1-Fan-Bundle-Planar Drawings of Graphs Patrizio Angelini Michael A. Bekos Michael Kaufmann Philipp Kindermann Thomas Schneck Beyond Planarity Planar Beyond Planarity 1-planar Beyond Planarity 2-planar Beyond Planarity k -planar Beyond

slide-1
SLIDE 1

1-Fan-Bundle-Planar Drawings of Graphs

Patrizio Angelini Michael A. Bekos Michael Kaufmann Philipp Kindermann Thomas Schneck

slide-2
SLIDE 2

Beyond Planarity

Planar

slide-3
SLIDE 3

Beyond Planarity

1-planar

slide-4
SLIDE 4

Beyond Planarity

2-planar

slide-5
SLIDE 5

Beyond Planarity

k-planar

slide-6
SLIDE 6

Beyond Planarity

Fan-planar k-planar

slide-7
SLIDE 7

Beyond Planarity

Fan-planar k-planar

slide-8
SLIDE 8

Beyond Planarity

Fan-planar k-planar

slide-9
SLIDE 9

Beyond Planarity

Fan-planar k-planar

slide-10
SLIDE 10

Bundled Edge Drawings

[Holten & van Wijk ’09]

slide-11
SLIDE 11

Bundled Edge Drawings

[Lambert, Bourqui &Auber ’10]

slide-12
SLIDE 12

Bundled Edge Drawings

[Wu, Zeng, Zhu & Yu ’17]

slide-13
SLIDE 13

Bundled Edge Drawings

[Ye ’17]

slide-14
SLIDE 14

k-Fan-Bundle-Planarity

slide-15
SLIDE 15

k-Fan-Bundle-Planarity

slide-16
SLIDE 16

k-Fan-Bundle-Planarity

slide-17
SLIDE 17

k-Fan-Bundle-Planarity

1-sided

slide-18
SLIDE 18

k-Fan-Bundle-Planarity

1-sided 2-sided

slide-19
SLIDE 19

k-Fan-Bundle-Planarity

1-sided 2-sided k crossings per bundle

slide-20
SLIDE 20

k-Fan-Bundle-Planarity

1-sided 2-sided k crossings per bundle 1-Fan-Bundle-Planarity

slide-21
SLIDE 21

k-Fan-Bundle-Planarity

1-sided 2-sided k crossings per bundle Density 1-Fan-Bundle-Planarity

slide-22
SLIDE 22

k-Fan-Bundle-Planarity

1-sided 2-sided k crossings per bundle Density Relationships 1-Fan-Bundle-Planarity

slide-23
SLIDE 23

k-Fan-Bundle-Planarity

1-sided 2-sided k crossings per bundle Density Relationships Recognition 1-Fan-Bundle-Planarity

slide-24
SLIDE 24

Density

slide-25
SLIDE 25

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-26
SLIDE 26

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-27
SLIDE 27

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-28
SLIDE 28

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-29
SLIDE 29

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-30
SLIDE 30

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-31
SLIDE 31

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-32
SLIDE 32

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-33
SLIDE 33

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-34
SLIDE 34

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-35
SLIDE 35

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-36
SLIDE 36

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-37
SLIDE 37

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar

slide-38
SLIDE 38

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces

slide-39
SLIDE 39

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces

slide-40
SLIDE 40

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces

slide-41
SLIDE 41

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces

slide-42
SLIDE 42

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces

slide-43
SLIDE 43

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces

slide-44
SLIDE 44

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces

slide-45
SLIDE 45

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces Remove 1 edge, create 2 faces

slide-46
SLIDE 46

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces Remove 1 edge, create 2 faces

⇒ Planar graph G′, m′ ≤ 3n − 6, f ′ ≤ 2n − 4

slide-47
SLIDE 47

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces Remove 1 edge, create 2 faces

⇒ Planar graph G′, m′ ≤ 3n − 6, f ′ ≤ 2n − 4 ⇒ m ≤ m′ + 2f ′/3

slide-48
SLIDE 48

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces Remove 1 edge, create 2 faces

⇒ Planar graph G′, m′ ≤ 3n − 6, f ′ ≤ 2n − 4 ⇒ m ≤ m′ + 2f ′/3 ≤ 3n − 6 + 2 · (2n − 4)/3

slide-49
SLIDE 49

Density: 1-sided

Upper bound: Take maximally dense graph G, make it planar Remove 2 edges, create 3 faces Remove 1 edge, create 2 faces

