Thermal Energy Study Guide
SLIDE 4
4
Part 1 Define the following terms and/or concepts
SLIDE 5
5
1 Temperature
SLIDE 6
6
2 Kinetic Energy
SLIDE 7
7
3 Thermal expansion
SLIDE 8
8
4 Thermal contraction
SLIDE 9
9
5 Potential Energy (between molecules)
SLIDE 10
10
6 Thermal Energy
SLIDE 11
11
7 Heat
SLIDE 12
12
8 Thermal Equilibrium
SLIDE 13
13
9 Conduction
SLIDE 14
14
10 Radiation
SLIDE 15
15
11 Convection
SLIDE 16
16
12 Conductors
SLIDE 17
17
13 Insulators
SLIDE 18
18
14 Specific heat
SLIDE 19
19
15 Thermodynamics
SLIDE 20
20
16 Work
SLIDE 21
21
17 1st law of thermodynamics
SLIDE 22
22
18 2nd law of thermodynamics
SLIDE 23
23
19 entropy
SLIDE 24
24
20 heat engine
SLIDE 25
25
Part 2 Directions: Select the answer choice that best completes the statement or answers the question.
SLIDE 26
26
21 When a liquid is cooled, the liquid molecules A spread farther apart. B move slower than before. C experience thermal contraction. D increase their kinetic energy.
SLIDE 27
27
22 This type of heat transfer can occur in outer space. A Conduction B Convection C Radiation D Entropy
SLIDE 28
28
23 An insulator is a material that has molecules that A are closely packed together. B move easily past one another. C do not transfer heat easily. D will shrink when heated.
SLIDE 29
29
24 The following objects are all heated from 10°C to 30°C. Which object will transfer the most energy to your hand? A 5kg apples B 2kg apples C 5kg gold D 2kg gold
SLIDE 30
30
25 Two objects of the same material but different masses are subjected to the same thermal energy input. A The object with less mass will experience a greater change in temperature. B The object with more mass will experience a greater change in temperature. C They will both experience the same change in temperature. D It is impossible to compare their changes in temperature without knowing the specific heat of the objects.
SLIDE 31
31
26 All of the following are examples of conductors except A Silver B Water C Air D Aluminum
SLIDE 32
32
27 A 80°C object and a 60°C object sit (not touching) in a 21°C environment. Which best explains what will happen. A Both objects will get warmer. B The warmer object will exchange heat with the environment at a slower rate. C The environment will get warmer. D The warmer object will cool down while the cooler
- bject will stay the same temperature.
SLIDE 33
33
28 An example of heat transfer by convection is A touching a hot pan and burning your finger B water boiling in a pot on the stove C feeling the warmth of a campfire on your face D the sun warming the roof of a house
SLIDE 34
34
29 Which of the following is an example of energy conservation? A An apple hangs suspended from a tree. B A person stands on tiptoes. C A car waits at a red light. D A hockey puck slides to a stop due to friction.
SLIDE 35
35
30 When energy is transferred as heat, the amount
- f useable energy
A decreases. B remains the same. C increases. D is always zero.
SLIDE 36
36
Part 3 Directions: Answer the following thoroughly. A table of specific heats is attached.
SLIDE 37
37
Substance Specific Heat (J/kg °C) Aluminum 897 Apples 3,300 Bricks 800 Carbon 709 Copper 385 Gold 129 Iron 449 Mercury 140 Steam 1,870 Tin 230 Water 4,186 Wood 1,700
SLIDE 38
38
31 How are temperature and kinetic energy related?
SLIDE 39
39
32 Describe what happens to motion and spacing of molecules when heated or cooled for a:
A liquid B solid C gas
SLIDE 40
40
33 What does a thermometer measure?
SLIDE 41
41
34 Describe characteristics of the three temperature scales including freezing and boiling point of water for each.
SLIDE 42
42
35 Complete the following conversions:
A 37°C to Fahrenheit B 384 Kelvin to degrees Celsius C 45°C to Kelvin D 45°F to degrees Celsius
SLIDE 43
43
36 Using the ideas of thermal expansion and contraction, describe how a liquid thermometer works.
SLIDE 44
44
37 Recall the video shown in class of the bimetallic strip that was bent when it was heated. Explain why it bent. (HINT: remember that the strip was made of two different metals)
SLIDE 45
45
38 When does potential energy between molecules increase? Decrease?
SLIDE 46
46
39 What two types of energy do molecules possess?
SLIDE 47
47
40 Explain why thermal energy and temperature, though related, are different.
SLIDE 48
48
41 Provide an example of when two substances might have the same temperature but different thermal energy.
SLIDE 49
49
42 Which will cool fastest initially in a room temperature room? Boiling water or lukewarm water?
SLIDE 50
50
43 How are heat flow and temperature differences related?
SLIDE 51
51
44 Will heat flow between two objects touching that have the same temperature? Why or why not?
SLIDE 52
52
45 Which direction does heat flow? Give an example.
SLIDE 53
53
46 What are the three methods of thermal energy transfer? Give a couple of examples of each.
SLIDE 54
54
47 Do all objects emit the same amount of radiation? Why or why not?
SLIDE 55
55
48 Conduction occurs primarily in solids. Why?
SLIDE 56
56
49 What is the primary difference between conductors and insulators?
SLIDE 57
57
50 Give several examples of conductors and insulators.
SLIDE 58
58
51 If you wanted water to boil quickly in a tea kettle, what kind of material would you use for the tea kettle?
SLIDE 59
59
52 If you wanted to maximize heat transfer, what kind of material would you use? How about if you wanted to minimize heat transfer?
SLIDE 60
60
53 If you have several spoons made of conducting materials and insulating materials, which will feel cooler to the touch and why?
SLIDE 61
61
54 Suppose you took a bite of pie that was at a certain temperature. The crust doesn’t burn you but the filling does. Using the idea of specific heat, explain why the filling burned you but the crust didn’t even though they had the same temperature.
SLIDE 62
62
55 State whether the variable is “inversely” or “directly” proportional to the temperature change. Provide an illustrative example for each. A mass B specific heat C thermal energy transferred
SLIDE 63
63
56 Calculate the heat input (or output) required to change the temperature of 3kg of iron by 3 degrees Celsius.
SLIDE 64
64
57 Calculate the final temperature of 0.020 kg of mercury that loses 500J of thermal energy and started with a temperature of 400Kelvin.
SLIDE 65
65
58 Calculate the change in temperature of 10kg of wood that gains 3,000J of thermal energy.
SLIDE 66
66
59 Give an example of the 1st law of thermodynamics in action.
SLIDE 67
