Y P O C Mechanisms of T Transcranial Current Stimulation O N O D Flavio Frohlich University of North Carolina - Chapel Hill E Department of Psychiatry S Department of Cell Biology and Physiology Department of Biomedical Engineering

slide-1
SLIDE 1

Mechanisms of Transcranial Current Stimulation

Flavio Frohlich

University of North Carolina - Chapel Hill

Department of Psychiatry Department of Cell Biology and Physiology Department of Biomedical Engineering Department of Neurology Neuroscience Center

www.networkneuroscientist.org

www.facebook.com/FrohlichLabUNC

P L E A S E D O N O T C O P Y

slide-2
SLIDE 2
  • UNC owns IP related with FF as the lead inventor.
  • UNC has determined the absence of a conflict of

interest (COI) for the majority of work presented here and has determined a “COI with administrative considerations” for the clinical trials in the Frohlich Lab.

  • FF is the founder, chief scientific officer, and

majority owner of Pulvinar Neuro LLC.

  • Received industry funding from Tal Medical (travel +

research)

  • I frequently travel and give presentations. I typically

receive reimbursement and a stipend.

  • My preferred brain stimulation modality is doppio

espresso.

Conflicts of Interest – You Decide

P L E A S E D O N O T C O P Y

slide-3
SLIDE 3

Neurons, Synapses, and Circuits. Measuring, Perturbing, and Analyzing Brain Networks Cortical Oscillations Network Disorders Toolboxes

P L E A S E D O N O T C O P Y

slide-4
SLIDE 4

Standing on the Shoulders of Giants

P L E A S E D O N O T C O P Y

slide-5
SLIDE 5

NEUROTECHNOLOGY

Synergies with other treatments. Adaptive, individualized therapies. Mobile, on-demand diagnosis and treatment.

P L E A S E D O N O T C O P Y

slide-6
SLIDE 6

P L E A S E D O N O T C O P Y

slide-7
SLIDE 7

Frohlich et al. 2015 Brunelin et al. 2012

P L E A S E D O N O T C O P Y

slide-8
SLIDE 8

Sellers et al. 2015

P L E A S E D O N O T C O P Y

slide-9
SLIDE 9

Lesson #1 Do not skip measuring brain activity (EEG, fMRI, etc.). #BeDifferent

P L E A S E D O N O T C O P Y

slide-10
SLIDE 10

VERTICAL INTEGRATION

Patients Model Systems

COMPLEXITY TRACTABILITY Clinical Trials Brain Stimulation, Human Neurophysiology In vivo (Animal) Electrophysiology In vitro (Animal) Electrophysiology Computer Simulations

P L E A S E D O N O T C O P Y

slide-11
SLIDE 11

Lesson #2 Leverage the tools of (network) neuroscience. #Collaboration

P L E A S E D O N O T C O P Y

slide-12
SLIDE 12

TRANSCRANIAL CURRENT STIMULATION STUDY DESIGN

Behavioral Target Network Target Target Engagement

P L E A S E D O N O T C O P Y

slide-13
SLIDE 13

Lesson #3

Make sure you know your target and have a plan how to engage it. #RationalDesign

P L E A S E D O N O T C O P Y

slide-14
SLIDE 14

TARGET ENGAGEMENT

How do we best engage a network target? We need to understand what the effect of stimulation is on the brain in terms of neurophysiology.

P L E A S E D O N O T C O P Y

slide-15
SLIDE 15

OUTLINE

  • 1. Cellular Effects
  • 2. Spatial Targeting
  • 3. Targeting Network Dynamics

P L E A S E D O N O T C O P Y

slide-16
SLIDE 16

ELECTRIC FIELDS

How do electric fields change electric signaling in neurons?

P L E A S E D O N O T C O P Y

slide-17
SLIDE 17

“Anodal” Depolarized Soma Hyperpolarized Dendrite “Cathodal” Hyperpolarized Soma Depolarized Dendrite

P L E A S E D O N O T C O P Y

slide-18
SLIDE 18

CABLE EQUATION

Frohlich and McCormick. 2010

P L E A S E D O N O T C O P Y

slide-19
SLIDE 19

NEURONAL MORPHOLOGY AND STATE

Change in somatic membrane voltage:

  • Increases with cable length.
  • Decreases with membrane conductance.
  • Increases with cable diameter.

A B vs.

Radmann et al. 2009

P L E A S E D O N O T C O P Y

slide-20
SLIDE 20

Change in somatic membrane voltage can be modeled as a sub- threshold somatic current injection.

