CSA Group Update

May 14, 2014 ALA Engineering Committee Meeting Sam Loggia, C. E. T. Standards Manager, Energy Electrotechnical Program Avery Yearwood, P. Eng. Technical Advisor - Lighting Service Quality, Science and Engineering

Agenda

3

1. CSA Group 2. CSA Group Standards

• CSA in the Lighting Sector
• Standardization Activities – Lighting, Controls & Ceiling Fans
• NRCan Update
• New Communities of Interest - COI

3. CSA Group Lighting & Ceiling Fan Labs

4

Create a Better, Safer, More Sustainable world where Standards work for People and Business Our Vision

Consumer Product Evaluation Standards Product Certification & Testing

1,700+ Employees Offices in: ‐ Canada ‐ United States & Mexico ‐ Asia ‐ Europe

‘One’ CSA

Overview of CSA Group

Accredited by ANSI in the US Within North America

Long‐time contributor to international standards activities

CANADA

On the International Scene

CSA Standards

Health & Safety Sustainability Energy Fuel Burning

54

areas of technology

94%

member satisfaction

95%

• f customers recommend

the use of CSA standards In surveys, Customers and Members say CSA exhibits the following key attributes:

Professional Trustworthy Integrity

Standards development methodology

• CSA members develop standards content; staff facilitates

the accredited development process

• Decisions are made by consensus and balanced stakeholder

representation

• Committee members are selected to represent various

interest groups most likely to be affected by the standard

CSA Group

9

Standards - Bridging the gap between Policy & Implementation…

10

ORGANIZATION STRUCTURE

11

PRESIDENT & CEO Ash Sahi

PRESIDENT STDS

Bonnie Rose

EVP FINANCE

Esteban De Bernardis

EVP HR

Paul Keane

DIRECTOR PR

Borjana Bulajic

GENERAL COUNSEL LEGAL

Ellen Pekilis

COO

Magali Depras

CORP SEC & GR

RJ Falconi

CIO IT

John Harrickey

EVP SCIENCE & ENG

Hélène Vaillancourt

RVP EUROPE

Ralf Schunk

RVP CHINA & HONG KONG

Yi Jiang

RVP NORTH & SE ASIA

Claudia Chan

RVP CANADA

Nashir Jiwani

RVP USA & MEXICO

Rich Weiser

GLOBAL BUSINESS LEADERS APPLIANCES & GAS

Todd Lumpkin

PLUMBING, CONSTRUCTION, LIGHTING & WIRING

Glenn Tubrett

• HAZ. LOC. &

INDUSTRIAL PRODUCTS

Gunter Drischel

MEDICAL, SAFETY & TECHNOLOGY

Sudhir Joshi

ALTERNATIVE ENERGY & SUSTAINABILITY

Terry Nagy

CONSUMER PRODUCT EVALUATION

Adam Davies

TRANSPORTATION

Paul Wilkinson

Standards STRUCTURE

12

12 12

Bonnie Rose

President, CSA Standards Ruth George

• Exec. Assistant

Rodney Jackson Confidential Secretary Vikki Burger Leadership Team Support Specialist

Greg Orloff

Director, Energy, Fuel Burning & Distribution Equipment

Karim Nazarali

Director, Electrical Sector

Doug Morton

Director, Government Relations

Inga Hipsz

Director, Sustainability

Loretta Wegman

Director, Operations Quality Assurance

Lisa Eberman

Director, Sales & Marketing

Gianluca Arcari

Director, Learning Institute

Bob Main

Director, Health & Safety & Membership

Abi Mercado‐Cloet

Manager, Finance Mihaela Stochitoiu Financial & Planning Specialist

Electrotechnical STRUCTURE

13

13

Karim Nazarali Director, Electrotechnical Sector

• M. Wilson

Program Mgr Part I, II, III

Vacant

Program Mgr Energy Efficiency, ICT, Renewables

Vacant

Program Mgr Alternative Energy Vehicles

• S. Loggia

Manager Standards

AA

Gobeil

Project Managers

Stefancic, Letea, Mereuta, O’Neill, Hawley, Hendricks, Humphries, Glowacki, Andronescu, McEwen

Project Managers

Hopkins, Donovska, Contasti, Elkouche, Wong, Tumkur, Alleyne, Vacancy

Project Managers

Tucky, Rondeau, Weis, Cairns, Marxen

• T. Pope

Project Manager Pt I

Lighting Safety Standards Changes driven by LEDs:

• Class 2 voltages - historically different
• New loads (i.e. Inrush Current - TLEDs used

with existing ballasts)

• Evolving lighting controls (i.e. programmable)
• “Global” technology – IEC standards

14

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

15

Class 2 voltages

• Canadian Electrical Code Part I updates

Section 16 (Class 1 and Class 2 circuits)

– Proposed increased Class 2 voltage - from 42.2 V DC to 60 V DC Voltage – Current status – at ballot

• Product Standards updates

C22.2 No. 250.13

– introducing new “LED Class 2” power supply – Current status – balloted and approved.

