10 Objects, Variables, Memory Michele Van Dyne MUS 204B - - PowerPoint PPT Presentation

10 Objects, Variables, Memory Michele Van Dyne MUS 204B mvandyne@mtech.edu https://katie.mtech.edu/classes/csci136 Where Java stores stuff The Heap The Stack Breaking both Java Garbage Collector (GC) Creating objects


slide-1
SLIDE 1

Michele Van Dyne MUS 204B mvandyne@mtech.edu https://katie.mtech.edu/classes/csci136

10 – Objects, Variables, Memory

slide-2
SLIDE 2

 Where Java stores stuff

  • The Heap
  • The Stack
  • Breaking both
  • Java Garbage Collector (GC)

 Creating objects

  • Copy constructors
  • Methods creating objects

 Static keyword

  • Static methods and instance variables
slide-3
SLIDE 3

 Stack

  • Where method invocations live
  • Where local variables live
  • A chunk of memory

 Heap

  • Where all objects live
  • Another chunk of memory

3

slide-4
SLIDE 4

 Methods are “stacked”

  • You call a method → put on top of a call stack
  • A method stays on stack until it finishes executing
  • Each stack frame contains:

 What line it is executing  Values of all the method’s local variables

 This includes parameters to the method

4

slide-5
SLIDE 5

5

public void doStuff() { boolean b = true; go(4); } public void go(int x) { int z = x + 24; crazy(); } public void crazy() { char c = 'a'; }

slide-6
SLIDE 6

6

public void doStuff() { boolean b = true; go(4); } public void go(int b) { int c = b + 24; crazy(); } public void crazy() { char c = 'a'; }

doStuff() boolean b → true doStuff() boolean b → true go() int b → 4 int c → 28

1 2

doStuff() boolean b → true go() int b → 4 int c → 28

3

crazy() char c → 'a' doStuff() boolean b → true go() int b → 4 int c → 28

4

slide-7
SLIDE 7

7

public class Factorial { public static long fact(long n) { if (n <= 1) return 1; return n * fact(n - 1); } public static void main(String [] args) { long result = fact(4); System.out.println("4! = " + result); } }

0! = 1 1! = 1 2! = 1 x 2 = 2 3! = 1 x 2 x 3 = 6 4! = 4 x 3 x 2 x 1 = 24 Some example factorials.

main() fact(4) n → 4 fact(3) n → 3 fact(2) n → 2 fact(1) n → 1

slide-8
SLIDE 8

8

public class Factorial { public static long fact(long n) { if (n <= 1) return 1; return n * fact(n - 1); } public static void main(String [] args) { long result = fact(4); System.out.println("4! = " + result); } }

main() fact(4) = 24 fact(4) n → 4 return 4 * fact(3) fact(3) n → 3 return 3 * fact(2) fact(2) n → 2 return 2 * fact(1) fact(1) n → 1 return 1

0! = 1 1! = 1 2! = 1 x 2 = 2 3! = 1 x 2 x 3 = 6 4! = 4 x 3 x 2 x 1 = 24 Some example factorials.

slide-9
SLIDE 9

0! = 1 1! = 1 2! = 1 x 2 = 2 3! = 1 x 2 x 3 = 6 4! = 4 x 3 x 2 x 1 = 24 Some example factorials.

9

public class Factorial { public static long fact(long n) { return n * fact(n - 1); } public static void main(String [] args) { long result = fact(4); System.out.println("4! = " + result); } }

main() fact(4) n → 4 fact(3) n → 3 fact(2) n → 2 fact(1) n → 1 fact(0) n → 0 fact(-1) n → -1 fact(-2) n → -2

Exception in thread "main" java.lang.StackOverflowError at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) at Factorial.fact(Factorial.java:6) ...

slide-10
SLIDE 10

 Local variables live on the stack

ck

  • Local variables in a method
  • Parameters passed to a method
  • Reference variables

 e.g. passing in a int [] array, a Hero object, …  Only the remote control lives on the stack