Frohlich and McCormick. 2010

P L E A S E D O N O T C O P Y

slide-21
SLIDE 21

Lesson #4

tDCS/tACS cause small changes in neuronal membrane voltage. #synergy #EndogenousBrainActivity

P L E A S E D O N O T C O P Y

slide-22
SLIDE 22

SPATIAL TARGETING

Tissue Resistivity [Ohm cm] Copper 2e-6 CSF 64 Cortex 350 White Matter 650 Bone 8,000-16,000

P L E A S E D O N O T C O P Y

slide-23
SLIDE 23

IMPLEMENTATION

  • MR Scan
  • Tissue segmentation
  • Numerical solution (e.g. finite elements).
  • 1. Develop you own code
  • 2. Collaborate
  • 3. Buy tool / use free tool

P L E A S E D O N O T C O P Y

slide-24
SLIDE 24

P L E A S E D O N O T C O P Y

slide-25
SLIDE 25

P L E A S E D O N O T C O P Y

slide-26
SLIDE 26

Modeling performed by Angel Peterchev Sellers et al 2015

P L E A S E D O N O T C O P Y

slide-27
SLIDE 27

P L E A S E D O N O T C O P Y

slide-28
SLIDE 28

Lesson #5

MR scan + Segmentation + EF modeling = Spatial Targeting #KnowYour3D #HowGoodisHD

P L E A S E D O N O T C O P Y

slide-29
SLIDE 29

STRUCTURE DYNAMICS BEHAVIOR

P L E A S E D O N O T C O P Y

slide-30
SLIDE 30

MODELING DYNAMICS

Frohlich 2014

P L E A S E D O N O T C O P Y

slide-31
SLIDE 31

OSCILLATIONS

Caution: Most tACS literature refers to the peak-to-peak amplitude as amplitude.

P L E A S E D O N O T C O P Y

slide-32
SLIDE 32

NETWORK DYNAMICS

  • 1. Raw trace.
  • 2. Spectrum: Power as a

function of frequency.

  • 3. Spectrogram: Spectrum as

a function of time.

  • 4. Coherence: Interaction

between two sites as a function of frequency.

Raw Trace Spectrum

P L E A S E D O N O T C O P Y

slide-33
SLIDE 33
  • 1. Raw trace.
  • 2. Spectrum: Power as a function of frequency.
  • 3. Spectrogram: Spectrum as a function of time.

Raw Trace Spectrogram

P L E A S E D O N O T C O P Y

slide-34
SLIDE 34
  • 1. Raw trace.
  • 2. Spectrum: Power as a function of frequency.
  • 3. Spectrogram: Spectrum as a function of time.
  • 4. Coherence: Interaction between two sites as a function
  • f frequency.

P L E A S E D O N O T C O P Y

slide-35
SLIDE 35

Lesson #6

Brain rhythms effectively targeted by rhythmic brain stimulation #MiddleSchoolMath

P L E A S E D O N O T C O P Y

slide-36
SLIDE 36

TARGETING BRAIN NETWORK DYNAMICS

Write / Input tACS Transcranial Alternating Current Stimulation (tACS)

Neuroconn

Read / Output EEG

Berger 1929

P L E A S E D O N O T C O P Y

slide-37
SLIDE 37

NATURALISTIC ELECTRIC FIELDS

Frohlich and McCormick. 2010

P L E A S E D O N O T C O P Y

slide-38
SLIDE 38

ARNOLD TONGUE

Frohlich 2014

P L E A S E D O N O T C O P Y

slide-39
SLIDE 39

SPIKING NEURAL MODEL (NETWORK)

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-40
SLIDE 40

SPATIO-TEMPORAL DYNAMICS

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-41
SLIDE 41

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-42
SLIDE 42

STIMULATION PHASE

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-43
SLIDE 43

HOTSPOTS

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-44
SLIDE 44

NETWORK-LEVEL MECHANISM

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-45
SLIDE 45

CELLULAR-LEVEL MECHANISM

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-46
SLIDE 46

TARGETING A SUBPOPULATION

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-47
SLIDE 47

NETWORK RESONANCE

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-48
SLIDE 48

PHASE SLIPPING

Ali et al. 2013

P L E A S E D O N O T C O P Y

slide-49
SLIDE 49

INTERACTING NETWORKS

Kutchko and Frohlich 2013

P L E A S E D O N O T C O P Y

slide-50
SLIDE 50

MULTISTABILITY

“Rapid Fire” “Slow Propagating” “Spiral Waves”

Kutchko and Frohlich 2013

P L E A S E D O N O T C O P Y

slide-51
SLIDE 51

STATE SWITCHING BY tACS

Kutchko and Frohlich 2013

P L E A S E D O N O T C O P Y

slide-52
SLIDE 52

Lesson #7

Complexity of brain dynamics requires computer simulations to understand target engagement.

