Y P O C T O N O TMS in Special Populations D E S A E Alexander Rotenberg, M.D., Ph.D. L Director, Neuromodulation Program P Dept. Neurology, Div. Epilepsy and Clinical Neurophysiology Childrens Hospital, Boston Y Conflict of

slide-1
SLIDE 1

TMS in Special Populations

Alexander Rotenberg, M.D., Ph.D.

Director, Neuromodulation Program

  • Dept. Neurology, Div. Epilepsy and Clinical Neurophysiology

Children’s Hospital, Boston

P L E A S E D O N O T C O P Y

slide-2
SLIDE 2

Conflict of Interest Disclosure

Alexander Rotenberg

Current:

Neuro’motion Inc. (co-founder, consultant) NeuroRex Inc. (consultant, medical advisory board) Brainsway Inc. (research support) Soterix Medical Inc. (research support) Neuroelectrics Inc. (research support) Sage Therapeutics Inc. (research support)

Wuhan Yirude Medical Equipment New Technology Co., Ltd. (research support)

Assimon Family Fund (research support) NIH NIMH, NIH NINDS, DoD, CIMIT, ERF, TRP, MassLife, Assimon Family, Autism Speaks (research grants)

Past:

Research support from: Neuropace Inc., Neuronetics Inc., Nexstim Inc., Fisher Family Fund, Al Rashedi Family Fund

P L E A S E D O N O T C O P Y

slide-3
SLIDE 3

NBS in Children

Boston Children’s Hospital Neuromodulation Program

P L E A S E D O N O T C O P Y

slide-4
SLIDE 4

Neuronetics Trial N=164; 23 centers; triple blind L DLPF 10 Hz rTMS 120% MT 4 sec trains 26 sec ITI 3000 pulses/day 2-3 weeks

Lisanby et al., 2008

P L E A S E D O N O T C O P Y

slide-5
SLIDE 5

N=6

P L E A S E D O N O T C O P Y

slide-6
SLIDE 6

N=64 (32: 90% RMT; 32: 20% RMT) 0.5 Hz rTMS over seizure focus

P L E A S E D O N O T C O P Y

slide-7
SLIDE 7

Clinical trials: gaps in knowledge

  • Limited TMS data in pediatrics
  • Few clinical trials segmented by

developmental stage

  • Fragmented pediatric data available from

inclusive prospective trials

14yF 15yF

Fregni et al., 2005

P L E A S E D O N O T C O P Y

slide-8
SLIDE 8

...but, conventional TMS does not reach the temporal lobe

Electrical current distribution (phantom model) Roth and Zangen

P L E A S E D O N O T C O P Y

slide-9
SLIDE 9

1 Hz rTMS in temporal lobe epilepsy, trial in progress

Deep TMS H-Coil System

Boston Children’s Hospital Neuromodulation Program

Epilepsy Therapy Project (PI: Rotenberg) Seizure frequency around rTMS block Seizures per day * rTMS

20 40 60 80 100 120 140 160 sham verum

Seizure frequency (% of baseline)

*

P L E A S E D O N O T C O P Y

slide-10
SLIDE 10

2 4 6

1 3 5 7 9 11 13 15 17 19 21 23 25 27 2 4 6 8 10 12 14 16 18 20 22 24 26 28

First treatment block

seizure cluster 1 2 3 4 5 6

1 3 5 7 9 11 13 15 17 19 21 23 25 27 2 4 6 8 10 12 14 16 18 20 22 24 26 28

Second treatment block

1 2 3 4 5 6

1 3 5 7 9 11 13 15 17 19 21 23 25 27 2 4 6 8 10 12 14 16 18 20 22 24 26 28

Third treatment block

A B C Figure 1

10 sessions rTMS 15 sessions rTMS 30 sessions rTMS

Gersner et al., 2016

P L E A S E D O N O T C O P Y

slide-11
SLIDE 11

Stimulation protocols

Frye, Rotenberg, et al. Child Neurol 2007

P L E A S E D O N O T C O P Y

slide-12
SLIDE 12

Presurgical motor mapping by TMS

P L E A S E D O N O T C O P Y

slide-13
SLIDE 13

Motor cortex TMS in children

P L E A S E D O N O T C O P Y

slide-14
SLIDE 14

Motor TMS example

P L E A S E D O N O T C O P Y

slide-15
SLIDE 15

Right hand (APB) map

P L E A S E D O N O T C O P Y

slide-16
SLIDE 16

Right foot (TA) map

P L E A S E D O N O T C O P Y

slide-17
SLIDE 17

P L E A S E D O N O T C O P Y

slide-18
SLIDE 18

Motor map relative to lesion (hand; FDI)

P L E A S E D O N O T C O P Y

slide-19
SLIDE 19

Motor map relative to lesion (foot; TA)

