Joint ICTP-IAEA International School on Nuclear Waste Vitrification 23 - 27 September 2019, Trieste, Italy Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 1 25-Sept-19 Laboratory Introduction Subatomic Physics and Associated

slide-1
SLIDE 1

25-Sept-19

1

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Joint ICTP-IAEA International School on Nuclear Waste Vitrification 23 - 27 September 2019, Trieste, Italy

slide-2
SLIDE 2

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Subatomic Physics and Associated Technologies (SUBATECH) Laboratory – High energy universe – Nuclear and environment (Radiochemistry Group) – Nuclear and Health (Radiochemistry Group)

25-Sept-19

2

Laboratory Introduction Under the Guidance of

  • Prof. Abdesselam ABDELOUAS

Head of Radiochemistry Group (SUBATECH Laboratory)

  • Dr. Tomo SUZUKI-MURESAN

Associate Professor, IMT Atlantique (SUBATECH Laboratory)

  • Ms. Haohan ZHANG

Ph.D. fellow (SUBATECH Laboratory)

slide-3
SLIDE 3

25-Sept-19

3

Subatech laboratory & IMT Atlantique (Nantes)

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

slide-4
SLIDE 4

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • Background
  • Objectives
  • Literature review
  • Materials and Methods
  • Characterization Techniques
  • Results and Discussion
  • Conclusion

25-Sept-19

4

Outlines

slide-5
SLIDE 5

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • French policy for Spent Nuclear Fuel

– recycling/reprocessing

  • Immobilization of fission products and minor

actinides in named R7T7

  • High level nuclear waste glass in

– Current project at Meuse/Haute-Marne centre (Cigéo project- ANDRA)

25-Sept-19

5

Background

Picture- ANDRA.fr

slide-6
SLIDE 6

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 25-Sept-19

6

Background (cont.)

Picture- Retrieval Test of HLW package in the Cigeo Project, Andra (IGD-TP Technical Forum, Berlin- 2018)

to waste package

  • f

waste package production, creates internal pressure prevent the entrance of groundwater fluid to waste package (glass+container) Glass alteration

slide-7
SLIDE 7

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • Number of water layers adsorbed on the glass surface

25-Sept-19

7

Literature review: evolution of glass under vapor condition

Figure- Chemical durability of Glasses (Abdelouas et al.- 2019)

W.L.Ebert et al., The Sorption of Water on Obsidian and a Nuclear Waste Glass (1991)

slide-8
SLIDE 8

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • The hydrated layer thickness depends on

, , and also .

25-Sept-19

8

Figures- Vapor hydration of SON68 glass from 90°C to 200°C: A kinetic study and corrosion products investigation (J. Neeway et al.- 2012)

Literature review: evolution of glass under vapor condition (cont.)

  • Hydration rate increases with the RH and Temperature increases
slide-9
SLIDE 9

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

I. Investigation of hydration kinetics in Vapor phase of French surrogate SON68 glass and ISG (International Simple Glass).

  • at two temperatures (90°C and 125°C)
  • at two RH- Relative Humidities (95% and 99%)

II. In Autoclave and Climate Test Chamber (which is not widely used).

25-Sept-19

9

Objectives

slide-10
SLIDE 10

25-Sept-19

10

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Materials & Methods

slide-11
SLIDE 11

25-Sept-19

11

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Materials

Oxides ISG (wt %) SON68 (wt %) SiO2 56.2 45.85 B2O3 17.3 14.02 Na2O 12.2 9.86 Al2O3 6.1 4.91 CaO 5.0 4.04 ZrO2 3.3 2.65 Fe2O3

  • 2.91

Li2O

  • 1.98

MoO3

  • 1.70

Others

  • 12.08

SON68 glass ISG glass

Glass composition- ISG (Chaoua et al.- 2014), SON68 (K M Davis et al.- 1996)

slide-12
SLIDE 12

25-Sept-19

12

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Autoclave (AC)

Autoclave figure- Chemical durability of Glasses (Abdelouas et al.- 2019)

Climate Test Chamber (CC)

slide-13
SLIDE 13

25-Sept-19

13

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Experimental conditions

Glass RH (%) Temperature (°C) Time of hydration (days)

Autoclave (AC) SON68 99 125 112 90 112 95 90 47 37 ISG 99 125 112 90 112 95 90 47 37 Climate Test Chamber (CC) SON68 95 90 44 37 ISG 44 37

slide-14
SLIDE 14

25-Sept-19

14

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Characterization Techniques

slide-15
SLIDE 15

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 25-Sept-19

15

Characterization Techniques

SEM

  • Determination of hydrated thickness

FTIR

  • To follow the glass hydration
  • To determine the physical hydration thickness

ICP-MS

  • Determination of chemical hydration thickness
slide-16
SLIDE 16

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 25-Sept-19

16

Sample preparation for SEM analysis

SEM- Scanning Electron Microscopy

slide-17
SLIDE 17

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 25-Sept-19

17

FTIR Spectroscopy

0.0000 0.2000 0.4000 0.6000 0.8000 1.0000 1.2000 1.4000 1.6000 1.8000 2.0000 2500 2700 2900 3100 3300 3500 3700 3900 4100 Absorbance (a.u.) Wavenumber (cm-1)

SON68_125°C-99%RH_AC

0 day 7 days 14 days 29 days 42 days 56 days 77 days 91 days 112 days

Deconvolution - five Gaussian using Origin 8.0 software (OriginLab) H.Tomozawa, M.Tomozawa. Diffusion of water into a borosilicate glass