#MultiStability #NerdForPresident

P L E A S E D O N O T C O P Y

slide-53
SLIDE 53

TARGET: ALPHA OSCILLATIONS

  • Neurofeedback, rTMS (10 Hz), tACS,
  • thers…
  • “Offline” state, long-range

functional connectivity, gating.

P L E A S E D O N O T C O P Y

slide-54
SLIDE 54

COGNITIVE ENHANCEMENT

High Creative Ideation Low Creative Ideation

“increased alpha power during creative ideation is among the most consistent findings in neuroscientific research on creativity” (Fink and Benedek, 2010)

Lustenberger et al. (2015)

P L E A S E D O N O T C O P Y

slide-55
SLIDE 55

ENHANCING CREATIVITY

  • Blinding was successful (p > 0.2).
  • 10 Hz tACS significantly enhances creativity as measured by the Torrance

Test of Creative Thinking (7.45 % ± 3.11 % S.E.M.; F1,16 = 5.14, p = 0.036).

  • No enhancement with 40Hz-tACS..

Lustenberger et al. (2015)

P L E A S E D O N O T C O P Y

slide-56
SLIDE 56

OSCILLATION ENHANCEMENT

P L E A S E D O N O T C O P Y

slide-57
SLIDE 57

FEEDBACK tACS TO MODULATE SLEEP SPINDLES

Lustenberger et al. (2015)

P L E A S E D O N O T C O P Y

slide-58
SLIDE 58

IMPROVING MEMORY CONSOLIDATION

Lustenberger et al. (2015)

P L E A S E D O N O T C O P Y

slide-59
SLIDE 59

TARGET ENGAGEMENT

P L E A S E D O N O T C O P Y

slide-60
SLIDE 60

Lesson #8

Individualize with feedback stimulation to enhance target engagement. #OMGWasThatASpindle

P L E A S E D O N O T C O P Y

slide-61
SLIDE 61

SUMMARY: TARGETING NETWORK DYNAMICS

  • Oscillations represent fundamental activity structure.
  • tACS ideal to target cortical oscillations.
  • Endogenous network dynamics represent oscillator to

be modulated by weak periodic perturbations.

  • Arnold Tongue: Necessity of individualizing

stimulation frequency?

  • Multistable dynamics: State-dependent stimulation

effects.

P L E A S E D O N O T C O P Y

slide-62
SLIDE 62

Charles Zhou Caroline Lustenberger Sankar Alagapan Yuhui Li Guoshi Li Ehsan Negahbani Juliann Mellin Courtney Lugo Morgan Alexander Philipp Lustenberger Iain Stitt Supritha Dugyala Toheed Khan Quique Toloza Nadia Mishal Mia DeMarco Matt Mattoni Jhana Parikh Hemanth Ambala Carolyn Rapp Franz Hamilton Jessica Page Maadhurya Duvvuri

Alumni Lab Members

Mohsin Ali Kristin Sellers Katrina Kutchko Stephen Schmidt Chunxiu Yu Carrington Merritt Collaborators

ECOG: Dr. Haewon Shin Sleep Spindles: Dr. Bradley Vaughn Modeling ECOG: Dr. Jeremy Lefebvre Electric Field Spatial Targeting: Dr. Angel Peterchev SCZ Clinical Trial: Dr. Fred Jarskog, Dr. John Gilmore Mood Disorders Clinical Trials: Dr. David Rubinow

Funding

NIMH BRAINS R01 MH101547, NIMH R21MH105557, NIMH R21MH105574, Human Frontier Science Program, UNC School of Medicine, Department of Psychiatry, NCTraCS (CTSA #1UL1TR001111), Foundation of Hope, UNC SOM TTSA, NARSAD, Tal Medical, Patient Donations.

P L E A S E D O N O T C O P Y

slide-63
SLIDE 63

Thank you for your attention. flavio_frohlich@med.unc.edu www.networkneuroscientist.org @FrohlichLab
