1 2 Renewable Sun Power Team members Niels Brandenburg Wim Faes Johannes Ihle Hafizul Ilias Vctor Porras Ionu Marius Dobroaia 3 Team members Niels Ionu Marius Wim Johannes Ihle Hafizul Vctor Brandenburg Dobroaia Faes Ilias


slide-1
SLIDE 1

1

slide-2
SLIDE 2

2

slide-3
SLIDE 3

Renewable Sun Power

Team members

Niels Brandenburg Wim Faes Johannes Ihle Hafizul Ilias Víctor Porras Ionuț Marius Dobroaia

3

slide-4
SLIDE 4

Team members

Niels Brandenburg Ionuț Marius Dobroaia Wim Faes Johannes Ihle Hafizul Ilias Víctor Porras Mechanical Engineering Mechanical Engineering Construction Engineering Mechanical Engineering Mechanical Engineering Electrical Engineering The Hague University of Applied Sciences Politehnica University of Bucharest University of Antwerp University of Applied Sciences Kempten EPSEVG EPSEVG

4

slide-5
SLIDE 5

Index

  • Planning
  • Goals
  • Renewable energy sources
  • Mirror system
  • The ORC system
  • Protoype
  • Working fluids
  • Heat exchanger
  • Generator
  • Pump
  • Conclusion

5

slide-6
SLIDE 6

Planning

  • Planning
  • Goals
  • Renewable energy sources
  • Mirror system
  • The ORC system
  • Protoype
  • Working fluids
  • Heat exchanger
  • Generator
  • Pump
  • Conclusion

6 6

slide-7
SLIDE 7

Goals

  • Main goal:
  • Design and calculate a solar ORC system
  • Sub goals:
  • Calculate the minimum requirements of the condenser,

evaporator, generator and pump

  • Find a matching standardized condenser and evaporator
  • Find a matching standardized generator and pump

7

slide-8
SLIDE 8

Renewable energy sources

8

Types of renewable energy

Solar (1%) Wind (4%) Geothermal (5%) Biomass (48%) Hydro (42%)

slide-9
SLIDE 9

The need for renewable energy

39% 24% 23% 7% 3% 4% 0.5%

Oil Coal Gas Nuclear Hydroelectric Biomass Others

9

slide-10
SLIDE 10

The mirror system

10

slide-11
SLIDE 11

Mirror materials

11

slide-12
SLIDE 12

Organic Rankine Cycle (ORC)

12

slide-13
SLIDE 13

Pressure-Enthalpy Diagram

13

slide-14
SLIDE 14

Prototype

  • Pump
  • Turbine
  • Plant

14

kW QPlant 2 . 7 

kW QPump 8 . 1 

kW QTurbine 9 . 8 

slide-15
SLIDE 15

Prototype

  • Solar constant
  • Required area of mirrors

15

2

1367 m W E       % 60 % 50

Turbine Pump

 

% 8

23

  q wt

ORC

2

75m E Q A

total Plant

   

% 7 % 95 % 90 % 8         

total Mirror Pipes ORC

   

slide-16
SLIDE 16

16

R245 fa

Industrial water Treat water

Working fluids

slide-17
SLIDE 17

R245 fa

P1( bar) P2(bar) Tc(ºC) Vapor Quality (%) Efficiency (%) R134a 32.47 10.170 101.0 96.15 4.57 R245fa 28.15 2.496 154.0 100 9.19 R227ea 25.56 7.003 102.8 100 4.50 R423a 29.47 9.306 99.52 100 2.64

17

slide-18
SLIDE 18
  • Excellent Thermal
  • Excellent Chemical Stability
  • High Specific Heat
  • Non Toxicity
  • Low Cost
  • Corrosion

Industrial water

18

slide-19
SLIDE 19
  • Non Toxicity
  • Excellent Thermal
  • Excellent Chemical Stability
  • High Specific Heat Capacity
  • Save Water
  • Low Cost

Treated water

19

slide-20
SLIDE 20

Heat Exchangers

20

A heat exchanger is a piece of equipment built for efficient heat transfer from one medium to another.

slide-21
SLIDE 21

Heat Exchangers

Applications

  • space heating
  • refrigeration
  • air conditioning
  • power plants
  • petrouleum refineries
  • natural gas procesing
  • sewage treatment

21

slide-22
SLIDE 22

Heat Exchangers

Types

22

Double pipe heat exchangers Shell and tube heat exchangers Plate heat exchangers Plate and shell heat exchangers

slide-23
SLIDE 23

Heat Exchangers

ORC Evaporator

23

Material: Stainless steel (AISI 316L) Pipes length: 1.4 m Shell diameter: 0.44 m

  • No. of pipes: 196

Water flow: 1.2 kg/s R245fa flow: 0.4 kg/s

slide-24
SLIDE 24

Heat Exchangers

ORC Condenser

24

Material: Stainless steel (AISI 316L) Pipes length: 1.4 m Shell diameter: 0.4 m

  • No. of pipes: 90

Water flow: 4.1 kg/s R245fa flow: 0.4 kg/s

slide-25
SLIDE 25

Generator

  • Turbine

25

𝑋𝑈𝑣𝑠𝑐𝑗𝑜𝑓 ≈ 8.9 𝑙𝑋 𝑋 = 𝑛 · 𝑋

𝑢34

slide-26
SLIDE 26

Generator

26

𝑋

𝐵𝑚𝑢𝑓𝑠𝑜𝑏𝑢𝑝𝑠 ≈ 8.9 𝑙𝑋

  • Alternator
slide-27
SLIDE 27

Pump

27

𝑋

𝑄𝑣𝑛𝑞 ≈ 1.8 𝑙𝑋

𝑛 𝑄𝑣𝑛𝑞 ≈ 0.4 𝑙𝑕/𝑡 𝑞𝑄𝑣𝑛𝑞 ≈ 31 𝑐𝑏𝑠

slide-28
SLIDE 28

Conclusions

28

WGenerator = 8.9 kW WPump = 1.8 kW

T = 145 °C T = 40 °C

slide-29
SLIDE 29

Thank you for your attention! Feel free to ask any questions!