C22.2 No. 223

– Increase the voltage for all Class 2 transformers. – Current status – development stage

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

• CAN/CSA C22.2 No 250.13 - LED equipment for lighting applications

LED Class 2 power supply Printed-wiring boards connected to energy limited circuits Interconnect Class 1 and Class 2 circuits Revise requirements for abnormal tests

• C22.2 No. 250.0 – Luminaires

Branch circuit disconnect for fluorescent luminaires New annex for RV luminaires

• C22.2 No. 206 – Lighting Poles
• Lighting poles equipped with power supply systems that are alternate to the grid
• CSA C22.2 No. 43 – Lampholders
• Ceiling outlet-box lampholders with shades – removed from Scope
• CAN/CSA C22.2 No 62031 – LED Modules
• LED Modules, LED Engines, Software safety function
• CAN/CSA E62471 - Photobiological Safety of Lamps and Lamp Systems

16

Standards recently published

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

17

IEC adoptions

To support the ongoing effective deployment of LED products in the marketplace and facilitate international trade, CSA is also adopting the following IEC standards:

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Designation Title Type Publication

IEC 62778 Application of IEC 62471 for the assessment of blue light hazard to light sources and luminaires NS

• Mar. 2015

IEC 61347-2-13 D.C. or A.C. electronic controlgear for LED modules NS

• Jul. 2014

IEC 62560 Solid-State Lighting Controls NS

• Dec. 2014

IEC60838-2-2 Connectors for LED-modules NS

• Dec. 2014

IEC 60598-1 Luminaires: General Requirements and Tests NE

• Jul. 2015

IEC 62868 Organic Light Emitting Diode (Oled) Panels For General Lighting - Safety Requirements NS

• Apr. 2015

Lighting Safety Standards

• C22.2 No. 250.1 – Kits for Retrofitted Luminaires

– New Standard – Estimated publication date Jan. 2015 – To replace TIL B79 – TLED Retrofit Kits – For self-ballasted lamps please see CSA C22.2 No. 1993

• C22.2 No. 250.13 - LED equipment for lighting applications

– New Edition – Estimated publication date Jun. 2015 – Dimmable LED drivers for use with controls electrically wired in series with mains supply.

• C22.2 No. 250.0 – Luminaires (Tri-national)

– New Edition – Trinational - Estimated publication date Jul. 2015 – Add requirements for clothes closets luminaires.

18

Current activity

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

• C22.2 No. 184 – Solid-State Lighting Controls

– New edition - Estimated publication date Nov. 2014 – Inrush Current (347V) – Compatibility between misc. types of lamps and controls - NEMA SSL7

• C22.2 No.184.1 - Solid-State Dimming Controls

– New edition - Binational - Estimated publication date Nov. 2014 – Field replaceable actuator assemblies – Wall-box dimmer switches for use with LED lamp with integral driver light source

• C22.2 No. C22.2 No. 1993 – Self-ballasted Lamps and Lamp

Adaptors

– New edition - Trinational - Estimated publication date Dec. 2015 – Annex for Self–ballasted T-LEDs (T8 direct replacement)

19

Current activity

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

• C22.2 No. 256 – Direct Plug-in Nightlights

– New edition – Binational - Estimated publication date Jul. 2015 – Polarization requirements for nightlights provided with switches – Nightlights with vessels containing liquid – Scope clarification regarding plasma lamps

• C22.2 No. 250.570 – Track Lighting

– New standard - Estimated publication date Apr. 2015 – Include Low voltage track systems and their integration into the suspended ceiling grid

• C22.2 No. C22.2 No. 250.4 – Portable Luminaires

– New standard - Estimated publication date Jun. 2015 – will replace C22.2 No. 12 and – will also include: - extension hand lamps - cabinet lighting - heavy-duty hand lamps (TIL B-60) - extension hand lamps ( TIL B-67) - temporary lighting strings (TIL-B31)

20

Current activity

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

• C22.2 No. 74 – Equipment for Use with Electric Discharge

Lamps

– New edition – Estimated publication date May 2015 – Include requirements from TIL-B68 – Inrush Current (347V) – Maximum harmonic values of input current as a percentage of the fundamental components

