ENGINEERING & PROCUREMENT

• FULL DESIGN FROM GROUND UP WITH P.E.

STAMP

• STRUCTURAL, CONVEYOR, PLATEWORK,

PIPING AND EQUIPMENT

• 2D & 3D DESIGN AND DETAILING
• SMALL MODELING CAPABILITY
• FIELD SUPPORT
• FOUNDATION TO FINISH CONSTRUCTION
• FULL DESIGN AND DETAIL TO CUSTOMER

SPECS OF EQUIPMENT AND SPECIAL PLATEWORK

ENGINEERING (CONT.)

CONVEYORS

• CAPABILITIES TO HANDLE MOST ABOVE GROUND AND BELOW GROUND BELT DESIGN AND

FABRICATION

• IN HOUSE COMPONENTS
• ALL TYPES' OF STACKER CONVEYORS
• SCREW CONVEYORS
• BUCKET ELEVATORS

PLATEWORK, CUSTOM EQUIPMENT, AND SIEVES

• HEAD CHUTES, DISCHARGE CHUTES, SPECIAL CONTROL TRANSFER FLOW CHUTES LINED

AND UNLINED

• CHUTES DESIGNED WITH LINERS SUITED FOR APPLICATION
• FULL RANGE OF SIEVES , FEED BOXES, CYCLONE BOXES, & DISTRIBUTORS

ENCLOSED PIPE CONVEYOR

300 TON ROCK BIN

STRUCTURAL STEEL FABRICATION

STRUCTURAL STEEL FABRICATION

• OFFER FULL DESIGN FROM GROUND UP
• DRILLED HOLE CONNECTIONS FOR GUSSETS,

BASE, & CAP PLATES PREPARED WITH PEDDINGHAUS PLATE MACHINE

• CAN DESIGN WITH LRFD & ASD METHODS
• ACCESS TO DESIGNS IN TEKLA STRUCTURE

PIPING, CUSTOM CERAMICS, AND DUCTWORK

• CERAMIC LINED PIPING
• CUSTOM CERAMIC ELBOWS
• FIELD MEASURED TO ENSURE EASE OF

INSTALLATION

• DESIGN AND FABRICATION OF COMPLEX PIPING

AND ELBOWS

• DUST COLLECTION SYSTEMS

PIPING, CUSTOM CERAMICS, & DUCTWORK

MATERIAL PREPARATION

CUT/FORM/MACHINING

• ESAB TABLE TORCHES
• PEDDINGHAUS HSFDB2500 PL MACH
• CUT MATERIAL FROM 1/8"-3"
• CNC MILLING, DRILLING, & TAPPING

ROLLS

• CNC ROLLS W/ CONE ROLLING CAPABILITIES
• CAPACITY: 1/2"-20" DIA. X 120" LG TO 1/2"X72" DIA.X120"LG

PRESS BRAKE

• 400 TON
• 13 FT BED
• CAPACITY: ½” THK X 96" LG @ 90 o
• BEND 16 GA - 3/4"

SAW

• AUTO SAW THAT CAN BE PROGRAMMED FOR MITER CUTS
• UP TO 65o POSITIVE & NEGATIVE

PEDDINGHAUS HSFDB 2500

FAB & WELDING

• CUSTOM FABRICATION AND WELDING WITH A LARGE

RANGE OF VERSATILITY

• YEARS OF EXPERIENCE IN ALL TYPES OF WELDING AND

FABRICATION

• 12 FT X 45FT PANGBORN

ENCLOSED BOOTH

• (4) AUGERS CONTINUOSLY

DUMPING INTO A (2) TON HOPPER

• USE STEEL GRIT TO BLAST

TO A SP6 FINISH

BLAST FACILITY

PAINT BOOTH

• 20 FT X 65 FT ENCLOSED

AREA

• D.E.Q. CERTIFIED
• EQUIPPED WITH 130o DRY

STATION

• SPRAY MULTIPLE TYPES &

BRANDS:

• PPG
• DEVOE
• SHERWIN WILLIAMS
• EPOXIES
• URETHANES
• ENAMELS
• POLYURETHANES

REBUILD/REPAIR (VACUUM PUMPS, MAG SEPARATORS & HEATERS)

• MAGNETIC SEPARATOR TANKS & DRUMS (ERIEZ & STEARNS)
• VACUUM PUMPS & BLOWERS (ROOTS, G/D, SUTORBILT,

HOFFMAN, LAMSON, & MYERS)

• CERTIFIED GE/ROOTS REPAIR FACILITY
• OEM REPLACMENT PARTS
• NEW UNITS
• FULL ANALYSIS & TESTING REPORTS
• SITE EVALUATIONS
• MISC PREP PLANT EQUIPMENT
• CONVEYOR COMPONENTS

BELT WIPERS & CRC INDUSTRIAL HEATERS

BELT WIPERS

• FREE BELT EVALUATIONS
• INSTALLATION INCLUDED IN PRICE OF COMPONENTS
• VARIATIONS OF DESIGNS FOR MULTIPLE

APPLICATIONS

• MULTIPLE PRODUCTS
• REPLACEMENTS PARTS AVAILABLE

HEATERS

• STAINLESS STEEL OR GALVANIZED DESIGNS
• ABILITY TO WASH DOWN UNIT
• UNIT REPAIRS
• REPLACEMENT PARTS AVAILABLE
