The Contribution Of EU Funded Research & Innovation Programmes To The Renaissance Of The European Mining Industry 12/10/2016, London By Dr Chris Broadbent Director - Wardell Armstrong International Ltd Project Co-ordinator - FAME

slide-1
SLIDE 1

Dr Chris Broadbent 02.09.2016

The Contribution Of EU Funded Research & Innovation Programmes To The Renaissance Of The European Mining Industry 12/10/2016, London

By Dr Chris Broadbent Director - Wardell Armstrong International Ltd Project Co-ordinator - FAME

slide-2
SLIDE 2

30 Years of EU Funded R&I

Annual budget (in Billion €)

slide-3
SLIDE 3

HORIZON 2020

  • The European Unio

ion programme for rese search an and in innovation for 20 2014 14-2020 with a budget of €77 billion (in current prices th that in inclu clude in infl flation, compris ising bot

  • th th

the TFE FEU an and Euratom par arts)

  • A core par

art of

  • f Europe 20

2020 20, In Innovation Unio ion & European Research Area:

− Responding to the economic crisis to invest in jobs and

growth

− Addressing people’s concerns about their livelihoods, safety

and environment

− Strengthening the EU’s global position in research,

innovation and technology

  • 20

20% of

  • f EU28 GD

GDP will ill be fr from in industry ry by y 20 2020 20

slide-4
SLIDE 4
  • Aim: securing sustainable supplies of raw materials
  • Launched in 2008, consolidated in 2011
  • Non-energy, non-agricultural raw materials
  • Connecting EU external and internal policies
  • Integrated strategy (3 pillars)
  • Introduced list of 14 Critical

Raw Materials (CRM) in 2010, updated 20 CRMs in 2014

EU Raw Materials Initiative

slide-5
SLIDE 5

Critical Raw Materials (CRM’s)

slide-6
SLIDE 6
slide-7
SLIDE 7

H2020 TOPICS SO FAR (1) 2014

  • Mining of small and complex deposits and alternative mining
  • ¡VAMOS!, Real-Time-Mining, BioMOre
  • Flexible processing technologies
  • FAME, Optimore
  • Substitution of Critical Raw Materials (electronics)
  • INREP, INFINITY
  • Raw materials policy support actions

BUDGET: 68 M€

slide-8
SLIDE 8

H2020 TOPICS SO FAR (2) 2015

  • Deep mining on continent and/or in sea-bed
  • New sustainable exploration technologies and geomodels
  • New metallurgical systems
  • Su

Substitution of Critical Raw Materials - materials under extreme conditions

  • Raw materials policy support actions

BUDGET: 70 M€

slide-9
SLIDE 9

H2020 TOPICS SO FAR (3) 2016

  • Sustainable selective low impact mining
  • New technologies for the enhanced recovery of by-products
  • Intelligent mining on land
  • Raw materials policy support actions

BUDGET: 70 M€

slide-10
SLIDE 10

H2020 TOPICS SO FAR (4) 2017

  • New sensitive exploration technologies
  • Processing of lower grade and/or complex primary and/or

secondary raw materials in the most sustainable ways

  • Sustainable metallurgical processes
  • Raw materials policy support actions

BUDGET: 75 M€

slide-11
SLIDE 11

FAME Overview

  • Increase the competitiveness of European mining enterprises
  • Stimulate private engagement and investment in the European mining sector

Dissemination Exploitation

  • f Knowledge

Generation

Explore and Distribute Marketing Plan

Dissemination

Public Awareness Maximising Impact Education

Exploitation

  • Market Analysis
  • IPR management
  • Business plan

FAME Goals:

  • New flotation reagents for oxidic minerals
  • Optimised flotation regimes
  • New flotation cells for very fine grain flotation
  • Modular equipment supply on Build Own Operate

elements

WP7

PERFORMANCE INCREASE 10 TO 20%  HIGHER MARKETABLE CONCENTRATE STIMULATING MINING + ATTRACTING INVESTORS

Skarn Pegmatites Greisen

WP2 Economic potential of skarn, pegmatite and greisen ore deposits and requirements

for profitable mining, Mineralogical variables significant for process flow design

WP5

Energy savings in physical mineral liberation + Enhancement of separation contrast for better flotation recovery + Intensification of the processes + (Bio-) Leaching using fine grain activation Engineering/design at TRL5 of flexible, modular, economic and environmental friendly processing

  • f skarn and greisen ores, at TRL 6 (mobile) of pegmatites including recovery of strategic elements

WP6 Smaller socio-ecological footprint for marketing European resources at a global scale,

“clean mining” + more raw material awareness and public acceptance

WP4 Flowsheet and basic

engineering of flexible technology for skarn ore processing Concentrate upgrading, by-product recovery and utilization of rejects