• C22.2 No. 74.1 – Discharge Lamp Control Devices

– New standard – Trinational - Estimated publication date Jul. 2015 – Will be first in a series of technology specific standards to be consecutively developed – Will replace C22.2 No. 74 (above)

• C22.2 No. C22.2 No. 166 – Stage and Studio Luminaires

– New edition - Estimated publication date May 2015 – Add requirements for moving lights, fluorescent, HMI arc, and LED luminaires – Alignment with ESA Guide ESA-SPEC-003

21

Current activity

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

• C22.2 No. 166.1 – Distribution, Dimming and Switching

Equipment for Stage and Studio Luminaires

– New standard – Estimated publication date TBD – Will cover equipment remote from the luminaires. Equipment integral with the luminaires is covered in C22.2 No 166

• C22.2 No. 141 – Emergency Lighting

– New edition - Estimated publication date Jul. 2015 – Include two arrows and the running man pictogram on a single legend. – Include warnings for equipment with double power sources.

• C22.2 No. C22.2 No. 89 – Submersible Luminaires

– New edition - Estimated publication date Nov. 2015 – complete rewrite which will also include requirements for non- metallic junction boxes – Include requirements from TIL B44 and TIL B72

22

Current activity

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

Lighting Safety Standards

• C22.2 No. 207 – Portable and Stationary Electric Signs and

Displays

– New edition – Estimated publication date Jun. 2015 – Add LED Sign and LED retrofit kits – Include requirements from TILs B-46, TIL B-53 and TIL B-55 – Not utility connected signs (solar) – Components for electric signs.

• C22.2 No. 37 – Christmas Tree and Other Decorative Lighting

Outfits

– New edition - Estimated publication date Nov. 2015 – Complete rewrite - wiring / fusing requirements – harmonized with USA. – Include all decorative lighting (silhouettes, rope lights, etc)

• C22.2 No. C22.2 No. 184.2 – Advanced / Intelligent Lighting

Controls

– New Standard - Estimated publication date TBD – Proposed

23

Current activity

Discover the power of community. https://community.csagroup.org/ For membership and info please contact Julian.Mereuta@CSAGroup.org

24

• Focuses on standardization needs in energy efficiency and
• ther performance criteria for lighting products
• Identifies standards needs for emerging technologies
• Harmonization, where possible/practical with regional and

international standards

For membership and info please contact namat.elkouche@CSAGroup.org

Lighting Energy Efficiency Standards

Key Activities & Areas of Focus TC on Performance of Lighting Products (TC 419)

Lighting Energy Efficiency Standards Standards published in FY 2013/2014

Designation Type Standard Title Description CSA C875–13 New Standard Performance of general service directional lamps Technology neutral standard that sets the performance criteria for GSDL CSA C653‐13* New Edition Photometric performance of roadway and street lighting luminaires Expanded to include all the main technologies used in roadway and street lighting applications CSA C811‐13* New Edition Performance of highmast luminaires for roadway lighting Expanded to include all the main technologies used in highmast luminaires

25

* http://novascotia.ca/news/release/?id=20110418006

(Cont’d)

26

Designation Type Standard Title Description CSA C873 SERIES‐14 (Part 4: Lighting) New Standard Building energy estimation methodology. Part 4: Energy consumption for lighting Series of 9 systems standards that provide a methodology for assessing the overall energy efficiency of buildings. CSA C871 New Standard Performance of LED replacement lamps Defines minimum energy efficiency and performance requirements for light emitting diode (LED) lamps.

Lighting Energy Efficiency Standards Standards published in FY 2013/2014

27

Lighting Energy Efficiency Standards

Active Projects (FY 2014/15)

For membership and info please contact namat.elkouche@CSAGroup.org

Designation Type Standard Title Description Expected publication CSA C654 New Edition Fluorescent lamp ballast efficacy measurements Harmonized requirements for fluorescent lamp ballasts with the US DoE for 277V, but includes the 347V ballasts as well Sep‐2014 CSA C877 New Standard Performance of portable electric signs Defines minimum energy efficiency and performance requirements for portable signs in accordance with CEC Title 24 Dec‐2014 CSA C880 New Standard Performance of stationary electric signs Defines minimum energy efficiency and performance requirements for stationary signs in accordance with CEC Title 24 Mar‐2015

28

Lighting Energy Efficiency Standards

Projects to be initiated shortly (FY 2014/15)

For membership and info please contact namat.elkouche@CSAGroup.org

Designation Type Standard Title Description CSA C863 New Edition Energy efficiency of high‐intensity discharge (HID) and low‐pressure sodium (LPS) lamp ballasts Harmonized requirements for with the US DoE for 277V, but will also include requirements for the 347V ballasts as well CSA CXXX New Standard Performance requirements for HID lamps Harmonized requirements with the US DoE CSA C873 Amendment Building energy estimation methodology. Update to the standard based on validation results

