Slide 1 of 9 Wolfram Technologies: Graph Theory and Social Networks Martin Hadley Wolfram martinh@wolfram.com | 2 Wolfram-Technologies_Graph-Theory-Social-Networks.nb Slide 2 of 9 Wolfram Technologies Twenty-Four Years of

slide-1
SLIDE 1

Slide 1 of 9

Wolfram Technologies: Graph Theory and Social Networks

Martin Hadley

Wolfram

martinh@wolfram.com

  • |
slide-2
SLIDE 2

Slide 2 of 9

Wolfram Technologies

Twenty-Four Years of Scientific and Technological Innovation

Founded by Stephen Wolfram in 1987, British scientist, creator of Mathematica and Wolfram|Alpha and the author of A New Kind of Science Based in Illinois, USA with EMEA offices near Oxford, UK and Asia offices in Tokyo, Japan Employs 600 staff worldwide Wolfram Technology users number in the millions - used in most of the Euro Stoxx 50 companies, several major government departments across the E.U. and all of the world's top 200 universities.

The Core of Wolfram Technologies is Mathematica

2 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-3
SLIDE 3

Computability drives us forward

We have developed a free to use Computable Knowledge Engine with an ever growing array of computational algorithms and curated data. We’ve recently launched Wolfram SystemModeler, a multidomain modelling and simulation environment with tight Mathematica integration.

  • |
  • Wolfram-Technologies_Graph-Theory-Social-Networks.nb 3
slide-4
SLIDE 4
  • |
  • 4 Wolfram-Technologies_Graph-Theory-Social-Networks.nb
slide-5
SLIDE 5

Slide 3 of 9

Graph Theory & Social Networks in Mathematica

Building a Graph in Mathematica

Directed and Undirected Graph Interacting with Graph Importing/Exporting Graph

Graph Theory Analytical Methods

Graph Isomorphs, Complement, Difference and GraphDistributions Cliques, Centralities, and Communities Tours and Paths

Graph Theory in Financial Engineering: Risk-Diverse Investment Portfolios Analysing Social Networks with Wolfram Technologies

Wolfram|Alpha Personal Analytics for Facebook Social Network APIs in Mathematica

  • |
  • Wolfram-Technologies_Graph-Theory-Social-Networks.nb 5
slide-6
SLIDE 6

Slide 4 of 9

Building Graph in Mathematica

The Graph Function

In Mathematica a Graph is built by providing a list of edges to the Graph function

Provide a list of undirected edges, myUnDirectedGraphGraph13,21,34,1

Undirected Graph Directed Graph Building a graph is a non-destructive process, we can easily extract both edges and vertices

We apply the EdgeList function to a graph EdgeListmyUndirectedGraph

1 3, 2 1, 3 4, 1 4 Extracting Edges Extracting Vertices From this list of rules we can reconstruct the original graph, GraphEdgeRulesmyDirectedGraph

Symbolic Input

We can easily insert symbolic objects into our graph,

6 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-7
SLIDE 7

symbolic1 Graph

  • ,
  • ,
  • ,
  • ,

VertexLabels "Name", VertexSize Tiny, ImagePadding 50 symbolic2 Graph 2 3 4 1 0 8 5 7 , 9 0 1 1 2 3 4 1 , 0 8 5 7 9 8 7 5 , 2 3 4 1 9 8 7 5 , VertexLabels "Name", VertexSize Small, ImagePadding 30

2 3 4 1 8 5 7 9 1 1 9 8 7 5

The content remains undestroyed by the Graph function. EdgeRulessymbolic1

  • ,
  • ,
  • ,
  • MapMatrixForm, EdgeRulessymbolic2, 2

2 3 4 1 0 8 5 7 , 9 0 1 1 2 3 4 1 , 0 8 5 7 9 8 7 5 , 2 3 4 1 9 8 7 5 We can extend this functionality to build more complicated visualisations

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 7

slide-8
SLIDE 8

web "Aphid" "Ladybug", "Beetle" "Mouse", "Caterpillar" "Beetle", "Caterpillar" "Mouse", "Caterpillar" "Towhee", "Grasshopper" "Mouse", "Grasshopper" "Towhee", "Ladybug" "Towhee", "Louse" "Mouse", "Mosquito" "Dragonfly", "Mosquito" "Towhee", "Mouse" "Owl", "Sunflower" "Aphid", "Sunflower" "Caterpillar", "Sunflower" "Grasshopper", "Sunflower" "Louse", "Towhee" "Owl"; shapes "Sunflower" , "Aphid" , "Ladybug" , "Towhee" , "Owl" , "Grasshopper" , "Louse" , "Caterpillar" , "Beetle" , "Mosquito" , "Dragonfly" , "Mouse" ;

