shimmick Disney JV July
2017 for $ 82,890,000
- Original Completion Date Jan. 2020.
9
SLIDE 10
Project Funding, in Millions
$74 $12 $10 $84
Measure A City of San Mateo State Section 190 State HSR Prop 1A
10
$ 180 Project
SLIDE 11
Project Elements
Construct Grade Separation (elevated rails, lowered roads) between Hillsdale Blvd and Highway 92
- Five bridges
- Approx. 1 mile of Mechanically
Stabilized Earth (MSE) Wall
- New elevated station at Hillsdale
11
SLIDE 12
Elevated Track
12
SLIDE 13
East-West Connection (28th Ave)
13
SLIDE 14
Relocated Hillsdale Station
14
SLIDE 15
Construction - Status
SLIDE 16
Progress
- Bridges
– Beresford Creek Bridge Complete – Four (4) remaining Bridges substructure complete; superstructure ongoing.
- Wall Construction
– North of 25th Complete this month – Betwn 25th and 28th Ongoing
16
SLIDE 17
Bridges
17
SLIDE 18
MSE Wall
18
SLIDE 19
Construction - Challenges
SLIDE 20
Project Impacts
Utility Relocation – Major Utility relocations by Utility Companies, including:
- Fiber Optic Duct Bank
- PGE Gas Line
- ATT Communication Duct Bank
Station – Relocation and opening delayed by 10 months, with an anticipated opening of June 2020
20
SLIDE 21
Impacts Due To Fiber Optic
21
SLIDE 22
Working Around Live Fiber
22
SLIDE 23
PG&E Gas Line Relocation
23
SLIDE 24
AT&T
24
SLIDE 25
Weather Impacts
2018-2019 “Atmospheric Rivers”
- Caused Project Delays due to excess
rain days
- Created significant stormwater flows
requiring substantial dewatering
25
SLIDE 26
Weather Impacts
26
SLIDE 27
Contract and Budget
SLIDE 28
Contract and Budget
- All impacts from the Fiber Optic delay in 2018 have
been addressed and the project schedule has been re-baselined.
- Fiber Optic delays continued through March 2019.
Total Project Delayed up to 12 months. Current Anticipated Completion Date of January 2021.
- Return to this board with a recommendation to:
increase Contract Authority; No additional budget needed
- No current impact to PCEP
28
SLIDE 29
Questions
SLIDE 30
Grade Separation (25th Ave)
30
SLIDE 31
East-West Connection (31st Ave)
31
