24.01.17 Swiss Can Machinery AG V-matic Can Line for 60 cpm 24.01.17 Swiss Can Machinery AG V-matic Can Line for 60 cpm Semi-automatic depalletizer - Forklift with extended throw - Level compensation elevator - Wide conveyor CBW
SLIDE 2
SLIDE 3
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Semi-automatic depalletizer
- Forklift with extended throw
- Level compensation elevator
- Wide conveyor CBW 1170-1500
- Wide conveyor CBW 1170-1000
- Rotary Table Feeder RTF 1100
SLIDE 4
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Empty Can Cleaning ECC 153-3000
- Turning upside down and cleaning of empty
cans with cleaned compressed air
- 2 compressed air nozzles: 1 x permanent, 1 x
intermittent
- Clean compressed air to blow out cans –
- dourless and residue-free cleaning air with
0.01 µ particle filter and activated carbon filter
SLIDE 5
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Empty Can Cleaning ECC 153-3000
- Air ionizing against static loading as option
- Rotation of empty can during cleaning
- Separate compact deduster with filters, dust
box etc.
- Speed control for can conveyor
- Energy-saving, FI optimized asynchron motor
with 47 Nm output torque with PROFINET connection to main control
SLIDE 6
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Empty Can Disinfection UV 153-3000
- 8 UVC tubes with individual surveillance
- Warning previous to the end of the UVC tubes
durability (to order new ones on time)
- Machine stop at damage or exceeding of the
durability of the UVC tubes
- UVC tubes with shatter protection, HACCP
compliant
- Very easy accessibility for maintenance works
SLIDE 7
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Empty Can Disinfection UV 153-3000
- Stainless steel, low-maintenance construction with
easy changeable belts
- Speed control for can conveyor
- Energy-saving, FI optimized asynchron motor
with 47 Nm output torque with PROFINET connection to main control
- > 99 % (log2) bacterias killed (microbiological
base with “Bacillus subtilis SA (DSM 4181)”
SLIDE 8
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Spoon Dispenser
- Stainless steel, low-maintenance construction with
easy changeable belts
- Speed control for can conveyor
- Energy-saving, FI optimized asynchron motor
with 47 Nm output torque with PROFINET connection to main control
SLIDE 9
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Spoon Dispenser
- Can separating device
- Spoon feeder with spoon separating device
- Vibration hopper for spoons with additional bowl
- Can stops – spoon falls in – Can will be released
- If there is any interruption (no spoon, spoon not
thrown inside can), the machine will stop and give a signal
SLIDE 10
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Can Filling and Check-Weighing machine matic 127 Twin FC
- Stainless steel, low-maintenance construction
- Dosing with highly precise servo drive with control to
automatically process the data of the subsequent check weigher with feedback control
- Feeding of filling powder via horizontal auger with level
control
SLIDE 11
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Can Filling and Check-Weighing machine matic 127 Twin FC
- All parts in immediate contact with the filling powder are in
stainless steel, gaskets are FDA certified
- Automatic FI optimized asynchron motors for horizontal auger
and agitator
SLIDE 12
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm 3 x V-matic 127-3
- Max. can-Ø 127 mm – compatible with different
can-Ø und heights
- Can height easy adjustable via HMI (Touchscreen)
- Stainless steel, low-maintenance construction
- Indexing turret gear with Hybrid drive (max. 220
Nm) and und positioning accuracy ± 65“
SLIDE 13
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm 3 x V-matic 127-3
- Evacuating, gassing and seaming, all in one station!
- Adjustable pressure inside can, controlled by pressure
sensor (i.e. 850 mbar)
- < 0.5 % O2 inside can possible
- Completely new updated heads for 2015!
SLIDE 14
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm 3 x V-matic 127-3 NEW IN 2015!
- Servomotor for Seaming
- New hygienic design for better cleaning
- New Machine Frame (Stainless)
- New Base Plate (stainless)
- New ultrasonic sensors
SLIDE 15
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Capper C127 with SC 127
- Max. cap-Ø 127 mm – compatible with different cap-Ø
- Slope Conveyor stainless steel with FI asynchron motor and continuosly
variable speed
- Stainless steel, low-maintenance construction with easy changeable belt
- Energy-saving, FI optimized async. motor (0.55 kW, 120 Hz, 47 Nm)
- Congestion control with automatic machine start and stop
- Automatic discharching of wrongly positioned lids
SLIDE 16
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm Capper C127 with SC 127
- New designed capping system
- 2 servomotors synchronized with main belt
- Side conveyors to guide the cans
- 2 adjustable rolls to push lid onto can
- Easy to change format
SLIDE 17
24.01.17
OPTION: Lid destacker LD 127
- Fully automatic lid destacker with stainless steel
lid conveyor with FI asynchron motor and continuosly variable speed
- Variable overall length
Swiss Can Machinery AG V-matic Can Line for 60 cpm
SLIDE 18
24.01.17
Swiss Can Machinery AG V-matic Can Line for 60 cpm OPTION: Lid disinfection UV 127
- 4 UVC tubes with individual surveillance
- Warning previous to the end of the UVC tubes
durability (to order new ones on time)
- Machine stop at damage or exceeding of the
durability of the UVC tubes
- UVC tubes with shatter protection, HACCP