Styling a Graph Highlighting Graph Features

Individual elements of a graph (vertices and edges) can be highlighted specifically HighlightGraphCompleteGraph5, 1, 2, 3 HighlightGraphCompleteGraph5, 1 2, Style3 4, Green

8 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-9
SLIDE 9

Importing and Exporting Graph

Import/Export Formats

We support import/export of the most widely used file formats, including; GraphML, GXL, Graphlet, Pajek, TGF, DOT, DIMACS, Graph6, Sparse6, and LEDA. Import"ExampleDataattributes.graphml", "Graph", VertexLabels "Name", ImagePadding 10

n0 n1 n2 n3 n4 n5

Curated Graph in Mathematica

Theoretical Graphs

A wide variety of theoretical graphs, and their properties are available via the GraphData function

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 9

slide-10
SLIDE 10

GraphData"PappusGraph" GraphData"HeawoodGraph", "Properties" Short Acyclic, AdjacencyMatrix, AllImages, 353, ZeroTwo, ZIndex We can also make queries, like whether a graph belongs to a Class GraphData"CubicalGraph", "Cage" False

Empirical Graphs

ExampleData provides a wide catalogue of empirical graph data, including NetworkGraphs ExampleData"NetworkGraph" Short, 4 & NetworkGraph, AmericanCollegeFootball, NetworkGraph, AskOpinionRecall, NetworkGraph, AskOpinionRecognition, 161, NetworkGraph, WorldCup1988, NetworkGraph, WorldWideWeb, NetworkGraph, ZacharyKarateClub ExampleData"NetworkGraph", "ZacharysKarateClub"

Applying Graph Theory to Example Data

Mathematica provides a wide range of curated data that are usefully visualised with Graph Theory,

10 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-11
SLIDE 11

AstronomicalData ElementData GraphData PolyhedronData ChemicalData FinancialData IsotopeData ProteinData CityData GenomeData KnotData WeatherData CountryData GeodesyData ParticleData WordData GraphFlattenThread CountryData, "BorderingCountries" & CountryData"SouthAmerica", VertexShapeFunction "Name"

Argentina Bolivia Brazil Chile Paraguay Uruguay Peru Colombia FrenchGuiana Guyana Suriname Venezuela Ecuador Panama

  • |
  • Wolfram-Technologies_Graph-Theory-Social-Networks.nb 11
slide-12
SLIDE 12

Slide 5 of 9

Graph Theory Analytical Methods

Graph Isomorphs, Complement, Difference and GraphDistributions

Isomorphs

Here we compute the isomorph that would convert a PetersenGraph, g PetersenGraph4, 1, VertexLabels "Name", ImagePadding 10

1 2 3 4 5 6 7 8

into an equivalent CompleteGraph. v1 "a", "b", "c", "d"; v2 "e", "f", "g", "h"; edge Tablev1i & Deletev2, 5 i, i, 4 Flatten;

12 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-13
SLIDE 13

h GraphJoinv1, v2, edge, VertexLabels "Name", ImagePadding 10, VertexSize Large, AbsoluteOptionsCompleteGraph4, 4, VertexCoordinates

a b c d e f g h

map FindGraphIsomorphismg, h 1 a, 2 e, 3 b, 4 f, 5 g, 6 c, 7 h, 8 d a First map; b Last map; highlightGraphg_, v_ : HighlightGraphg, TableStyleLabeledvi, vi, ColorData"TemperatureMap"i VertexCountg, i, VertexCountg; highlightGraphg, a, highlightGraphh, b

  • 1

2 3 4 5 6 7 8

,

a b c d e f g h

  • Complement

We can compute GraphComplements through the GraphComplement function. complementList Table CycleGraphn, DirectedEdges True, EdgeStyle Arrowheads0.1, n, 4, 6

  • ,

,

  • GraphComplement complementList
  • ,

,

  • Difference

Graph differences may be computed easily through the GraphDifference function.

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 13

slide-14
SLIDE 14

randGraph1 RandomGraph13, 14, VertexLabels "Name", ImagePadding 10

1 2 3 4 5 6 7 8 9 10 11 12 13

randGraph2 RandomGraph9, 10, VertexLabels "Name", ImagePadding 10

1 2 3 4 5 6 7 8 9

GraphDifferencerandGraph1, randGraph2, VertexLabels "Name", ImagePadding 10

2 3 4 5 6 7 9 10 11 12 13

14 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-15
SLIDE 15

GraphDistributions

Mathematica allows you to request a wide-range of parametric graphs.