WP3 Flowsheet and basic

engineering of flexible technology for greisen-pegmatitic ore processing; Concentrate upgrading, lithium and metallic by-product recovery

WP1 + WP8

Project Management Ethics

  • Enhanced pre-processing, fragmentation, sorting
  • Viability of bioagglomeration, bioflotation
  • Rapid techno-economic appraisals of mineral deposits
  • Valorisation of residues, Recovery of strategic elements
slide-12
SLIDE 12

TARGETING SPECIFIC DEPOSIT TYPES: CRM FOCUS

  • Which deposit classes in

the EU contain significant “Critical Raw Material” Resources?

  • Skarns
  • Greisens
  • Pegmatites
  • Complex mineralogy
  • Frequently small

resources not economically viable using existing large scale process flow designs

slide-13
SLIDE 13

FAME REFERENCE SITES

slide-14
SLIDE 14

FAME DEPOSIT MINERALOGY

  • Characterise the total mineralogical diversity and

residency of specific elements and materials of interest within the differing ore types

  • The “Good” vs the “Bad”
  • Understand the spatial characteristics of that

mineralogy

  • Grain size, morphologies, modal quantities, the spatial

distribution within the ore bodies

slide-15
SLIDE 15

MINERALOGICAL CHARACTERISTICS

slide-16
SLIDE 16

BOND WORK INDEX CHARACTERISATION AND TESTING

WAI Results Per STD Test (kWh/ton) University of Luleå- Ongoing Field Test (kWh/ton) Gonçalo 1 21.4 20.8 Gonçalo 2 19.2 17.1

Comparison of Bond Work Index “Field” and Standard Tests

slide-17
SLIDE 17

PRE-CONCENTRATION TESTWORK

LNEG / GEOS

slide-18
SLIDE 18

HIGH VOLTAGE PULSE (HVP) FRAGMENTATION

Figures: Left: Plasma channel along natural grain boundaries (HVP technology) Right: Conventional crushing, FDF WORK LED BY BRGM

slide-19
SLIDE 19

HVP - ELECTROFRAGMENTATION

GOAL : LOWER ENERGY COSTS : AVOID “FINES” GENERATION TESTWORK BY BRGM ON TWO FAME REFERENCE ORES (Gonçalo – Li Pegmatite and Tabuaço – W Skarn) Initial Results Encouraging → lower energy costs, improved recovery

→ innovative process flow sheet.

slide-20
SLIDE 20

CONCLUSION

Role of EU Research in European Mining Sector

  • Major Funder of R&I is Greater than 80% of

European Research Level

  • Import Globally Within the Mining Sector
  • Example of EU Project – FAME:

Brings Together Expertise from Across Europe Maintains Skills in Europe Can Assist and Fast track Mine Developments EU: Europe is Open For Mining

slide-21
SLIDE 21

EXPOITATION AND DISSEMINATION

  • What is Expected of FAME
  • Patents / Other
  • Scientific Papers
  • Impact on GDP
  • Impact on Jobs

New Mines Manufacturing

slide-22
SLIDE 22

FAME CONSORTIUM DRIVEN BY INDUSTRY

  • COLT RESOURCES – PORTUGAL
  • FAME HELPING TO DELIVER BUSINESS PLAN
  • GEOMET – CZECH REPUBLIC
  • FAME RESEARCH SHORTENS TIME TO BFS AND

REOPENING

  • SAXORE - GERMANY
  • FAME RESEARCH CAN IDENTIFY BY-PRODUCTS AND

EXPLOITATION ROUTE

  • WOLF - UK
  • FAME HELP TO REDUCE OPERATING COSTS / IMPROVE

RECOVERY???

slide-23
SLIDE 23

BREXIT

  • WHAT HAPPENS TO UK R&I
  • EU WILL CONTINUE TO FUND A

SUCCESSOR TO H2020

  • WILL UK STILL BE ABLE TO JOIN

CONSORTIA?

  • COMMODITY PRICES – NOT

INFLUENCED BY BREXIT

slide-24
SLIDE 24

CONTRIBUTION OF EU FUNDING TO RENAISSANCE OF EUROPES MINING INDUSTRY

  • BEGINS TO REVERSE A LONG DECLINE
  • WILL HELP KEEP SKILL BASE INTACT
  • DESIRE TO HAVE A EUROPEAN SUPPLY

OF RAW MATERIALS (Esp. CRM’s) BUT WILL THERE BE NEW MINES? JURY OUT → COME BACK < 2020

slide-25
SLIDE 25

FAME Co-ordinator: Wardell Armstrong International Ltd