29

Lighting Energy Efficiency Standards

Lighting Controls

• Considered a high priority
• TC is monitoring developments in dimming compatibilities as well

as activity on energy efficiency data from lighting controls in Canada and United States

• Proposal for new standard could move forward once more data is

available on energy efficiency results and dimming compatibility

• Residential control applications vs. commercial control applications

For membership and info please contact namat.elkouche@CSAGroup.org

30

Ceiling Fan Energy Efficiency Standards Energy Performance of Ceiling Fans

• CSA C814 Published in 2010.
• Specifies energy performance and marking requirements for

suspended and hugger ceiling fans for use in residential and industrial/commercial applications.

• Also specifies requirements for ceiling fan light kits and ceiling fans

with integrated lights. Requirements were developed in conjunction with TC on Performance of Lighting (TC 419).

• N/C

For membership and info please contact namat.elkouche@CSAGroup.org

NEW Interface for members (TC and TSCs)

31

Energy Efficiency Standards Access

32

NRCan Update

Forward Regulatory Plan 2014-2016 NRCan is working with the Canada-U.S. Regulatory Cooperation Council to advance Canada’s ability to align energy efficiency regulations with those in the U.S. Some mechanisms being considered include: powers to streamline NRCan’s ability to regulate; better use of incorporation by reference to maintain alignment; identifying efficiencies in the current national standards making process; greater collaboration with the U.S. in standards development (to reference jointly-made standards) and compliance

• perations. This work may affect the form of future regulatory amendments.

Amendment 13: http://www.nrcan.gc.ca/energy/regulations-codes-standards/6853 Amendment 14: http://www.nrcan.gc.ca/energy/regulations-codes-standards/6855

Contact: Debbie Scharf - NEW Director, Equipment Division Office of Energy Efficiency, Energy Sector equipment@nrcan.gc.ca 33

Learn more about our programs

Register and Begin to Explore!

https://community.csagroup.org

CSA online communities

• Learn about what’s going on in

CSA’s Electrotechnical program and

• ther programs
• Network with committee members,

industry experts, other users of standards

• Obtain standards (paid service) and

view on multiple platforms (e.g. mobile)

• Ask questions, start or join

discussions, respond to surveys

• Share ideas and areas for

improvement!

35

https://community.csagroup.org

Learn more about our programs

36

CSA Lighting Lab

• Alpharetta, GA Building is 30,000 sq ft: 3,000 sq ft office + 27,000 sq ft

lab space

• 17 dedicated employees
• 4 Goniophotometers (3 Type C and 1 Type A-Automotive Applications)
• 4 Integrating Spheres (One 1.5m, Two 2.0m and One 3.0m)
• 3,120 Elevated Ambient lamp-holders (45 Deg. C.)
• 2, 640 Non-elevated Ambient lamp-holders (25 Deg. C.)
• 2 Rain Chambers
• Full Service for Certification and Performance in one location.

NOTEs:

• Full Photometric Testing Capabilities (LM-79 and Others)
• CSA Group has three additional lab locations in Toronto, Shanghai and

Guangzhou.

For info please contact sean.clifford@csagroup.org

CSA Lighting Lab

37

CSA Ceiling Fan Lab

38

• Earned the U.S. Environmental Protection Agency(EPA)

recognition as an ENERGY STAR Testing Facility and Certification Body.

• For Canada, accredited by SCC to verify that products

comply with Natural Resource Canada(NRCan) regulations.

• CSA tests to Energy Star, NRCan as well as California

Energy Commission (CEC) requirements including:

– Energy Star: Residential Ceiling Fans V3.0 – NRCan requirements: CSA 814

• CSA has two Ceiling Fan testing laboratories.

– Cleveland, Ohio – Shanghai, China

CSA Group Seattle (Orb Optronix)

NVLAP Accredited to LM-79 and LM-80 ISO 17025 Certified Laboratory Electronics Laboratory Machine Shop Consulting Capabilities sales@orboptronix.com CSA Group/Orb Optronix - Proprietary

39

Engineering Services

Test and Measurement Products

LED Testing Services

Testing Services by Facility

sales@orboptronix.com CSA Group/Orb Optronix ‐ Proprietary

40

Contacts: Sam Loggia, C.E.T. Standards Manager, Energy Electrotechnical Program Sam.loggia@csagroup.org Avery Yearwood, P. Eng. Technical Advisor - Lighting Service Quality, Science and Engineering

Avery.Yearwood@csagroup.org

41

Thank You!