1 2 3 4 5

CompleteGraph

1 2 3 4 5 6 7 8 9 10 11 12

ButterflyGraph

1 2 3 4 5 6 7 8 9 10

CirculantGraph

1 2 3 4 5

CycleGraph

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

HypercubeGraph

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16

KnightTourGraph

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25

PathGraph

1 2 3 4 5 6 7 8 9 10

PetersenGraph

You can request a RandomGraph with n vertices and m edges, RandomGraph6, 7, 3

  • ,

,

  • Or ask for a RandomGraph with an underlying distribution.

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 15

slide-16
SLIDE 16

BarabasiAlbertGraphDistribution graph with n vertices where each

BarabasiAlbertGraphDistribution BernoulliGraphDistribution DegreeGraphDistribution PriceGraphDistribution UniformGraphDistribution WattsStrogatzGraphDistribution

Cliques, Centralities and Communities

Cliques

We can use the FindClique function to find a clique, but in Version 9 we will provide the ability to find n cliques containing k vertices. Here’s an example analysing a standard empirical graph, “DolphinSocialNetwork”. g ExampleData"NetworkGraph", "DolphinSocialNetwork"; FindCliqueg 7, 10, 14, 18, 58

16 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-17
SLIDE 17

HighlightGraphg, FindCliqueg

Centralities

Mathematica includes a number of centrality measures, as with all functions these are fully documented at http://www.reference.wolfram.com ? *Centrality

System`

BetweennessCentrality DegreeCentrality HITSCentrality PageRankCentrality ClosenessCentrality EigenvectorCentrality KatzCentrality

Communities

Mathematica 9 will introduce a number of functions for finding communities and clans in graph.

Tours and Paths

Mathematica 9 will introduced FindHamiltonianCycle, FindMaximumFlow and FindPostmanTour in addition to other tour/path functions.

General Properties

We have a number of built-in functions for computing generic graph properties, including: GraphAssortative GraphDistanceMatrix GraphLinkEfficiency GraphDensity GraphDistance GraphPeriphery GraphDiameter GraphHub GraphReciprocity For example, we can compute a Histogram of the GraphReciprocity of 100 RandomGraph.

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 17

slide-18
SLIDE 18

HistogramGraphReciprocity RandomGraph10, 20, 100, DirectedEdges True

0.1 0.2 0.3 0.4 0.5 0.6 5 10 15 20 25 30 35

In Mathematica 9 graph information is easily accessible from an in-built palette. RandomGraph20, 21

  • |
  • 18 Wolfram-Technologies_Graph-Theory-Social-Networks.nb
slide-19
SLIDE 19

Slide 6 of 9

Applying Graph Theory in Financial Engineering

Samual Chen wrote us a blog post recently on using Graph Theory to help build a Risk Diverse Invest- ment Portfolio. These portfolios are constructed in such a way that the underlying financial instruments have uncorre- lated returns, suggesting that either the instruments are entirely unrelated or move in opposite directions.

Traditional Approach

Traditionally a portfolio manager would generate a correlation matrix and generate a heat map, but these are difficult to interrogate.

The Mathematica Approach

The Investment Portfolio

In Mathematica, we would first build a portfolio,

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 19

slide-20
SLIDE 20

commodities "GLD", "SLV", "CAFE", "UNG", "USO", "DBA"; bonds "TUZ", "FIVZ", "TENZ", "ZROZ", "TRSY", "STPZ", "TIPZ", "CORP", "HYS", "AUD", "CAD", "BUND"; Then we can use Mathematica’s in-built access to curated FinancialData to find the returns of each instrument in a given time period. bigport Joincommodities, bonds; portRet FinancialData, "Return", 2012, 1, 1, 2012, 1, 10, "Value" & bigport;

