2 Background:

n

Located in Cochrane, Alberta, Canada

n

Officially incorporated in 1994

n

Rick Littlewood – President & Founder

n

Dedicated to the Forage Export Industry

n

Designed & Manufactured over 86 Forage Presses; currently developing P90 & P91

n

Installed in Canada, USA, Australia, Europe & Africa

3 Why Choose Hunterwood:

n

We are a world-leader in hay compression technology

n

Our equipment is efficient and reliable

n

We use the most current technologies on our equipment

n

We are continually growing, evolving and innovating

4 Design Philosophy:

n

Engineered Approach

n

Simplistic and Modular Design

n

Bolted Attachments versus Welds

n

High Quality Components and Materials

n

Industrial versus Agricultural-based Equipment

n

World Leader: Pioneering & Innovation for Forage Export Industry

5 OUR PRODUCT LINES:

• FC6700
• FC7700
• FC8000 series
• FC10000
• CHAFF PRESS
• CUSTOM AUTOMATION

6

FC6700 Mid-Capacity Export Hay Press

Sample Layout

7

FC6700 Mid-Capacity Export Hay Press

• Big Bale Input:
• 26”x4’ OR 3’x4’ OR 4’x4’
• Speed = Buffer
• Promotes Leaf Retention
• Consistent fiber length

Key to Speed: Grid Slicing System

8

FC6700 Mid-Capacity Export Hay Press FC6700 Performance

• Low-cost of entry coupled with high container weights
• 330 kg output bales in alfalfa
• Fills a high-cube container to 26.4 MT
• 45” x 43” x 26” output bales
• Consistent production rate of 15 MT/hr
• Small machine footprint: 44’ x 57’

9 Dedicated Big Bale output

FC7700 Full-Capacity Export Hay Press

Sample Layout

10 Features:

• High-Speed, High Density
• Blending Ability
• Automated Operation
• FC7700 is third-generation
• Dependable Run-time
• Efficiency
• Modular Devices
• ¼ Cut Output Option

FC7700 Full-Capacity Export Hay Press

* 60 bales fill a standard or high cube container

11

FC7700 Full-Capacity Export Hay Press

• Big Bale Inputs:
• 3’ x 4’ x 8’
• 4’ x 4’ x 8’
• Speed = Buffer
• Promotes Leaf Retention
• Consistent fiber length
• Bad Bottom Reject

Key to Speed: Grid Slicing System

12

FC7700 Full-Capacity Export Hay Press Key to Speed and Efficiency: Hydraulics & Programming

• Pre-wired, pre-plumbed Self-Contained Power Pack
• 5,500 psi (2 x 12” main cylinders = 1,244,000 lbs of force)
• High Flow Manifolds
• 2017 Operating System
• Data Tracing and Acquisition
• Synchronization of Devices
• HWD Full Time Programmers
• HWD Full Time Support

13

FC7700 Full-Capacity Export Hay Press Standard Devices

• Self-Contained Power Pack:

(motors & pumps)

• Incline Conveyors
• Digital Scaling Conveyor
• FC7700 Press Core (heaper, stuffer,

compress, gates, eject, sleeve box)

• Simple elevator row push at output
• Cooling fan and pump

14

FC7700 Full-Capacity Export Hay Press Optional Devices

• Grid Slicing System (2nd box & crane)
• QC Options: Bad bottom trimming

Side Flake chutes Dump Door Reject conveyors

• Chaff Pit
• Multiple Conveyor options
• 2 wide + 3 high block former

15

FC7700 Full-Capacity Export Hay Press Customizable

• Power Pack (pumps and motors)
• Multiple Input Systems
• Integration of other devices & inputs:

(choppers, grinders, mixers, augers)

• (TMR) Conveyors
• Service Packages
• Hunterwood Online Production

Reporting software

16

FC7700 Full-Capacity Export Hay Press FC7700 Performance

• 1,244,000 lbs of force = Great peak bale weights, best average bale weights
• 450 kg output bales in the most types of forage possible*.
• Alfalfa = 450kg (fills container to 26.5 MT)
• Timothy Hay = 450kg (fills container to 26.5 MT)
• Sudan Grass = 400 kg – 430 kg (880 lbs – 945 lbs)
• Wheat Straw = 378 kg (835 lbs)
• +125,000 M/T annual capacity
• Consistently delivers a container an hour (Sprint rates up to 30 MT/hr)

17

• Original press design
• Destacker for 3-tie Product
• Big Bale Slicing System addition
• 10 – 17 MT/hr
• Most common equipment 1994 – 2002
• 23 in our fleet
• 13 are FC8322 - (20%)
• Creates 60kg whole bales & 30kg half-cuts

FC8222 / FC8322

18

FC10000 Premium Export Hay Press

19

VERSATILITY!

• Double width Intake
• Input sources (3-tie bales, 3’x4’, 4’x4’)
• Output Products: 30 kg-450 kg (66 lbs – 992

lbs)

• Standard export products
• 20-26+ MT/hr
• Customizable & Modular
• 16 in our fleet

FC10000 Premium Export Hay Press

20 FC10000 replaced FC9322 model

• Improved hydraulic power & response
• Advanced Software
• Enhanced Diagnostics
• Remote Monitoring
• Greater “Up Time”
• Up to 20% more production
• 15+ second cycle time (@ 260lbs in alfalfa)
• 1,244,000 lbs of Force
• +100,000 MT Annual Capacity

FC10000 Premium Export Hay Press

21

OUTPUTS:

• 120 kg full log ( 264 lb)
• Four half-cuts @ 30 kg (66 lb)
• 450 kg MAG ‘Jumbo’ bales (high cubes)
• 26.5 MT in Sea Containers

FC10000 Premium Export Hay Press

22

OUTPUT OPTION:

• Jumbo “MAG” Bale: 450 kg (992 lb)
• No interior straps
• Multiple cuts within bale

FC10000 Premium Export Hay Press

23

Options on interior cuts: 4, 8, 12, 16, 24.

FC10000 Premium Export Hay Press

24

CHAFF PRESS

25

CHAFF PRESS

OUTPUT :

• Mid-Density bales: 650 lbs – 850 lbs
• 30” x 45” X 43”

26

CHAFF PRESS

PRESS *

HYDRAULIC POWER UNIT

M/Tons Hour BALE WEIGHT (in Alfalfa) CP100 50 HPU 4 650 – 750 lbs CP200 125 HPU 7 650 – 750 lbs CP300 200 HPU 10 750 – 850 lbs

*Does not include an Input System

Fills a container to: 60 bales x 650 lbs = 39,000 lbs (17.7 MT) 60 bales x 750 lbs = 45,000 lbs (20.4 MT) 60 bales x 850 lbs = 51,000 lbs (23.1 MT)