⇒ Planar graph G′, m′ ≤ 3n − 6, f ′ ≤ 2n − 4 ⇒ m ≤ m′ + 2f ′/3 ≤ 3n − 6 + 2 · (2n − 4)/3 ≤ (13n − 26)/3

slide-50
SLIDE 50

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-51
SLIDE 51

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-52
SLIDE 52

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-53
SLIDE 53

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-54
SLIDE 54

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-55
SLIDE 55

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-56
SLIDE 56

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-57
SLIDE 57

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

slide-58
SLIDE 58

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

(5n − 10)/3

slide-59
SLIDE 59

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

(5n − 10)/3 +4 · (2n − 4)/3

slide-60
SLIDE 60

Density: 1-sided

Lower bound: Upper bound: (13n − 26)/3

(5n − 10)/3 +4 · (2n − 4)/3= (13n − 26)/3

Tight

slide-61
SLIDE 61

Density: 1-sided

2-layer

  • uter

general 1-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

LB UB LB UB LB UB

slide-62
SLIDE 62

Density: 2-sided

Flower Drawing:

slide-63
SLIDE 63

Density: 2-sided

Flower Drawing: – Vertices on circle

slide-64
SLIDE 64

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle

slide-65
SLIDE 65

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle

slide-66
SLIDE 66

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle

slide-67
SLIDE 67

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross

slide-68
SLIDE 68

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross

slide-69
SLIDE 69

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing

slide-70
SLIDE 70

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets

slide-71
SLIDE 71

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets

slide-72
SLIDE 72

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets

slide-73
SLIDE 73

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets

slide-74
SLIDE 74

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets

slide-75
SLIDE 75

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets – Cycle through terminals

slide-76
SLIDE 76

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets – Cycle through terminals

slide-77
SLIDE 77

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets – Cycle through terminals – Zigzag pattern in each partition

slide-78
SLIDE 78

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets – Cycle through terminals – Zigzag pattern in each partition

slide-79
SLIDE 79

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets – Cycle through terminals – Zigzag pattern in each partition

slide-80
SLIDE 80

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets – Cycle through terminals – Zigzag pattern in each partition

slide-81
SLIDE 81

Density: 2-sided

Flower Drawing: – Vertices on circle – Every vertex has left and right bundle – Consecutive bundles cross Water Lily Drawing: – Flower Drawing – Terminals partitioned into 3 sets – Cycle through terminals – Zigzag pattern in each partition

slide-82
SLIDE 82

Density: 2-sided

Water Lily Drawings have 4n − 9 edges

slide-83
SLIDE 83

Density: 2-sided

Water Lily Drawings have 4n − 9 edges

⇒ LB for outer-2-sided: 4n − 9

slide-84
SLIDE 84

Density: 2-sided

Water Lily Drawings have 4n − 9 edges

⇒ LB for outer-2-sided:

Merge 2 Water Lilys

⇒ LB for 2-sided:

4n − 9 6n − 18

slide-85
SLIDE 85

Density: 2-sided

Water Lily Drawings have 4n − 9 edges

⇒ LB for outer-2-sided:

Merge 2 Water Lilys

⇒ LB for 2-sided:

4n − 9 6n − 18

slide-86
SLIDE 86

Density: 2-sided

Water Lily Drawings have 4n − 9 edges

⇒ LB for outer-2-sided:

Merge 2 Water Lilys

⇒ LB for 2-sided: ⇒ LB for 2-layer 2-sided:

4n − 9 6n − 18 2n − 4

slide-87
SLIDE 87

Density

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 4n − 9 6n − 18 LB UB LB UB LB UB

slide-88
SLIDE 88

Density

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 3n − 7 4n − 9 6n − 18 LB UB LB UB LB UB

slide-89
SLIDE 89

Density

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 3n − 7 4n − 9 4n − 9 6n − 18 LB UB LB UB LB UB

slide-90
SLIDE 90

Density

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 3n − 7 4n − 9 4n − 9 6n − 18 8.6n − 15.6 LB UB LB UB LB UB

slide-91
SLIDE 91

Relationships

slide-92
SLIDE 92

Relationships

PLANAR

slide-93
SLIDE 93

Relationships

K4

PLANAR

slide-94
SLIDE 94

Relationships

K4

PLANAR

1-PLANAR

slide-95
SLIDE 95

Relationships

K4

PLANAR

K6 1-PLANAR

slide-96
SLIDE 96

Relationships

2-PLANAR

K4

PLANAR

K6 1-PLANAR

slide-97
SLIDE 97

Relationships

2-PLANAR

K4

PLANAR

K6 1-PLANAR K3,10

slide-98
SLIDE 98

Relationships

2-PLANAR

FAN-PLANAR

K4

PLANAR

K6 1-PLANAR K3,10

slide-99
SLIDE 99

Relationships

2-PLANAR

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

slide-100
SLIDE 100

Relationships

2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

slide-101
SLIDE 101

Relationships

1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

slide-102
SLIDE 102

Relationships

1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

? ? ? ?

slide-103
SLIDE 103

K3,14

slide-104
SLIDE 104

K3,14

slide-105
SLIDE 105

K3,14

slide-106
SLIDE 106

K3,14

slide-107
SLIDE 107

K3,14

slide-108
SLIDE 108

K3,14

slide-109
SLIDE 109

K3,14

slide-110
SLIDE 110

K3,14

slide-111
SLIDE 111

K3,14

slide-112
SLIDE 112

Relationships

1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

? ? ? ?

slide-113
SLIDE 113

Relationships

1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

? ? ?

slide-114
SLIDE 114

Relationships

1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

? ?

