The world needs fixed nitrogen

World population (millions) % World population Average fertilizer input (kg ha⁻¹ yr⁻¹) Year

2

Erisman, JW, et al. Nature, 2008.

Problems with Haber Bosch

• Energy-intensive
• Creates

greenhouse gases

• Fertilizer run-off

3

An alternative to Haber Bosch

• Cyanothece sp. 51142

photosynthesizes and fixes nitrogen ○ Separates them temporally

• Nitrogenase enzyme

4

need reference

Bandyopadhyay, et al. Nature, 2010.

From Cyanothece to plants?

• Cyanothece related to

chloroplasts

• Can we engineer

nitrogen-fixing plants?

5

Diagram courtesy of Wikimedia.org

The nitrogen project

6

Images courtesy of cfb.unh.edu, landcareresearch.com, geneticliteracyproject.org, edenbrothers.com

Expressing a minimal Cyanothece nif cluster in

• E. coli would

lead to... ...faster characterization of the Cyanothece nitrogenase, which would be used to... ...engineer a better diazotrophic Synechosystis

Engineering nitrogen-fixing E. coli

7

Images courtesy of columbiariverkeeper.org, wikipedia, and ucdavis.edu

Nitrogen fixation is not easy for

• E. coli
• The nitrogenase reaction:

16 H2O + 16 ATP + 1 N2 + 8 Reduced Flavodoxin → 16 ADP + 16 Phosphate + 2 NH4 + 4 H+ + 1 H2

• Cyanothece sp. ATCC 51142’s nif cluster is 35 contiguous genes
• Cyanothece promoters, transcription factors, and RBSs may be incompatible

with E. coli

8

9

Project

• verview

Refining the nif cluster

2014 iGEM Team Native nif cluster - 35 genes

• Regulatory Barriers
• Unnecessary genes
• Uncharacterized genes

2015 iGEM Team Our designed nif cluster - 14 genes

• Inducible Expression
• Optimized synthetic RBS
• A Minimal Set of Genes

10

The minimal nif cluster

• 2 plasmids for simpler cloning
• Operons organized by expression level

Structural Iron Molybdenum Synthesis Iron Sulfur Synthesis Nitrogenase Stabilization

11

Inducible promoter (pTrc) Strong RBS Inducible promoter (araBAD) Weak RBS

CRISPR/dCas9 allows for targeted knockdowns

• Blocks gene transcription
• Knockdown genes on

minimal cluster

• 3 sgRNAs per

gene/promoter

12

Qi, et al. Cell, 2013.

Overexpression plasmids

• 14 plasmids of nif

genes

• Inducible

promoter

13

Results

14

• Sequence-confirmed

CRISPR/dCas9 plasmids

○ H1 ○ H3 ○ D1 ○ D2 ○ K1 ○ K2 ○ K3 ○ ara1 ○ ara3 ○ E1 ○ E2 ○ E3 ○ N2 ○ N3

• Sequence-confirmed

minimal nif cluster plasmids

○ araBAD-cysE2USVWZhesB- Kan-Rep101 ○ S1 ○ S2 ○ W1 ○ W2 ○ Z1 ○ Z2 ○ hesB1 ○ hesB2 ○ hesB3 ○ Trc1 ○ Trc2 ○ B2 ○ V2

• Restriction-digest-

confirmed

• verexpression

plasmids

○ cce_0551 ○ cce_0552 ○ cce_0555 ○ cce_0556 ○ cce_0562 ○ cce_0566 ○ cce_0567 ○ hesA ○ nifB ○ nifEN ○ nifV ○ nifX

Status of wet lab work

CRISPR/dCas9 targeted knockouts

• 27 complete
• 21 on their way

Complete minimal nif plasmids

• First complete
• Second on its way

Testing

• Acetylene reduction

assay protocol developed by 2014 member Caroline Focht

Overexpression plasmids

• 12 complete
• 2 on their way

15

Introduction to modeling

• Genome-scale model (GSM):

set of metabolic reactions identified for a given organism

• Gene-Protein-Reaction (GPR)

relationships

• Reaction directionality
• Scaled biomass equation
• Flux Balance Analysis (FBA):

paired with GSMs to estimate metabolic flux through organism

(Orth et al. PNAS, 2010)

16

Main objectives

Goal: Optimize nitrogen fixing E. coli using computational modeling

• Task 1: Identify media supplements to increase ATP

production and growth for N2 fixing cells

• Task 2 : Perform in silico single and double gene

knockouts

• Task 3: Identify flux redistributions between diazotrophic

and non-diazotrophic E. coli

17

Media supplementation

• Supplemented glucose in

existing media with additional substrate equivalent to 60

18

• Identified 15 metabolites

as having:

• Largest increase in

ATP production per increase in max biomass

• Larger increases in

ATP production than additional glucose

In silico gene knockouts

• Iteratively performing FBA
• Double gene knockouts:

computationally intensive

• Want to couple metabolite

production to biomass

• No coupling found

between flavodoxin reduction and biomass

Single Gene Knockouts Double Gene Knockouts (50% of total) No effect on biomass 1072 573070 Some effect on biomass 39 42383 Lethal 255 40

19

Changes in pyruvate metabolism

• Flux variability analysis: cells allocate

more flux through pyruvate synthase (POR5) under N2 fixing conditions

• POR5 produces reduced flavodoxin
• In silico pyruvate dehydrogenase

knockout (PDH) = increased flux through POR5

• PDH KO leads to pyruvate buildup in

cell2

• Recommended in vivo PDH knockout,

combined with POR5 overexpression

(adapted from Voet, Voet)

• 2. U.S. National Library of Medicine. Result Filters. National Center for Biotechnology Information.

20

Human practices

• Agriculture-focused panel presentation
• pen to the WashU community
• Discussion included safety, regulation,

ecological effects, labeling, potential to solve problems in the world

• Team and attendees got a space to have

questions answered, learn, and think critically about important issues

• Hope that it will spark further discussion on

campus

21

Part characterization collaboration

with Vanderbilt iGEM

• Ran induction experiments to determine

validity of the part

22

• Part K314100 + RFPyy did not work in either strain

Registry characterization

23

K577895 in DH10B

• Part is TetR-pTet system that

expresses RFP when induced

• First transformation produced

cells that were red in color

BBa_K577895 characterization

24

• Performed a second

transformation

BBa_K577895 characterization

25

• Performed a third induction

experiment

• Results highlight the

discrepancy in the two transformations

Added 12 new composite RBS parts to the registry

• RBSs used for genes

in minimized nif cluster

• Differing levels of

expression

• On each BioBrick:

○ Constitutive pTet promoter ○ RBS ○ mRFP ○ Two terminators

26

Special thanks to our sponsors...

The Focht, Bourg, and Heeney/Toomey Families NSF-MCB Award #1331194

27

Special thanks to our mentors...

(Left to right) Carlos Barba, Cheryl Immethun, Yi Xiao, Andrea Balassy, Thomas Mueller, Young Je Lee, Ray Henson, Caroline Focht

28

Tae Sook Moon Fuzhong Zhang Costas Maranas

Learn more about our team and project

2015.igem.org/Team:WashU_StLouis washu.igem@gmail.com @WashUiGEM WashU iGEM

29

Visit our poster: Hall C, No. 70