P L E A S E D O N O T C O P Y

slide-20
SLIDE 20

Map identifies surgical access

P L E A S E D O N O T C O P Y

slide-21
SLIDE 21

Presurgical motor mapping by TMS

P L E A S E D O N O T C O P Y

slide-22
SLIDE 22

Dashed: contra Solid: ipsi

P L E A S E D O N O T C O P Y

slide-23
SLIDE 23

P L E A S E D O N O T C O P Y

slide-24
SLIDE 24

Left hand Right hand

P L E A S E D O N O T C O P Y

slide-25
SLIDE 25

Healthy 12yF

P L E A S E D O N O T C O P Y

slide-26
SLIDE 26

P L E A S E D O N O T C O P Y

slide-27
SLIDE 27

Hand Motor Task - fMRI R hand L hand

P L E A S E D O N O T C O P Y

slide-28
SLIDE 28

N=4 boys with hemispheric polymicrogyria fMRI: ipsilesional BOLD signal in 3 / 4 nTMS: 0 / 4 crossed lesional corticospinal connections 4 / 4 with preserved grasp in paretic hand after hemispherectomy

P L E A S E D O N O T C O P Y

slide-29
SLIDE 29

Right (ipsilesional) Hemisphere Stimulation

Right FDI MEP

P L E A S E D O N O T C O P Y

slide-30
SLIDE 30

Left (ipsilesional) Hemisphere APB Stimulation

APB R APB L

P L E A S E D O N O T C O P Y

slide-31
SLIDE 31

Tib L Tib R

Right (ipsilesional) Hemisphere Stimulation

P L E A S E D O N O T C O P Y

slide-32
SLIDE 32

Color Coded Left and right Tibialis Anterior Map

P L E A S E D O N O T C O P Y

slide-33
SLIDE 33

Special considerations in pediatric TMS

  • Head and brain growth
  • Developmental regulation of

neuronal excitability

P L E A S E D O N O T C O P Y

slide-34
SLIDE 34

Developing brain is a moving target

  • Vulnerability (or resistance) to injury likely

varies with age

  • Studies restricted to narrow age windows are

lacking

  • Subdivision of the pediatric age group may be

necessary

P L E A S E D O N O T C O P Y

slide-35
SLIDE 35

Potential mechanisms for injury to the developing brain

  • Enhanced excitabilty and vulnerability to seizure in

early life

– Risk for excitotoxicity

  • Enhanced synaptic plasticity

– Risk for interference with learning and memory

  • Ongoing neurogenesis, synaptogenesis, myelination,

etc.

– Risk of use‐dependent structural change

P L E A S E D O N O T C O P Y

slide-36
SLIDE 36

Physiology is reflected in disease …and maybe in neurostimulation risks

Status epilepticus by age

DeLorenzo et al., 1992

P L E A S E D O N O T C O P Y

slide-37
SLIDE 37

Motor threshold

Smith et al., 2011

P L E A S E D O N O T C O P Y

slide-38
SLIDE 38

Motor Threshold v. Age

P L E A S E D O N O T C O P Y

slide-39
SLIDE 39

Motor threshold and age

P L E A S E D O N O T C O P Y

slide-40
SLIDE 40

P0 P5 P10 P15 P20 P25 P30 Adult

Neuronal Receptor Expression vs Age

Kainate

% Adult Function

Human Rodent

preterm term 1-2y >10y Adult

EXCITATION INHIBITION excitatory glutamate

Silverstein and Jensen, Ann Neurol, 2007 Rakhade and Jensen, Nature Rev., 2010

GABA (excitatory) GABA (inhibitory) AMPA NMDA

P L E A S E D O N O T C O P Y

slide-41
SLIDE 41

Chloride homeostasis in the immature brain

Ben-Ari 2002

P L E A S E D O N O T C O P Y

slide-42
SLIDE 42

NKCC1:KCC2

0.0 1.0 2.0 3.0 4.0 5.0

****

Fold change

*** **

100 200 300 400

* ***

NKCC1

% of Control

**** **** ****

KCC2

% of Control

20 40 60 80 100 120

NKCC1 and KCC2 expression in autism, as compared epilepsy and controls

Autism Frontal Lobe (A-FL) Autism Temporal Lobe (A-TL) Epilepsy Temporal Lobe (E-TL)

Salah and Talos, in preparation

P L E A S E D O N O T C O P Y

slide-43
SLIDE 43

1

Conditioning TMS 2 Test TMS Control SICI; 2 ms ISI ICF; 12 ms ISI

0.5 mV 25 ms

LICI; 200 ms ISI

0.5 mV 50 ms

Rotenberg and Pascual-Leone, 2010

Measures of Cortical Excitability by Paired‐Pulse TMS (ppTMS)