 Objects live on the heap

ap

  • Objects instantiated with new, live on the heap
  • Instance variables of an object

 Stored as part of the object living on the heap

10

slide-11
SLIDE 11

 Creating an object in 3 easy steps:

1) Declare a reference variable

11

Heap Duck myDuck

myDuck

slide-12
SLIDE 12

 Creating an object in 3 easy steps:

1) Declare a reference variable 2) Create an object

12

Heap new Duck();

myDuck

slide-13
SLIDE 13

 Creating an object in 3 easy steps:

1) Declare a reference variable 2) Create an object 3) Link the object and the reference

13

Heap Duck myDuck = new Duck();

myDuck

You have now consumed memory on the heap based on how much state a Duck requires (i.e. the number and type of its instance variables).

slide-14
SLIDE 14

 Java tracks # of variables referring to an

  • bject
  • As soon as nobody refers to an object, its memory

can be freed

  • Java's automatic Garbage Collector (GC) periodically

handles this for you

 Exactly when is up to the JVM  Enjoy it (while it lasts)

14

You're so going to have to this yourself in data structures.

slide-15
SLIDE 15

 Object-killer #1

  • Reference goes out of scope

permanently

15

public class DuckKiller1 { public static void makeDuck() { Duck d = new Duck(); } public static void main(String [] args) { makeDuck(); while (true) { // Do something } } }

main() main() makeDuck() main()

d Heap Heap

slide-16
SLIDE 16

 Object-killer #1b

  • Variable inside curly braces

goes out of scope

16

00 public class DuckKiller1b 01 { 02 public static void main(String [] args) 03 { 04 if (args.length >= 0) 05 { 06 Duck d = new Duck(); 07 } 08 while (true) 09 { 10 // Do something 11 } 12 } 13 }

main() line 04 line 05 line 06

d Heap

slide-17
SLIDE 17

 Object-killer #1b

  • Reference goes out of scope

permanently

17

00 public class DuckKiller1b 01 { 02 public static void main(String [] args) 03 { 04 if (args.length >= 0) 05 { 06 Duck d = new Duck(); 07 } 08 while (true) 09 { 10 // Do something 11 } 12 } 13 }

main() line 04 line 05 line 06 line 07 line 08

Heap

slide-18
SLIDE 18

 Object-killer #2

  • Assign the reference to another object

18

00 public class DuckKiller2 01 { 02 public static void main(String [] args) 03 { 04 Duck d = new Duck(); 05 System.out.println("quack!"); 06 d = new Duck(); 07 System.out.println("quack!"); 08 d = new Duck(); 09 System.out.println("quack!"); 10 } 11 }

d Heap

main() line 04

slide-19
SLIDE 19

 Object-killer #2

  • Assign the reference to another object

19

00 public class DuckKiller2 01 { 02 public static void main(String [] args) 03 { 04 Duck d = new Duck(); 05 System.out.println("quack!"); 06 d = new Duck(); 07 System.out.println("quack!"); 08 d = new Duck(); 09 System.out.println("quack!"); 10 } 11 }

Heap d

main() line 04 line 05 line 06 After executing line 06, no one is referring to the first Duck object anymore. It is now subject to garbage collection.

slide-20
SLIDE 20

 Object-killer #2

  • Assign the reference to another object

20

00 public class DuckKiller2 01 { 02 public static void main(String [] args) 03 { 04 Duck d = new Duck(); 05 System.out.println("quack!"); 06 d = new Duck(); 07 System.out.println("quack!"); 08 d = new Duck(); 09 System.out.println("quack!"); 10 } 11 }

Heap d

main() line 04 line 05 line 06 line 07 line 08 After executing line 08, both the first and second Ducks objects can be garbage collected.

slide-21
SLIDE 21

 Object-killer #3

  • Set the reference variable to null

21

00 public class DuckKiller3 01 { 02 public static void main(String [] args) 03 { 04 Duck d = new Duck(); 05 System.out.println("quack!"); 06 d = null; 07 System.out.println("quack!"); 08 } 09 }

main() line 04

d Heap

slide-22
SLIDE 22

 Object-killer #3

  • Set the reference variable to null

22

00 public class DuckKiller3 01 { 02 public static void main(String [] args) 03 { 04 Duck d = new Duck(); 05 System.out.println("quack!"); 06 d = null; 07 System.out.println("quack!"); 08 } 09 }

