Your Cloud Based Modeling Workbench in 15 minutes with Eclipse Sirius

@melaniebats CTO @Obeo

ECLIPSE SIRIUS

An Eclipse project to easily create your own Graphical Modeling Workbench

Sirius is Alive!

Two major releases per year In June and October A release every Committers actively working

PART OF THE RELEASE TRAIN 2 MONTHS MORE THAN 10

Principles of Sirius

Metamodel

Principles of Sirius

Metamodel Sirius configuration +

Principles of Sirius

Metamodel Sirius configuration Graphical modeler + =

Metamodel Sirius configuration Graphical modeler Sirius specifier + =

Principles of Sirius

Sirius specifier Workbench end users

Principles of Sirius

Metamodel Sirius configuration Graphical modeler + =

Sirius as an RCP application

DEMO

Use the specification editor...

Use the specification editor...

Sirius configuration

… to specify the end user graphical workbench

Sirius configuration

… to specify the end user graphical workbench

13

Sirius configuration End user workbench

Workbench structure

Defines the complete structure

• f the modeling

workbench

Sirius configuration

Workbench structure

15

End user workbench

Model Explorer

Sirius configuration

Dashboard

16

End user workbench Dashboard Sirius configuration

Viewpoint

Provides viewpoints adapted to the user’s role or activity

Sirius configuration

Viewpoint

18

End user workbench Sirius configuration

Representation

Each viewpoint corresponds to a set

• f representations

Sirius configuration

Representation

20

End user workbench Sirius configuration

Representation

21

End user workbench Sirius configuration

Layers

Each diagram provides default and optional layers

Sirius configuration

Layers

23

Sirius configuration End user workbench

Mappings

Each layer defines mappings : node, container and edge

Sirius configuration

Mappings

25

Sirius configuration End user workbench

Mappings

26

Sirius configuration End user workbench Node Node

Mappings

27

Sirius configuration Metamodel

Mappings

28

Sirius configuration Metamodel

Mappings

29

Sirius configuration End user workbench

Mappings

30

Sirius configuration End user workbench Container Container

Mappings

31

Sirius configuration End user workbench

32

Sirius configuration End user workbench Edge Edge

Mappings

Sirius as an RCP application

DEMO

Diagram, Table, Matrix and much more..

Tree

Sequence diagram

Properties views

Obeo Designer is there for you

All you need to work with Sirius

COMMUNITY EDITION

Obeo Designer is there for you

All you need to work with Sirius For real time collaborative edition in Eclipse based workbenches

COMMUNITY EDITION TEAM EDITION

Obeo Designer is there for you

All you need to work with Sirius For real time collaborative edition in Eclipse based workbenches Integrated platform to deploy easily to the cloud

COMMUNITY EDITION TEAM EDITION CLOUD PLATFORM

How do we configure a Cloud-ready graphical designer with Sirius ?

Sirius specifier Workbench end users

We keep the principles of Sirius

Metamodel Sirius configuration Graphical modeler + =

Sirius specifier Workbench end users

We keep the principles of Sirius

Metamodel Sirius configuration Graphical modeler + =

RCP Application

Sirius specifier Workbench end users

We keep the principles of Sirius

Metamodel Sirius configuration Graphical modeler + =

RCP Application

Sirius specifier Workbench end users

We keep the principles of Sirius

Metamodel Sirius configuration Graphical modeler + =

Web Application

Backend

How it works

Frontend Obeo Cloud Platform

Backend

How it works

React Components

Frontend Obeo Cloud Platform

Backend

How it works

React Components

Frontend

Pages Buttons Forms ...

Obeo Cloud Platform

Model explorer

Backend

How it works

React Components

Frontend

Pages Buttons Forms Diagrams (Sprotty) Properties ...

Obeo Cloud Platform

Model explorer

My Spring Application

Backend

How it works

React Components

Frontend

GraphQL WebSocket

Java Services Pages Buttons Forms Diagrams (Sprotty) Properties ... My EMF Ecore My EMF Edit

• design

Obeo Cloud Platform

Model explorer

Core My Spring Application

Backend

How it works

React Components

Frontend

GraphQL WebSocket

Java Services Pages Buttons Forms Diagrams (Sprotty) Properties ... My EMF Ecore EMF Json PostgreSQL My EMF Edit Sirius interpreter

• design

Components Diagrams / Layout (ELK)

Obeo Cloud Platform

Practical exercice

STEP 1 STEP 2 STEP 3

Specify a classical odesign Configure the web application Run the server

Sirius as a web application

DEMO

Features Backlog Status

54

Done WIP Basic set of properties Upload / Download Model Explorer Tools Undo/Redo

CRUD

Diagrams (Node, Container, Edge, Cond. Style, SVG, Auto layout…) Layers Pin/Unpin Palette

Representations

Basic backend Live Visualization

Collaboration

EMF.Edit Java Services

Extensibility

Next Direct Edit Copy/Paste Complete set of widgets Table, Tree, Dashboard Text Editor Better auto layout... One click model share Historic Review system Spring components

Obeo Cloud Platform Capabilities

Modeling tool made easy

Visualize, create and edit on the fly.

• Diagrams, Tables, Forms,
• Text editor,
• Explorer, Dashboard...

Be efficiently consistent & consistently efficient

Structure your information thanks to models in the cloud.

• All your data are always one click away.
• Increase consistency with a powerful referential that’s accessible from your

browser.

Turn engineering tool creation into a handshake

Everything is there to build your engineering applications quickly

• Dynamic interpretation engine
• Map your data to the meaningful representation for your domain
• Ease the onboarding by creating a dedicated tooling
• Be agile and reactive

Built with all the benefits

• f any cloud software

Easy deployment. It’s Cloud, It’s On-Premised.

• Never have to save files again with auto-save
• Goodbye export, share models with a live link
• Worry-free editing & collaboration with a version control
• Control user permissions, manage who can view, edit and contribute

Would like to try? Contact me!

We are looking for beta testers. You already use Eclipse Sirius? You are interested in migrating to a web application, subscribe to :

Beta testing team

We are working on both sides...

Optional table header

Sirius 6.1

Optional table header

Sirius 6.1

Contribute to Menus

Sirius 6.1

Mode Visibility

Sirius 6.1

Improve ELK integration

Sirius 6.1

Experimental

December - 1st public preview

• f Obeo Cloud Platform

2 possibilities :

• Sirius RCP
• Obeo Cloud Platform

WE develop what YOU need!

2019 2020

…working on the 2 flavors!

Sirius rocks!

Diagrams, tables, trees, properties views

Visual

Sirius rocks!

No code generation

Declarative

Diagrams, tables, trees, properties views

Visual

Sirius rocks!

No code generation

Declarative

Your Cloud/Desktop modeling workbench in hours

Easy

Diagrams, tables, trees, properties views

Visual

More at EclipseCon EU

All along: visit our NO goodies booth! 15:10 A playful introduction to MBSE (interactive talk inside) by Obeo 11:15 Stepping up Sirius - Tips & Tricks for your visualization journey by Bosch

Stop plastic, save the ocean!

Contribute to the project to clean the

• ceans :

https://www.theseacleaners.org/en

Does anyone have any questions? melanie.bats@obeo.fr