The Correlation Matrix

Mathematica has a wide range of statistical functions built right in, but we just need a correlation matrix. portcor CorrelationTransposeportRet; TableFormportcor, TableHeadings bigport, bigport GLD SLV CAFE UNG USO DBA GLD 1. 0.634889 0.33332 0.443286 0.15746 0.0815666 SLV 0.634889 1. 0.346153 0.80205 0.117413 0.463332 CAFE 0.33332 0.346153 1. 0.0155808 0.660596 0.408883 UNG 0.443286 0.80205 0.0155808 1. 0.4888 0.0241931 USO 0.15746 0.117413 0.660596 0.4888 1. 0.71324 DBA 0.0815666 0.463332 0.408883 0.0241931 0.71324 1. TUZ 0.820138 0.230868 0.485541 0.138007 0.546777 0.00950066 FIVZ 0.549785 0.345095 0.832193 0.202497 0.880094 0.491304 TENZ 0.590204 0.348091 0.264696 0.062688 0.245704 0.178264 ZROZ 0.474319 0.197856 0.654274 0.287453 0.35119 0.304815 TRSY 0.252542 0.227312 0.483952 0.396105 0.167837 0.111934 STPZ 0.122471 0.739592 0.652738 0.458889 0.395456 0.761189 TIPZ 0.619214 0.922686 0.612142 0.527811 0.482329 0.661586 CORP 0.420205 0.418745 0.89102 0.134684 0.895057 0.646981 HYS 0.61749 0.706698 0.789741 0.574632 0.183865 0.161655 AUD 0.352033 0.508619 0.259998 0.0554305 0.753487 0.807583 CAD 0.690335 0.915651 0.668296 0.553421 0.444178 0.557434 BUND 0.353519 0.49391 0.546124 0.437549 0.167376 0.180343

The Application

  • f

Graph Theory

We then build a function that defines a correlation cut off for our portfolio, portfolioMatrixΘ_ : ReplacePartportcor, i_, i_ 0 . x_ ; x Θ 1, x_ ; x Θ 0 Finally, we can ask for a graph of our portfolio to make sense of it, specifying the correlation cut-off at 0.58.

20 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-21
SLIDE 21

GLD SLV CAFE UNG USO DBA TUZ FIVZ TENZ ZROZ TRSY STPZ TIPZ CORP HYS AUD CAD BUND

Stocks Commodities Bonds

The Application

  • f

Interactivity

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 21

slide-22
SLIDE 22

Slide 7 of 9

Analysing Social Networks with Wolfram Technologies

Wolfram|Alpha Personal Analytics for Facebook

Live Example

Calling Social Network APIs in Mathematica

In Mathematica 9 we are introducing a new function for importing Social Networking data into a notebook. At launch we will support data importation from the following networks, Facebook GooglePlus LinkedIn Twitter

22 Wolfram-Technologies_Graph-Theory-Social-Networks.nb

slide-23
SLIDE 23

Slide 8 of 9

Wolfram Technologies’ Unique Principles and Benefits

Innovative Automation

Graph are provided automated visualisation options, but are very easily customised RandomGraph9, 10

Multi-Paradigm Language

The ability to choose your programming style, in conjunction with an in-depth Documentation Centre, reduces your learning curve. Well defined Mathematica function definitions provide easy to use functionality.

Hybrid Numeric-Symbolic Methodology

Graph will accept any symbolic data and exist as computable symbolic objects.

Integrated All-In-One Platform with Built-In Knowledge

In addition to a wide variety of curated data, we support an array of import/export formats. Mathematica 9 brings the ability to directly query Social Networks in a notebook.

Document Centric Workflow

Computation is useless without the ability to communicate results Mathematica can be used as a “computational typesetting environment”

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 23

slide-24
SLIDE 24

Integrate 1 1 x7 , x

  • 1

7 Sin Π 14 Logx2 2 x Sin Π 14 1

  • 1

7 Sin 3 Π 14 Logx2 2 x Sin 3 Π 14 1 1 7 Cos Π 7 Logx2 2 x Cos Π 7 1 1 7 Logx 1 2 7 Sin Π 7 ArcTanCsc Π 7

  • x Cos

Π 7 2 7 Cos Π 14 ArcTanSec Π 14

  • x Sin

Π 14 2 7 Cos 3 Π 14 ArcTanSec 3 Π 14

  • x Sin

3 Π 14 Mathematica notebooks may be saved as .cdf files and distributed to anyone via the Free CDF Player* For examples of what the .cdf document standard allows, see the Demonstrations Project

  • |
  • 24 Wolfram-Technologies_Graph-Theory-Social-Networks.nb
slide-25
SLIDE 25

Slide 9 of 9

Initialisations

graphsty SequenceVertexLabels MapThreadRule, RangeLengthbigport, Style, 7, GrayLevel.3, FontFamily "Verdana" & bigport, VertexSize Large, GraphLayout "PackingLayout" "ClosestPacking", ImagePadding 20;

MapThread::mptd : Object bigport at position 2, 2 in MapThreadRule, , bigport has only 0 of required 1 dimensions.

blueo_ : RGBColor.15, .4, .6, o;

Wolfram-Technologies_Graph-Theory-Social-Networks.nb 25
