Zun Project Update

Hongbin Lu (Huawei) Madhuri Kumari (Intel) Shu Muto (NEC)

Agenda

• Containers on OpenStack
• Zun Basics
• Zun Internals
• Others
• Demo

Containers on OpenStack

OpenStack

Container

Nova Instance (container) Hypervisor (Container Runtime) Compute Network Storage Nova Instance (container) Nova

Containers on OpenStack

OpenStack Nova Instance (VM) Container Hypervisor Compute Network Storage Nova Instance (VM) Container Container Container Nova

Containers on OpenStack

OpenStack Nova Instance (VM) Container Hypervisor Compute Network Storage VM Nova Instance (VM) Container Container Container Container Orchestration Engine (COE) Nova

Containers on OpenStack

COE/Container Engine (Kubernetes, Docker, etc.) Deployment (Magnum) Authentication (Keystone) Zun Images (Glance?) Fuxi Storage (Cinder) Network (Neutron) Kuryr Monitoring (Telemetry?)

OpenStack API Native API

Agenda

• Containers on OpenStack
• Zun Basics
• Zun Internals
• Others
• Demo

What is Zun?

• Container API
• Resource management
• OpenStack Integration

○ Keystone ○ Neutron/Kuryr-libnetwork ○ Glance ○ Horizon ○ Heat ○ OpenStackClient ○ Nova ? ○ Placement API ? ○ Telemetry ? ○ Swift ?

COE/Container Engine (Kubernetes, Docker, etc.)

Magnum Keystone Zun Images (Glance?) Fuxi Cinder Neutron Kuryr Monitoring (Telemetry?) OpenStack API Native API

What is Zun?

Nova Instance Nova Instance DB Web Server Neutron Net Nova Instance Zun Container DB Web Server Neutron Net

Zun APIs

Create a container POST /containers List containers GET /containers Show a container GET /containers/<ID> Delete a container DELETE /containers/<ID> Retrieve logs of a container GET /containers/<ID>/logs Execute a command in a container POST /containers/<ID>/execute Attach to a container POST /containers/<ID>/attach ... ...

Run a Container

• Find an image from an image store (i.e. DockerHub, Glance)

$ docker search cirros

• Run a container with a command

$ zun run cirros ping -c 4 google.com

Enter into a Container

• Attach to a running container

$ zun attach mycontainer

• Open a new shell in a running container

$ zun exec --interactive mycontainer /bin/sh

Real Application

$ zun run -e MYSQL_ROOT_PASSWORD=rootpass \

• e MYSQL_DATABASE=wordpress \

mysql:latest $ zun run -e WORDPRESS_DB_HOST=$mysql_ip \

• e WORDPRESS_DB_USER=root \
• e WORDPRESS_DB_PASSWORD=rootpass \

wordpress:latest Wordpress Neutron Net Mysql

Orchestration with Heat

resources: db: type: OS::Zun::Container properties: image: mysql environment: MYSQL_ROOT_PASSWORD: rootpass MYSQL_DATABASE: wordpress wordpress: type: OS::Zun::Container properties: image: "wordpress:latest" environment: WORDPRESS_DB_HOST: {get_attr: [db, addresses, private, 0, addr]} WORDPRESS_DB_USER: root WORDPRESS_DB_PASSWORD: rootpass

Wordpress Neutron Net Mysql

Agenda

• Containers on OpenStack
• Zun Basics
• Zun Internals
• Others
• Demo

Architecture

Zun API Zun Compute Docker Keystone Kuryr Neutron Glance

Cloud Controller Node

Deployment

Zun API AMQP Keystone SQLdb Neutron Server

Compute Node

Zun Compute Neutron Agent Kuryr-libnetwork Docker

Compute Node

Zun Compute Neutron Agent Kuryr-libnetwork Docker

Compute Node

Zun Compute Neutron Agent Kuryr-libnetwork Docker

Compute Node

Zun Compute Neutron Agent Kuryr Docker

Cloud Controller Node

Zun API AMQP Keystone SQLdb Neutron Server

Agenda

• Containers on OpenStack
• Zun Basics
• Zun Internals
• Others
• Demo

Features

• Container APIs
• Container host management
• Multi-tenancy
• Neutron integration
• Support multiple image repositories

○ Docker Hub ○ Glance

• Heat Integration
• Horizon Integration
• OpenStackClient Integration

Roadmap

• Run containers on baremetal, VM, or COEs
• Additional container runtimes
• Stateful container
• Containers group
• Scheduling (integrate with Placement APIs)
• Keep container alive
• Monitoring
• Container snapshot
• Quota

Non-goal

• Container orchestration

○ Zun doesn’t provide container orchestration by itself ○ Use Heat with Zun resources for that

• COEs provisioning

○ Consider Kargo or Magnum

• System container

○ Consider Nova-lxd

• Build container from source code

○ Consider Solum

Comparison

• Zun VS nova-docker

○ Nova-docker: allow accessing docker containers via Nova’s API ○ Zun: full-featured container API

• Zun VS Kubernetes

○ Kubernetes: advanced container orchestration tool ○ Zun: simple container management tool ○ Kubernetes is an integrating target for Zun

Community

Agenda

• Containers on OpenStack
• Zun Basics
• Zun Internals
• Roadmap
• Demo

Demo

https://youtu.be/s758L_dIsLU