OH stretching mode in SiOH OH stretching mode in the bound water silanol groups OH stretching mode in the free water molecule OH stretching mode in bound silanol groups silica matrix

slide-18
SLIDE 18

25-Sept-19

18

NL calculation

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Boron

slide-19
SLIDE 19

25-Sept-19

19

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Results & Discussion

slide-20
SLIDE 20

25-Sept-19

20

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 90°C ISG glass 95% RH 2.6×10-4 per day 99% RH 9.8×10-4 per day Factor 3.8

Effect of relative humidity at 90°C

  • Hydration rate increases with the RH increases
  • The results consistent with the literature@

@ literature (Abdelouas et al.- 2013) (Neeway et al.- 2012) (Chaou et al.- 2017) 0.02 0.04 0.06 0.08 0.1 0.12 20 40 60 80 100 120 Absorbance (a.u.) Hydration time (days)

ISG_90°C

95% RH 99% RH

slide-21
SLIDE 21

25-Sept-19

21

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 99% RH SON68 glass 90°C 4.3×10-4 per day 125°C 45.0×10-4 per day Factor 10.5

Effect of temperature at 99% RH

@ literature (Abdelouas et al.- 2013) (Neeway et al.- 2012) (Chaou et al.- 2017) 0.02 0.04 0.06 0.08 0.1 0.12 0.14 0.16 0.18 20 40 60 80 100 120 Absorbance (a.u.) Hydration time (days)

SON68_99%RH

90°C 125°C

  • Hydration rate increases with the Temperature increases
  • The results consistent with the literature@
slide-22
SLIDE 22

25-Sept-19

22

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

SON68 glass ISG glass At 125°C-99%RH 45.0×10-4 per day 12.0×10-4 per day At 90°C-99%RH 4.3×10-4 per day 9.8×10-4 per day

Effect of Glass Composition

  • The glass composition also affect the hydration rate
slide-23
SLIDE 23

25-Sept-19

23

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

Physical & Chemical Thicknesses

0.2 0.4 0.6 0.8 1 1.2 1.4 1.6 10 20 30 40 50 60

Thickness (µm) Hydration time (days)

SON68_99%RH

SON68_125°C_NL SON68_90°C_NL SON68_125°C_FTIR SON68_90°C_FTIR

  • The physical thicknesses (FTIR)

shows the maximum hydration.

  • The difference between physical

(FTIR) and chemical (NL) thicknesses is maybe boron were not released from hydrated layer to the solution.

slide-24
SLIDE 24

25-Sept-19

24

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL SON68 glass ISG glass Autoclave (AC) 2.1×10-4 per day 2.6×10-4 per day Climate test chamber (CC) 3.3×10-4 per day 7.6×10-4 per day Factor 1.6 3.0

Comparison of Autoclave (AC) and Climate Test Chamber (CC)

0.002 0.004 0.006 0.008 0.01 0.012 0.014 0.016 5 10 15 20 25 30 35 40 Absorbance (a.u.) Hydration time (days)

SON68_90°C-95%RH

AC CC

0.005 0.01 0.015 0.02 0.025 0.03 5 10 15 20 25 30 35 40 Absorbance (a.u.) Hydration time (days)

ISG_90°C-95%RH

AC CC

  • The hydration rate in the climate test chamber is higher than the autoclave
slide-25
SLIDE 25

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • Hydrated layer is not clearly visible in SEM images, not sure about the hydrated layer thickness

25-Sept-19

25

90°C-95%RH_CC SON68 glass ISG glass SEM analysis 0.24 μm 0.37 μm

Surface analysis

CC- Climate Test Chamber

slide-26
SLIDE 26

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL 25-Sept-19

26

99% RH_AC SON68 glass ISG glass SEM analysis 1.44 μm 0.69 μm FTIR 1.10 μm 0.63 μm

Surface analysis (cont.)

AC- Autoclave

  • Found a gap between Resin and Glass sample

gap

slide-27
SLIDE 27

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • Correlation factor,

0.1 SiOH absorbance unit per 0.99 μm of hydrated layer (125°C-99%RH) 0.1 SiOH absorbance unit per 1.5 μm of hydrated layer (90°C-99%RH)

  • Verifying,

– The hydration rate increasing with the RH and temperature increases

25-Sept-19

27

@ Primary Investigation of the ISG Glass Vapor Hydration (Abdelouas et al.- 2013), # Ph.D. thesis, University of Nantes (J. Neeway- 2010)

Conclusion

Jeet PATEL (for ISG_125°C-99%RH) Abdelouas et al. @ (for ISG_175°C-98%RH)

0.1 0.11

Jeet PATEL (for SON68_90°C-99%RH)

  • J. Neeway #

(for SON68 glass)

0.07 0.09

slide-28
SLIDE 28

25-Sept-19

28

Acknowledgment

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • Guillaume Blain (Subatech) for FTIR

formation.

  • Nicolas Stéphant from Centre of

Micro-characterization, University of Nantes (France) for SEM analysis.

slide-29
SLIDE 29

Hydration of Nuclear Waste Glass in Vapor Phase by Jeet PATEL

  • Prof. Abdesselam ABDELOUAS
  • Dr. Tomo SUZUKI-MURESAN
  • Ms. Haohan ZHANG

25-Sept-19

29

Special Thanks to

Thank you very much !