P L E A S E D O N O T C O P Y

slide-44
SLIDE 44

1

Conditioning TMS 2 Test TMS

50 ms

Paired-pulse MEP inhibition

GABAergic cortical inihibition measures by paired‐pulse TMS (ppTMS)

Rotenberg and Pascual-Leone, 2010

GABA-mediated inhibition

P L E A S E D O N O T C O P Y

slide-45
SLIDE 45

P L E A S E D O N O T C O P Y

slide-46
SLIDE 46

P L E A S E D O N O T C O P Y

slide-47
SLIDE 47

Stagg et al., J Neurophysiol, 2009

P L E A S E D O N O T C O P Y

slide-48
SLIDE 48

Theta burst stimulation and synaptic plasticity

Oberman et al., Eur. J. Neuroscience, 2012

P L E A S E D O N O T C O P Y

slide-49
SLIDE 49

Hyperplasticity in Autism Spectrum Disorders

0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50 1.60 5 10 20 30 40 50 60 75 90 105 120

cTBS iTBS

Time after TBS [ min] MEP amplitude

[ proportion of baseline]

Baseline

Oberman et al. 2009 & in press

P L E A S E D O N O T C O P Y

slide-50
SLIDE 50

Maturation of motor plasticity

P L E A S E D O N O T C O P Y

slide-51
SLIDE 51

P L E A S E D O N O T C O P Y

slide-52
SLIDE 52

Paradoxical facilitation in children with ASD

Oberman et al., 2014

P L E A S E D O N O T C O P Y

slide-53
SLIDE 53

Why is this interesting?

Chloride homeostasis may be dysmature in the ASD brain, and NKCC1 block may rescue the ASD phenotype

P L E A S E D O N O T C O P Y

slide-54
SLIDE 54

CARS: childhood autism rating scale

P L E A S E D O N O T C O P Y

slide-55
SLIDE 55

Threshold: TMS safety in pediatrics

P L E A S E D O N O T C O P Y

slide-56
SLIDE 56
  • N = 40
  • Avg age 12y 7mo
  • no serious adverse events
  • Five of 40 children reported mild,

self-limited adverse events:

  • a subjective sensation of

finger twitching (1)

  • neck stiffness (1)
  • mild headache (3)
  • Total adverse event rate was

11.6%. No emotional changes, as rated with the visual analog mood scale, were identified (p > 0.05).

Wu et al., Annual Meeting Child Neurology Society, 2011

…..Though still limited, pediatric data are emerging

P L E A S E D O N O T C O P Y

slide-57
SLIDE 57

more enjoyable than “a long car ride”

J Child Neurol, 2001

P L E A S E D O N O T C O P Y

slide-58
SLIDE 58

Heart Rate Measures

P L E A S E D O N O T C O P Y

slide-59
SLIDE 59

Heart Rate Stability During nTMS

P L E A S E D O N O T C O P Y

slide-60
SLIDE 60

Right deltoid sample

P L E A S E D O N O T C O P Y

slide-61
SLIDE 61

Right Deltoid sample (stim in CSF)

P L E A S E D O N O T C O P Y

slide-62
SLIDE 62

Right deltoid map

P L E A S E D O N O T C O P Y

slide-63
SLIDE 63

P L E A S E D O N O T C O P Y

slide-64
SLIDE 64

Left deltoid and tibialis anterior Motor Maps

Left deltoid Left tibialis anterior Kaye et al., Epilepsy & Behav. Case Repor

P L E A S E D O N O T C O P Y

slide-65
SLIDE 65

Diffusion Tractography Imaging

corticospinal connectivity within the tuber tissue

Kaye et al., Epilepsy & Behav. Case Reports 2016

P L E A S E D O N O T C O P Y

slide-66
SLIDE 66
  • No spurious VNS trigger
  • Minimal current (200 nA X 1 ms)

induced between the leads

P L E A S E D O N O T C O P Y

slide-67
SLIDE 67

rTMS safety after cranial surgery

Rotenberg et al., 2007 Rotenberg and Pascual-Leone 2009

P L E A S E D O N O T C O P Y

slide-68
SLIDE 68

Ex vivo stimulation

Rotenberg et al., Clin Neirophysiol 2007

Titanium Skull Plates and Gold EEG Electrode Temperature vs. Time During 1Hz rTMS

Time (s)

200 400 600 800 1000 1200 1400 1600 1800

Temperature (oC)

20 30 40 50 60 70

P L E A S E D O N O T C O P Y

slide-69
SLIDE 69

Ex vivo stimulation (aneurism clip)

Hsieh et al., Clin Neurophys 2011

P L E A S E D O N O T C O P Y

slide-70
SLIDE 70

THANKS!