Heap

main() line 04 line 05 line 06

d

After executing line 06, no one is referring to the Duck object anymore. The Java garbage collector can now free up the Duck's memory.

slide-23
SLIDE 23

 Memory is not infinite

  • Can't keep new’ing forever w/o getting rid of any
  • You can buy yourself some time:

 Increase memory with JVM flag: -Xmx<num>[k|m|g]

23

import java.util.*; public class HeapDeath { public static void main(String [] args) { ArrayList<Duck> list = new ArrayList<Duck>(); while (true) { Duck d = new Duck(); list.add(d); } } }

While variable d scopes out every loop, the Duck reference persists inside the ArrayList. Memory is never freed!

slide-24
SLIDE 24

24

Type Memory ry size (bits, 8 bi bits = byte)

byte

8

short

16

int

32

long

64

float

32

double

64

boolean

not precisely defined

char

16 NOTE: The size of a reference variable’s remote control is JVM dependent. But there is always overhead for the reference variable and for any instance variables inside the data type!

http://righteousit.wordpress.com/tag /tcpip/

slide-25
SLIDE 25

25

00 public class HeapPuzzler 01 { 02 public static void main(String [] args) 03 { 04 Duck d = new Duck(); 05 Duck [] a = new Duck[4]; 06 for (int i = 0; i < a.length; i++) 07 a[i] = new Duck(); 08 System.out.println("quack!"); 09 a[0] = null; 10 a[1] = d; 11 System.out.println("quack!"); 12 } 13 }

After r execu cutin ing g line # Du Duck cks on t the heap ap Variable(s) le(s) that t point to a a Du Duck

  • bject

ct

04 05 08 09 10

1 d 1 d 5 d, a[0], a[1], a[2], a[3] 4 d, a[1], a[2], a[3] 3 (d, a[1]), a[2], a[3]

Two variables that refer to the same Duck

slide-26
SLIDE 26

 Copy constructor

  • A special constructor
  • Parameter is another object of the same type
  • Simply copies all the state of the passed in object

26

public class Duck { private String name = ""; private double weight = 0.0; public Duck(Duck other) { this.name = other.name; this.weight = other.weight; } }

A copy constructor!

slide-27
SLIDE 27

 An instance method can create a new object

and return it

27

Hey rabbit, what do you know? “My location and my size!” Hey rabbit, what can you do? “I can draw myself.” “I can tell if somebody clicks on me.” “Ohh and um, well you know, I can make them there baby rabbits…”

slide-28
SLIDE 28

public class Rabbit { private double x = 0.0; private double y = 0.0; private static final double size = 0.06; public Rabbit(double x, double y) { this.x = x; this.y = y; } public void draw() { StdDraw.picture(x, y, "rabbit.png"); } public boolean intersect(double x, double y) { double deltaX = (this.x - x); double deltaY = (this.y - y); return (Math.sqrt(deltaX * deltaX + deltaY * deltaY) < size); } ...

28

slide-29
SLIDE 29

public Rabbit breed() { Rabbit baby = new Rabbit(this.x + (0.2 - Math.random() * 0.4), this.y + (0.2 - Math.random() * 0.4)); return baby; } public static void main(String [] args) { ArrayList<Rabbit> rabbits = new ArrayList<Rabbit>(); rabbits.add(new Rabbit(0.5, 0.5)); while (true) { for (int i = rabbits.size() - 1; i >= 0; i--) { Rabbit r = rabbits.get(i); r.draw(); if (r.intersect(StdDraw.mouseX(), StdDraw.mouseY())) rabbits.add(r.breed()); } StdDraw.show(100); } } }

29

slide-30
SLIDE 30

 Static methods

  • Forbidden from using instance vars of the class

 Non-static methods (instance methods)