K3,14

slide-115
SLIDE 115

Relationships

1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

?

K3,14 D12

slide-116
SLIDE 116

Relationships

K4,12

2-SIDED 1-FBP 1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

?

K3,14 D12

?

slide-117
SLIDE 117

K9

slide-118
SLIDE 118

K9

slide-119
SLIDE 119

K9

slide-120
SLIDE 120

Relationships

K4,12

2-SIDED 1-FBP 1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

?

K3,14 D12

?

slide-121
SLIDE 121

Relationships

K4,12

2-SIDED 1-FBP 1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4,n−4 K4

PLANAR

K6 1-PLANAR K3,10

?

K3,14 D12 K9

slide-122
SLIDE 122

Relationships

K4,12

2-SIDED 1-FBP 1-SIDED 1-FBP 2-PLANAR

[Binucci et al.]

FAN-PLANAR

K4

PLANAR

K6 1-PLANAR K3,10 K3,14 D12 K9 K4,567

slide-123
SLIDE 123

Recognition

slide-124
SLIDE 124

Recognition: general

slide-125
SLIDE 125

Recognition: 2-layer 1-sided

slide-126
SLIDE 126

Recognition: 2-layer 1-sided

K2,3 is drawable

slide-127
SLIDE 127

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not!

slide-128
SLIDE 128

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

slide-129
SLIDE 129

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

slide-130
SLIDE 130

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

slide-131
SLIDE 131

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

  • Max. bicon. fan-planar:
slide-132
SLIDE 132

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

  • Max. bicon. fan-planar:
slide-133
SLIDE 133

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

  • Max. bicon. fan-planar:
slide-134
SLIDE 134

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

  • Max. bicon. fan-planar:
slide-135
SLIDE 135

Recognition: 2-layer 1-sided

K2,3 is drawable ... but K2,4 is not! [Binucci et al.]

  • Max. bicon. fan-planar:
  • Max. bicon. 1-sided 1-fbp:
slide-136
SLIDE 136

Recognition: 2-layer 1-sided

slide-137
SLIDE 137

Recognition: 2-layer 1-sided

slide-138
SLIDE 138

Recognition: 2-layer 1-sided

slide-139
SLIDE 139

Recognition: 2-layer 1-sided

slide-140
SLIDE 140

Recognition: 2-layer 1-sided

slide-141
SLIDE 141

Recognition: 2-layer 1-sided

slide-142
SLIDE 142

Recognition: 2-layer 1-sided

slide-143
SLIDE 143

Recognition: 2-layer 1-sided

  • Max. fan-planar
slide-144
SLIDE 144

Recognition: 2-layer 1-sided

  • Max. fan-planar
slide-145
SLIDE 145

Recognition: 2-layer 1-sided

  • Max. fan-planar
slide-146
SLIDE 146

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp
slide-147
SLIDE 147

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp
slide-148
SLIDE 148

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp
slide-149
SLIDE 149

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp
slide-150
SLIDE 150

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs

slide-151
SLIDE 151

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs

slide-152
SLIDE 152

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs

slide-153
SLIDE 153

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs Small Legs

slide-154
SLIDE 154

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs Small Legs

slide-155
SLIDE 155

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs

slide-156
SLIDE 156

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs

slide-157
SLIDE 157

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs

slide-158
SLIDE 158

Recognition: 2-layer 1-sided

  • Max. fan-planar
  • Max. 1-sided 1-fbp

Big Legs

  • Max. 1-sided 1-fbp
slide-159
SLIDE 159

Summary

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 3n − 7 4n − 9 4n − 9 6n − 18 8.6n − 15.6 LB UB LB UB LB UB

slide-160
SLIDE 160

Summary

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 3n − 7 4n − 9 4n − 9 6n − 18 8.6n − 15.6 LB UB LB UB LB UB K4,12 2-SIDED 1-FBP 1-SIDED 1-FBP 2-PLANAR [Binucci et al.]

FAN-PLANAR

K4 PLANAR K6 1-PLANAR K3,10 K3,14 D12 K9 K4,567

slide-161
SLIDE 161

Summary

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 3n − 7 4n − 9 4n − 9 6n − 18 8.6n − 15.6 LB UB LB UB LB UB K4,12 2-SIDED 1-FBP 1-SIDED 1-FBP 2-PLANAR [Binucci et al.]

FAN-PLANAR

K4 PLANAR K6 1-PLANAR K3,10 K3,14 D12 K9 K4,567 General:

slide-162
SLIDE 162

Summary

2-layer

  • uter

general 1-sided 2-sided

5n−7 3 5n−7 3 8n−13 3 8n−13 3 13n−26 3 13n−26 3

2n − 4 3n − 7 4n − 9 4n − 9 6n − 18 8.6n − 15.6 LB UB LB UB LB UB K4,12 2-SIDED 1-FBP 1-SIDED 1-FBP 2-PLANAR [Binucci et al.]

FAN-PLANAR

K4 PLANAR K6 1-PLANAR K3,10 K3,14 D12 K9 K4,567 General: 2-layer 1-sided:
