ZERO KNOWLEDGE PROOFS Satya Lokam 15 Dec 2019 IndoCrypt 2019 - - PowerPoint PPT Presentation

ZERO KNOWLEDGE PROOFS

Satya Lokam 15 Dec 2019

IndoCrypt 2019

Akbar – Birbal Games

Prover Verifier

Akbar

• Switch or not with prob. ½
• Reject if wrong answer
• Else accept

§ Claim: different colors § Answer yes or no to “switched?”

Arthur – Merlin Games

Verifier Prover

• Switch or not with prob. ½
• Reject if wrong answer
• Else accept

§ Claim: different colors § Answer yes or no to “switched?”

Why is this a good proof?

• Completeness: If Prover’s claim is correct, he succeeds in convincing an

untrusting verifier of his claim (with prob. 1)

• If Birbal’s claim is correct, he always answers correctly, and Akbar will be

convinced that the balls are of different colors

• Soundness: A cheating prover (trying to prove an incorrect claim), can
• nly succeed with negligible probability in convincing the verifier, i.e.,

the verifier will catch a cheating prover with high probability

• If Birbal is lying, he will fail with prob. ½ in each round and hence

Akbar will catch him with prob. Exponentially close to 1.

Why is it Zero Knowledge?

• Whatever (distribution of) responses Birbal gave to Akbar can be simulated by

Akbar without talking to Birbal

• Simulator: can simulate verifier’s view of the world without interacting with the

prover, given the input and prover’s assertion

• ⇒ Verifier did not learn anything from the prover, i.e., the proof is zero knowledge!
• Existence of Simulator è Zero Knowledge

Every problem in 𝑂𝑄 has a ZKP

Verifier

Akbar

Prover

§ 3-colorability (without revealing the coloring ) § Sudoku Puzzle (without revealing the solution ) § Good RSA Modulus 𝑂 = 𝑞 ⋅ 𝑟 (without revealing prime factors 𝑞 and 𝑟 ) [GMW ‘86]

Correct execution of any (feasible) program 𝐷 has a ZKP

Verifier

Akbar

Prover

𝑦

input

𝑥

witness Circuit 𝐷

𝐷 𝑦, 𝑥 = 𝑧 ?

e.g., 𝑂 e.g., 𝑞, 𝑟

𝑦 𝑦, 𝑥

ZKP of a good RSA modulus

Verifier

Akbar

Prover

? =

𝑂

𝑞 ⋅ 𝑟

𝑞𝑠𝑗𝑛𝑓? 𝑞𝑠𝑗𝑛𝑓?

𝑞 𝑞 𝑟 𝑟 𝑂

∧

𝑂 𝑂, 𝑞, 𝑟

Parameters of ZKP systems

ZKP Prover Complexity Proof Length Verifier Complexity Interaction Models Crypto Assumptions Setup Assumptions Generality

exp(n), poly(n), n log n, n . . .

• No. of Rounds,

Interactive Oracle Noninteractive,

sqrt(n), log^c(n), O(1)

n, sqrt(n), log^c(n), O(1), . . . Trusted, CRS, SRS, Public CRH, DDH, BDH, KoE, Post-Quant

• Arith. C,
• Bool. C,

R1CS, QAP, QSP, IOP, MPC in head C prog, SQL, Range, Sigs, Enc,

Zero Knowledge Proof Systems

• Pinocchio [PGHR ‘13]
• libSNARK [BCTV ‘14]
• Ligero [AHIV ’17]
• libSTARK [BBHR ’18]
• BulletProofs [BBBPWM ’18]
• Hyrax [WTsTW ’18]
• Aurora [BCRSVW ’19]
• Libra [XZZPS ‘19]
• Spartan [S ’19]
• …

§ Aurora: for circuits with ≈ 1𝑁 gates § Prover time 800 sec. § Proof size 200KB § Verifier time 8 sec. § Libra: 256×256 MatMul § Prover time 100 sec. § Proof size 10 KB § Verifier time 0.1 sec. § zCash deploys zkSNARKS § 288 bytes of proof per txn § 6 ms to verify per txn § 1 min to generate proof per txn § 896 MB fixed parameters Non- interactive Proofs

C program

• Arith. Ckt
• Poly. Eqns

Sum Check Interactive Proof Non-interactive Proof Zero Knowledge Proof

Example flow to construct a zkSNARK

ZKP’s for Blockchains Anonymity and Confidentiality

• Monero – RingCT
• BulletProofs – Range Proofs and more
• Omniring – Range Proofs + Ring Sigs
• zCash – zkSNARKS
• Ethereum – zkSNARKS
• . . .

Conclusions (for the warm-up)

• Significant progress bridging theory and practice
• Powerful cryptographic tool with applications

within Crypto

• Encryption, Sigs, Id Schemes, MPC
• Privacy preserving technologies
• Selective Disclosure, Policy Compliance,
• Blockchains
• anonymity and confidentiality in

cryptocurrencies

• verify transactions, smart contracts, and block

formation

• Complex tradeoffs pose challenges
• Long way to go, e.g., performance, avoid trusted

set-up, etc.

Theory Practice

Rest of the talk(s)

Outline

• Basics and background
• Simple examples
• Two specific constructions

Tutorial, but …

• Non-rigorous
• Not a substitute for classroom and

reading papers

Interactive Arguments/Proofs

From [WTsTW ’18]

𝒬 𝒲

Zero Knowledge Proof/Argument

From [WTsTW ’18]

𝒯 𝒲

ZKP for Graph 3-Coloring

• Let 𝜓 be a 3-coloring of 𝐻
• Randomly Permute the colors
• 𝜃 𝑤 ≔ 𝜌(𝜓 𝑤 )
• Send 𝜃 in n locked boxes; keep the keys
• Sends the keys to boxes for 𝑣 and 𝑤
• Uniformly select a random edge

(𝑣, 𝑤) of 𝐻

• Open the boxes for 𝑣 and 𝑤
• Accept iff they contain different

colors

A ZKP of Discrete Log

• Group 𝐻 = ⟨𝑕⟩ of prime order 𝑞. Let 𝑟 = 𝑞 − 1
• Assumption: Decisional Diffie Hellman (DDH) is hard in 𝐻

knows 𝑧 and 𝑕

Claim: know 𝑦 in ℤK such that 𝑧 = 𝑕L

A ZKP of Discrete Log

• Pick 𝑠 in ℤK
• 𝑓 = 𝑕M
• 𝑡 = 𝑑𝑦 + 𝑠

𝑓 = 𝑕M

• Pick 𝑑 ∈ ℤR
• Verify:

𝑕S = 𝑓 ⋅ 𝑧T c 𝑡 = 𝑑𝑦 + 𝑠

• Pick 𝑠 ∈ ℤK
• 𝑓 = 𝑕M
• c = H(e)
• s = cx+r

𝑓 = 𝑕M

• Pick c in Z_q
• Verify:

𝑕S = 𝑓 ⋅ 𝑧U V

s = cx + r

Non-Interactive ZK (Fiat-Shamir Paradigm)

Homomorphic Commitments

• Commitment like a sealed envelope/locked box : Commit and Open
• Binding
• Hiding
• Pedersen Commitment
• Generators g and h in G
• Commit(x): C(x,r) := g^x . h^r
• Open(C):= (x,r)
• Additive Homomorphism
• g^a . g^b = g^(a+b)
• C(x1,r1).C(x2,r2) = C(x1+x2, r1+r2)

Pedersen (Multi)Commitments

• Knowledge of Opening
• Equality of Committed Values
• Proof of a Product Relationship
• Proof of Dot Product

From [WTsTW ’18]

Some interesting properties

Range Proofs

• Balancing Blindfolded: Hide your money in the exponent!
• Pedersen Vector Commitments
• g = (g1, . . . , gn), h
• Com(x) = h^r g^x = h^r. (g1^x1. … .gn^xn) = h^r. Π XYZ

[

gi^xi

• Inner Product Proof
• Prover claims he knows two vectors – committed as above – have a committed inner

product value

• P := g^a.h^b.u^c, where c = <a,b> := ∑ 𝑏X𝑐X
• Range check with Inner Product
• V in [0,R] iff <v,2^r> = V, where R=2^r-1
• v = (v1, v2, …., vr) such that V = v1.2^0+v2.2^1 + . . . +vr.2^{r-1},
• 2^r = (2^0, 2^1, 2^2, …, 2^{r-1})

Conclusions

• ZKP’s a powerful cryptographic tool
• Can provide anonymity and confidentiality in cryptocurrencies
• Useful in blockchains in general to verify transactions, smart contracts, and

block formation while preserving privacy

• Complex tradeoffs makes bridging the theory and applications challenging
• Long way to go, e.g., performance, avoid trusted set-up, etc.

THANK YOU!