  • Allowed to use instance vars

 A class can have:

  • All static methods

 e.g. Math class

  • All non-static methods
  • A mix of both

 e.g. Wrapper classes like Double and Integer

30

slide-31
SLIDE 31

31

Metho thod signatur nature Descri cripti tion

  • n

public static int round(float a)

Round to the nearest integer

public static long round(double a) public static int min(int a, int b)

Find the minimum of two numbers

public static long min(long a, long b) public static float min(float a, float b) public static double min(double a, double b) public static int abs(int a)

Return absolute value of a number

public static long abs(long a) public static float abs(float a) public static double abs(double a) public static double random()

Get a random number in [0.0, 1.0)

public static double sqrt(double a)

Take the square root of a number

A selection of the static methods in Math.java

slide-32
SLIDE 32

32

public static final double E = 2.7182818284590452354; public static final double PI = 3.14159265358979323846; /** * Don't let anyone instantiate this class. */ private Math() {}

Constants in Math.java. The constructor of the Math class.

A private constructor. Makes it impossible to instantiate an object of type Math. All calls via static method calls, e.g. Math.sqrt(), Math.min()

slide-33
SLIDE 33

33

int x = Math.round(42.2); int y = Math.min(56, 12); int z = Math.abs(-343);

These methods don't use instance variables, so there is no specific object to call the methods on. Methods called using class name.

Math mathObj = new Math();

You can't do this since the constructor is private:

Exception in thread "main" java.lang.Error: Unresolved compilation problem: The constructor Math() is not visible

There is no persistent state in the Math object, so no need to create an object on the heap.

slide-34
SLIDE 34

 Static methods

  • Cannot use non-static instance variables

34

public class Cow { private String name = ""; private double weight = 0.0; public static double getWeight() { return weight; } }

Since getWeight() is declared static, any use of a non-static instance variable results in a compile error:

Cow.java:8: non-static variable weight cannot be referenced from a static context return weight; ^

Cow cow1 = new Cow(); Cow cow2 = new Cow(); System.out.println("weight = ", Cow.getWeight());

The weight of which cow?

slide-35
SLIDE 35

 Static methods

  • Cannot call non-static methods

35

public class Cow { private String name = ""; private double weight = 0.0; public double getWeight() { return weight; } public static boolean isBig() { return (getWeight() > 500.0); } }

Since isBig() is declared static, any use of a non-static instance method results in a compile error:

Cow.java:13: non-static method getWeight() cannot be referenced from a static context return (getWeight() > 500.0); ^

slide-36
SLIDE 36

 Static instance variable

  • One var shared among all instances of a class
  • Why?

 Commonly used for constants  Eliminate repeated variables that are always the same

 Reduce memory, doesn’t keep copies of identical objects

 Track a single value related to a class type

 e.g. Number of objects created for a particular class

36

public static final double PI = 3.14159265358979323846;

slide-37
SLIDE 37

37

public class Cow { private String name = ""; private double weight = 0.0; private static AudioFile sound = new AudioFile("cow.wav"); public static void makeNoise() { sound.play(); } }

Normal instance variables, each Cow object has its own set of these variables. All Cow objects share the same sound object. Only one

AudioFile object is created on

the heap, thus saving memory.

slide-38
SLIDE 38

38

public class Cow { private String name = ""; private double weight = 0.0; private static int numCows = 0; public Cow() { numCows++; } public Cow(Cow otherCow) { this.name = otherCow.name; this.weight = otherCow.weight; numCows++; } public static int getNumCows() { return numCows; } }

No matter how many Cow

  • bjects we create, there

is only ever one numCows instance variable that has a single value. Normal instance variables, each Cow object has its own set of these variables. Methods that only use static variables can be declared static (but don't have to be).

slide-39
SLIDE 39

 How your data is stored

  • Stack
  • Heap
  • Garbage collector

 Creating new objects

  • Copy constructor
  • Other methods creating new object instances

 Static keyword

  • For methods
  • For instance variables

Heap
